midiplus X6 User manual

Contents
1.Introduction
2.Cautions
3.Features
4.Operations
4.1 MIDI/SELECT button
4.2 Sub-functions under edit mode
4.3 Configuration and function selection for knobs
and button controllers
4.4 Pulley and Octave adjustment
5. Interface of rear panel
6.Factory reset
7.Operation examples
8.Appendix:
 Appendix 1:Specifications
Appendix 2:CC controller parameters
XSeries--UserManual 01

Thank you for purchasing MIDIPLUS X series MIDI Keyboard. X series MIDI
Keyboard has lots of functions and is easy to operate. You can enjoy making
music by combining USB with X series MIDI Keyboard whenever you want to .
This manual can help you quickly know about the features and operations of
X series MIDI Keyboard. Please preserve it well for your future reference.
1.Introduction
Please pay attentions to the below in order to avoid any damage to the unit
and any harm to yourself.
1. Avoid placing or using the unit in wet environment, e.g. Button room,
swimming pool, etc.
2. Avoid placing or using the unit in high temperature or under direct solar
radiation, e.g. close to heater or radiator.
3. Avoid using the unit in thunderstorm weather, in case of lightning strike.
4. Unplug the external power supply when not in use.
5. Be aware of litter metals dropping into the unit which could cut the internal
circuit.
6. Only professional repairmen are allowed to disassemble the unit.
7. Children should not use the unit without adults' guidance.
8. Don't clean the device with gasoline, alcohol or other solvent in case of
damaging the device. Please use moist cloth to clean device, unplug the
external power and USB cable to avoid electric shock when cleaning..
2.Cautions:
3.Features:
X series includes X6, X8 which have 61 and 88 full-scale velocity keys
respectively.
It's powered by USB, no external supply is needed.
XSeries--UserManual
02

Capacitive touch sensors to control PITCH and MODULATION.
With function-editing button (MIDI/SELECT) and Octave switching button.
4 editable knob controllers(T1~T4) are for allocating CC function.
6 editable knob controllers with default and transport function for
allocating transport function/CC function.
1 MIDI OUT 1 SUSTAIN PEDAL interface and 1 USB interface. interface,
4.Operations
4.1. MIDI/SELECT button
MIDI/SELECT button:A button for switching the performing mode and
sub-functions editing mode.
Keyboard is in performing mode by default when switched on, Press the key
to send Note information, and Press MIDI/SELECT button, the keyboard will shift
to sub-functions mode ( indicators on , display shows “ ” ) , there is
corresponding label on each other key. Then select your function and press
“ENTER”, press MIDI/SELECT button again to finish editing, the keyboard will be
back in performing mode.
4.2.Sub-functions under edit mode:
4.2.1. Key channel selection MIDI CHANNELS(1~16):
For key channel selection.(The default channel 10 is percussion instrument
channel) (Please refer to Operation example 1 for details.)
XSeries--UserManual 03

4.2.2 Transmission selection
For changing tonality of the keys.
(Please refer to Operation example 2 for details.)
4.2.3. Sub-functions for other keys:
(1) VEL: The selection for velocity sense curve of the key. ( range: 1~8).
(Please refer to Operation example 3 for details.)
(2) CTRL CC: CC function selection (range:0~138).
(Please refer to Operation example 4)
(3) CTRL CHL: Channel setting(range:0~16).
(Please refer to Operations example 5)
(4) BANK MSB: Sound librar y high byte adjustment.(range:0~127)
(5) BANK MSB: Sound librar y low byte adjustment.(range:0~127)
(6) PRO:Sound setting. (range:0~127).
(Please refer to Operations example 6 for details)
Notes:The selection of CC function Please read
<<Appendix 2:Controller CC schedule>>；when CTRL CHL(controller
channel) is set to zero, the controller is set to be full channel, the controller
channel will follow the keyboard channel automatically.
4.2.4. NUMERIC KEYPAD、CANCAL and ENTER:
For numeric input, cancel and enter when setting other sub-functions.
XSeries--UserManual
04

4.3. Configuration and function selection for knobs and
buttons:
Knob controller:(T1~T4)
(1)4 independent potentiometer knobs which are 270°and with back light.
(2)User defined CC functions.(Please refer to operations example 4 for details.)
(3)Turn left means decrease, turn right means increase.Default functions of knob:
T1: Volume
T2: Pan
T3: Expression controller
T4: Reverb
Button controller:(B1~B6)
(1) 6 independent on/off buttons which with bicolor LED can configure CC
function or MMC transport function.
( Please refer to Operations example 7 for details).
(2) The light is blue when sending CC information.
( but the light is red if it's “135” when sending CC information.)
(3) Default setting is transport function.
MMC transmission information: backward, forward, stop, play, loop and
recording.
4.4.Pulley and Octave adjustments:
XSeries--UserManual 05

4.4.1 PITCH Pulley
Modulate the effect of pitch bend: Slide up by touching then pitch rises ;
slide down then pitch downs; if you loosen then pitch returns to median.
4.4.2 MODULATION Pulley
Modulate the effect of trill: Slide up by touching then trill increases; slide
down then trill decreases.
4.4.3 Octave
Range: （X6：-2~+2，X8：-1~+1）；Modulating directly by press button
“OCTAVE”, and press two buttons at the same time to default to be octave.
5. Connector of rear panel introduction:
5.1 SUSTAIN PEDAL pedal interface:
For interface switching in sustain pedal.
5.3 USB interface:
For X series MIDI Keyboard and computer combining with other devices, to
make it convenient for information transmission and power supply.
5.2 MIDI OUT interface:
sending MIDI information to other devices.
1.Unplug power supply, the keyboard will be off.
2.Press the two buttons of OCTAVE at the same time.
3.Then connected with USB, the start up LCD of device shows “ ”, and
 loosenthe button after three seconds, it will be back to factor y reset.
6.Factor y reset:
XSeries--UserManual
06

7.Operation examples:
(1) Press MIDI/SELECT keypad, you'll be in sub-function editing mode.
( the indicator is on, LCD display shows “ ”.)
(2) Press the key labeled under MIDI CHANNELS ”10”, display shows the
selected key channel NO. “10”.
(indicator light is off, the selected key channel is effective now.)
2:Transposition(e.g: changed to be A key)
(1) Press MIDI/SELECT keypad, you'll be in sub-function edit mode.
(the indicator light is on, LCD display shows “ ”.)
(2) Press the key labeled “A”, the display shows “ ” .
(the indicator light is off, the selected transposition is effective now.)
(1) Press MIDI/SELECT keypad, you'll be in sub-function edit mode.
(the indicator light is on, display shows “ ”.)
(2) Press the key corresponding to “VEL.” labeled, display shows the current
velocity curve NO., its velocity curve NO. is “4” under factor y reset.
(3) Press the key labeled number under “NUMERIC KEYPAD” on the right, input
“1”, and press the key corresponding to “ENTER”, display shows “ ”,
means setting succeed.)
(4) Press MIDI/SELECT keypad again, you'll be back in performing mode,
display shows channel number.(THE indicator light is off, the velocity curve
changes to be “ velocity curve 1” and be memorized.)
1: Switch channel(e.g:selection channel 10)
XSeries--UserManual 07

4: Knob controller “T1” is for controlling the reverb effect CC91.
(1) Press MIDI/SELECT keypad, you'll be in sub-function edit mode.
(the indicator light is on, display shows “ ”.)
(2) Press the key corresponding to “CTRL CC”, display shows the current CC
number of controller.
(3) Rotate “T1” knob and edit, it should shows”7” by default.
(4) Press the key labeled number under “numeric keypad” on the right, input
“91”, and press the key corresponding to “ENTER” to confirm, display shows
“”, means setting succeed.
(5) Press MIDI/SELECT keypad again, the keyboard will be back to performing
mode, display shows the channel number.(the indicator light is off, the
optional function of knob “T1” CC91(Reverberation) is memorized.)
Note:It's the same operation if you want to edit other knobs.
5: Knob controller “T1” is for controlling channel 10.
(1) Press MIDI/SELECT button, you'll be in edit mode.
( the indicator light is on, display shows “ ”).
(2) Press the key corresponding to “CTRL CHL.”, the display shows the current
channel NO. of controller.
(3) Rotate knob “T1” and edit, it should shows “17” by default.
(4) Press the key labeled number under “NUMERIC KEYPAD” on the right, input
10”, and press the key corresponding to “ENTER” to confirm, display “
shows “ ”, means setting succeed.
XSeries--UserManual
08

6: Set the sound program to be “123”.
(1) Press MIDI/SELECT button, you'll be in sub-function mode.
(the indicator light is on, display shows “ ”).
(2) Press the key corresponding to “PRO.”, display shows current sound
number.
(5) Press NIDI/SELECT button again, the keyboard will be back to performing
mode, display shows channel number.(the indicator light is off, the
controller channel selected by knob “T1” is memorized.)
Note:It's the same operation if you want to edit other knobs.
(3)Press the key labeled number under “NUMERIC KEYPAD” on the right, input
“123”, and press the key corresponding to “ENTER” to confirm, display
shows“”, means setting succeed.
(4)Press MIDI/SELECT button again, you'll be back in performing mode,
display shows channel number.
( the indicator light is off, the PROGREM value is memorized now).
7: Button controller ”B1” sending CC information “51”.
(1) Press MIDI/SELECT button, you'll be in sub-function mode.
( the indicator light is on, display shows “ ”).
(2) Press the key corresponding to “CTRL CC ”, display shows the current CC
number of controller.
(3) Press “B1” button and edits, it should shows “134” under the default of
factor y reset.
XSeries--UserManual 09

(4) Press the key labeled number under “NUMERIC KEYPAD” on the right, input
“51”, and press the key corresponding to “ENTER” to confirm, display shows
“ ”, means it succeed.
(5) Press MIDI/SELECT button, be back to performing mode, display shows the
channel number.(the indicator is off, the button “B1” selected CC function
are memorized now).
Note:It's the same operation if you want to edit other buttons.
Note:
1. Only completing the configuration data of keys in 10 seconds
can be saved.
2. The saved data still remains when you start up next time.
XSeries--UserManual
10

8. Appendices
Appendix 1: Specifications
Product Specifications
MIDI/SELECT, OCTAVEgroup,
Buttons with editable and transmission function(B1 - B6),
Knobs editable knob controller (T1 - T4)
Jack USB connector, MIDI OUT connector,
SUSTAIN PEDALS connector,
Accessories USB cable, User manual,InfoCard
Weights X6 :4.6kg
X8 :6.4kg
Size X6 : 978mm*215mm*74mm
X8 : 1356mm*215mm*74mm
LED Display
61/88 semi-weighted keyboard
0 Bank Select 1 Modulation Wheel or Lever 2 Breath Controller
3 Controller Change #3 4 Foot Controller 5 Portamento Time
6 Data Entry MSB 7 Channel Volume(formerly Main
Volum 8 Balance
9 Undefined 10 Pan 11 Expression Controller
12 Effect Control 1 13 Effect Control 2 14 Controller Change #14
15 Controller Change 16 General Purpose Controller 1 17 General Purpose Controller
18 General Purpose Controller 3 19 General Purpose Controller 4 20 Controller Change #20~#31
21-32 LSB for Control 0 (Bank Select) 33 LSB for Control 1 (Modulation
Wheel or Lever) 34 LSB for Control 2 (Breath Controller)
35 LSB for Control 3 (Undefined) 36 LSB for Control 4 (Foot Controller) 37 LSB for Control 5 (Portamento Time)
38 LSB for Control 6 (Data Entry) 39 LSB for Control 7 (Channel
Volume, formerly Main Volume) 40 LSB for Control 8 (Balance)
41 LSB for Control 9 (Undefined) 42 LSB for Control 10 (Pan) 43 LSB for Control 11 (Expression Controller)
Appendix 2: List of CC Controllers
XSeries--UserManual 11

44 LSB for Control 12 (Effect control 1) 45 LSB for Control 13 (Effect control
2) 46 LSB for Control 14 (Undefined)
47 LSB for Control 15 (Undefined) 48 LSB for Control 16 (General
Purpose Controller 1) 49 LSB for Control 17 (General Purpose Controller 2)
50 LSB for Control 18 (General Purpose
Controller 3) 51 LSB for Control 19 (General Purpose Controller 4) 52 Controller Change #52~#63
53-64 Damper Pedal on/off (Sustain) 65 Portamento On/Off 66 Sostenuto On/Off
67 Soft Pedal On/Off 68 Legato Footswitch 69 Hold 2
70 Sound Controller 1 (default Sound
Variation) 71 Sound Controller 2 (default Timbre/Harmonic Intens.) ) 72 Sound Controller 3 (default Release Time)
73 Sound Controller 4 (default Attack
Time) 74 Sound Controller 5 (default Brightness) 75 Sound Controller 6 (default Decay Time - see MMA RP-021)
79 Sound Controller 10 (default
undefined - see MMA RP-021) 80 General Purpose Controller 5 81 General Purpose Controller 6
82 General Purpose Controller 7 83 General Purpose Controller 8 84 Portamento Control
85 Controller Change #85 86 Controller Change #86 87 Controller Change #87
88 High Resolution Velocity Prefix 89 Controller Change #89 90 Controller Change #90
91
Effects 1 Depth (default Reverb Send
Level - see MMA RP-023) (formerly
External Effects Depth)
92 Effects 2 Depth (formerly Tremolo
Depth) 93 Effects 3 Depth (default Chorus Send Level - see MMA RP-023) (formerly Chorus Depth)
94 Effects 4 Depth (formerly Celeste
[Detune] Depth) 95 Effects 5 Depth (formerly Phaser Depth) 96 Data Increment (Data Entry +1) (see MMA RP- 018)
97 Data Decrement (Data Entry -1) (see
MMA RP-018) 98 Non-Registered Parameter Number (NRPN) - LSB 99 Non-Registered Parameter Number (NRPN) - MSB
100 Registered Parameter Number (RPN)
- LSB 101 Registered Parameter Number (RPN) - MSB 102 Controller Change #102~#119
123 [Channel Mode Message] All Notes
Off 124 [Channel Mode Message] Omni Mode Off (+ all notes off) 125 [Channel Mode Message] Omni Mode On (+ all notes off)
126 [Channel Mode Message] Mono
Mode On (+ poly off, + all notes off) 127
[Channel Mode Message] Poly
Mode On (+ mono off, +all
notes off)
128 Sound select
129 After touch 130 Stop 131 Start
132 Loop 133 Forward 134 Rewind
135 Record 136 MMC transpose control key 137 （CC52-56
138 （CC57-62
[Channel Mode Message] All Sound
Off 121
7876 Sound Controller 7 (default Vibrato
Rate - see MMA RP-021) 77
Sound Controller 8 (default
Vibrato Depth - see MMA RP-
021)
103-
120
[Channel Mode Message] Reset
All Controllers (See MMA RP-015) 122 [Channel Mode Message] Local Control On/Off
Sound Controller 9 (default Vibrato Delay - see
MMA RP-021)
XSeries--UserManual
12

目录
1.前言
2.安全事项
3.产品特色
4.操作介绍:
4.1MIDI/SELECT按键
4.2编辑模式下的副功能
4.3旋钮和按键控制器的配置及功能选择
4.4滑轮和八度切换
5.后面板接口简介
6.恢复出厂设置
7.操作举例
8.附表:
附表1:规格表
附表2:CC控制器一览表
XSeries--UserManual
01

1.前言
感谢您购买MIDIPLUS X系 列MIDI键盘。X系列MIDI键盘具有丰富的功能且操作简
单。通过USB连接X系列MIDI键盘，你可以随时享受音乐创作的乐趣。本说明书可以
帮助您快速了解X系列MIDI键盘的功能与操作方法。请妥善保存本说明书，以便查
阅。
2.安全事项:
请注意以下安全事项，以免损坏设备或者造成人身伤害。
1. 避免在潮湿的环境放置或操作本设备，如浴室，游泳池等。
2. 避免在高温或太阳直射的环境放置本设备，如散热器，暖气片附近。
3. 避免在雷雨天气使用本设备，以防雷击。
4. 若长时间不使用该设备，请断开外部电源连接。
5. 避免小金属块落入设备，从而导致内部电路短路。
6. 请勿自行打开设备，如果需要请咨询相关专业人士。
7. 儿童需在成人的指引下使用。
8. 不要使用汽油、酒精以及其它的溶解性溶剂清洗设备，以免造成设备损伤。
应用稍微湿润的布擦洗设备；擦洗时，请拔掉外部电源和USB连接线，避免
造成电击。
3. 产品特色
● X系列具有X6、X8 两个型号，分别拥有61和88个全尺寸力度琴键。
● 即插即用， USB供电，无需连接外部电源即可弹奏。
● 舍弃传统调音轮，采用触摸感应控制技术实现PITCH和MODULATION的触控调节新体
验。
● 配有功能编辑按键MIDI/SELECT和八度切换键OCTAVE。
● 4个可编辑旋钮控制器（T1~T4）， 用于配置CC功能。
● 6个默认走带功能的可编辑按键控制器（B1~B6），用于配置走带功能/CC功能。
● 拥有一个MIDI OUT接口, 一个SUSTAIN PEDAL踏板接口和一个USB接口。
XSeries--UserManual 02

4. 操作介绍
4.1. MIDI/SELECT按键
MIDI/SELECT按键:演奏模式与副功能编辑模式切换按键
开机时琴键默认处于演奏模式，按下琴键发送Note信息。按下MIDI/SELECT
按键，琴键进入副功能编辑模式（指示灯点亮，显示屏显示“ ”），每个琴键
上方对应相应的标注功能。选择你所需要的功能，按下“ENTER”确认，再次按下
MIDI/SELECT按键完成编辑，琴键返回到演奏模式。
4.2. 编辑模式下的副功能
4.2.1. MIDI CHANNELS(1~16)琴键通道选择
用于琴键通道的选择。（默认通道10为打击乐器通道）（详情请参考操作举例一）
4.2.2. 移调选择
用于移动琴键的调性。（详情请参考操作举例二）
XSeries--UserManual
03

4.2.3. 其它琴键副功能
（1） VEL.：琴键力度感应曲线选择（调整范围：1~8）。（详情请参考操作举例三）
（2） CTRL CC：CC功能选择（调整范围：0~138）。（详情请参考操作举例四）
（3） CTRL CHL.：通道选择（调整范围：0~16）。（详情请参考操作举例五）
（4） BANK MSB：音色库高字节调节（调整范围：0~127）。
（5） BANK LSB：音色库低字节调节（调整范围：0~127）。
（6） PRO.：音色选择（调整范围：0~127）。（详情请参考操作举例六）
注：CC功能选择的功能详情请查看《附表二：CC控制器一览表》；
CTRL CHL.（控制通道）选择0时，该控制器配置为全域通道，控制器的
通道将自动跟随琴键通道。
4.2.4. NUMERIC KEYPAD、CANCEL和ENTER
用于配置“其它琴键副功能”时用的数字输入、清除和确认。
4.3. 旋钮和按键控制器的配置及功能选择
旋钮控制器：（T1~T4）
（1）4个独立270度带背光灯的电位器旋钮。
（2）用户可自定义CC功能。（详情请参考操作举例四）
（3）向左减少，向右增加。
XSeries--UserManual 04

旋钮默认功能：
T1 Volume旋钮： （音量）
旋钮： （声像）T2 Pan
旋钮： （表情控制）T3 Expression Controller
旋钮： （混响效果）T4 Reverb
按键控制器：（ ）B1~B6
个带双色指示灯独立控制开关按键，可配置 功能或 走带信息。(1) 6 CC MMC
（详情请参考操作举例七）
( ) 当发送 信息是蓝灯。（除了发送 信息 时亮红灯）2 CC CC 135
( ) 默认为 走带控制功能。3 MMC
走带信息：后退、前进、停止、播放、循环、录音。 MMC
4.4 滑轮和八度调节:
4.4.1. PITCH滑轮
调制弯音效果：通过触摸向上滑动，音高升高；向下滑动，音高下降；松开
回归中间值
4.4.2. MODULATION滑轮
调制颤音效果：通过触摸向上滑动，颤音增加；向下滑动，颤音减小。
XSeries--UserManual
05
