midiplus PM110 User manual
1. Introduction
Welcome to MIDIPLUS!
Thank you for choosing the PM110 –our contribution to
minimal music –a professional, powerful and compact
amplifier system for acoustic instruments in superb
quality with MIDIPLUS typical authentic, transparent and
self-asserting sound performance. One channel - two
individual inputs allow parallel use of instrument and
microphone even though the instrument is the main
focus. Dynamic controlled 50 Watts and the 10“+ 20
Watts and the 2.5“speaker system give perfect
performance at all sound pressure levels.
We wish you hours of happy playing with your PM110!
2. Safety Precautions
The following guidelines shall help minimize the risk of injury through fire or electric shock.
1. Carefully read these safety notes before you use the device!
2. Keep these safety notes in a safe place.
3. Pay attention to all warnings, instructions and additional texts on the unit.
4. Do not install or use your amp near the water or if you are wet yourself.
5. Use your amp in a safe place where nobody can step on cables or trip over and damage them.
6. Pay attention to an unhindered air circulation around the amp, never obstruct the air vents or grilles.
7. Always pull the mains plug before cleaning your amp. Use only a dry cloth for cleaning. Avoid the use of
detergents and do not let any liquids seep into the unit.
8. Use only the right fuses with the same current rating and trigger characteristic as replacements. Never mend
fuses! Pull the mains plug before replacing a fuse. Should a fuse blow again after a short while, the device
needs to be checked.
9. Never install your amp close to devices with strong electromagnetic fields such as large mains transformers,
revolving machines, neon illumination etc. Do not lay signal cables parallel to power current cables.
10. There are no user-serviceable components inside the unit. To avoid the risk of an electric shock, the unit
must not be opened. All maintenance, adjustment and repair works should be carried out by qualified staff
only. Any unauthorized tampering will void the 1-year warranty.
11. In keeping with the EMV regulations screened cables with correctly fitted connectors must be used for all
signal connections.
12. Always use an earthed power supply with the correct mains voltage. If you are in doubt about the power
outlets ground, have it checked by a qualified technician.
13. Cable up your amp only when it is powered off.
3. Controls and Connections
Bank panel
INPUT 1-4
¼(6.35mm) mono jack socket
What you should have received in the box
VOLUME 1-4
Input level control
…An audio interface box
BASS
Bass control
…A power cable, L=2m
MIDDLE
Midrange control
…An Owner’s Manual
TREBLE
Treble control
Power on
Combined power switch with fuse holder
4. Operation Summary
•Cabling and startup
Check if your local mains voltage(e.g.120V in the USA,230V in Euro-pe) complies with the required operating
voltage for your amplifier. The proper mains voltage is printed on the rating plate on the rear panel of the unit, e.g.
AC 230V (AC means alternating current).
Then make all the necessary cable connections (mains, instrument etc.).
•Level adjustment
Using the VOLUME1/VOLUME 2/VOLUME 3/VOLUME4 control, you can adapt the amplifier to your signal
sources (guitar pickups, microphone etc.) to achieve the best possible signal-to-noise ratio (SNR).
•Equalization
The three-band equalizer with individual bass, middle and treble control of your PM110 has been designed
in such a way that it both complies with the special requirements of acoustic instruments and also with the
more general demands of other sources. The color switch activates a midrange contour filter which is
especially useful for picking techniques.
One more note: Adjusting the EQ controls can also affect the level setting. Whenever you see the clip
www.midiplus.cn www.midiplus.com.tw
V0.2
5. Technical Data
Inputs
INPUT 1-4
Jack ¼” (6.35 mm) socket
line mode: High impedance, balanced input for instruments (pick-ups) and line-level
sources Jack socket only
Sensitivity: 15 mV (–36 dBV) Impedance: 1 KΩ
Equivalent input noise, A-weighted: 2.5 uV (–112 dBV)
Tone controls
Bass
±8 dB at 100 Hz, shelf type
Middle
±6 dB at 800 Hz
Treble
±8 dB at 10 kHz, shelf type
Power
Power amp
50 W / 8 Ω, DMOS, monolithic I.C. Dynamic range, A-weighted: 92 dB (note 2).
Analog signal processing
Dedicated equalizer, subsonic filter, adaptive peak limiter
Speaker system
10”(50 W / 8Ω)bass speaker, 2.5”(20 W / 8Ω)tweeter speaker reflex enclosure
Mains power
Mains voltage (depending on model): 100, 120, 230, or 240 V AC, 50–60 Hz.Power
consumption: max. 100 W
Mains fuse
5x20 mm Slow 1 A for 230 and 240 V models Slow 2 A for 100 and 120 V models
General
Cabinet
15 mm (0.58”) finish birch plywood
Finish
Water based acrylic, black spatter finish
Dimensions
360 mm , high 350 mm ,wide 358.5 mm
Weight
12.08 kg
Notes:
1. Input sensitivity
Input sensitivities refer to 35 watts into 4 ohms, full gain and master settings, neutral tone control settings, and 1 kHz
sine-wave test signal.
2. Noise and dynamic range
Equivalent input noise voltage was obtained by measuring noise voltage at speaker output and dividing by the effective
voltage gain of the amplifier. Full gain and master settings, neutral tone control settings, input shorted, measuring
bandwidth 20 Hz –20 kHz.
Dynamic range of power amplifier: Range between output signal at limiter threshold and A-weighted output noise with
master volume in zero position.
Specifications and appearance subject to change without notice.
Owner’s Manual
PM110
Professional Percussion Monitor Speaker
