EDIFIER E3100 User manual

User's Manual
Designed and Engineered in Canada
Edifier Enterprises Canada Inc.
310 0
e
POWER
VOL
BAS
TRE
The Audio Artist
Multimedia Speaker

IMPORTANT SAFETY INFORMATION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Copyright 2003
All Rights Reserved.
Manual Edition 1.0, Nov 2003
Printed in CHINA
Welcome !
Very thanks for choosing Edifier multimedia speaker,it can provide good sound for multimedia Computer and home
theater. Before operating the system, please read this manual thoroughly and retain it for future reference.
The lightning flash with arrowhead, within an equilateral
triangle, is intended to alert the user to the presence of
Uninsulated "dangerous voltage" within the product's
Enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
CAUTION: TO PREVENT THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral
triangle is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the
Appliance.
SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Install in accordance with the manufacturer's
Instructions.
Do not use the speakers near water, and do not
immerse them in any liquid or pour any liquid on them.
Do not block the openings in the speaker cabinets,
never push objects into speaker vents or slots
because of fire or electric shock hazards, and provide
sufficient space around the speakers for proper
ventilation.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized plug.
A polarized plug has two blades with one wider than
the other. The wide blade is provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
For added protection during lightning storms, unplug
the speakers from the electrical outlet and turn off the
Computer.
Unplug this apparatus when unused for long periods
of time.
Water and moisture ----Do not use the speakers near
water, and do not immerse them in any liquid or pour
any liquid on them.
Heat---- Place the speakers away from all heat sources.
Ventilation ---- Do not block the openings in the
speaker cabinets, never push objects into speaker
Vents or slots because of fire or electric shock
Hazards, and provide sufficient space around the
Speakers for proper ventilation.
Location ---- Place the speakers in a stable location
so they will not fall causing damage to the speakers or
bodily harm.
Cleaning ---- Unplug the speakers from the computer
and from the electrical outlet before cleaning them
with a damp cloth.
Lightning ----For added protection during lightning
storms, unplug the speakers from the electrical outlet
And turn off the computer.
Servicing is required when the apparatus has been
Damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have
Fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped. Refer all servicing to qualified
service personnel.
Please adjust the audio to proper volume to avoid
damaging your health and the system.
One Year Limited Warranty
Edifier warrants to the end user that all of its computer speaker systems are free from defects in material and
workmanship in the course of normal and reasonable use for a term of one year from the date of purchase.
This warranty is the exclusive and only warranty in effect relative to Edifier multimedia speaker systems and any other warranties,
either expressed or implied, are invalid. Neither Edifier nor any authorized Edifier reseller is
responsible for any incidental damages incurred in the use of the speakers. (This limitation of incidental or
consequential damage is not applicable where prohibited.)
Edifier obligation under this warranty does not apply to any defect, malfunction or failure as a result of misuse, abuse, improper
installation, use with faulty or improper equipment or the use of the speaker systems with any equipment for which they were not
intended.
The terms of this warranty apply only to speaker systems when such speakers are returned to the respective authorized Edifier
reseller where they were purchased.
Under the terms of this warranty the original consumer purchaser has certain legal rights and may have other rights which vary
worldwide.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
Notice
Edifier and Edifier logo are owned by and may be registered. And other
brand names and trademarks are the property of their owners. Edifier assumes
Edifier Enterprises Canada Inc.
no responsibility for any
errors that may appear in this manual. Information contained herein is subject to change without notice.

Introduction
Open the packing
Overview
Introduction of back panel
1 x Sub Woofer
2 x satellite Speakers
1 x Audio Connecting Cord
1 x User's Manual
e3100 packing list:
1 Sub Woofer
2 Satellite Speakers (left and right)
3 Power Switch
4 Power Indicator
5 Volume Control
6
7 Treble Control
8 Line In Port
9 Satellite Speakers C
10 Power Cord
11
User's Manual
Super Bass Control
onnector
Audio connecting cord
12
Please check the speaker pattern marked on the package. Please contact the seller as soon as possible if you
find the speaker is not the pattern you want.
MDF wooden case satellite design .
5 Long-throw subwoofer driver.
2-way satellite speakers.
1 PV membrane dome tweeter .
3 paper coil mid-range driver.
Yellow power indicate.
Bass,treble and volume controllers.
Magnetically shielded design.
POWER
VOL
BAS
TRE
The Audio Artist
LINE IN
Speaker Output
RL
Multimedia speaker
HOT PANEL
TOUCH WITH CARE
HOT PAN EL
TOUCH WITH CARE
HOT PANEL
TOUCH WITH CARE
HOT PAN EL
TOUCH WITH CARE
Edifier Enterprises Canada Inc.
Designed and Engineered in Canada

CONNECTING
R
SOUND CARDSOUND CARD
WHITE
RED
L
Line InLine In
Spk OutSpk Out
Sound Card
SPECIFICATIONS:
1
2
3 Playing the audio device
CONNECTING
Connect the satellite speakers to the output splints on the back panel of the Sub-woofer. Please note to match
the color, red to red and white to white.
Connect the subwoofer to the Audio device.
Using Audio connecting cord , connect the Line-input port of the subwoofer to Line-out of the Audio Device
(Such as the computer, Discman, etc).
Plug the AC power plug into the wall outlet and turn on the power switch, Now your speaker system is ready for
Use. Adjusting the volume control and the Super bass,then you can enjoy the music.
Total Power Output :
Input Impedance:
Input Sensitive:
Bass Unit:
M
Tweeter Unit:
Frequency Response:
Dimension(Subwoofer):
Dimension(Satellite):
Gross Weight:
id-range Unit:
RMS 8WX2+12W
10K Ohm
450 mV
5 Aluminum coil, 4 Ohm
3 Paper coil, 4 Ohm
1
45Hz~20KHz
157(W) x235(H) x 334(D)mm
91(W) x 172(H) x139(D)mm
About 7 Kg
PV membrane dome
LINE IN
Speaker Output
RL
Multimedia speaker
HOT PANEL
TOUCH WITH CARE
HOT PANEL
TOUCH WITH CARE
HOT PANEL
TOUCH WITH CARE
HOT PANEL
TOUCH WITH CARE
Edifier Enterprises Canada Inc.
Designed and Engineered in Canada
~AC
