NNNN Comium 30 User manual
V1.1Surface mounted loudspeaker
Comium 30
COMIUM 30 V1.1 EN
Professional audio EN
Version 1.1
Updated versions uploaded to www.nnnn.no
©2021 by NNNN AS ; all rights reserved
Keep this document with the product or
in safe storage so it is readily available if
needed.
This document should accompany the
product if it is ever resold.
NNNN AS
Syretårnet 43, 3048 Drammen, Norway
T +47 982 89 816
Comium 30 owner’s manual
2
COMIUM 30 V1.1 EN
Material damage
Loudspeakers contain magnets which may
damage electronic equipment such as hard
drives, bank cards, and video monitors.
Please store and transport such equipment
separately or within appropriate distance to
the loudspeakers.
Personal injury
Never stand in the immediate vicinity of loud-
speakers driven at a high level. Professional
loudspeaker systems are capable of causing
sound pressure levels detrimental to human
health. Even seemingly non-critical sound
levels (from approx. 95 dB SPL) can cause
hearing damage if people are exposed to it
for longer periods of time.
In order to prevent accidents when deploying
loudspeakers on the ground or when flown,
please take note of the following:
When setting up the loudspeakers or loud-
speaker stands, make sure they are standing
on a firm surface. If you place several
systems on top of one another, use appropri-
ate securing gear to prevent movement.
Only use accessories which have been
tested and approved by NNNN for assembly
and mobile deployment. Pay attention to
the correct application and maximum load
capacity of the accessories as detailed in our
rigging manuals.
Ensure that all third party hardware, fixings
and fasteners used for installation or mobile
deployment are of an appropriate size and
load safety factor. Pay attention to the man-
ufacturers’ instructions and to the relevant
safety guidelines.
Be careful of pinching and other physical
hazards when deploying or transporting
equipment.
Regularly check the loudspeaker cabinets
and accessories for visible signs of wear and
tear, and replace them when necessary.
Regularly check all load bearing bolts in the
mounting devices.
Safety
4
COMIUM 30 V1.1 EN
The Comium 30 is a surface mounted point source for
a wide range of applications. It is capable of provid-
ing high-quality bass output in spaces that
would normally miss out on this important aspect due
to space and interior requirements. The Comium 30
combines 8” and 1” drivers in a compact combined
horn and transmission line cabinet.
Full range
The Comium 30 has a low frequency extension similar
to a medium sized home theater subwoofer despite
it’s compact form factor. Bass is an important part
of how we experience sound with both our ears and
body. For both music and film, a proper low frequency
reproduction is often what separates a great sound
system from a decent one. This is as true for custom
installation as it is for a home audio setup.
Product
Description
5
COMIUM 30 V1.1 EN
High tech
The technology employed in the
Comium 30 enables high sensitivity,
good impulse response and low
distortion level across the loudspeak-
er’s full frequency range.
Deployment
The Comium 30 is a in/on-surface
point source, and can be mounted
on or built into the wall or ceiling. The
spring loaded quick connect termi-
nals make wiring and installation
simple.
Materials
The Comium 30 is designed to be
light and sturdy. The cabinet is made
of plywood that is covered with a
scratch, and impact resistant polyu-
rethane coating. The grilles and input
panel are made of coated aluminium.
6
COMIUM 30 V1.1 EN
The Comium 30 is a surface-mounted point source,
best suited for installation. In the rear panel there are
spring loaded quick connect terminals which make
for quick and versatile setups and installation. While
one of the connectors is used to power the cabinet,
the second can be used to interconnect cabinets.
Operation
The Comium 30 is a 2-way cabinet that can be
driven by any Powersoft amplifier with a NNNN preset
or amplifiers with at least two output channels of an
appropriate capacity and the NNNN preset loaded
into its DSP/external DSP, any of these solutions must
be wired into a SpeakON 8 pole connection. Updated
Powersoft amplifiers include presets for the Comium
30 in several different setups, which can be accessed
through the native menu Speaker preset > NNNN >
Turage > Comium 30. A detailed description of the
operation of Powersoft amplifiers can be found in the
Powersoft Quick Guides.
Electroacoustics
1+
1-
2+
2-
7
COMIUM 30 V1.1 EN
System data
Loudspeaker data
Frequency response
Max cont. SPL (1m, 2Pi)
Nominal dispersion
Nominal impedance
Power handling capacity (cont.)
Connections
Components
30Hz - 22kHz
114dB
90° radial
HF 8 ohms
LF 8 ohms
25 W
1 × Euroblock
1 × 1”
1 × 8”
Specifications
Comium 30
8
COMIUM 30 V1.1 EN
Height
Width
Depth
Weight
Measurements
Physical data
120 mm
592 mm
592 mm
592 mm / 23.3”
592 mm / 23.3”
120 mm / 4.8”
13.8 kg / 30.4 lbs
9
COMIUM 30 V1.1 EN
This declaration applies to loudspeakers
manufactured by NNNN AS. A more detailed
document may be found at nnnn.no.
NNNN AS declares that all versions of the
following product(s):
Comium 30
We declare that these product(s) are in
conformity with the provisions of the
respective EC directives including all
applicable amendments.
2014/35/EU, Low Voltage Directive
2011/65/EU, RoHS
NNNN AS accept responsibility for this
declaration
EU conformity
10
COMIUM 30 V1.1 EN
Electrical and electronic equipment must be disposed of
separately from normal waste at the end of its opera-
tional lifetime. Please dispose of this product according
to the respective national regulations or contractual
agreements. If there are any further questions concern-
ing the disposal of this product, please contact NNNN.
WEEE statement
11
COMIUM 30 V1.1 EN
NNNN AS Comium 30 owner’s manual V1.0
nnnn.no
