Midland BIZTALK BR200 User manual

BR100/200
Owners Manual

Model BR200
midlandusa.comPage 2
TABLE OF CONTENTS
FEATURES ����������������������������������������������������������������3
FCC NOTICE �������������������������������������������������������������4
EXPOSURE TO RADIO FREQUENCY ENERGY����������������������������������4
BODY WORN OPERATION ���������������������������������������������������������������������4
ISED NOTICE ������������������������������������������������������������6
GETTING TO KNOW YOUR RADIO�����������������������������������8
CONTROLS ������������������������������������������������������������������������������������������������8
INSTALLING THE BATTERY����������������������������������������������������������������������9
INSTALLING THE BELT CLIP ��������������������������������������������������������������������9
INSTALLING THE ANTENNA�������������������������������������������������������������������10
INSTALLING EXTERNAL ACCESSORIES ����������������������������������������������10
CHARGING THE BATTERY PACK ����������������������������������������������������������10
OPERATING YOUR RADIO������������������������������������11
POWER ON/OFF AND VOLUME������������������������������������������������������������� 11
TRANSMITTING AND RECEIVING A CALL��������������������������������������������� 11
ABOUT RANGE����������������������������������������������������������������������������������������12
MONITOR �������������������������������������������������������������������������������������������������12
CHANNEL SELECTION ���������������������������������������������������������������������������12
SCAN FUNCTION ������������������������������������������������������������������������������������12
PRIVACY CODES�������������������������������������������������������������������������������������13
TROUBLESHOOTING GUIDE ��������������������������������14
USE AND CARE ���������������������������������������������������������������������������������������15
SPECIFICATIONS ���������������������������������������������������16
DEFAULT FREQUENCIES CHART����������������������������������������������������������16
AVAILABLE FREQUENCIES CHART ������������������������������������������������������16
CTCSS PRIVACY CODES CHART����������������������������������������������������������16
DCS PRIVACY CODE CHART�����������������������������������������������������������������17
LIMITED WARRANTY���������������������������������������������18
ACCESSORIES�������������������������������������������������������19

Model BR200
midlandusa.com Page 3
For over half a century, Midland Radio has been providing radio
communication with superior Quality, Reliability, and Strong Value� With
these Core Values in mind, the Midland BR200 provides a communication
solution for Small Business, Hospitality, Construction, Warehousing,
Maintenance, and other Business uses�
FEATURES
- 16 Channels
- 56 Frequencies
- 142 Privacy Codes (38 CTCSS / 104 DCS)
- Monitor Function
- Scan Function
- Voice Prompted Battery Alert & Channel Selection
- External Speaker/Microphone Jack
- PC Programmable

Model BR200
midlandusa.comPage 4
FCC NOTICE
The radios operates on UHF frequencies which require an FCC (Federal
Communications Commission) license� You must be licensed prior to operating
on these frequencies� Serious penalties could result from unlicensed use of these
frequencies, in violation of FCC rules, as stipulated in the Communications Act’s
Sections 501 and 502 (amended)�
You will be issued a call sign by the FCC which should be used for station
identification when operating the radio on these channels� You should also
cooperate by engaging in permissible transmissions only, avoiding channel
interference with other users, and being prudent with the length of your
transmission time�
To obtain a license or ask questions about the license application, contact the
FCC at 1-888-CALL FCC or go to the FCC’s website:
http://www�fcc�gov and request form 601�
Exposure To Radio Frequency Energy
Your Midland radio is designed to comply with the following national and
international standards and guidelines regarding exposure of human beings to
radio frequency electromagnetic energy:
- United States Federal Communications Commission, Code of Federal
Regulations: 47 CFR part 2 sub-part J
- American National Standards Institute (ANSI)/Institute of Electrical &
Electronics Engineers (IEEE) C95� 1-1992
- Institute of Electrical and Electronics Engineers (IEEE) C95� 1-1999 Edition
- National Council on Radiation Protection and Measurements (NCRP) of the
United States, Report 86, 1986
- International Commission on Non-lonizing Radiation Protection (ICNIRP) 1998
To control your exposure and ensure compliance with the general population
or uncontrolled environment exposure limits, transmit no more than 50% of
the time� The radio generates measurable RF energy exposure only when
transmitting�
Body-Worn Operation
If you wear the radio on your body when transmitting always use Midland
supplied or approved belt clip, holster, case, or body harness for this product�
Use of any accessories not supplied or approved by Midland may exceed FCC/
Health Canada RF exposure guidelines� If you do not use accessories supplied
or approved by Midland, ensure the radio and its antenna are at least 1 inch
(2�5cm) from your body when transmitting�

Model BR200
midlandusa.com Page 5
To maintain compliance with FCC’s RF exposure guidelines, for body-
worn operation, this radio has been tested and meets the FCC RF
exposure guidelines when used with Midland Radio Corp� accessories
supplied or designated for this product� Use of other accessories may
not ensure compliance with FCC RF exposure guidelines�
This device complies with Part 15 of the FCC Rules� Operation is subject
to the following two conditions: (1) this device does not cause harmful
interference, and (2) this radio must accept any interference that may
cause undesired operation�
IMPORTANT: Changes or modifications to this unit not expressly
approved by MIDLAND RADIO CORP� could void your right to
operate this unit� Your radio is set up to transmit a regulated signal
on an assigned frequency� It is against the law to alter or adjust the
settings inside the COMMUNICATOR to exceed those limitations� Any
adjustment to your radio must be made by qualified technicians�

Model BR200
midlandusa.comPage 6
IMPORTANT: This device complies with Industry Canada licence exempt
RSS standard(s)� Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may
cause undesired operation of the device�
IMPORTANT: Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de licence�
L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil
ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi même si le brouillage est
susceptible d’en compromettre le fonctionnement�
IMPORTANT: Under Industry Canada regulations, this radio transmitter
may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada� To reduce
potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power
(e�i�r�p�) is not more than that necessary for successful communication�
IMPORTANT: Conformément à la réglementation d’Industrie Canada, le
présent émetteur radio peut fonctionner avec une antenne d’un type et
d’un gain maximal (ou inférieur) approuvé pour l’émetteur par Industrie
Canada� Dans le but de réduire les risques de brouillage radioélectrique
à l’intention des autres utilisateurs, il faut choisir le type d’antenne
et son gain de sorte que la puissance isotrope rayonnée quivalente
(p�i�r�e�) ne dépassepas l’intensité nécessaire à l’établissement d’une
communication satisfaisante�
ISED NOTICE

Model BR200
midlandusa.com Page 7
IMPORTANT: This radio transmitter (3690A-BR200) has been approved
by Industry Canada to operate with the antenna types listed below with
the maximum permissible gain and required antenna impedance for
each antenna type indicated� Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are
strictly prohibited for use with this device�
•Quarter-Wave Helically Wound Antenna- 50 Ohm, 2dBi
IMPORTANT: Le présent émetteur radio (3690A-BR200) a été
approuvé par Industrie Canada pour fonctionner avec les types
d’antenne énumérés ci-dessous et ayant un gain admissible maximal
et l’impédance requise pour chaque type d’antenne� Les types
d’antenne non inclus dans cette liste, ou dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour l’exploitation de
l’émetteur
•Quarter-Wave Helically Wound Antenna- 50 Ohm, 2dBi

Model BR200
midlandusa.comPage 8
CONTROLS
A� LED INDICATOR: The LED is
Green when receiving signals and
Red when transmitting�
B� CHANNEL SELECTOR: Rotate to
select channels 1-16�
C� POWER/VOLUME KNOB: Turn
clockwise to turn the power on and
increase the volume level� Turn
counter-clockwise to decrease the
volume level and turn the power off�
D� PTT (Push to Talk): Press and hold
to transmit voice communication�
E� Monitor Button: Press to enter the
Monitor mode�
F� Scan Button: Press to enter the
Scan mode�
G� External Speaker/Mic Jack
GETTING TO KNOW YOUR RADIO

Model BR200
midlandusa.com Page 9
INSTALLING THE BATTERY
Your radio operates with a Lithium-Ion battery� The belt clip should be
removed (see below) to make the installation and removal of the battery
easier�
To install the battery:
With the back of the radio facing you, install the battery by sliding the
pack along the back of the radio until the latch on the radio locks�
To remove the battery:
Press the release latch and slide the pack away from the radio�
INSTALLING THE BELT CLIP
With the back of the radio facing you,
align the BELT CLIP with the screw
holes on the radio� Attach the BELT
CLIP with the Phillips-Head screws
provided in the gift box�
*Be careful not to over tighten screws
to avoid damaging radio chassis*�

Model BR200
midlandusa.comPage 10
INSTALLING THE ANTENNA
Align the antenna with the threaded
connector located on the top of the
radio� Holding the antenna at the
base, rotate the antenna clockwise
until secure�
*Be careful not to over tighten to
avoid damaging antenna mount�*
INSTALLING EXTERNAL
ACCESSORIES
Pulling the rubber cover to the side
exposing the speaker/mic jacks, insert
the accessory plugs into the speaker/
mic jack�
CHARGING THE BATTERY PACK
Your radio is equipped for using a rechargeable Lithium-Ion battery pack
which can be recharged by inserting the radio or battery into the desktop
charger (as described below)� Midland recommends charging the battery
pack when the charge battery alert comes on and removing the radio from
the charger when the charging is finished�
To charge using the Desktop Charger:
1� Plug the AC adaptor into a 120V AC wall outlet� The charger’s LED
turns green when power is present�
2� Making sure the battery contacts and charge terminals are clean and
in good condition, slide the battery or radio with installed battery into
the charger�

Model BR200
midlandusa.com Page 11
OPERATING YOUR RADIO
PROGRAMMING SOFTWARE
Your Midland BR200 radio comes with 16 preprogrammed channels�
The BR200 also comes with programming software to personalize your
business radio� To download the software please go to: midlandusa�com
Note: If there is not a frequency programmed into a channel, you will hear
a loud continueos tone indicating that there is nothing programmed for
that channel�
POWER ON/OFF AND VOLUME
Rotate the POWER/VOLUME knob clockwise to turn the radio on
and increase the volume level� Rotate the control counter-clockwise
to reduce the volume level and to turn the radio off� During Power On,
the radio will beep once and indicate the last channel selected�
3� The charger LED will turn red and begin charging the unit� Charging
time depends on the charge of the battery� After charging is complete
the LED will turn Green�
In order to ensure that the battery pack is fully charged, it is
recommended that the battery pack be charged with the radio
turned off.
1� Only use the Midland Lithium-Ion battery pack�
2� Do not attempt to charge any battery packs other than the one
indicated in the manual� This may cause leakage and damage
to the radio�
3� For long term storage of the radio, turn the radio OFF and
remove the batteries from the radio�

Model BR200
midlandusa.comPage 12
ABOUT RANGE
Your BR200 radio is designed to give you maximum range under optimum
conditions�
Optimum Conditions are:
•Openwarehousefloorplanorarea.
•Openruralareaswithoutobstructions.
• Flat areas where you can see the other person to ensure you get
maximum range�
• Be sure to use fresh or fully charged batteries - a low battery will
cause low power conditions�
TRANSMITTING AND RECEIVING A CALL
1� For maximum clarity, hold the radio at least 1 inch (2�5cm) from your
mouth�
2� Press and hold the PTT button and speak in a normal voice into the
microphone� The RX/TX LED will glow RED while transmitting�
3� To receive a call, release the PTT button� The RX/TX LED will glow
GREEN when your radio is receiving a transmission�
MONITOR
Pressing the Monitor button will let you hear noise so you can adjust the
volume level of the radio when not receiving a signal� This should be used
to check activity on your current channel before transmitting�
CHANNEL SELECTION
Rotate the Channel Selector knob to select one of the 16 channels�
SCAN FUNCTION
1� To begin scanning, press and hold the Scan Button for 3 seconds�
•Your radio will beep twice alerting you that the radio has entered
scan mode
2� When in Scan Mode, the radio will rapidly scan through all programmed
channels and will pause on any active channel�
Industrial Multi-Level
Inside Steel/ Concrete Industrial Building Inside Multi-Level Building
Up To 250,000 sg� ft� Up to 20 floors

Model BR200
midlandusa.com Page 13
•While Scan Function is active the Green LED will flash to indicate
that the radio is scanning�
3� After stopping on an active channel, Scanning will resume once there
has been 4 seconds of no activity on the channel�
4� To reply to a received transmission when the Scan Mode is enabled,
press and hold the PTT button (on radio or headset accessory) while
the radio is paused on the active channel, the radio will then transmit
on the active channel’s frequency�
•The radio will remain on the active channel for 4 seconds after the
PTT button is released�
5� To transmit on the frequency selected by the Channel Knob while Scan
Mode is enabled, the user will verify that the radio is not receiving a
transmission, then press PTT button (on radio or headset accessory)�
•Once the PTT button is released the radio will go back into
scanning after 4 seconds of inactivity�
6.ToexitScanMode,theuserwillLongPress(≥3seconds)theScan
Button�
•The radio will emit a single beep, alerting the user that the radio
has exited Scan Mode�
PRIVACY CODES
CTCSS (Continuous Tone Coded Squelch System) and DCS (Digitally Coded
Squelch) are systems that allow several users to share the same channel without
disturbing each other� With CTCSS or DCS enabled, the channel is muted to all
incoming signals unless they carry the correct CTCSS or DCS tone� When a
transmission with the correct tone is received, the channel un-mutes and the voice
audio can be heard� When the transmission ends the channel becomes muted
again� Transmissions that do not have the correct tone will not be heard�
Your BR200 Series radio has 142 Privacy Codes, which are available on any
channel� The selected Privacy Code may be different for each channel�
Privacy Codes can only be set using the programming software� This
software can be downloaded from the midlandusa�com website�
Note: If you select a CTCSS Privacy Code, any pre-selected
DCS Privacy Code will be cancelled and vice-versa�

Model BR200
midlandusa.comPage 14
TROUBLESHOOTING GUIDE
PROBLEM SOLUTION
No Power
- Check battery installation and/or replace battery
pack�
- Check Power/Volume control knob�
Cannot Receive
Messages
- Confirm the radios have the same channel and
privacy code settings�
- Make sure that you are within range of the other
transceivers�
- Buildings and other structures may interfere with
your communication�
Charger Not
Functioning
- Contacts on the bottom of the radio may require
cleaning�
- Ensure the outlet where the charger is plugged in
is functioning properly�
- Check that the battery pack is installed properly�
If you have a problem which you believe requires service,
please call first and speak with a service technician at
816-241-8500� Many problems can be remedied over the
phone without returning the unit for service�

Model BR200
midlandusa.com Page 15
USE AND CARE
1� Use a soft damp cloth to clean the radio
2� Do not use alcohol or cleaning solutions to clean the radio�
3� Do not immerse the radio in water�
4� Dry the radio with a dry lint-free cloth should it get wet�
5� Turn off the radio and remove the batteries during long-term
storage�

Model BR200
midlandusa.comPage 16
SPECIFICATIONS
Channels 16 Channels + 142 Privacy Codes
Operating Frequency UHF 461�0375 ~ 469�5625MHz
Power Source 3�7Vdc Li-ion Battery Pack
DEFAULT FREQUENCIES CHART
CH. No CH. Freq (MHz) Code CH. No CH. Freq (MHz) Code
1 464.5500 1 9 464.5500 29
2 467.9250 1 10 467.9250 29
3 467.8500 1 11 467.8500 29
4 467.8750 1 12 467.8750 29
5 464.5500 6 13 464.5500 -
6 467.9250 6 14 467.9250 -
7 467.8500 6 15 467.8500 -
8 467.8750 6 16 467.8750 -
AVAILABLE FREQUENCIES CHART
Code Freq (MHz) Code Freq (MHz) Code Freq (MHz) Code Freq (MHz)
1 464.5000 15 461.1875 29 462.9125 43 466.2625
2 464.5500 16 461.2125 30 464.4875 44 466.2875
3 467.7625 17 461.2375 31 464.5125 45 466.3125
4 467.8125 18 461.2625 32 464.5375 46 466.3375
5 467.8500 19 461.2875 33 464.5625 47 466.3625
6 467.8750 20 461.3125 34 466.0375 48 467.7875
7 467.9000 21 461.3375 35 466.0625 49 467.8375
8 467.9250 22 461.3625 36 466.0875 50 467.8625
9 461.0375 23 462.7625 37 466.1125 51 467.8875
10 461.0625 24 462.7875 38 466.1375 52 467.9125
11 461.0875 25 462.8125 39 466.1625 53 469.4875
12 461.1125 26 462.8375 40 466.1875 54 469.5125
13 461.1375 27 462.8625 41 466.2125 55 469.5375
14 461.1625 28 462.8875 42 466.2375 56 469.5625
CTCSS PRIVACY CODES CHART
Code Freq (Hz) Code Freq (Hz) Code Freq (Hz) Code Freq (Hz) Code Freq (Hz)
1 67.0 9 91.5 17 118.8 25 156.7 33 210.7
2 71.9 10 94.8 18 123.0 26 162.2 34 218.1
3 74.4 11 97.4 19 127.3 27 167.9 35 225.7
4 77.0 12 100.0 20 131.8 28 173.8 36 233.6
5 79.7 13 103.5 21 136.5 29 179.9 37 241.8
6 82.5 14 107.2 22 141.3 30 186.2 38 250.3
7 85.4 15 110.9 23 146.2 31 192.8
8 88.5 16 114.8 24 151.4 32 203.5

Model BR200
midlandusa.com Page 17
DCS PRIVACY CODE CHART
No. CODE No. CODE No. CODE No. CODE
1 23 27 165 53 413 79 731
2 25 28 172 54 423 80 732
3 26 29 174 55 431 81 734
4 31 30 205 56 432 82 743
5 32 31 223 57 445 83 754
6 43 32 226 58 464 84 36
7 47 33 243 59 465 85 53
8 51 34 244 60 466 86 122
9 54 35 245 61 503 87 145
10 65 36 251 62 506 88 212
11 71 37 261 63 516 89 225
12 72 38 263 64 532 90 246
13 73 39 265 65 546 91 252
14 74 40 271 66 565 92 255
15 114 41 306 67 606 93 266
16 115 42 311 68 612 94 274
17 116 43 315 69 624 95 325
18 125 44 331 70 627 96 332
19 131 45 343 71 631 97 356
20 132 46 346 72 632 98 446
21 134 47 351 73 654 99 452
22 143 48 364 74 662 100 454
23 152 49 365 75 664 101 455
24 155 50 371 76 703 102 462
25 156 51 411 77 712 103 523
26 162 52 412 78 723 104 526

Model BR200
midlandusa.comPage 18
LIMITED WARRANTY (United States and Canada)
Subject to the exclusions set forth below, Midland Radio Corporation will repair or replace, at
its option without charge, any Midland UHF transceiver which fails due to a defect in material or
workmanship within One Year following the initial consumer purchase�
This warranty does not apply to water damage, battery leak, abuse or misuse of unauthorized
accessories,unauthorizedserviceormodicationoralteredproducts.Accessorieshavea90
day warranty from date of purchase, including any antennas or chargers that are included with
the unit�
ANY IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED AS SET FORTH HEREIN AND TO THE DURATION OF THE LIMITED
WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER AND IS
PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED� IN NO EVENT
SHALL MIDLAND BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING BUT NOT
LIMITED TO NEGLIGENCE, GROSS NEGLIGENCE, BODILY INJURY, PROPERTY DAMAGE
AND DEATH) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT
OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS,
LOSS OF INFORMATION OR DATA OR OTHER FINANCIAL LOSS ARISING OUT OF
OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS OR
ACCESSORIES TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW�
For Product Purchased in the USA:
Performance of any obligation under this warranty may be obtained by returning
the warranted product, prepaid freight, along with proof of purchase to:
Midland Radio Corporation
Warranty Service Department
5900 Parretta Drive
Kansas City, MO 64120
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights,
which vary from state to state�
NOTE: The above warranty applies only to merchandise purchased in the United States of
America or any of the territories or possessions thereof, or from a U.S. Military exchange.
For Product Purchased in Canada:
Performance of any obligation under this warranty may be obtained by returning the warranted
product, along with proof of purchase, to your place of purchase in Canada�
Thiswarrantygivesyouspeciedlegalrights.Additionalwarrantyrightsmaybeprovidedbylaw
in some areas within Canada�

Model BR200
midlandusa.com Page 19
BA1
1 Programming
cable for BR200
radio
$9�99
Speaker mic
$39�99
D-Ring headset
$29�99
1 Multi unit charger
for BR200 radio
$99�99
Over the ear
headset
$29�99
Concealed
headset
$39�99
BA4
BA2
BA9
BGC200
BA3
ACCESSORIES
Accessories can be purchased at midlandusa�com
1 Replacement battery
for BR200 radio
$29�99
BRB200

5900 Parretta Drive
Kansas City, MO 64120
Call 816�241�8500
We’d love to hear from you! Let us know what you
think of your new Midland product at
or by visiting us at
midlandusa�com
Note: Features & Specifications are subject to change without
notice� MIDLAND is not responsible for unintentional errors or
omissions on its packaging�
