Midwest Menards ALBANY User manual

www.midwestmanufacturing.com
Approximate Weight: 600 lbs
Approximate Size: 3' 10" exterior diameter x 2' 4" interior diameter x 10½" H
ALBANY FIRE PIT
Autumn Blend: 198-9234
Quarry Gray: 198-9231
Sienna: 198-9232
Tan: 198-9233

Tumbled Belgian Wall Block (W) Tumbled Belgian Wall Block (S)
TUMBLED BELGIAN WALL BLOCK
179-3649
179-3647
179-3652
179-3639
Wedge
179-3731
179-3732
Sienna
Quarry Gray
Tan
Autumn Blend
Small
Color
PRODUCT:
Tumbled Belgian Wall (W)
Tumbled Belgian Wall (S)
QUANTITY
48
48
CONCRETE BLOCK MATERIALS
ADDITIONAL MATERIALS
PRODUCT:
Fire Pit Adhesive
28"Fire Ring
DESCRIPTION
10 oz Ube
Steel
QUANTITY
3
1
SKU#
638-4313
259-5005
DESCRIPTION
Color of Choice
Color of Choice
179-3733
179-3734
2PREPARE

A solid foundation is necessary to prevent settling and tiling of each project. We recommend using a
leveling pad, unless local building code requires you to pour a concrete foundation or build another type
of foundation.***Fire rings should be placed on stone, dirt, or sand surfaces. Pavers or concrete can be
installed around fire rings, but should not be under fire rings. Fire rings should not be placed on wood or
composite decking surfaces.
FOUNDATION:
• Choose the location for the completed project; place and mark the position of the base layer
of blocks. Once marked, remove the blocks and the organic top soil within the marked area.
• If applicable to your area, create a leveling pad with a non-frost susceptible, well graded,
compacted angular gravel-sand mixture with nes (GW as per ASTM D248). The leveling pad
should be a minimum of 4 to 6 inches thick. For leveling pads greater than 8” thick, the ll
material shall be placed in more than one lift. Each layer or lift of ll material shall be leveled
and compacted to a 95% Standard Proctor density before moving on.
• Once the top layer of ll material is compacted and level, place the base layer of blocks.
The base layer should sit 1 to 2 inches below grade to help further prevent shifting. Use
additional ll material to level the base layer as needed.
* If a concrete slab is required, prepare a leveling pad using the procedures listed in the paragraphs above. The
concrete shall have a minimum compressive strength of 2500 psi. A 4-inch thick concrete slab should be more
than sufcient. A thickened edge and reinforcement of the leveling slabs may be required. Please consult a
professional engineer for specic requirements.
TIPS FOR BUILDING LEVELING PADS:
3
PREPARE
These plans will walk you through each step as you Prepare, Assemble and Enjoy the new addition to
your yard. Check out the Progress Bar at the bottom of each page to track your advancements as you
complete each phase of your project!
INSTRUCTIONS:
PREPARE ASSEMBLE ENJOY
It is the responsibility of the owner to ensure compliance with all applicable laws, codes and regulations
for any project. Proper safety precautions must be taken prior to and during the construction of each
project. Please follow standard safety guidelines and wear necessary protective equipment when
building and using your new backyard addition.
RESPONSIBILITIES:
Rubber Mallet
Level
Utility Knife
Caulk Gun
Protective Equipment
Tape Measure
TOOL CHECK LIST
• Please research and
follow local building
codes prior to the
excavation, construction
and assembly of your
project.
• Exercise caution when
you work with concrete
block designs.
Wear protective safety
equipment such as safety
glasses, dust masks,
gloves and a hard hat.
• Whether you plan to build
the project yourself or to
hire a professional, every
project requires a call to
mark your utility lines.
BEFORE YOU BEGIN:

10½"
3' 10"
2' 4"
PREPARE:
FIRE PIT DIMENSIONS
TABLE OF CONTENTS
Level 1 - Level 4
Materials List
Tool Check List
Foundation Guidelines
ASSEMBLE:
Finished Elevations
Use and Maintenance
ENJOY:
2
3
3
5
6
7
4PREPARE
TECHNIQUES
Fasten each layer of block together with
¼” - ⅜" bead of construction adhesive on
all adjacent block faces unless otherwise
noted. Refer to the construction adhesive’s
application instructions for proper use.
INSTALLATION INSTRUCTIONS
* Do not over apply adhesive. It may reduce effectiveness.
Use mineral spirits to remove any unwanted adhesive.
Follow suggestions on page 3 to build a proper foundation before starting your new project. If
not already set, place the rst level of block 1"- 2" below grade, level and ll in any gaps. Use
Level 1 as a reference to place the blocks for all remaining levels.
Refer to the illustrations on the following pages to guide you through each step. Prior to
adhering each level to the previously laid block, place the entire level of blocks and check to
make sure it ts properly. Remove small sections at a time to place the adhesive.
Let adhesive dry for a minimum of two days before using the table.

(16) Tumbled Belgian Wall (W)
(16) Tumbled Belgian Wall (S)
Level 1 Level 2
Level 4
Level 3
ASSEMBLE 5
(16) Tumbled Belgian Wall (W)
(16) Tumbled Belgian Wall (S)
(16) Tumbled Belgian Wall (W)
(16) Tumbled Belgian Wall (S)
(1) 28" Fire Ring

ELEVATION PERSPECTIVES
Top View
Side View
6ENJOY

ENJOY 7
With proper use and maintenance you can enjoy this new addition to your
landscape for years to come.
Fire Pit Use:
• When using your fire pit, always following burning regulations in your area and never
leave a re unattended.
Use and Maintenance
Fire Pit Maintenance:
• Clean your fire pit often.
• Wait until the fire has burned out
completely and all ashes have cooled
before cleaning the fire pit.
• Begin by removing the larger pieces
of debris; the remaining ash can be
scooped out and/or lightly sprayed
with a hose to rinse away.
