Miele CM 5100 User manual

Operating instructions
Freestanding coffee machine
CM 5100
To avoid the risk of accidents or
damage to the machine, it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 07 902 360
en - GB, HK, SG, ZA

Packing material / Disposal of old machine ............................5
Guide to the machine ..............................................6
Warning and Safety instructions .....................................8
Preparing the coffee machine for use ................................13
Before using for the first time.........................................13
Switching on for the first time.........................................13
Water hardness ...................................................14
Filling the water container .........................................16
Filling the coffee bean container ....................................17
Switching on and off ..............................................18
Pre-heating cups .................................................19
To switch cup heating on or off .......................................19
Pre-heating cups using the cup heating function .........................19
Making coffee or espresso .........................................20
Making coffee or espresso ..........................................20
Making two portions of coffee or espresso at the same time ................20
Cancelling preparation .............................................21
Adjusting the coffee spouts to the correct cup height .....................21
Making coffee or espresso using ready ground coffee ..................22
Adding ready ground coffee .........................................22
Preparing coffee or espresso using ready ground coffee...................23
Cancelling preparation .............................................23
Frothing and heating milk ..........................................24
Preparation ......................................................24
Preparing milk froth ................................................24
Preparing hot milk .................................................25
Cancelling preparation .............................................25
After preparing milk ................................................25
Temperature of the milk and consistency of the milk froth ..................26
Coffee specialities .................................................26
Preparing hot water ...............................................27
Coffee the way you like it ..........................................28
Grinder setting ....................................................28
Amount of coffee ..................................................29
Pre-brewing the coffee .............................................30
Brewing temperature ...............................................30
Contents

Setting the portion sizes ...........................................32
Programming the amount using the .,/,-or *button ....................32
Setting the portion sizes for espresso, coffee and hot water ..............32
Setting the duration of the steam used for hot milk and milk froth ..........33
Selecting the PROG. THE AMOUNT option in the SETTINGS menu...........33
The SETTINGS menu ..............................................34
Operating principles ...............................................34
Possible setting options.............................................35
Language .......................................................36
Time of day and Clock display ......................................37
To set the clock display .............................................37
To set the time of day ..............................................37
Timer function ...................................................38
To set the timer ...................................................38
To activate and deactivate the timer ...................................40
Factory default ...................................................41
Operating modes .................................................42
To lock the coffee machine.........................................43
To activate and deactivate the system lock .............................43
To deactivate the system lock temporarily ..............................43
To display information ............................................44
Cleaning and care ................................................45
Quick guide ......................................................45
Rinsing the system.................................................46
Switching automatic rinsing on and off...............................46
Rinsing the system manually ......................................47
Cappuccinatore ...................................................47
Rinse the cappuccinatore.........................................48
Cleaning the cappuccinatore ......................................48
Water container ...................................................49
Drip tray cover ....................................................49
Drip tray and waste container ........................................50
Coffee bean container ..............................................51
Brew unit ........................................................52
Remove the brew unit and wash by hand ............................52
Cleaning the brew unit ...........................................53
Casing ..........................................................54
Contents

Descaling .......................................................55
Selecting the Descale option in the MAINTENANCE menu .................56
Problem solving guide ............................................57
After Sales / Guarantee ............................................68
Accessories .....................................................69
Saving energy ...................................................70
Transporting the coffee machine ....................................71
Evaporating the coffee machine ......................................71
Packing the machine ...............................................71
Electrical connection..............................................72
Installation ......................................................73
Coffee machine dimensions ........................................74
Contents
Short instructions
A short instruction leaflet is supplied
with this coffee machine which gives
basic information on how to operate
and clean the machine on a daily basis.
It is not a substitute for this operating
and installation instruction manual.
To avoid the risk of accidents or
damage to the machine it is important
to read this operating and installation
instruction manual carefully and take
note of the Warning and Safety
instructions.
You can keep the short operating
instructions in the slot at the back of the
coffee machine so that they are always
to hand.

Packing material
The packing material protects the
machine during transit.
Please retain the original box and
polystyrene pieces so that you can
pack the coffee machine securely,
should you wish to transport it in the
future.
The original packaging will also be
useful should you wish to return the
coffee machine to Miele for servicing.
Disposing of your old machine
Electrical and electronic machines
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your machine.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre, or contact your Dealer for
advice.
Ensure that it presents no danger to
children while being stored for
disposal.
Packing material / Disposal of old machine
5

aCup heating surface
bBean container, ground coffee chute
and rotary control for selecting
fineness of ground coffee
cDisplay and controls
dSteam and hot water spout
eCappuccinatore for frothing milk
(see inset diagram above)
fCoffee spouts
gDrip tray cover
hDrip tray with waste container
iMaster switch
jWater container
kCappuccinatore dial for selecting hot
milk, hot water and milk froth
lAir intake nozzle
mMilk tube
nDispensing spout
Symbols on the cappuccinatore dial:
-Hot water
zMilk froth
JHot milk
Guide to the machine
6

Display and controls
Control How to operate Function
aCoffee button /Press For dispensing coffee
bEspresso button .Press For dispensing espresso
cOn/Off button -Press For switching the coffee machine on or off
(Standby mode)
dRotary control Turn clockwise or
anti-clockwise
For displaying options or settings
eOK button Press For confirming a selection or action
For cancelling drink preparation
For calling up the SETTINGS menu
(Press and hold for 2 seconds)
The crescent will light up, if the option is
available
The crescent will flash before steam is generated
fHot water button -Press For dispensing hot water
gSteam button *Press For dispensing milk froth or hot milk
hDisplay For displaying messages
For customising the coffee machine
(in the SETTINGS menu)
Guide to the machine
7

This coffee machine conforms with
all current safety requirements.
Improper use can, however, lead to
personal injury and damage to
property.
To avoid the risk of accidents and
damage to the machine, please
read these instructions carefully
before using it for the first time.
They contain important notes on the
installation, safety, operation and
care of the machine.
Keep these instructions in a safe
place and pass them on to any
future owner.
Correct application
~The coffee machine is not designed
for commercial use. It is intended for
use in domestic households and for use
in similar working and residential
environments such as:
–Shops
–Offices and showrooms
and by residents in establishments
such as:
–Hostels and guest houses.
Should it be used in such
environments, it must be used as a
domestic appliance and only for the
preparation of (a maximum of 20 cups
a day) espresso, cappuccino, latte
macchiato etc.
Any other usage is not supported by
the manufacturer and could be
dangerous. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation.
The coffee machine is not intended for
outdoor use.
~The coffee machine is intended for
use by people with reduced physical,
sensory or mental capabilities, or lack
of experience or knowledge, only if they
are supervised whilst using it or have
been shown how to use it correctly by a
person responsible for their safety.
Warning and Safety instructions
8

Safety with children
Caution. The coffee spouts and the
cappuccinatore present a danger of
burning or scalding.
Children's skin is very sensitive and
reacts to hot temperatures.
~Place the coffee machine where it is
out of the reach of children.
~It is not a toy! To avoid the risk of
injury do not allow children to play with
it or its controls. Supervise children
whilst you are using it.
~Children 8 years and older may use
the machine only if they have been
shown how to use it in a safe way and
understand the hazards involved. Older
children may only use the machine if its
operation has been clearly explained to
them and they are able to use it safely,
recognising the dangers of misuse.
~Children under 8 years of age must
be kept away from the machine unless
they are constantly supervised.
Remember that coffee and espresso
are not suitable drinks for children.
Technical safety
~Before setting up the machine,
check it for any externally visible
damage. Never use a damaged
machine. Danger of injury.
~To avoid the risk of damage to the
machine, make sure that the rating on
the data plate corresponds to the
voltage and frequency of the household
supply, before connecting the machine
to the mains supply. Consult a qualified
electrician if in any doubt.
~The electrical safety of this machine
can only be guaranteed if correctly
earthed. It is most important that this
basic safety requirement is observed
and regularly tested and where there is
any doubt the household wiring system
should be inspected by a qualified
electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
~Do not connect the machine to the
mains electricity supply by a
multi-socket adapter or an extension
lead. These do not guarantee the safety
of the appliance, (e.g. danger of
overheating).
Warning and Safety instructions
9

~Disconnect the machine from the
electricity supply immediately you
notice any damage or the smell of
scorching, for example.
~Ensure that the mains connection
cable cannot become trapped or
damaged by any sharp edges.
~The mains connection cable should
not hang down. Someone could trip
over it and the machine could be
damaged. Excess cable can be
pushed through the cable exit at the
back of the machine.
~The coffee machine must not be
used in a non-stationary location (e.g.
on a ship).
~Only use the coffee machine in
rooms where the ambient temperature
is between 10 °C and 32 °C.
~Ensure that there is sufficient
ventilation around the coffee machine.
Do not cover the vent on the top of the
machine.
~If the coffee machine is installed
behind a kitchen furniture door, it may
only be used with the furniture door
open. Do not close the furniture door
while the coffee machine is in use.
~Protect the coffee machine from
water and water spray.
~Installation work and repairs may
only be carried out by suitably qualified
and competent persons to ensure
safety. Repairs and other work by
unqualified persons could be
dangerous and the manufacturer will
not be held liable.
~While the machine is under
guarantee, repairs should only be
undertaken by a service technician
authorised by the manufacturer.
Otherwise the guarantee will be
invalidated.
~Faulty components must only be
replaced by genuine Miele original
spare parts. Only genuine Miele original
spare parts guarantee the safety of the
machine.
~The machine must be disconnected
from the electricity supply during
installation, maintenance and repair
work.
~Disconnect the coffee machine from
the electricity supply if it is not going to
be used for a while, e.g. during
holidays.
Warning and Safety instructions
10

Correct use
Caution. The coffee spouts and the
cappuccinatore present a danger of
burning or scalding. The liquids and
steam dispensed are very hot.
~Please note:
–Keep well away from the area
underneath the coffee spouts or
cappuccinatore when hot liquids and
steam are being dispensed.
–Do not touch hot components.
– Ensure that the cappuccinatore is
fitted correctly. Only fit the
cappuccinatore if it is clean. If it
becomes clogged, hot liquid or
steam could spatter from the nozzle
or it could dislodge.
– The machine must not be used for
cleaning objects.
~Clean the coffee machine
thoroughly before using it for the first
time. Rinse through the coffee and milk
pipework (see "Cleaning and care").
~Please note the following regarding
water:
–Only use cold, clean tap water to fill
the water container. Warm or hot
water or other liquids could damage
the machine.
–Change the water every day to
prevent a build-up of bacteria.
–Do not use mineral water. Mineral
water will cause serious limescale
deposits to build up in your machine
and damage it.
–Do not use water from reverse
osmosis units. The machine could be
damaged.
~Only fill the bean container with
roasted coffee beans. Do not fill the
bean container with coffee beans which
have been treated or with ground
coffee.
~Do not reach into the grinding
mechanism.
~Only add ground coffee or cleaning
tablets to the ground coffee chute. The
cleaning tablets remove grease from
the brew unit.
~Only use milk without additives.
Sugar additives would stick to the milk
pipework and the cappuccinatore.
~Do not use coffee beans which have
been treated with caramel, sugar or
other substances as they could
damage the machine.
~Do not place any alcohol mixtures
which are alight underneath the coffee
spouts. The flames could ignite plastic
components and cause them to melt.
~Do not place any naked flames, e.g.
a candle, on or near the coffee
machine. The coffee machine could
catch fire.
Warning and Safety instructions
11

~Please note the following with
regard to cleaning the coffee machine:
–Disconnect the coffee machine from
the electricity supply before
cleaning.
–Clean the coffee machine every day
(see "Cleaning and care" for more
information).
–Do not use a steam cleaner to clean
this appliance. Steam could cause a
short circuit.
–Descale the coffee machine regularly
using the appropriate number of
Miele descaling tablets for the water
hardness level in your area. Descale
the machine more frequently in areas
with very hard water. The
manufacturer cannot be held liable
for damage arising from insufficient
descaling.
– Degrease the brew unit regularly with
Miele cleaning tablets. Depending on
the natural oil content of the coffee
used, the brew unit can become
blocked quite quickly.
–Used coffee grounds should be
disposed of with organic rubbish or
on the compost heap, but not
emptied down the sink as they could
block it.
For machines with a stainless steel
trim:
~Do not use sticky notes, transparent
adhesive tape, masking tape or other
types of adhesive on the stainless steel
trim. These damage the surface,
causing it to lose its dirt repellent
protective coating.
~The surface of the stainless steel
trim is susceptible to scratching. Even
magnets can cause scratches to
appear.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
12

Please read the operating
instructions and take the time to
familiarise yourself with the coffee
machine before using it for the first
time.
Before using for the first time
^Set up the coffee machine and
remove any protective film (see
"Installation").
^Insert the plug of the coffee machine
into the socket (see "Electrical
connection"). If the connection cable
is too long, you can push some of it
through the opening in the rear of the
appliance.
Please clean the machine
thoroughly before filling the water
container and the coffee bean
container (see "Cleaning and care").
^Fill the coffee bean container with
coffee beans (see "Filling the coffee
bean container").
^Fill the water container with fresh,
cold tap water (see "Filling the water
container").
Switching on for the first time
When you switch the coffee machine on
for the first time, after the welcome
screen has appeared you will be
prompted to set the following:
–Language
–Clock format
–Time of day
^Set the master switch at the back of
the coffee machine to "l".
^Press the On/Off button -.
The welcome message MIELE -
WILLKOMMEN will appear in the
display briefly.
To set the language
^Turn the rotary control until the
language you require appears in the
display.
Press the OK button.
The setting is now saved.
Preparing the coffee machine for use
13

To set the clock display
^If you want the time to be shown as a
12 hour clock, turn the rotary control
until 12 H appears.
or
^If you want the time to be shown as a
24 hour clock, turn the rotary control
until 24 H appears.
^Press the OK button.
The setting is now saved.
To set the time of day
You can now enter the hours and
minutes:
^Turn the rotary control until the
current hour appears.
Press the OK button.
^Turn the rotary control until the
current minutes appear.
Press the OK button.
The setting is now saved. SET UP
SUCCESSFUL will appear in the
display.
^Press the OK button.
If the water container is empty, the
following will appear in the display
FILL WATER CONTAINER
AND PLACE IN MACHINE
^Fill the water container with fresh,
cold tap water.
TIP Place a suitable container
underneath the cappuccinatore.
The following will appear in the display:
SYSTEM FILLING UP
START
^Press the OK button.
TIP Continue following the instructions
given in this booklet to set up your
machine and familiarise yourself with it.
Water hardness
The water hardness indicates how
much calcium is dissolved in the water.
The higher the calcium content, the
harder the water, and the harder the
water, the more often the coffee
machine will need to be descaled.
The coffee machine measures the
quantity of water and steam used. The
number of drinks which can be
dispensed before the machine needs to
be descaled will depend on the water
hardness level set.
Set the water hardness level on the
coffee machine to the water hardness
level for the local area to ensure that
the machine functions correctly and is
not damaged. This will ensure that the
reminder to descale the machine will
appear in the display at the correct
time.
Preparing the coffee machine for use
14

There is a choice of four water
hardness levels:
–Level 1 (soft):
Local water hardness range 0-8.4 °d
(0-1.5 mmol/l)
Water flow rate: approx. 220 l
Steam flow rate: approx. 440 min
–Level 2 (medium):
Local water hardness level 1
8.4-14 °d (1.5-2.5 mmol/l)
Water flow rate: approx. 100 l
Steam flow rate: approx. 200 min
–Level 3 (hard):
Local water hardness range 2
14-21 °d (2.5-3.8 mmol/l)
Water flow rate: approx. 70 l
Steam flow rate: approx. 140 min
–Level 4 (very hard):
Local water hardness range 3-4
21 °d (21 °d (>21 °d (>3.8 mmol/l) or
more
Water flow rate: approx. 40 l
Steam flow rate: approx. 80 min
Measuring the water hardness
You can use the test strip supplied to
check the water hardness level, or your
local water supplier will be able to
advise you on the water hardness in
your area.
^Dip the test strip in water for a
second, then shake off any excess
water. The result will be evident after
about a minute.
You can now set the water hardness
level for the coffee machine.
Setting the water hardness
^In the main menu, press the OK
button for two seconds.
SETTINGS
rWATER HARDNESS s
^Turn the rotary control until WATER
HARDNESS appears in the display.
Press the OK button.
^Turn the rotary control until the water
hardness level you require appears
in the display.
Press the OK button.
The setting is now saved.
Preparing the coffee machine for use
15

The quality of the water plays an
important part in the overall quality of
the coffee.
The water container should therefore be
emptied and filled with fresh tap water
every day.
Warning. Bacteria can cause
infection.
It is important to empty and fill the
container with fresh tap water every
day to avoid the risk of bacteria
building up.
Hot or warm water or other liquids
can damage the coffee machine.
Do not use mineral water in the
water container. Mineral water will
cause serious limescale deposits to
build up in your machine and
damage it.
^Open the lid on the left hand side of
the coffee machine a. Pull the water
container up by its handle and
remove it b.
^Fill the water container with fresh,
cold tap water up to the "Max."
marker.
^Replace the water container in the
coffee machine. Make sure that the
water container fits correctly onto the
notch at the top of its housing.
^Close the lid.
TIP If the water container is a little high
or at a slant, check whether the surface
that the water container sits on is dirty.
If the water container is not sitting
correctly, the drainage valve will not be
sealed.
Clean the surface, if necessary.
Filling the water container
16

If you want to use freshly ground coffee
beans for each cup of espresso or
coffee, fill the coffee bean container
with roasted coffee beans.
Alternatively, you can make coffee or
espresso with ready ground coffee (see
"Preparing coffee or espresso using
ready ground coffee").
Warning. Only put roasted coffee
beans in the container.
Anything else, including ground
coffee, will damage the grinder.
Warning. Do not use coffee beans
that have been treated with sugar,
caramel, or other substances and
do not put drinks containing sugar in
the coffee bean container. Sugar will
damage the machine.
^Open the lid on the right hand side of
the coffee machine a. Remove the
coffee bean container lid b.
^Fill the container cwith roasted
coffee beans .
^Replace the container lid and close
the lid of the coffee machine.
TIPP Only add enough beans to last for
a few days as contact with the air
causes coffee beans to loose their
flavour.
Filling the coffee bean container
17

You can use the On/Off button -
(standby) to switch the coffee machine
on and off, if the master switch at the
back of the machine is switched on.
Switching on
When the On/Off button -is pressed,
the coffee machine will heat up and the
pipework will be rinsed through. This
cleans and heats the pipework ready
for coffee preparation. After rinsing, hot
water will run into the drip tray.
If the coffee machine still has an
operating temperature which is higher
than 60 °C, then rinsing will not take
place.
^Press the On/Off button -.
The following will appear in the display:
HEATING-UP PHASE
If automatic rinsing has been activated,
then the following will appear in the
display after the heating-up phase:
RINSING
Hot water will be dispensed from the
coffee spouts.
The main menu will then appear:
SELECT TYPE OF DRINK
You can now prepare coffee or
espresso.
Switching off
^Press the On/Off button -.
If the automatic rinsing function has
been switched on, the pipework will be
rinsed through before the coffee
machine switches itself off.
If you have switched the automatic
rinsing function off, you should rinse the
pipework manually (see "Cleaning and
care") before switching the coffee
machine off.
TIP To save energy, use the master
switch at the back of the coffee
machine to switch it off if it is not going
to be used for a long period of time,
e.g. during holidays.
Please note that the time of day will not
be saved and must be entered again
the next time the coffee machine is
switched on.
Switching on and off
18

Cups should always be pre-heated to
allow the flavour of the coffee to
develop and be retained.
The smaller the volume of
coffee/espresso and the thicker the
cup, the more important it is to pre-heat
the cup.
You can use the cup heating surface on
the top of the coffee machine to
pre-heat coffee cups and glasses. The
cup heating function must be switched
on.
TIP To save energy you could also heat
cups with hot water by using the
-button.
To switch cup heating on or off
^In the main menu, press the OK
button for two seconds.
SETTINGS
rCUP HEATING s
^Turn the rotary control until CUP
HEATING appears in the display.
Press the OK button.
^To switch the cup heating function
on, turn the rotary control until YES
appears in the display.
or
^To switch the cup heating function
off, turn the rotary control until NO
appears in the display.
^Press the OK button.
Pre-heating cups using the
cup heating function
^Arrange the cups or glasses on the
cup heating surface on the top of the
coffee machine.
The cup heating surface will be heated
continually until the coffee machine is
switched off.
Pre-heating cups
19
-
*

Making coffee or espresso
When the /or .button is pressed, the
coffee machine grinds the beans and
then uses the freshly ground beans to
brew the coffee.
^Place a cup under the coffee spouts.
^To make a coffee press the /button.
or
^To make an espresso press the .
button.
The coffee or espresso will be
dispensed from the coffee spouts into
the cup.
To ensure that any coffee residues
from the factory testing process are
removed from the brewing system,
please throw away the first two cups
of coffee when using the coffee
machine for the first time.
Making two portions of coffee
or espresso at the same time
You can select two portions of coffee or
espresso at the same time. The coffee
machine will then make the portions
one after the other.
To prepare two cups of coffee or
espresso at the same time:
^Place one cup under each of the
coffee spouts.
^Then press the /button twice to
dispense two portions of coffee.
or
^Press the .button twice to dispense
two portions of espresso.
Two portions of the coffee/espresso will
be dispensed from the two coffee
spouts.
Making coffee or espresso
20
