NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010605
Product and Cut-out Dimensions
Plate Warmer and Coffee System
EGW2060 & CVA2660
21 7/8" min.
22 1/16" - 22 3/8"
Plugged electrical main connects left
back side (NEMA 5-15P).
120 Volt - 15Amp - 3 Wire outlet
(live / neutral / ground - NEMA 5-15R).
Locate in adjoining cabinet
Plugged electrical main connects left
back side (NEMA 5-15P).
120 Volt - 15Amp - 3 Wire outlet
(live / neutral / ground - NEMA 5-15R).
Locate in adjoining cabinet
E1-
01 -
E2-
02-
Location Codes
• All installations must be done in
accordance with local codes.
Notes
4"
20 1/2"
23 7/ 16"
7/ 8"
3 1/16"
21 1/8"
17 3/4"
13 3/4"
11 5/ 8"
23 7/ 16"
7/ 8"
14 5/ 8"
21 15/16"
1/ 2"
O1
3/4"
1/8"
E1
O2
E2
