Miele G2832SCi User manual

Operating Instructions
Dishwasher
G 2832
To prevent accidents
and appliance damage
read these instructions
before
installation or use. M.-Nr. 07 724 120
en - US, CA

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control panel ......................................................9
Display ..........................................................10
Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
To open the door ..................................................12
To close the door ..................................................12
Child Safety Lock..................................................12
Water softener ....................................................15
Filling the salt container .............................................16
Salt refill message .................................................16
Rinse aid ........................................................17
Adding rinse aid ..................................................17
Rinse aid refill message.............................................18
Loading the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Items not recommended for dishwashing ...............................20
Split cutlery tray ..................................................21
Upper basket .....................................................22
Adjusting the upper basket ..........................................25
Lower basket .....................................................26
Basket accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Adding detergent..................................................31
Program guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Selecting options ..................................................35
Starting a program.................................................36
Time display......................................................36
At the end of a program.............................................37
Interrupting a program..............................................37
Additional options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Contents
2

Settings !. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Drying Plus.......................................................44
Water hardness ...................................................44
External water softener .............................................44
Filter check ......................................................45
Button tone.......................................................50
RemoteVision .....................................................50
RemoteVision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Technical faults ...................................................53
Problems water intake/drain .........................................55
General problems with the dishwasher .................................57
Sounds..........................................................59
Poor cleaning results ...............................................60
Comparison Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
User Maintenance Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Triple filter system .................................................69
Cleaning the spray arms ............................................71
Cleaning the water inlet filter .........................................72
Cleaning the drain pump and non-return valve...........................73
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Plumbing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Waterproof system .................................................77
Connection to the water supply ........................................77
Drainage ........................................................78
Contents
3

WARNING –
When using your dishwasher, follow
basic precautions, including the
following:
Read all instructions before
installation or use of the dishwasher
to prevent injury and machine
damage.
Use the dishwasher only for its
intended purpose. This appliance is
intended for residential use only.
Keep these operating instructions in
a safe place and pass them on to
any future user.
Electrical Safety
~Before installation, make sure that
the voltage and frequency listed on the
data plate correspond with the
household electrical supply. This data
must correspond to prevent injury and
machine damage. Consult a qualified
electrician if in doubt.
~Before installation or service,
disconnect the power supply to the
work area by unplugging the unit,
"tripping" the circuit breaker or
removing the fuse.
~Do not use an extension cord to
connect this appliance to electricity.
Extension cords do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
~Be certain your appliance is
properly installed and grounded by a
qualified technician. To guarantee the
electrical safety of this appliance
continuity must exist between the
appliance and an effective grounding
system. It is imperative that this basic
safety requirement be met. If there is
any doubt, have the electrical system of
the house checked by a qualified
electrician.
IMPORTANT SAFETY INSTRUCTIONS
4

Installation
~The dishwasher must be installed
and connected in compliance with the
installation instructions.
~Installation and repair work should
be performed by a Miele authorized
service technician. Work by unqualified
persons could be dangerous and may
void the warranty.
~Do not install or use a damaged
dishwasher. A damaged appliance is
dangerous. Unplug the machine and
call your Miele dealer or the Miele
Technical Service Department.
~Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
~This equipment is not designed for
maritime use or for use in mobile
installations such as recreational
vehicles or aircraft. However, under
certain conditions it may be possible for
an installation in these applications.
Please contact the nearest Miele dealer
or the Miele Technical Service
Department with specific requirements.
~It is recommended that the
dishwasher only be connected to the
mains with the plug (no hard-wiring).
The outlet must be accessible at all
times after installation to disconnect the
dishwasher.
~,WARNING - Fire hazard
Do not cover or crush the plug of the
appliance. Ensure that the cabinet
opening for the dishwasher provides
ample space for the plug. Installing the
dishwasher in a tight space may crimp
the power cord or put pressure on the
plug which could cause overheating.
~This dishwasher should only be
installed under a continuous counter
top secured to adjacent cabinetry.
~Do not install this dishwasher
beneath a cooking surface, oven or any
appliance that radiates heat.
High temperatures from these units
may damage the dishwasher.
~When installing the dishwasher
under a counter top and removing the
toe-kick, a build-under toe-kick must be
installed. Use the respective installation
kit. Danger of injuries.
~Do not cut the intake hose or
submerge it in liquid. This hose
contains electrical components that
could cause injury or property damage
if cut or submerged.
~Only connect the dishwasher to the
mains when all installation and
plumbing work is complete.
IMPORTANT SAFETY INSTRUCTIONS
5

Use
~To reduce the risk of injury, do not
allow children to play in, on or near the
dishwasher.
~Only use the dishwasher if all panels
are properly in place.
~Do not tamper with the controls.
~Do not damage, sit or stand on the
door or baskets of the dishwasher.
Close the door when not in use.
~Under certain conditions, hydrogen
gas may be produced in a hot water
system that has not been used for two
weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has
not been used for such a period, turn
on all hot water faucets and let water
flow from each for several minutes
before using the dishwasher. This will
release any accumulated hydrogen
gas. Do not smoke or use an open
flame during this time.
~Be sure that all items placed in the
dishwasher are "dishwasher safe". For
items not labeled, check the
manufacturer’s recommendations.
~When loading tableware, place
sharp items away from the door to
prevent damage to the seal. Load
sharp items pointing downwards to
prevent injuries.
~Only use detergents and rinse aids
recommended for residential
dishwashers. Keep all detergents and
rinse aids out of the reach of children.
~Do not inhale or swallow detergents.
Dishwasher detergents contain irritant
and corrosive ingredients. They can
cause burning in the mouth and throat if
swallowed, or inhibit breathing. Consult
a doctor immediately if detergent has
been swallowed or inhaled.
~Do not drink water from the
dishwasher! Harmful residues could be
present.
~Do not fill the rinse aid reservoir or
salt container with detergent. It will
destroy the rinse aid compartment and
water softener.
~If the power cord is damaged it
must only be replaced by a Miele Ser-
vice technician with a genuine Miele
power cord.
~This model offers a Drying Plus
feature, i.e. the door will automatically
open, without an audible signal first
being given, at the end of the program
releasing warm air from the dishwasher.
Use caution, the air may be hot!
~This model offers an AutoClose
feature, i.e. the door will automatically
shut once close enough to engage the
catch.
IMPORTANT SAFETY INSTRUCTIONS
6

~Advise the user of the AutoClose
feature to avoid injuries by walking,
bumping or knocking into the partially
opened door.
~Supervise children near the
dishwasher to ensure fingers or other
parts of the body are not caught when
the AutoClose feature is in operation.
Disposal of an appliance
~If the appliance is removed from its
installation site and will not be used,
remove the doorlock to the wash
cabinet to prevent children from locking
themselves in the machine.
SAVE THESE
INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
7

aUpper spray arm (not visible)
bCutlery tray
cUpper basket
dMiddle spray arm
eAir inlet for drying
(depending on model)
fLower spray arm
gTriple filter system
hData plate
iChild Safety Lock in the door handle
(not visible)
jRinse aid reservoir
kDual compartment detergent
dispenser
lSalt container
Guide to the dishwasher
8

Control panel
aK(Information) touch control
To display more info about the
displayed menu
bs(On/Off) touch control
To turn the dishwasher on and off
cSelection touch controls
To select a menu point displayed
next to the touch control.
To change the displayed value (+/-).
To browse between menus.
dDisplay
See the following pages for more
information
eStandby indicator
The indicator flashes when the
dishwasher is turned on but the
display is turned off.
fClear touch control
To switch back to the previous menu
level or to delete a selected setting.
gTechnical Service interface
Allows a service technician to check
and update the machine when
applicable.
Guide to the dishwasher
9

Display
The following can be selected in the
display :
–the wash program
–the options
–the start time
– the settings Jmenu
– information
During a running program the display
shows :
– the program name
– the current time of day
– the program sequence
–the approximate remaining time
–faults and messages
To save energy, if a button is not
pressed, the display will turn off after
a few minutes. To show the display
again, press any button.
!
A bullet in the display next to the touch
control shows that a function can be
selected with this control.
n
The arrows on the right side in the
display shows that more selections or
text follow and can be displayed with
the respective control.
------
A dotted line is shown to indicated the
last selection available.
OK
To confirm these messages or settings
touch OK and the next menu or another
menu level will appear.
(
A check will appear beside the
currently selected option.
The "Settings J" menu allows you to
customize the dishwasher settings.
See "Settings" for more information.
Guide to the dishwasher
10
