Miele PFD 101 User manual

OPERATING INSTRUCTIONS
Commercial Dishwasher
PFD101 / PFD101 U /
PFD101i / PFD102i
 To prevent accidents and machine damage,
read these instructions before installation or
use.
en-US, CA
M.-Nr. 11 673 620

2

Contents
3
Notes about these instructions........................................................................ 6
Operating steps ................................................................................................... 6
IMPORTANT SAFETY INSTRUCTIONS ............................................................ 7
APPROPRIATE USE ............................................................................................ 7
Machine description.......................................................................................... 17
Appliance overview ............................................................................................. 17
Control field......................................................................................................... 18
Display functions................................................................................................. 19
Caring for the environment .............................................................................. 20
Initial commissioning ........................................................................................ 21
Opening the door ................................................................................................ 21
Closing the door.................................................................................................. 22
Activating the safety lock .................................................................................... 22
Miele@home ........................................................................................................ 23
Basic settings...................................................................................................... 24
Setting the language ...................................................................................... 24
Setting up Miele@home ................................................................................. 24
Setting the time .............................................................................................. 25
Setting water hardness................................................................................... 25
Reactivation salt.................................................................................................. 26
Refilling the salt .............................................................................................. 27
Rinse aid.............................................................................................................. 28
Adding rinse aid ............................................................................................. 29
Filling the rinse-aid reservoir .......................................................................... 29
Caring for the environment .............................................................................. 30
Energy-saving dishwashing................................................................................. 30
EcoFeedback consumption display .................................................................... 31
Loading the dishwasher.................................................................................... 32
General information............................................................................................. 32
Upper basket....................................................................................................... 34
Adjusting the upper basket ................................................................................. 37
Lower basket....................................................................................................... 38
Cutlery ................................................................................................................. 41
Cutlery basket (depending on model) ............................................................ 41
Loading examples ............................................................................................... 42
Detergents ......................................................................................................... 44
Dispensing detergent .......................................................................................... 45
Adding detergent................................................................................................. 46

Contents
4
Operation............................................................................................................ 47
Turning on the dishwasher .................................................................................. 47
Selecting a program ............................................................................................ 47
Display of program cycle time............................................................................. 48
Starting a program .............................................................................................. 48
Program end........................................................................................................ 49
Energy management ........................................................................................... 49
Turning off the dishwasher .................................................................................. 50
Unloading the dishwasher................................................................................... 50
Interrupting a program......................................................................................... 51
Canceling or changing a program ....................................................................... 51
Options ............................................................................................................... 52
Options................................................................................................................ 52
Timer .............................................................................................................. 53
Activating Remote start.................................................................................. 57
Program chart.................................................................................................... 58
Cleaning and care ............................................................................................. 61
USER MAINTENANCE INSTRUCTIONS ............................................................. 61
Cleaning the wash cabinet .................................................................................. 61
Cleaning the door and the door seal................................................................... 62
Cleaning the control panel .................................................................................. 62
Cleaning the front of the machine ....................................................................... 62
Cleaning the spray arms...................................................................................... 63
Checking the filters in the wash cabinet ............................................................. 65
Cleaning the filters............................................................................................... 65
Cleaning the water-inlet filter............................................................................... 67
Cleaning the drain pump..................................................................................... 68
Frequently asked questions ............................................................................. 70
Technical faults.................................................................................................... 70
Fault messages ................................................................................................... 71
Door release ........................................................................................................ 72
Water intake fault................................................................................................. 73
Water drainage fault ............................................................................................ 74
General dishwasher problems............................................................................. 75
Noises.................................................................................................................. 76
Poor cleaning results........................................................................................... 77
Miele Service ..................................................................................................... 80
Contact in the event of a fault ............................................................................. 80
Program updates ................................................................................................ 80

Contents
5
INSTALLATION INSTRUCTIONS ....................................................................... 81
Electrical connection ........................................................................................ 82
Plumbing ............................................................................................................ 83
The Miele Waterproof system.............................................................................. 83
Water inlet ........................................................................................................... 83
Connecting the water drainage system............................................................... 85
Technical details................................................................................................ 86
Settings ........................................................................................................... 87
Opening the Settings menu................................................................................. 87
Changing settings ............................................................................................... 87
Language......................................................................................................... 88
Time of day.......................................................................................................... 88
Water hardness ................................................................................................... 89
Rinse Aid ............................................................................................................. 90
Temperature unit.................................................................................................. 90
High-temperature final rinse................................................................................ 90
Miele@home ........................................................................................................ 90
Remote control.................................................................................................... 94
RemoteUpdate .................................................................................................... 94
SmartStart ........................................................................................................... 95
EcoStart............................................................................................................... 96
Consumption (EcoFeedback) .............................................................................. 98
Display brightness............................................................................................... 98
Volume................................................................................................................. 99
Memory ............................................................................................................... 99
Refill reminders.................................................................................................... 99
AutoOpen ............................................................................................................ 100
BrilliantLight (depending on model)..................................................................... 100
Software version.................................................................................................. 100
Showroom program............................................................................................. 100
Factory default..................................................................................................... 101
Sound emission tests........................................................................................ 102

Notes about these instructions
6
Warnings
Warnings important for safety are highlighted like this. This alerts you to the
potential danger of injury to people or damage to property.
Read the warnings carefully and follow the instructions and directions.
Notes
Notes contain information that is particularly important to follow.
They are highlighted in a thick framed box.
Additional information and comments
Additional information and comments are contained in a narrow frame.
Operating steps
Instructions on how to operate the commercial dishwasher are identified by
marked operating steps. They explain the procedure step by step.
Operating steps are identified by a black square bullet point.
Example:
Select the setting you want and press OK to confirm.
Display
Information that is shown in the commercial dishwasher display appears in a spe-
cial font similar to the display text.
Example:
When the messageEnd or Auto Open Dryingappears in the display...

IMPORTANT SAFETY INSTRUCTIONS
7
APPROPRIATE USE
This Commercial Dishwasher complies with all current local and
national safety requirements. Inappropriate use can, however, lead
to personal injury and material damage.
WARNING:
When using your dishwasher, follow basic precautions, including
the following:
Read the operating instructions carefully before using the Com-
mercial Dishwasher for the first time. They contain important infor-
mation on the safety, use, and maintenance of the machine. Keep
these operating instructions in a safe place and pass them on to
any future user.
 This dishwasher with its short program cycle times and powerful
cleaning performance is intended for commercial use in offices,
lunch rooms, clubhouses, workshops, large kitchens, and similar
professional environments.
It is also suitable for use in domestic households and in similar resi-
dential environments; for example, by customers in hotels, motels,
bed and breakfasts, and other related establishments.
 The commercial dishwasher is subsequently referred to as a dish-
washer in these operating instructions.
Glasses, cutlery and dishes are referred to generally as cookware
when not more specifically defined.
 This dishwasher is not intended for continuous use.
 This dishwasher is not intended to be used to clean medical de-
vices or products.
 This machine is designed exclusively for use as a “dishwasher” for
cleaning wash items as described in these instructions. Conversions,
modifications, and any other use are not permitted.
 This dishwasher is intended for stationary, indoor use only.

IMPORTANT SAFETY INSTRUCTIONS
8
 This dishwasher is intended for use at altitudes of up to 13,000ft
(4,000m) above sea level.
 The special inserts in the baskets should only be used for their
specific application.
 This dishwasher can only be used by people with reduced physi-
cal, sensory or mental capabilities, or lack of experience or knowl-
edge, if they are supervised while using it or have been shown how
to use it in a safe way and understand and recognize the conse-
quences of incorrect operation.
 The dishwasher is equipped with interior lighting. It is not suitable
for room lighting. Replacement lamps may only be installed by a
Miele-authorized specialist or by Miele Service.

IMPORTANT SAFETY INSTRUCTIONS
9
Proper installation
 Do not install the machine in an area where a danger of explosion
or of freezing temperatures may be present.
 Be careful when installing the dishwasher. Wear protective
gloves to avoid injury on any sharp metal components.
 To ensure the stability of undercounter dishwashers, these units
may only be installed beneath a continuous countertop that is bolted
to adjacent cabinetry.
 In order to reduce the risk of damage from condensation, the cab-
inetry in the area around the dishwasher should be designed for
commercial use.
Delicate cabinetry can be protected using the damp protection set,
which is available as an optional accessory.
The vapor barrier film needs to be adhered to the underside of the
countertop where the dishwasher door is opened.
 The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the door
cannot fall open.
The machine must only be operated with properly adjusted door
springs.
If the door cannot be adjusted properly, contact the Miele Customer
Service.
The maximum weight of the front panel that can be aligned with the
factory-installed door springs is 22-26.5 lb (10–12kg) (depending on
model).

IMPORTANT SAFETY INSTRUCTIONS
10
Technical safety
 This dishwasher should be installed, commissioned, repaired, and
maintained by Miele Service, a dealer, or a suitably qualified special-
ist. Unauthorized installation, maintenance, and repairs can cause
considerable danger for the user.
 This dishwasher should only be operated by appropriately trained
personnel. They should be instructed and trained regularly.
 Do not operate your dishwasher unless all enclosure panels are
properly in place. Before using the dishwasher, check it for any ex-
ternally visible damage. Do not use a damaged dishwasher. This
could be dangerous.
 In the event of a damaged or leaking dishwasher, switch off at the
power supply immediately and call Miele Technical Service, a Miele
dealer, or a suitably qualified service technician.
 Faulty components should only be replaced by genuine Miele
original parts. Only when these parts are fitted can Miele guarantee
the safety standards of the appliance.
 WARNING – Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check with a quali-
fied electrician or service representative if you are in doubt whether
the appliance is properly grounded. Do not modify the plug provided
with the appliance, if it will not fit the outlet, have a proper outlet in-
stalled by a qualified electrician.
 Be sure to follow the installation instructions in this manual and in
the installation diagram.
 Ensure that the connection data on the data plate (voltage, fre-
quency, and fuse rating) match those of your electrical supply.

IMPORTANT SAFETY INSTRUCTIONS
11
 The dishwasher may only be operated if the door-opening mecha-
nism is working correctly. Otherwise there could be a risk of danger
while the automatic door-opening mechanism (depending on the
model) is active.
The maximum weight of the front panel that can be aligned with the
factory-installed door springs is 22-26.5 lb (10–12 kg) (depending on
model).
To check that the door-opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half
open (approx. 45° opening angle). It is also important that the
door cannot fall open.
- The door locking pins automatically retract when the door opens
at the end of the drying phase.
 The control elements of the dishwasher must not be tampered
with.
 WARNING - Fire hazard! Do not cover or crush the plug of the ap-
pliance. Ensure that the cabinet opening for the dishwasher provides
ample space for the plug and cord. Installing the dishwasher in a
tight space may crimp the power cord or put pressure on it. See
“Electrical connection”.
 Do not use an extension cord to connect this machine to electric-
ity. Extension cords do not guarantee the required safety of the ma-
chine (e.g., danger of overheating).
 Do not open the casing of the dishwasher. Any contact with live
connections or tampering with the electrical or mechanical compo-
nents of the dishwasher will endanger your safety and may lead to
machine malfunctions.
 The dishwasher must not be used if the wire is damaged. A dam-
aged wire may only be replaced by a suitable wire of the same type.
For safety reasons, such replacement may only be carried out by
Miele Technical Service or a qualified service technician.

IMPORTANT SAFETY INSTRUCTIONS
12
 Before servicing the appliance, disconnect it from the power sup-
ply.
 The plastic housing of the water connection contains electrical
components. It must not be dipped in water.
 There are live wires in the water intake hose. Do not shorten the
water intake hose, even if it is too long.
 The built-in Waterproof system offers reliable protection against
water damage if the following conditions are met:
- Installation has been carried out correctly.
- The dishwasher is properly maintained and parts are replaced in
case of noticeable damage.
- The shut-off valves have been turned off during longer absences
(for example, vacation).
The Waterproof system will work even when the dishwasher is
switched off. However, the dishwasher must remain connected to
the electricity supply.

IMPORTANT SAFETY INSTRUCTIONS
13
Correct use
 This dishwasher is designed for operation with water and cleaning
agents suitable for use in dishwashers only. Organic solvents and
flammable liquid agents must not be used.
This could cause an explosion, damage rubber or plastic compo-
nents in the dishwasher, and cause liquids to leak out of it.
 You could injure yourself on the open dishwasher door or trip over
it. Avoid leaving the door open unnecessarily.
 Do not sit, stand, or lean on the opened door or dish rack. This
could tip or damage the dishwasher.
 After any plumbing work, the water pipework to the dishwasher
will need to be vented. If this is not done, components can be dam-
aged.
 Please be aware that the dishwasher may be operating at high
temperatures. When the door is opened there is a risk of burning or
scalding. Wash items, baskets, and inserts must be allowed to cool
down before they are unloaded. Any water remaining in containers
could still be very hot. Empty them into the wash cabinet before tak-
ing them out.
 The water in the wash cabinet is NOT safe to drink!
 The pretreatment of items (for example with dishwashing liquid
and other detergents), but also some types of soiling and some de-
tergents, can cause a build-up of foam in the wash cabinet. Foam
can have an adverse effect on the cleaning result.
 Depending on the properties of the flooring and footwear worn on
it, liquids can cause a slipping hazard. Keep the floor dry where pos-
sible and take care to clean up any liquid spills straight away. Take
the necessary precautions when cleaning up hazardous substances
and hot liquids.

IMPORTANT SAFETY INSTRUCTIONS
14
 Foam escaping from the wash chamber can cause damage to the
dishwasher. If foam escapes, the program must be canceled imme-
diately and the dishwasher must be disconnected from the mains
electrical supply.
 When using detergents and specialized products, it is essential
that the manufacturer's instructions are followed. Detergents must
only be used for the purpose they are designed for by the manufac-
turer to avoid any material damage or the occurrence of strong
chemical reactions (e.g., oxyhydrogen explosion).
 Under certain conditions, hydrogen gas might be produced in a
hot-water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the dishwasher turn on all
hot-water faucets and let the water flow from each for several min-
utes. This will release any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during this time.
 Miele cannot be held liable for any effect chemical detergents may
have on the material of the items being cleaned. Observe the deter-
gent manufacturer's instructions with regard to storage conditions,
use, and dosage.
 Do not inhale or ingest powder detergent. Dishwasher detergents
contain irritant or corrosive ingredients which can cause burning in
the nose, mouth and throat if swallowed, or inhibit breathing. Seek
medical attention immediately if detergent has been swallowed or in-
haled.
 Powder and liquid detergents containing active chlorine must not
be used. You may damage plastic parts and the seals of the dish-
washer.
 To avoid material damage and corrosion, do not allow any acids
or solutions containing chloride to get into the wash cabinet or onto
the casing. Similarly avoid any ferrous materials with a corrosive ef-
fect.

IMPORTANT SAFETY INSTRUCTIONS
15
 Do not wash items soiled with ash, sand, wax, lubricating grease,
or paint in the dishwasher. These materials will cause damage to the
dishwasher.
 Do not clean the dishwasher or its near vicinity with a hose or a
pressure washer.
 Be careful when sorting items with sharp pointed ends and posi-
tioning them in the dishwasher so that you do not hurt yourself or
create a danger for others. Cutlery should be placed in baskets in
such a way that no injuries can occur.
 Arrange sharp and pointy utensils so that they cannot damage the
door seal.
 Remove any coarse food deposits from the items being cleaned
before loading them in the dishwasher.
Children in the vicinity
 Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the dishwasher. There is a danger
that children might shut themselves in the dishwasher.
 Children must be kept away from the dishwasher unless they are
constantly supervised.
 Children aged eight and older may only use the dishwasher with-
out supervision if they have been shown how to use it in a safe man-
ner. Children must be able to recognize and understand the potential
risks of improper use.
 If the automatic door opening mechanism is active, keep young
children away from the area in which the door opens. There is a dan-
ger of injury in the unlikely event of a fault with the opening mecha-
nism.

IMPORTANT SAFETY INSTRUCTIONS
16
 Keep children away from process chemicals. These contain ingre-
dients which can cause burning in the mouth or throat, or inhibit
breathing. Keep children away from the dishwasher when the door is
open. There could still be residual process chemicals in the dish-
washer. Seek medical advice immediately if a child has swallowed or
inhaled any process chemicals.
Accessories
 Accessories may only be fitted if approved by Miele. If other parts
are used, any warranty and product liability claims shall be void.
Transport
 Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
 If you wish to transport the dishwasher, empty it and securely fas-
ten all loose parts such as baskets, hoses, and cords.
After use
 Remove the door to the washing compartment when removing an
old dishwasher from service or discarding it.
Miele cannot be held liable for damage caused by failure to com-
ply with these IMPORTANT SAFETY INSTRUCTIONS.
STORING THE INSTRUCTIONS

Machine description
17
Appliance overview
aTop spray arm
bUpper basket (depending on model)
cMiddle spray arm
dAeration valve
eBottom spray arm
fFilter combination
gSalt reservoir
hData plate
iRinse aid reservoir
jDetergent compartment

Machine description
18
Control field
aProgram selection
= Short
= Universal
= Intensive
= Plastics
= Glasses
= SaniWash
= Cold pre-rinse
= Economy
bDisplay
For further information, see “Display
functions” under “Guide to the appli-
ance”.
cOptions
= Time left
= Temperature
= Additional drying
= Settings
dStartsensor button
For starting the selected program.
eTimer sensor button
For selecting a later program start.
fOK sensor button
To select menu options and values
displayed.
To confirm messages.
gSensor buttons
For program selection.
For changing the values displayed.
For scrolling to other menu pages.
hBacksensor button
For navigating back to the previous
menu or deleting previously set val-
ues.
iRemote startsensor button
For activating/deactivating the Re-
mote start option.
jOptical interface
For Customer Service.
kOn/Offsensor button
For turning the dishwasher on and
off.

Machine description
19
Display functions
The display is used to select or set the
following:
- the program
- the timer
- the Settings 
The display can show the following:
- the program stage
- the estimated time left for the pro-
gram to run
- the current temperature of the pro-
gram stage
- the water consumption
- any relevant fault messages and in-
formation
To save energy, the dishwasher turns
off after a few minutes if you do not
press any sensor buttons during this
time.
Touch the sensor button to turn the
dishwasher back on.
The OKsensor button is used to con-
firm a message or setting and also to
move to the next menu or another level.
Under Settings, a scroll bar will ap-
pear in the right of the display. This of-
fers additional options. These options
can be shown using the sensor
buttons.
You can alter the dishwasher’s controls
to suit changing requirements in the
Settings menu (see “Settings”).
The option which is selected will have a
check next to it.
To exit a submenu again, use the
Backsensor button.
If you do not press any sensor buttons
for several seconds, the display will re-
vert to the previous menu. You will then
have to enter your settings again.

Caring for the environment
20
Disposal of the packing mate-
rial
The cardboard box and packing materi-
als protect the appliance during ship-
ping. They have been designed to be
biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children. Dan-
ger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these mate-
rials improperly by disposing of them in
your household waste can be harmful to
your health and the environment. There-
fore, please do not dispose of your old
appliance with regular household waste
and follow local regulations on proper
disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please en-
sure that your old appliance is kept
away from children until removal. Ob-
serve safety requirements for appli-
ances that may tip over or pose an en-
trapment hazard.
