Miele PDR 908 HP EL User manual

Operating and Installation
Instructions
Heat-Pump Dryer
Always read the operating instructions before setting up, installing,
and commissioning the appliance. This prevents both personal injury
and damage to the appliance.
en-US M.-Nr. 12 125 300

Contents
2
Caring for the environment ............................................................................. 8
IMPORTANT SAFETY INSTRUCTIONS ............................................................ 9
Operating the tumble dryer .............................................................................. 17
Control panel....................................................................................................... 17
Sensor controls and touch display with sensor controls .................................... 18
Main menu........................................................................................................... 18
Examples of how to operate the appliance......................................................... 19
Operating a laundromat machine........................................................................ 21
Initial commissioning ........................................................................................ 23
Switching on the tumble dryer ............................................................................ 23
Reference to external appliances........................................................................ 24
Setting the display brightness............................................................................. 24
Setting the date................................................................................................... 24
Selecting program packages .............................................................................. 25
Completing the commissioning process............................................................. 27
1. Notes on correct laundry care ..................................................................... 28
Washing............................................................................................................... 28
Drying .................................................................................................................. 28
Understanding the care-label symbols ............................................................... 28
2. Loading the tumble dryer ............................................................................. 29
Checking the socket for the fragrance flacon ................................................ 29
3. Selecting a program...................................................................................... 30
Switching on the tumble dryer ............................................................................ 30
Selecting a program ............................................................................................ 30
4. Selecting program settings .......................................................................... 31
Main menu for a program.................................................................................... 31
Selecting the drying level ............................................................................... 31
Selecting the duration (timed programs) ....................................................... 31
Selecting extra options........................................................................................ 32
Gentle ............................................................................................................. 32
Anti-crease ..................................................................................................... 32
5. Starting a program ........................................................................................ 33

Contents
3
6. End of program – removing the laundry...................................................... 34
End of program.................................................................................................... 34
Removing the laundry ......................................................................................... 34
Observing the care notes .................................................................................... 34
Timer................................................................................................................... 35
Program chart.................................................................................................... 36
Label.................................................................................................................... 36
Program packages .............................................................................................. 37
Standard.............................................................................................................. 37
Sport.................................................................................................................... 41
Soft furnishings ................................................................................................... 42
Hygiene ............................................................................................................... 43
WetCare............................................................................................................... 44
Flatwork............................................................................................................... 44
Special programs ................................................................................................ 45
Changing the program sequence .................................................................... 46
Changing a program once it has started............................................................. 46
Canceling a program ........................................................................................... 46
Reselecting a canceled program.................................................................... 46
Adding laundry .................................................................................................... 46
Fragrance flacon................................................................................................ 47
Inserting a fragrance flacon................................................................................. 47
Opening the fragrance flacon.............................................................................. 49
Closing the fragrance flacon ............................................................................... 49
Removing/replacing the fragrance flacon ........................................................... 50

Contents
4
Cleaning and care ............................................................................................. 51
When to clean ..................................................................................................... 51
1. Cleaning the lint filters................................................................................ 51
2. Cleaning the toe-kick filter ......................................................................... 52
3. Cleaning the bottom-right grille/heat exchanger for heat dissipation........ 53
Cleaning the lint filters......................................................................................... 54
Removing the fragrance flacon ...................................................................... 54
Removing visible lint....................................................................................... 54
Cleaning the lint filters and air-flow openings thoroughly .............................. 55
Cleaning the toe-kick filter .................................................................................. 57
Removing the lint filter.................................................................................... 57
Cleaning the lint filter with water .................................................................... 58
Replacing the toe-kick filter............................................................................ 58
Cleaning the filter insert (in the toe-kick)............................................................. 60
Removing the filter insert ............................................................................... 60
Checking the cooling fins on the heat exchanger .......................................... 61
Reinstalling the filter insert (in the toe-kick) ................................................... 62
Reinstalling the lint filter (in the toe-kick)............................................................. 62
Cleaning and closing the lint-filter flap................................................................ 63
Cleaning the bottom-right grille/heat exchanger................................................. 64
Removing the grille......................................................................................... 64
Cleaning the cooling fins................................................................................ 65
Replacing the grille......................................................................................... 65
Cleaning the tumble dryer ................................................................................... 66
Frequently Asked Questions ............................................................................ 67
Program cancellation and fault message in the display...................................... 67
Messages in the display...................................................................................... 70
Unsatisfactory drying results............................................................................... 72
The drying-cycle duration is very long ................................................................ 73
General problems with the tumble dryer ............................................................. 74
Reactivating the plinth filter................................................................................. 75
Customer Service.............................................................................................. 76
Contact in the event of a fault ............................................................................. 76
Optional accessories........................................................................................... 76

Contents
5
IMPORTANT SAFETY INSTRUCTIONS ............................................................ 78
Installation and connection .............................................................................. 80
Front view............................................................................................................ 80
Rear view............................................................................................................. 81
Installation locations............................................................................................ 82
Side view ........................................................................................................ 82
Steel toe-kick ................................................................................................. 82
View from above............................................................................................. 82
Washer-dryer stack ........................................................................................ 83
Transporting the tumble dryer to its installation site ........................................... 84
Installation ........................................................................................................... 85
Downtime after installation............................................................................. 85
Leveling the tumble dryer............................................................................... 85
Room ventilation ............................................................................................ 86
External control equipment ............................................................................ 86
Drain hose for condensed water ......................................................................... 87
Inserting the drain hose into a standpipe ....................................................... 87
Electrical connection ........................................................................................... 88
Technical data.................................................................................................... 89

Contents
6
Supervisor level ................................................................................................. 90
Opening the supervisor level............................................................................... 90
Access via code .................................................................................................. 90
Change code....................................................................................................... 90
Demo program .................................................................................................... 90
Closing the settings menu................................................................................... 90
Controls / Display................................................................................................ 90
Language........................................................................................................ 90
Language entry .............................................................................................. 91
Set languages................................................................................................. 91
Display brightness.......................................................................................... 91
Clock display.................................................................................................. 92
Date ................................................................................................................ 92
Volume............................................................................................................ 92
Res. moisture display..................................................................................... 92
Visibility parameters ....................................................................................... 92
Display off status............................................................................................ 93
Machine off status.......................................................................................... 93
Delay start ...................................................................................................... 93
Memory .......................................................................................................... 94
Temperature unit............................................................................................. 94
Weight unit ..................................................................................................... 94
Logo ............................................................................................................... 94
Supervisor code ............................................................................................. 94
Program selection ............................................................................................... 95
Controls.......................................................................................................... 95
Program packages ......................................................................................... 96
Favorite programs .......................................................................................... 97
Special programs ........................................................................................... 99
Sort programs ................................................................................................ 100
Program color allocation ................................................................................ 100
Process technology............................................................................................. 101
Anti-crease ..................................................................................................... 101
Drying levels ................................................................................................... 101
Service................................................................................................................. 101
Clean out the airways..................................................................................... 101
Service interval ............................................................................................... 102

Contents
7
External applications ........................................................................................... 103
Peak load signal ............................................................................................. 103
Peak load prevention...................................................................................... 103
Select KOM module ....................................................................................... 103
Availability of Miele digital products............................................................... 103
WiFi / LAN ...................................................................................................... 104
Network time .................................................................................................. 105
Remote ........................................................................................................... 105
Remote Update .............................................................................................. 106
SmartGrid ....................................................................................................... 106
Machine parameters............................................................................................ 107
Legal Information............................................................................................ 107
Payment system.................................................................................................. 107
Setting for payment systems ......................................................................... 107
Feedback sig. to pay system.......................................................................... 108
Payment system lock ..................................................................................... 108
Clear paid signal............................................................................................. 108
Debounce time ............................................................................................... 109
Pay system override time ............................................................................... 109
Duration Cool air ............................................................................................ 109
Duration Warm air........................................................................................... 109
FOC programs................................................................................................ 109

Caring for the environment
8
Disposal of the packing
material
The cardboard box and packing
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these
materials improperly by disposing of
them in your household waste can be
harmful to your health and the
environment. Therefore, please do not
dispose of your old appliance with
regular household waste and follow
local regulations on proper disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.

IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the
following:
 It is essential to read all instructions before using the appliance.
 Do not allow children to play on or in the appliance. Close
supervision is necessary when the appliance is used near children.
Always close the door after use to prevent child hazards.
 Before this appliance is removed for service or discarded, remove
the door to the drying compartment.
 Do not install or use a dryer with visible damage.
 Do not reach into the dryer if the drum is moving.
 Do not install or store this appliance where it will be exposed to
the weather.
 Do not tamper with the controls.
 Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in these operating
instructions. Repairs to electrical appliances should only be
performed by qualified personnel. Incorrectly repaired machines may
pose a considerable risk to the user.
9

IMPORTANT SAFETY INSTRUCTIONS
 Important information regarding use of fabric softener sheets:
We do not recommend use of fabric softener sheets. Use of fabric
softener sheets can clog the surfaces of the lint filters, extending the
drying time and increasing energy consumption. During subsequent
cleaning, the plastic and surfaces of the lint filters can be damaged!
The best results are obtained by using liquid fabric softener in the
washing machine. Follow the manufacturer's instructions.
If you still wish to use fabric softener sheets, be sure to follow the
cleaning instructions under “Cleaning and care” in the “Cleaning
instructions when using fabric softener sheets” section.
Tip:
Using a fragrance capsule (optional accessory) will add a pleasant
fragrance to your laundry.
When a fragrance capsule is used, the fragrance is acquired by the
entire load of laundry. The disadvantage of fabric softener sheets is
that under certain circumstances the fragrance is acquired by only a
few items of laundry, especially when drying a full load.
When you use a fragrance capsule, always follow the
warnings in this section as well as those under “Fragrance
capsule”.
10

IMPORTANT SAFETY INSTRUCTIONS
 To prevent the risk of fire, the following textiles must not be dried
in this dryer:
- items which have not been washed.
- items, such as work-wear, exposed to grease, oils, or other
deposits (such as lotions or cosmetics) in your dryer. If these
items have not been thoroughly cleaned there is a danger that
they may contribute to a chemical reaction that could cause the
laundry to ignite when heated even after being removed from the
dryer.
- items that have been previously cleaned, washed, soaked or
spotted with gasoline, dry-cleaning solvents or other flammable
or explosive substances. They may give off vapors that could
ignite or explode.
- items treated with flammable cleaning agents or items containing
acetone, alcohol, gas, stain remover, wax or chemicals from
buffing, etc.
- items which have been splashed with hair spray, nail polish
remover, etc.
When washing heavily soiled items ensure that sufficient
detergent is used with a high temperature. If in doubt wash the
item several times.
- items containing foam rubber or similarly textured rubber-like
materials.
- items with padding or filling (e.g. pillows or jackets) which have
been damaged. Loose filling could catch fire.
11

IMPORTANT SAFETY INSTRUCTIONS
 Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch fire. To reduce the risk of
fire due to contaminated loads, the final part of a tumble dryer cycle
occurs without heat (cool down period). Avoid stopping a tumble
dryer before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
 Allow the dryer to complete each stage of the program selected,
including the cooling down phase. This will ensure that the items
being removed are not too hot to handle.
 Clean the lint filter before or after each load.
 Keep the area around the air intake (toe kick) and adjacent
surrounding areas free from lint, dust and dirt.
 The interior of the machine should be cleaned periodically by
qualified personnel.
 GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
 WARNING – Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Contact a qualified
electrician if you are in doubt as to whether the appliance is properly
grounded.
12

IMPORTANT SAFETY INSTRUCTIONS
 Do not modify the plug provided with the appliance: if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
 Before installation, disconnect the tumble dryer from the electrical
supply by shutting off the power main, unplugging the power cord or
tripping the circuit breaker. Do not restore power until the installation
is complete.
 Miele Tumble Dryers and Miele Washing Machines can be
installed as a washer-dryer stack. This requires a Miele Washer-
Dryer Stacking Kit which can be purchased separately. Please
ensure that the washer-dryer stacking kit is suitable for the Miele
Tumble Dryer and the Miele Washing Machine.
 If you order a plinth for this tumble dryer (available from Miele as
an optional accessory), make sure it is the correct one.
 The maximum dry laundry weight is 17.6 lb (8 kg) kg. See the
“Program chart” for the maximum recommended loads for individual
programs.
 Do not place shoes inside the drum for drying. Placing shoes
inside the drum for drying can cause the belt to tear, requiring a
service call.
You must always use the dryer basket (optional accessory) when
drying/airing shoes. Follow the additional operating instructions for
the dryer basket.
13

IMPORTANT SAFETY INSTRUCTIONS
 This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g., temperature, moisture, chemical
resistance, abrasion resistance, and vibration). This special lamp
must only be used for the purpose for which it is intended. It is not
suitable for room lighting. Replacement lamps should only be fitted
by a Miele authorized person or by Miele Service.
 Information on the heat pump and refrigerant
- This tumble dryer uses refrigerant gas which is not flammable and
not explosive.
- The humming noises caused by the heat pump during the drying
process are normal. They do not impair the efficient functioning of
the tumble dryer.
Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer, wait for at least one hour before
switching it on.
- This tumble dryer contains fluorinated greenhouse gases.
Hermetically sealed.
Designation of refrigerant: R134a
Amount of refrigerant: 0.61kg
Global-warming potential of refrigerant: 1430kg CO2 e
Global-warming potential of appliance: 872kg CO2 e
14

IMPORTANT SAFETY INSTRUCTIONS
Using a fragrance capsule (optional accessory)
 Only use genuine Miele original fragrance capsules.
 Store the fragrance capsule in its original packaging.
 Make sure that you always keep the fragrance flacon or the lint
filter with the flacon inserted in it in a horizontal position when
carrying, and do not tip or place it down on any surface. The
fragrance can leak out of the flacon.
 Use an absorbent cloth to wipe up any fragrance which has
leaked out of the capsule onto the floor, the dryer or any dryer
components (e.g. the lint filter) immediately.
 If fragrance comes in contact with the body: Wash skin thoroughly
with soap and water. Flush eyes with clean water for at least
15minutes. If swallowed, rinse mouth thoroughly with clean water.
Seek medical attention if the fragrance comes in contact with the
eyes or is swallowed!
 Immediately change clothes that have come in contact with the
fragrance. Thoroughly wash clothing or fabric using a large amount
of water and detergent.
 There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
- Never refill a capsule with fragrance or any other substance.
- Never use a faulty fragrance capsule.
 Dispose of an empty fragrance capsule properly and never use it
for any other purpose.
 Please also observe the information supplied with the fragrance
capsule.
15

IMPORTANT SAFETY INSTRUCTIONS
FCC Declaration of Conformity
 This appliance complies with Part 15 of the FCC regulations. This
appliance has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules and is
subject to the following conditions: This appliance does not cause
harmful interference. The appliances may be interconnected as
desired.
FCC Radiation Exposure Statement
 This appliance complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. These appliances should be
installed and operated with a minimum distance of 8" (20cm)
between the radiator and body.
Industry Canada Statement
 This digital device does not exceed the Class B limits for radio
noise emissions from digital devices specified in the radio
regulations of the Canadian Radio-television and
Telecommunications Commission. This appliance complies with the
Class B specification of the Canadian ICES-003.
SAVE THESE INSTRUCTIONS
16

Operating the tumble dryer
17
Control panel
aLanguage sensor control
For selecting the current user
language.
The operating language is displayed
again at the end of the program.
bBack sensor control
Takes you back one level in a menu.
cTouch display
dSensor control Start/Stop
For starting the selected drying
program and canceling a program
once it has started. The program
selected can be started as soon as
the sensor control starts flashing.
eOptical interface
For Technical Service.
fButton
For switching the tumble dryer on
and off. The tumble dryer switches
off automatically to save energy. This
occurs 15minutes after the end of
the program/anti-crease phase, or
after being switched on if no further
selection is made.

Operating the tumble dryer
18
Sensor controls and touch
display with sensor controls
The,, andStart/Stopsensor
controls and the sensor controls in the
display react to finger-tip contact. Every
touch of a sensor control is confirmed
with an audible keypad tone. You can
adjust the volume of the keypad tone or
switch it off (see “Supervisor level”).
The control panel with sensor
controls and the touch display can
be scratched by pointed or sharp
objects, e.g., pens.
Only touch the display with your
fingers.
Main menu
After switching on the tumble dryer, the
main menu will appear in the display.
You can access all the important sub-
menus from the main menu.
Touch the sensor control at any
time to return to the main menu.
Values set previously are not saved.
 11:02
  
Programs Favorites Supervisor
Help

Programs
For selecting drying programs.
Favorites
For selecting one of 12 favorite drying
programs which can be set up and
saved by the supervisor (see “Favorite
programs” under “Supervisor level”).
Supervisor
You can alter the tumble dryer's
electronic to suit changing requirements
in the supervisor level (see “Supervisor
level”).
Networking
If the tumble dryer is networked, the
symbol indicates the signal strength
of the network (SSID) to which is it
connected. Touch the symbol to display
the name of the network.
Help
You can display help to assist you with
the operation of the tumble dryer.

Operating the tumble dryer
19
Examples of how to operate
the appliance
Option lists
Program menu (single-option list)
 11:02
ShirtsCottons Express
DenimDelicates
Programs
Minimum iron
You can scroll to the right or the left by
swiping your finger across the screen.
To do this, place your finger on the
touch display and swipe it in the
direction you want.
The orange bar under the pictures
shows that there are further options to
choose from.
Touch a program name to select the
drying program.
The display will change to the standard
menu for that program.
Options menu (multiple selection)
 11:02
Gentle tumble
Anti-crease


Extras
OK
Touch one or several Options to select
it/them.
Currently selected Options are
highlighted in orange.
To deselect an Option, simply touch the
Option again.
Use the OKsensor control to activate all
selected Options.
Setting numerical values
You can set numerical values in some
menus.
OK
12 00
11 59
10 58
13 01
14 02
Clock display




Enter the numbers by swiping upward
or downward. Place your finger on the
number that you want to change and
move your finger in the direction you
want. Use the OKsensor control to
accept the set numerical value.

Operating the tumble dryer
20
Tip: For some settings, depending on
the value range and increments, the
value can also be set using a numerical
keypad. Briefly touching the numbers
will bring up the numerical keypad.
Once a valid number has been entered,
the OKsensor control will be
highlighted in green.
OK
12 00
11 59
10 58
13 01
14 02
Clock display

Briefly touch a number between the
two lines.
The numerical keypad will appear.
OK
12:00
3
4
21
Clock display
5 6
7

8
0
9
Touch the numbers and confirm with
OK.
Pull-down menu
The pull-down menu can be used to
display information, e.g., about a drying
program.
 11:02

Cottons
Status
Time left h2:27
Drying


If an orange bar appears at the top of
the screen in the middle of the display,
you can open the pull-down menu.
Touch the bar and drag down with your
finger.
Exiting a menu
Tap the sensor control to return to
the previous screen.
Entries made before this which have not
been confirmed withOK will not be
saved.
Help display
With some menus, Help appears along
the bottom line of the display.
Touch the Helpsensor control to
display the text.
Touch the Closesensor control to
return to the previous screen.
