Miele T 8322 User manual

Operating instructions
for vented tumble dryer
T 8322
To avoid the risk of accidents
or damage to the appliance
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 127 330
en-GB

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings, bags
etc. are disposed of safely and kept out
of the reach of babies and young
children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if handled
or disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your appliance. Please
do not therefore dispose of your
appliance with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your Dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
–Load according to the optimum
amount of laundry recommended for
the programme being used (see
"Programme chart").
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– Make sure the fluff filter is clean
before using the dryer.
– Check all parts of the ventilation
system on a regular basis and
remove any build up of fluff etc.
–The vent ducting should be as short,
straight and smooth as possible to
minimise any resistance to the air
throughflow.
This helps to reduce running times
and energy consumption levels.
Caring for the environment
2

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating the tumble dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control panel .....................................................10
Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Care symbols .....................................................12
Tips on drying ....................................................12
How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Brief instructions ..................................................13
Extra options / Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Low temperature ..................................................16
Buzzer ..........................................................16
Delay start .......................................................16
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Once a programme has started.......................................20
- changing the programme ........................................20
- cancelling the programme and then selecting a different programme .....20
- cancelling the programme and then removing the laundry ..............20
Adding or removing laundry after a programme has started.................20
Time remaining ...................................................20
Electronic system lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cleaning the fluff filter ..............................................22
Cleaning the grilles in the door opening ................................23
Cleaning the tumble dryer ...........................................23
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Check and fault messages ..........................................24
Other problems ...................................................26
Changing the lamp ................................................29
After Sales service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Future updates (PC)................................................30
Appliance guarantee ...............................................30
Optional accessories ...............................................30
Contents
3

Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Frontview........................................................31
Rearview........................................................32
Installation site ....................................................32
Transporting the appliance to its installation site .......................32
Building under a continous worktop / in a kitchen run ...................32
Levelling the appliance...........................................33
Washer-dryer stack ..............................................33
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Electrical connection U.K. ...........................................34
Installation - venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
General .........................................................35
Calculating the effective duct length : ..................................36
Installation to the rear, left or right side of the appliance ....................37
Venting systems ...................................................38
aFlexible ducting hose ............................................38
bPlastic piping...................................................40
cConnect directly to a wall vent .....................................41
Washer-dryer stack ................................................42
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Extending the range of the drying levels ................................46
Altering the volume of the buzzer .....................................47
Memory function ..................................................48
Extending the cooling down time......................................49
Clean out airways indicator ..........................................50
Keypad tone......................................................51
Adjusting the dryer's electronics for very soft water .......................52
Contents
4

~It is essential to read these
instructions.
This tumble dryer conforms to
current safety requirements.
Inappropriate use can, however, lead
to personal injury and damage to
property.
To avoid the risk of accidents and
damage to the tumble dryer, please
read these instructions carefully
before using it for the first time. They
contain important information on its
safety, installation, use and
maintenance.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner.
Correct application
~This tumble dryer is only intended
for drying fabrics which have been
washed in a water solution, and marked
on the manufacturer's care label as
being suitable for tumble drying.
"Dry cleaning kits" for freshening up
garments in a tumble dryer are
increasingly available on the market. If
using, do so at your own risk, and follow
the instructions provided on the
packaging.
Any other applications may be
dangerous. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation.
~This appliance is not intended for
use by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience or
knowledge, unless they are supervised
whilst using it or have been shown how
to use it by a person responsible for
their safety.
Safety with children
~Keep children away from the tumble
dryer at all times. It is not a toy! To avoid
the risk of injury do not allow them to
play on or near it or to play with its
controls. Supervise children whilst you
are using it.
~Older children may only use it if its
operation has been clearly explained to
them, and they are able to use it safely,
recognising the dangers of incorrect
use.
Warning and Safety instructions
5

Technical safety
~Before setting up the tumble dryer,
check it for any externally visible
damage.
Do not install or use a damaged tumble
dryer.
~Before connecting the tumble dryer,
ensure that the connection data on the
data plate (voltage and connected
load) match the mains electricity
supply. If in any doubt, consult a
qualified electrician.
~The electrical safety of this tumble
dryer can only be guaranteed when
continuity is complete between it and
an effective earthing system which
complies with current local and national
safety regulations. It is most important
that this basic safety requirement is
present and regularly tested, and where
there is any doubt the household wiring
system should be inspected by a
qualified electrician. Miele cannot be
held liable for the consequences of an
inadequate earthing system (e.g.
electric shock).
~Do not connect the tumble dryer to
the mains electricity supply by an
extension lead. Extension leads do not
guarantee the required safety of the
tumble dryer (e.g. danger of
overheating).
~Unauthorised repairs could result in
unforeseen dangers for the user, for
which Miele cannot accept liability.
Repairs should only be undertaken by a
Miele approved service technician.
Ensure current is not supplied to the
tumble dryer until after maintenance or
repair work has been carried out.
~Faulty components must only be
replaced by genuine Miele original
spare parts. Only when these parts are
fitted can the safety standards of the
tumble dryer be guaranteed.
~If the connection cable is faulty it
must only be replaced by a Miele
approved service technician to protect
the user from danger.
~In the event of a fault or for cleaning
purposes, the tumble dryer is only
completely isolated from the electricity
supply when:
– it is switched off at the wall socket
and the plug is withdrawn, or
– it is switched off at the mains, or
– the mains fuse is disconnected, or
the screw-out fuse is removed (in
countries where this is applicable).
~This tumble dryer may only be used
in mobile installations such as ships if a
risk assessment of the installation has
been carried out by a suitably qualified
engineer.
~In countries where there are areas
which may be subject to infestation by
cockroaches or other vermin, pay
particular attention to keeping the
tumble dryer and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the guarantee.
~Do not make any alterations to the
tumble dryer, unless authorised to do
so by Miele.
Warning and Safety instructions
6

Correct use
~To prevent the risk of fire, the
following textiles must not be dried in
this tumble dryer:
–items which have not been washed.
–items, such as workwear, which have
not been thoroughly cleaned and
which are still soiled with grease, oil
or other desposits (such as
cosmetics, lotions etc).
If items have not been thoroughly
cleaned there is a danger that these
might ignite when heated, even after
they have been removed from the
dryer at the end of the programme.
– items which have been treated with
inflamable cleaning agents or
contain residues of acetone, alcohol,
benzine, petrol, stain remover,
turpentine, wax, wax remover or other
chemicals (e.g. mops and floor
cloths).
– items which have been splashed with
hair lacquer, hair spray, nail varnish
remover or similar substances.
When washing such heavily soiled
items ensure that you use sufficient
detergent and select a high
temperature. If in doubt, wash the
items several times.
~To prevent the risk of fire, the
following must not be dried in this
tumble dryer:
–fabrics which contain a large
proportion of rubber, foam rubber or
rubber-like materials. For example,
products made from latex foam
rubber, shower caps, waterproof
textiles, rubberised articles and items
of clothing and pillows with foam
rubber filling.
–items which contain padding or
fillings (e.g. pillows, jackets). If these
were damaged the filling could get
out with the risk of igniting in the
dryer.
~In many programmes, the heating
phase is followed by a cooling down
phase to ensure that the items are not
too hot to handle when you remove
them (this also avoids the danger of the
laundry self-igniting). The programme is
not finished until the cooling down
phase is complete.
Ensure that you always wait until the
end of the programme before removing
the laundry.
~Warning: Do not switch the tumble
dryer off before the end of the drying
programme. If this was done and the
laundry was then removed immediately,
it could give off a great amount of heat.
~Fabric conditioner and similar
products must be used according to
the instructions on the manufacturer's
packaging.
Warning and Safety instructions
7

~The dryer must not be used without
the fluff filter in place or if the fluff filter is
damaged in any way.
~The fluff filter must be cleaned
regularly.
~The tumble dryer must not be used
without vent ducting in place.
~The tumble dryer must not be
connected to a chimney or vent flue
which is in use.
~Do not install the tumble dryer in a
room where there is a risk of frost
occurring. At temperatures around
freezing point the tumble dryer may not
be able to operate properly.
The ambient room temperature should
be between +2°C and +35°C
~Check all parts of the extraction
system on a regular basis (e.g. wall
vent, external grille, bends in the
ducting etc.) and make sure they are all
free of any hindrance. A build-up of fluff
will prevent a free flow of air through the
system. If the dryer is to be connected
to an existing ducting system, this must
be checked for suitability beforehand.
~The exhaust air must not be vented
into a chimney or vent flue which is in
use, nor should it be connected to
ducting which ventilates rooms with
fireplaces. It would be dangerous if
smoke or exhaust fumes were drawn
back into the room.
~Adequate ventilation is essential to
avoid the danger of asphyxia and
toxic fumes where another appliance
which also uses the room air (e.g. gas,
oil or coal fired heater, continuous flow
or other water heater) is installed in the
same or an adjacent room.
To ensure safe operation, and to
prevent gases given off by these
appliances being drawn back into the
room, an underpressure of 0.04 mbar is
the maximum permissible.
Ventilation can be maintained by:
–air inlets in the external wall which
cannot be closed or blocked, or
– by fitting a window contact switch
which ensures that the tumble dryer
can only be operated when the
window is opened wide enough.
If in doubt, the advice of a competent
builder must be sought.
~The room in which the dryer is
installed must be clean and free of dust
and fluff.
Particles of dirt entering the dryer can
lead to blockages occurring.
Warning and Safety instructions
8

~Do not let anyone sit or lean on the
door, as this can cause the tumble
dryer to tip up.
~Always close the door after use. This
way you will avoid the danger of:
–children climbing onto or into the
dryer or hiding things in it.
–pets or other small animals climbing
into it.
~The tumble dryer must not be hosed
down.
Accessories
~Only use genuine Miele spare parts
and accessories with this appliance.
If non-Miele parts are used, guarantee,
performance and product liability
claims may be invalidated.
Miele cannot be held liable for
damage caused by non-compliance
with these Warning and Safety
instructions.
Warning and Safety instructions
9

Control panel
aLow temperature button
Delicate fabrics are dried at a lower
temperature.
bDrying level button
with indicator lights
cDisplay
dDelay start button
This button is used for:
- Selecting the duration of the
Timed drying programmes
- Delaying the start of a programme
eBuzzer button
An audible tone sounds at the end of
the programme.
fCheck lights
For a description of these lights see:
"Problem solving guide" / "After sales
service".
gStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
The indicator light flashes while a
programme is being selected and
then is on constantly when the
programme has started.
hProgramme selector
with indicator lights
iDoor button
Pressing this button will open the
door even when the dryer is switched
off at the mains.
jI-On/0-Off button
For switching the dryer on and off.
Operating the tumble dryer
10

Display
The following are selected via the
display:
–Delay start
–Duration of the Cool air and Warm air
programmes
–Programmable functions
The display also shows:
–Programme duration
–Programme stage
Drying
Cooling down
Finish
– Check and fault messages
Programme duration / Estimated time
remaining
When a programme is selected, the
estimated duration (time remaining) will
appear in the display. Please be aware
that it is only an estimate!
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the dryer and adjust the
estimated time remaining for a more
accurate reading. Because of this, the
time displayed can alter during the
course of a programme.
In the same way, the Woollens
handcare, Silks handcare and
Smoothing programmes can finish
earlier than expected if a certain
temperature is reached. This can
happen with particularly fine fabrics,
very small loads or if items were partly
dry beforehand.
Delay start
The delay start time selected will
appear in the display.
After the Start/Stop button has been
pressed, the delay start time will start
counting down.
Once the delay start time has elapsed,
the programme will begin and the
estimated programme duration will
appear in the display.
Programmable functions
The programmable functions can be
used to tailor drying programmes to suit
your individual requirements. In
programming mode, the display will
show the function selected.
Operating the tumble dryer
11

Care symbols
Before drying check the drying symbol
on the care label. If there are no
symbols, dry at your own risk!
q.........Dryatnormaltemperature
r............Dryatlowtemperature
s...............Donottumble dry
Tips on drying
–Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– Do not put soaking wet items into the
tumble dryer. Spin them thoroughly
after washing using the appropriate
spin speed.
–For delicates and fabrics with the
following care label rselect Low
temperature.
–Use the Automatic programme for
drying mixed loads of cottons and
minimum iron fabrics.
–Open jackets so that they can dry
evenly.
–Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. They can, however,
be partially dried using the Woollens
handcare programme.
–Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough. They can
be partially dried using the
Smoothing programme.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not over-dry these
textiles. When purchasing these
garments it is advisable to take their
shrinkage properties into account.
– For garments made from very fine
weave fibres, such as shirts or
blouses, only use the Shirts or
Delicates programme to avoid
creasing. If in doubt, reduce the load
or use the Smoothing programme.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed and dried separately from
light coloured garments to avoid the
danger of colours running and
discolouring other garments or even
plastic components in the appliance.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
Notes on laundry care
12

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
dryer.
ASort the laundry
To ensure an even drying result
separate out the washed laundry and
sort it according to:
. . . the drying level required
. . . the type of fibre or weave
. . . size
. . . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow cases
to prevent small items from being
trapped inside them.
–Fasten hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
I-On/0-Off button in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
CLoad the tumble dryer
^Press the Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for recommended
loads for each programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door make sure
the fluff filter is correctly positioned.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
13

DSelect a programme
^Select the programme you want.
The indicator lamp for the programme
selected will light up.
A drying level or extra option indicator
light may also light up, and the duration
may also be displayed.
Cottons, Minimum iron, Delicates,
Automatic, Shirts, Denim and
Outerwear programmes
^Press the Drying level button
repeatedly until the indicator light for
the drying level you want lights up.
Any of the drying levels can be
selected for the Cottons programme. A
more limited range is available when
using other programmes.
Important: Please note that the
programme duration shown in the
display will vary according to the
programme selected (see "Programme
duration/Estimated time remaining").
The Woollens handcare, Silks handcare
and the Smoothing programmes cannot
be changed.
Timed drying programmes
The indicator light for the Delay start
button will flash when the Cool air or
Warm air programme is selected.
^Press the Delay start button
repeatedly until the required duration
shows in the display.
You can select a duration of 20 minutes
up to 2:00 hours in 10 minute steps.
ESelect any Extra options / Delay
start
^Low temperature, buzzer and delay
start are selected by pressing the
appropriate button (see "Extra options
/ Delay start").
Anti-crease (see next page) is
permanently switched on.
N.B.: It is not possible to select Delay
start when using the Warm air or Cool
air programme.
How to dry correctly
14

FStart the programme
The Start/Stop button will flash when a
programme is being selected. The
flashing indicates that a programme
can be started.
^Press the Start/Stop button.
The Start/Stop button will now light up
constantly.
Drying will appear in the display and
the time remaining will start counting
down.
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence (Cooling
down will appear in the display). The
programme will not finish until the
cooling down phase has been
completed.
There is no cooling down phase at the
end of the Woollens handcare, Silks
handcare and Smoothing programmes.
GRemove the laundry when the
programme has finished
0and Finish will appear in the display
to indicate that the programme has
finished. The buzzer (if selected) will
sound at intervals.
The drum will continue to rotate at
intervals for up to an hour to prevent
laundry creasing, if you do not wish to
remove it immediately (anti-crease).
There is no anti-crease phase at the
end of the Woollens handcare or Silks
handcare programmes.
^Press the Door button.
^Open the door.
^Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
If the dryer is switched on at the mains
and the door is opened, the drum
lighting will come on. It will go out a few
minutes later to save energy.
^Switch the dryer off by pressing the
l-On/0-Off button.
^After every cycle, remove the fluff
from the fluff filter in the door.
^Close the door.
How to dry correctly
15

Low temperature
For all delicate or minimum iron
fabrics with the rsymbol on the care
label (e.g. acrylic garments).
–The programme duration is longer.
–On some programmes Low
temperature is a standard part of the
programme and so cannot be
deselected.
Buzzer
A buzzer sounds (at intervals for a
maximum of 1 hr) to let you know the
programme has finished.
The buzzer will still sound if there is a
fault, even if it has been switched off.
Delay start
The start of a programme can be
delayed by 30 minutes up to 24
hours.
After selecting a programme:
^Press the Delay start button
repeatedly until the required delay
period shows in the display.
–The Delay start indicator light will
flash.
–Times of:
up to 10^ are selected in 30 minute
steps
more than 10^ in 1 hour steps
–If you keep the Delay start button
pressed in, the time will continue to
increase up to 24^.
To begin delay start
^Press the Start/Stop button.
–The Delay start indicator light will
light up constantly.
The delay start time counts down
towards the start of the programme as
follows:
–more than 10^ by the hour
–less than 10^ in minutes
The drum will turn briefly every hour to
help prevent creasing.
While the delay start time is counting
down, you can still add laundry to the
drum:
^Switch the dryer off.
^Open the door and add the laundry.
^Close the door and switch the dryer
back on again.
To cancel/alter delay start
^Press the Start/Stop button.
This cancels delay start.
^To alter the delay start time, press the
Delay start button repeatedly until the
required delay period shows in the
display.
^Press the Start/Stop button.
The altered delay start time will start
counting down from the beginning
again.
Extra options / Delay start
16

Cottons Max. load: 6 kg*
Extra dry, Normal**
Fabric type Single and multi-layered cotton fabrics such as towelling,
jerseywear, T-shirts, underwear.
Notes –Select Extra dry for multi-layered and very thick fabrics.
–Do not use Extra dry for jersey fabrics (e.g. T-shirts,
underwear), as they have a tendency to shrink.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Hand iron**, Machine iron
Fabric type Cottons or linen fabrics, e.g.: table linen, bed linen, starched
laundry.
Note –To prevent laundry from drying out it should be rolled up
until you are ready for ironing.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Minimum iron Max. load: 3 kg*
Extra dry, Normal**, Hand iron
Fabric type Minimum iron items made of cotton, synthetic or blended
fabrics, e.g.: shirts, blouses, skirts and table cloths.
Notes – Select Hand iron for delicate fabrics and to reduce
creasing even more, reduce the load to 1.5 kg*.
–In the Minimum iron programme with the Hand iron drying
level, items are dried with very little creasing, depending on
fabric type and amount of laundry.
Low temperature Also select the Low temperature option for delicate fabrics
with the rsymbol on the care label.
Delicates Max. load: 2 kg*
Normal, Hand iron
Fabric type Delicate items made of synthetic fibres, easy care cotton or
blended fabrics, e.g. shirts, blouses and appliqued garments.
Low temperature Low temperature cannot be deselected.
* Weight of dry laundry
** Note for test institutes: Use this programme without selecting Low temperature
for testing according to EN 61121 Standard.
Programme chart
17

Woollens handcare Max. load: 2 kg*
Fabric type Woollen fabrics
Note –This programme only fluffs up woollen garments.
–Fabrics are not completely dried in this programme.
Remove garments as soon as the programme has finished
and leave to finish drying at room temperature.
Low temperature Low temperature cannot be deselected.
Silks handcare Max. load: 1 kg*
Fabric type Silks, e.g. blouses and shirts.
Notes –Smooths out creasing.
–Fabrics are not completely dried in this programme.
Remove garments as soon as the programme has finished
and leave to finish drying at room temperature.
Low temperature Low temperature cannot be deselected.
Smoothing Max. load: 3 kg*
Fabric type – Cotton and linen fabrics.
– Minimum iron mixed fibre, cotton or synthetic items, e.g.:
trousers, jackets, shirts.
Notes – Smooths out creasing caused during the spin cycle in the
washing machine.
– Fabrics are not completely dried in this programme.
Remove garments as soon as the programme has finished
and leave to finish drying at room temperature.
Low temperature Low temperature cannot be deselected.
* Weight of dry laundry
Programme chart
18

Automatic Max. load: 3.5 kg*
Normal, Hand iron
Fabric type Mixed loads of garments suitable for the Cottons and
Minimum iron programmes. Sort according to colour.
Shirts Max. load: 2 kg*
Normal, Hand iron
Fabric type Shirts and blouses.
Low temperature Select the Low temperature option for delicate fabrics with the
rsymbol on the care label.
Denim Max. load: 3 kg*
Normal, Hand iron
Fabric type Denim garments, e.g. jeans, jackets, skirts, shirts.
Low temperature Select the Low temperature option for delicate fabrics with the
rsymbol on the care label.
Outerwear Max. load: 2 kg*
Normal, Hand iron
Fabric type Outerwear which is suitable for drying in a tumble dryer.
Low temperature Low temperature cannot be deselected.
Cool air Max. load: 6 kg*
Fabric type Any item which only needs airing.
Warm air Max. load: 6 kg*
Fabric type –Multi-layered fabrics whose layers have different drying
characteristics, e.g. jackets, pillows.
–For drying individual items, e.g. bath towels, bathing
costumes, tea-towels and small loads.
Note –Do not select the longest drying time to start with. Check
the items as you are drying them to find the optimum time.
Tip You can use the Warm air programme to help remove odours
from cotton clothing which has been worn but it still clean (select
a duration of between 1/2 and 1 hour). Items must be suitable
for drying in a tumble dryer. Dampen the garments a little
beforehand or add a fabric conditioner sheet. The Warm air
programme will not be as effective at removing odours from any
parts of the garments which are made of synthetic fibres.
Low temperature Select the Low temperature option for delicate fabrics with the
rsymbol on the care label.
* Weight of dry laundry
Programme chart
19

Once a programme has started
- changing the programme
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations).
You will need to cancel the current
programme before you can select a
new one.
- cancelling the programme and then
selecting a different programme
^Press the Start/Stop button.
The items will be cooled down,
depending on the temperature
reached and how long they have
been dried for.
If you press the Start/Stop button
again during the cooling down
phase, Finish will light up in the
display.
^Switch the dryer off.
^Switch the dryer on.
^Select another programme and start
it.
- cancelling the programme and then
removing the laundry
^Proceed as described in "Adding or
removing laundry after a programme
has started" below.
^Switch the dryer off after closing the
door.
Adding or removing laundry
after a programme has started
^Press the Door button.
^Open the door.
,Danger of burning:
Do not touch the back of the drum
when adding or removing items. The
drum and the items can get very hot.
^Add or remove items as required.
^Close the door.
^Press the Start/Stop button.
Time remaining
The time left shown in the display may
now vary from the actual drying time.
Changing the programme sequence
20
