Miele PT 7135 C User manual

Commissioning,
Programme chart and Settings
PT 7135 C Vario
To avoid the risk of accidents or
damage to the machine, it is
essential to read these instructions
before it is installed, commissioned
and used for the first time. M.-Nr. 09 871 180
en-GB

Commissioning the tumble dryer.....................................4
Programme chart .................................................11
Basic programmes ................................................11
Household .......................................................15
Small businesses ..................................................16
Professional cleaners...............................................18
Special programmes ...............................................19
Settings/Supervisor level menu .....................................21
To open the Settings menu ..........................................21
To open the Settings menu via the Supervisor level .......................22
Language J......................................................23
Sort languages....................................................23
Language menu...................................................23
Supervisor level ..................................................24
Favourites .......................................................24
Anti-crease.......................................................24
Buzzer ..........................................................24
Time of day ......................................................25
Display contrast ...................................................25
Display brightness .................................................25
Standby .........................................................25
Extended cool down ...............................................26
Save ............................................................26
Temperature unit ..................................................26
Drying levels .....................................................27
Cottons drying levels ............................................27
Minimum iron drying levels ........................................27
Automatic drying levels ..........................................27
Machine iron drying levels ........................................27
Clean out airways .................................................27
Clean condenser unit...............................................28
Display res. moisture ...............................................28
Delay start .......................................................28
Controls .........................................................29
Logo............................................................30
Contents
2

Target groups ....................................................30
Demo programme .................................................30
Special programmes ...............................................30
Settings which can only be changed during the commissioning process . . 33
Payment system...................................................33
Coin mechanism lock ..............................................33
Signal to pin 7 ....................................................33
T-max exceeded ..................................................34
Duration cool air...................................................34
Cool air free ......................................................34
Duration hot air ...................................................34
Supervisor level code ..............................................34
Contents
3

Before using for the first time
,Before commissioning the tumble dryer, ensure that it
is correctly installed and connected. Read the separate
Operating and installation instructions as well as this
booklet.
The commissioning process must be carried out in full to
determine the settings for daily operation.*
* Some settings can only be altered during the
commissioning process. After that, these can only be
changed by a Miele service technician.
Setting the language J
Settings
Language F
#eština
dansk
deutsch
english H
^Turn the multi-function selector to highlight the language of
your choice.
^Press the multi-function selector to confirm your choice of
language.
Use this language?
OK
H
Back A
H
^Turn the multi-function selector to select OK, and confirm
by pressing the multi-function selector.
If you wish to select a different language:
^Select and confirm back.
Commissioning the tumble dryer
4

To set the time of day
The time may already have been set at the factory. If it has,
and is correct, you can skip this section. It is possible to alter
the time at any stage via the Settings menu.
Settings
Time of day
Back A
24 h clock...
12 h clock...
Time not displayed
^Confirm either 24 h or 12 h. If you confirm Time not
displayed, the following step will be skipped.
9:00
Set the time of day
^Turn the multi-function selector to select the hour and press
it to confirm your selection.
^Then set the minutes.
^Pressing the multi-function selector again saves the time of
day in memory.
Commissioning the tumble dryer
5

Determining target groups
By selecting target groups you are determining the
programme range of the washer-disinfector. You can see
which programmes are assigned to each target group
under "Programme chart" later in this booklet.
Settings
Target groups
§Small businesses V
~Professional cleaners
~Special programmes
Confirm selection
^Use the multi-function selector to select and confirm none,
one or several of the target groups, as required.
–A target group selected will be indicated with a tick: 9.
– Mark the target group programmes that you have selected
with a cross in the box 8.
8Household
8Small businesses
8Professional cleaners
8Special programmes
The target group programmes selected will be added to the
basic programmes.
^Once you have made your selection, select Confirm
selection and press the multi-function selector to confirm
your choice.
Commissioning the tumble dryer
6

Each of these settings must now be
confirmed (and altered if required).
More details about the settings are
given at the end of this booklet.
Place a cross in the box 8to
indicate your selection, or fill in the
gaps _____ as required.
Display contrast
Can be altered in 10 graduated steps.
Step _____ (1 to 10)
Display brightness
Can be altered in 10 graduated steps.
Step _____ (1 to 10)
Payment system
Settings for coin operation.
8No coin box
All additional settings are skipped.
Continue with "Code Supervisor
level".
8Programme operation
The machine is operated using a
coin box.
8Timed operation
The machine is coin operated using
a time meter.
8RS 232
When the tumble dryer is
coin-operated, serial interface RS
232 is activated (optional
accessory).
8IK6
When the tumble dryer is
coin-operated, serial interface RS
232 is activated for IK6.
Additional settings "Payment
system/Coin box"
–Coin mechanism lock
Time in which settings can be altered
without losing coins.
8Off
8Immediately after starting
(the programme)
8_____ minute(s) after starting
(the programme)
(pto)
Commissioning the tumble dryer
7

–Signal to pin 7
Setting the feedback signal for the
coin box.
8Programme end
8Release the start button
8Start and programme end
–T-max exceeded
Setting a security time margin to
prevent the coin box being tampered
with.
8_____ minutes
–Duration cool air
This determines the maximum
programme duration in control
options WS short cut keys, ex/int time
.
8_____ minutes
– Cool air free
The programme can be started
without payment.
8On
8Off
–Duration hot air
This determines the maximum
programme duration in control
options WS short cut keys, ex/int
time.
8_____ minutes
Supervisor level code
The Settings/Supervisor level menu can
be locked with a code to prevent it
being accessed by unauthorised
personnel (the Language Jsetting can
still be altered).
^Select the option you want.
8Code not required
Only some of the settings can be
changed (temporary Language
setting, Anti-crease, Buzzer, Time of
day, Contrast, Brightness, Standby,
Extended cool down, Memory and
Temperature unit).
These settings can be changed by
any user.
8Code required
A code must be entered in order to
change the settings. All settings (see
Settings menu) can be changed.
Select this option if you want users to
only be able to change settings via a
code.
Commissioning the tumble dryer
8

To repeat the commissioning process
If you are not certain that all of the settings are correct, you
will need to repeat the commissioning process.
Set up successful
i
OK
H
Back A
H
^Select Back and confirm your selection.
To finish the commissioning process
–1. Confirm
If you are sure that all of the settings are correct.
Set up successful
i
OK
H
Back A
H
^Confirm with OK.
1 Cottons Programme selection ...
2 Minimum iron Settings F...
3 Woollens handcare
4 Smoothing 10:00
The entry menu will appear (example).
Commissioning the tumble dryer
9

–2. Start a cool air programme
To complete the commissioning process, a programme cycle
using cool air (Cool air or Timed drying cool air) needs to be
started.
If the power to the tumble dryer is switched off before the
first programme is started (e.g. by pressing the Kbutton),
the commissioning process can be repeated. The
commissioning process is only completed once the first
programme cycle (at least 20 minutes) has finished.
^Select a cool air programme and confirm your selection.
The menu for the cool air programme appears.
^Press the flashing Start button.
After this programme has finished, the tumble dryer is ready
for use.
Commissioning the tumble dryer
10
