Miele HS15 User manual

Operating instructions
Vacuum cleaner
To avoid the risk of accidents or damage to the
vacuum cleaner, it is essential to read these
instructions before using it for the first time.
These operating instructions apply to
standard models SGPA0 as well as
to special edition models which are
distinguished by names rather than numbers. M.-Nr. 10 106 590
en - AU, NZ
HS15

Caring for the environment..........................................3
Description of the appliance.........................................4
Warning and Safety instructions .....................................6
Preparing for use .................................................11
Using the accessories supplied .....................................17
Use ............................................................18
Mains cable ......................................................18
Switching on and off ...............................................18
Selecting the suction power .........................................20
Switching the ElectroBrush on and off..................................22
Interrupting operation ..............................................22
Setting down, transportation and storage.............................23
ParkSystem for pauses in vacuuming ..................................23
ParkSystem for storage .............................................24
Maintenance and care .............................................25
Purchasing new dustbags and filters ..................................25
Ordering the correct dustbags and filters ...............................25
When to change the dustbag ........................................26
Replacing the dustbag .............................................27
When to change the dust compartment filter (for motor protection) ...........28
Correctly changing the dust compartment filter ..........................28
When to change the exhaust filter .....................................29
How to change the exhaust filter ......................................29
Replacing one type of exhaust filter with another .........................31
Maintenance indicator with reset button ................................32
When to change the thread lifters .....................................33
Correctly replacing the thread lifters ...................................33
Cleaning and care ................................................34
Problem solving guide / After sales service / Warranty ..................35
Optional accessories..............................................36
Electrical connection..............................................38
Contents
2

Disposal of packing material
The packing material protects the
vacuum cleaner from transport
damage. The transport and protective
packing has been selected from
materials which are environmentally
friendly for disposal and can normally
be recycled.
Rather than just throwing these
materials away, please ensure they are
offered for recycling. Sort packing
materials for disposal according to the
type of material (e.g. plastics or
cardboard).
Disposing of the dustbag and
filters
These are made from environmentally
friendly materials, and can be disposed
of with the normal household waste, as
long as they have been used
exclusively for general household dust.
Disposing of your old vacuum
cleaner
Before disposing of your old vacuum
cleaner, remove the dustbag and filters
and dispose of them with the normal
household waste.
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your vacuum
cleaner. Please do not dispose of your
old vacuum cleaner with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre.
Ensure that your old vacuum cleaner
presents no danger to children while
being stored for disposal.
Caring for the environment
3

Description of the appliance
4

aElectro suction hose SES 131
bRelease button for accessories compartment
cDustbag change indicator
dDisplay
eFoot switch for automatic cable rewind
fParkSystem for pauses in vacuuming
gOn/Off foot control s
hMains cable
iCastors
jExhaust filter
kParkSystem for storage (on either side of vacuum cleaner)
lDust compartment filter (for motor protection)
mOriginal Miele dustbag
nCarrying handle
oElectroBrush (either SEB 217 or SEB 236, depending on model)
pRelease buttons
qDust compartment release button
rElectro telescopic wand SET 220
sElectro telescopic wand release button
tConnection socket
uDisplay for power settings
vStandby button -for pauses in vacuuming with LED
wOn/Off control jfor ElectroBrush with LED
xSuction power selector +/-
yComfort handle
zOverheating warning light §
{Standby indicator -
|Maintenance indicator with reset button
Description of the appliance
5

This vacuum cleaner complies with statutory safety requirements.
Improper use can, however, lead to personal injury and damage
to property.
To avoid the risk of accidents and damage to the vacuum
cleaner, please read these instructions carefully before using it
for the first time. They contain important information on its safety,
operation and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Always disconnect the vacuum cleaner from the mains supply
when you have finished using it, before changing over
accessories, as well as for maintenance work and cleaning.
Switch the vacuum cleaner off at the wall socket and unplug it.
Correct application
~This vacuum cleaner is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
~This vacuum cleaner can be used for all normal cleaning of
carpets, rugs and robust hard flooring.
~This appliance is not suitable for outdoor use.
~This vacuum cleaner must only be used to vacuum dry floor
surfaces. Do not use on people or animals. Any other usage,
modification or alteration is at the owner's risk and could be
dangerous.
Warning and Safety instructions
6

~This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Safety with children
~Young children must not be allowed to use this appliance.
~Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
~Cleaning of the vacuum cleaner may only be carried out by older
children under the supervision of an adult.
~Supervise children whilst you are using the vacuum cleaner. This
vacuum cleaner is not a toy! To avoid the risk of injury, do not allow
children to play with it or to use the controls.
Technical safety
~Ensure that the connection data on the data plate (voltage and
frequency) matches the mains electricity supply. This data must
correspond in order to avoid the risk of damage to the appliance.
~The wall socket must be protected against short circuit by a delay
fuse 16 A or 10 A.
~Check the vacuum cleaner, the electro suction hose, the electro
telescopic wand and the ElectroBrush for damage before using. Do
not use any part if it is damaged.
~The socket on the vacuum cleaner must only be used for Miele
ElectroBrushes specified for use with this appliance.
Warning and Safety instructions
7

~The Miele ElectroBrush is a motor driven accessory for use only
with Miele vacuum cleaners. The vacuum cleaner must not be used
with an ElectroBrush produced by another manufacturer.
~Repairs should only be carried out by a Miele authorised service
technician. Repairs and other work by unqualified persons could be
dangerous and will void the warranty. Miele cannot be held liable for
unauthorised work.
~Do not use the vacuum cleaner if the mains cable is damaged. If
the cable is damaged, it must be replaced together with a complete
cable rewind. For safety reasons, this must only be done by a Miele
authorised service technician.
~Do not pull or carry the vacuum cleaner by the cable and be
careful not to damage the cable when withdrawing the plug from the
socket.
Keep the cable away from sharp edges and do not let it be
squashed, for example, under a door.
Avoid running the vacuum cleaner over the cable.
This could damage the cable, plug or socket and pose a safety
hazard.
~When vacuuming especially fine dust, electrostatic charges build
up naturally. Under certain conditions these charges will be
released. To avoid the unpleasant effects of these discharges, a
metal inlay has been incorporated into the underside of the handle.
Please make sure that you keep your hand in constant contact with
this metal strip during vacuuming.
~Do not let the vacuum cleaner, the electro suction hose, the
electro telescopic wand or the ElectroBrush get wet. Clean all parts
with a dry or slightly damp cloth.
~The electro suction hose and the electro telescopic wand contain
electrical wires. The plug connectors must not come in contact with
water. Danger of electric shock! They should only be cleaned with a
dry cloth.
Warning and Safety instructions
8

~Repairs should only be undertaken by a service technician
authorised by Miele. Repairs and other work by unqualified persons
could be dangerous. Miele cannot be held liable for unauthorised
work.
~Caution: The vacuum cleaner handle, hose and ElectroBrush
contain electrical connections. The handle, hose and ElectroBrush
are not parts which can be serviced by the user.
~The hose should be checked regularly for signs of damage. Do
not use the hose if it is damaged.
Correct use
~To avoid the risk of injury when vacuuming with a Miele
ElectroBrush or TurboBrush, do not touch the rotating roller brush.
~Floor attachments, accessories and tubes must not be used at
head level to avoid the risk of injury, e.g. to eyes and ears.
~To avoid the risk of damage, do not use the vacuum cleaner
without the dustbag, dust compartment filter and exhaust filter in
place.
~If a dustbag is not inserted, the dust compartment cover cannot
be closed. Do not force it.
~Do not vacuum up anything which has been burning e.g.
cigarettes, ashes or coal, whether still glowing or if apparently
extinguished.
~Do not vacuum up any liquids or damp dirt. Wait until any freshly
cleaned or shampooed carpets or floor coverings are completely
dry before attempting to vacuum.
~Do not vacuum toner dust. Toner, such as that used in printers
and photocopiers, can conduct electricity.
Warning and Safety instructions
9

~Do not vacuum up any inflammable or combustible liquids or
gases and do not vacuum in areas where such substances are
stored.
Accessories
~It is not advisable to vacuum directly with the handle, i.e. without
an accessory attached, as the rim could get damaged and you
could hurt yourself on sharp edges.
~Only use genuine Miele approved dustbags, filters and
accessories. This will ensure optimum performance of the appliance
throughout its life and will guarantee the safety of the vacuum
cleaner.
Miele cannot be held liable for damage caused by incorrect use
or operation or by non-compliance with these Warning and Safety
instructions.
Warning and Safety instructions
10

Attaching the electro suction
hose
^Insert the hose connector into the
socket until it clicks into position. To
do this, line up the guides on the two
pieces.
Removing the electro suction
hose
^Press the release buttons at the side
of the hose connector, and lift the
hose from the socket.
Connecting the comfort handle
to the electro telescopic wand
^Insert the comfort handle into the
electro telescopic wand until it clicks
into position.
^To release the handle from the
telescopic wand, press the locking
button and pull the handle away from
the telescopic wand.
Preparing for use
11

Adjusting the electro
telescopic wand
The telescopic wand is made of two
parts with one part being fitted within
the other. This enables height
adjustments for comfortable vacuum
cleaning.
^Press the telescopic wand release
button (see arrow) to release the
tubes and adjust to the required
height.
Connecting the electro
telescopic wand and the
ElectroBrush
^Insert the electro telescopic wand
into the Electrobrush until it clicks into
position.
For further information on use and
maintenance, please refer to the
separate instructions supplied with the
ElectroBrush.
Preparing for use
12

Using the ElectroBrush
It is important to observe the flooring
manufacturer’s cleaning and care
instructions.
Depending on the model, your vaccum
cleaner is fitted with one of the following
ElectroBrushes.
–ElectroBrush SEB 217
–ElectroBrush SEB 236
The ElectroBrush is particularly suitable
for intensive vacuuming of carpets
which are subject to hard wear. It is
very effective at removing deep seated
dirt and preventing areas of frequent
use being trodden into a path.
,Please note that the
ElectroBrush should not be used for
vacuuming deep-pile rugs and
carpets or valuable hand-knitted
rugs and carpets, e.g. Persian and
oriental rugs etc. There is a danger
of the threads being pulled out. If in
doubt, contact the carpet
manufacturer/retailer.
,Do not use the SEB 217
ElectroBrush to clean highly variable
or uneven floors. The brush might
come into contact with the floor and
cause damage.
Preparing for use
13

Using the standard floorhead
It is important to observe the flooring
manufacturer’s cleaning and care
instructions.
This floorhead can be used for all
normal cleaning of carpets, rugs and
robust hard flooring.
Miele offer a range of other floorheads,
brushes and accessories for other
types of flooring and special
requirements (see "Optional
accessories").
Connecting the electro
telescopic wand and the
standard floorhead
^Fit the electro telescopic wand into
the standard floorhead, and turn
clockwise or anti-clockwise until they
lock together with a click.
^Press the release button to separate
the floorhead from the telescopic
wand.
Adjusting the standard
floorhead
Vacuum carpets and rugs with the
brushes retracted:
^Press the foot switch %.
Clean hard flooring which is not
susceptible to scratching, as well as
flooring with gaps or deep crevices in it
with the brushes protruding:
^Press the foot switch ).
Preparing for use
14

Activating the exhaust filter
change indicator
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the following exhaust filters:
bActive AirClean 50
cHEPA AirClean 50
^Press the release button for the dust
compartment lid and raise the lid as
far as it will go.
^Remove the information strip.
Preparing for use
15

^Press the reset button ~for the
exhaust filter change indicator.
^A narrow red strip will appear on the
left edge of the display field after
10 - 15 seconds.
^Close the dust compartment lid
securely, making sure it clicks into
position. Take care not to trap the
dustbag when doing so.
How the exhaust filter change
indicator works
The exhaust filter change indicator
shows the usage life of the exhaust fil-
ter. After approx. 50 operating hours,
which equates to average use over one
year, the red display field will be
completely red.
Preparing for use
16

aCrevice nozzle
For cleaning in folds, crevices and
corners.
bDusting brush
For cleaning skirting boards, ornate,
carved or delicate articles, etc.
The head of the dusting brush can
be swivelled to attain the best
cleaning position.
cUpholstery nozzle
For cleaning upholstery, mattresses,
cushions, curtains, covers etc.
Removing accessories
^Press the release button on the
accessories compartment lid.
The lid will open.
^Take out the accessory you require.
^Press down firmly on the
compartment lid to close it.
Floorhead
For general use and also for vacuuming
stairs.
,For safety reasons when
vacuuming stairs, it is best to start at
the bottom of the stairs and move
upwards.
Using the accessories supplied
17

Mains cable
Unwinding the cable
^Pull out the connection cable to the
required length (max. cable length
approx. 7.5 m).
^Plug the connection cable into a wall
socket and switch on at the wall.
,If vacuuming for longer than 30
minutes, the connection cable must
be pulled out to its fullest extent.
Otherwise there is a danger of
overheating.
Rewinding the cable
^Switch off at the wall socket and
remove the plug.
^Press the rewind foot control. The
cable will rewind automatically.
Switching on and off
^Step on the On/Off foot control s.
The standby indicator light -lights up
yellow, as does the LED -on the
comfort handle.
Use
18

Using the vacuum cleaner for the
first time
The lowest power level can be directly
selected by pressing -, and the highest
power level by pressing +.
The next time you use the vacuum
cleaner, the previously selected power
level can be activated.
^Press the standby button -on the
comfort handle.
Use
19

Selecting the suction power
The suction power can be regulated to
suit the type of flooring. Reducing the
suction power reduces the amount of
effort required to manoeuvre the
floorhead.
The symbols on the comfort handle
indicate the type of use for which the
settings are suitable.
The setting lights up yellow when
selected.
#- Curtains, lightweight fabrics
$- Upholstery, cushions
%- High quality velour carpets, rugs
and runners
Auto automatic adjustment of the
suction power according to
the flooring
,Do not vacuum any light
materials or curtains with the "Auto"
power setting. These may be drawn
into the vacuum cleaner and
become damaged.
*- For everyday energy-saving
vacuuming
For vacuuming with a low
operating noise level
(- Loop-pile carpets and rugs
)- Hard flooring, and for intensive
cleaning of carpets and rugs
^Press the +button on the comfort
handle to select a higher setting.
^Press the -button on the comfort
handle to select a lower setting.
Use
20
