Miele Olympus HS12 User manual

Operating Instructions
Vacuum Cleaner
S 2000
To prevent accidents
and machine damage,
read these instructions
before
installation and use. M.-Nr. 07 821 170
en, fr, es - US, CA, MX
HS12

2

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to the vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before using the vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the included accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power cord.......................................................13
Turning the vacuum On/Off ..........................................14
Adjusting the suction ...............................................15
Opening the air inlet valve ...........................................15
Transport and storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Purchasing new dustbags and filters ..................................17
Which dustbags and filters are the right ones? ...........................17
When to change the dustbag ........................................18
Replacing the dustbag .............................................19
When to change the dust compartment filter (Pre-motor filter) ...............20
Replacing the dust compartment filter (Pre-motor filter) ....................20
When to replace the Air Clean exhaust filter .............................20
Replacing the Air Clean filter .........................................20
Exchanging exhaust filters...........................................21
When to change the Active HEPA exhaust filter ..........................21
Replacing the Active HEPA exhaust filter ...............................21
When to change the thread catcher ...................................22
Changing the thread catcher.........................................22
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Warranty.........................................................27
Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Contents
3

When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS APPLIANCE
WARNING-
To reduce the risk of fire,
electric shock or injury:
Before Using
~Check the voltage rating of the
vacuum cleaner before connecting the
power cord to an electrical outlet. Your
power source should correspond with
the voltage rating plate located on the
underside of the vacuum. Use only
household AC outlets. Never use DC
power sources. If you are not sure of
your home’s voltage supply, consult a
qualified electrician. Connecting the
vacuum cleaner to a higher voltage
may result in damage to the vacuum
cleaner or injury.
~To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other.) This
plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to
install the proper outlet. Do not alter the
plug in any way.
~A damaged vacuum cleaner can be
dangerous. Check the packaging,
vacuum cleaner and accessories for
any signs of damage. Do not use a
damaged appliance.
~Do not use with a damaged cord or
plug. If the appliance is not working as
it should, has been dropped, damaged,
left outdoors or submerged in water,
bring it to a service center.
~The electrical outlet must be fitted
with a 15 A fuse.
IMPORTANT SAFETY INSTRUCTIONS
4

Use
~Do not use on people or animals.
~Do not use outdoors or on wet
surfaces. Only dry surfaces should be
vacuumed.
~Use only as described in this
manual. Use only Miele recommended
accessories described in this manual.
~This appliance is intended strictly for
household use only.
~Do not allow the vacuum cleaner to
be used as a toy. Close attention is
necessary when used near children.
~Never use the vacuum cleaner
without the dustbag or filters in place.
Otherwise, it could be damaged.
~If the dustbag is not inserted , the
dust compartment lid will not close. Do
not force it shut.
~Do not leave the vacuum plugged
in. Unplug it from the outlet when not in
use and before servicing.
~On the underside of the vacuum
hand piece is a metal insert designed
to absorb static electricity. Please make
certain that your hand remains around
this metal insert when vacuuming.
~Persons who lack physical, sensory,
or mental capabilities or experience
with the machine should not use it
without supervision or instruction by a
responsible person.
~Unwind the cord completely to aid
the vacuum in dissipating heat.
~This vacuum should not be used to
entrap or retain any hazardous
materials.
~Do not use the vacuum cleaner to
pick up liquids or damp dirt. This could
impair the electrical safety of the
vacuum cleaner. Wait for freshly
shampooed carpets to dry.
~Do not vacuum anything that is
burning or smoking such as cigarettes,
matches or hot ashes. The vacuum
could catch fire.
~Do not vacuum toner dust. Toner,
such as that used in printers and
photocopiers can conduct electricity.
~Do not use the vacuum to pick up
any flammable or combustible liquids
such as gasoline or use in areas where
they may be present.
~Do not vacuum up items which are
heavy, hard or have sharp edges. They
could cause a blockage and damage
the appliance.
~Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around sharp
edges or corners. Do not run the
appliance over the cord. Keep the
cord away from heated surfaces.
~Do not unplug by pulling the cord.
To unplug grasp the plug, not the cord.
~Do not handle the plug or vacuum
with wet hands.
IMPORTANT SAFETY INSTRUCTIONS
5

~Keep hair, loose clothing, fingers,
and all parts of body away from
openings and moving parts.
~Do not place anything into the
openings of the vacuum. Do not use if
any openings are blocked; keep them
free of dust, lint, hair or anything that
may reduce air flow.
~To avoid risk of injury while
vacuuming, do not reach into the
moving beater bar of the Powerbrush.
Danger of injury.
~This appliance is equipped with a
power cord reel. Hold the plug when
rewinding onto cord reel. Do not allow
plug to whip when rewinding.
~Turn off all controls before
unplugging.
~Use caution when vacuuming on
stairs.
~Floor attachments, accessories and
wands must not be used at head level
to avoid injuries to the eyes and ears.
Using accessories
~The socket on the vacuum cleaner is
only to be used with the Miele
Powerbrush.
~Unplug the vacuum when changing
accessories, especially when using the
Powerbrush.
~The Miele Powerbrush is a
motor-driven accessory for use only
with Miele vacuum cleaners. The
vacuum must not be used with another
manufacturer's Powerbrush.
~Do not use the vacuum without an
accessory attached. The rim could be
damaged and injuries could result from
sharp edges.
~Miele dustbags are disposable and
intended to be used only once. Do not
attempt to reuse them. An over stuffed
dustbag will reduce the efficiency of the
vacuum cleaner.
~Only use genuine Miele dustbags
with the Miele quality signet and
original Miele filters and accessories.
Only then will the manufacturer
guarantee its safety.
~Always turn off this appliance before
connecting or disconnecting motorized
nozzle.
IMPORTANT SAFETY INSTRUCTIONS
6

Cleaning, maintenance and
repairs
~Turn the vacuum cleaner off after
each use and before every cleaning /
maintenance. Pull the plug from the
outlet.
~Never submerge the vacuum
cleaner in water. Clean only with a dry
cloth or slightly damp cloth when
disconnected from the mains supply. If
moisture gets into the appliance there
is a risk of electrical shock.
~Monitor the dustbag change
indicator and inspect all filters regularly.
For best performance, the dustbag and
filters should be replaced when
necessary. A full bag or blocked filter
will reduce the vacuum cleaners'
suction power. A temperature limiter
automatically switches the vacuum
cleaner off if it gets too hot, see
"Maintenance and Care - What if the
vacuum turns off automatically?".
~Repairs during the warranty period
should only be performed by an
authorized service agent in accordance
with national and local safety
regulations. Unauthorized repairs could
cause injury or machine damage and
may void the warranty.
Disposing of an old appliance
~Before discarding an old vacuum
cleaner, please cut off the power cord,
and render the plug useless. Ensure
the appliance presents no danger to
children while being stored for disposal
SAVE THESE
INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
7

Guide to the vacuum cleaner
8

aHand piece
bAir inlet valve
cLock release button
dConnection piece for storage *
eTelescopic wand *
fHose connector
gEasyLock wand *
hTelescopic wand release button *
iDust compartment lid release
jSuction power selector
kFloor brush *
lCarrying handle
mSocket for Powerbrush *
nDustbag
oDust compartment filter (pre-motor filter)
pExhaust filter
qOn/Off sfoot switch
rPark-System
sPower cord
tCord rewind switch
uAirflow indicator
vAccessory clip with three tools
wSuction hose
The features marked *may vary or not be available on your model.
Optional accessories are available from your Miele dealer or Miele.com
Guide to the vacuum cleaner
9

Connecting the hose a
^Insert the hose connector in the
suction socket until it clicks into
place.
Disconnecting the hose b
^Press the release buttons at the sides
of the hose connector and lift the
hose from the socket.
Depending on your model one of the
following wands is included (see "Guide
to the vacuum cleaner").
– EasyLock wand
– Telescopic wand
Connecting the EasyLock
wand
^Insert the wand with connection
piece into the second wand. Twist
until they lock with a click.
^Push the connection piece upwards
until it clicks into position.
Connecting the hand piece and
wand a
^Insert the hand piece into the wand
until it clicks into place. Use the inlet
guides to direct insertion.
Releasing the hand grip b
^Press the lock release button and pull
the hand piece away from the wand.
Before using the vacuum cleaner
10

Adjusting the telescopic wand
One part of the telescopic wand is fitted
inside the other and can be adjusted to
your height for comfortable vacuum
cleaning.
^Press the telescopic wand release
button to release the tubes and
adjust to the desired height.
Using the standard floor brush
Observe the cleaning instructions of
the floor manufacturer.
The floor brush is suitable for cleaning
carpets, rugs, carpeted stairs and hard
surfaces that are not susceptible to
scratching.
Connecting the floor brush
^Place the floor brush into athe
suction hose and twist until it clicks
into place.
^To separate the parts b, press the
lock release button and pull apart.
Adjusting the floor brush c
For vacuuming carpets and rugs, lower
the tool by:
^pressing the foot switch marked ö.
For cleaning smooth floors, raise the
tool by:
^pressing the foot switch marked ä.
Before using the vacuum cleaner
11

The following accessories are included:
aDust brush with natural bristles
bUpholstery tool
cCrevice nozzle
dAccessory clip for the included
accessories
Position the accessories as indicated.
Accessory clip
^Press the accessory clip either above
the hose connector or below the
suction hose. Be sure it clicks into
place.
Floor brush
The floor brush is suitable for cleaning
carpets, rugs, carpeted stairs and hard
surfaces that are not susceptible to
scratching.
For safety, when vacuuming stairs it
is best to start at the bottom and
move upwards.
Using the included accessories
12

Power cord
,Unwind the cord completely to
aid the vacuum in dissipating heat.
Do not pull or carry by the cord, use
the cord as a handle, close a door
on the cord, or pull the cord around
sharp edges or corners. Do not run
the appliance over the cord. Keep
the cord away from heated surfaces.
Do not unplug by pulling the cord.
To unplug grasp the plug, not the
cord.
This appliance is equipped with a
power cord reel. Hold the plug when
rewinding onto cord reel. Do not
allow plug to whip when rewinding.
Unwinding
^Hold the plug and pull aout the
power cord.
,To reduce the risk of electric
shock, the vacuum has a polarized
plug (one blade is wider than the
other). This plug will fit in a polarized
outlet only one way. If the plug does
not fit fully in the outlet, contact a
qualified electrician. Do not alter the
plug in any way.
Danger of overheating and damage.
Rewinding
^Unplug the vacuum from the outlet.
^Press the rewind switch - the power
cord will rewind automatically b.
Hold the plug so that it does not whip
around when rewinding.
Operation
13

Turning the vacuum On/Off
^Press the On/Off foot switch s.
,To prevent static electricity your
hand must touch the metal inlay on the
underside of the vacuum hand piece.
Be certain to continuously touch this
inlay when vacuuming fine dust, flour
or sawdust as these materials are more
likely to create a static discharge. To
further prevent static discharge, pull
the vacuum along by the hose with one
hand while continuing to hold the hand
piece in the other hand.
Operation
14

Adjusting the suction
You can adjust the suction power to suit
the type of flooring. By reducing the
suction power the floor brush can be
pushed easier.
The symbols on the controls indicate
the type of use the settings are suitable
for:
#curtains, lightweight fabrics
$upholstery, cushions
%thick pile carpets, rugs and
runners
*energy saving, daily vacuuming
with low noise level
(lightly soiled textured carpets
)textured hard flooring, and for
intensive cleaning of carpets
^Turn the suction power selector to the
desired setting.
Opening the air inlet valve
The air inlet valve can be opened to
quickly reduce the suction power of the
tool being used, e.g. when moving from
a carpet to an area rug.
^Open the air inlet valve far enough to
reduce the suction power.
Opening the air inlet valve reduces the
power to the tool being used.
Operation
15

Park-System
(unable to be used with the Powerbrush
SEB 228 / EB03.)
The Park system allows you to
conveniently park the wand and floor
brush on the vacuum cleaner during
brief pauses.
^Insert the lower clip on the floor brush
into the slot on the end of the vacuum
cleaner from above.
Transport and storage
^For easier transportation and storage
stand the vacuum cleaner vertically.
^Insert the parking clip attachment on
the floor brush into the parking slot
from above (does not apply to
Powerbrush SEB 228 / EB03).
If you model includes a telescopic
wand, to save space completely
collapse the tubes in the telescopic
wand.
If your model includes an EasyLock
wand, to save space:
^Press the lock release on the lower
wand, the two wands will separate.
^Put the connection piece of the upper
wand into the lower wand.
Transport and storage
16

,Turn off and unplug the vacuum
cleaner before performing any
maintenance work.
The Miele filter system consists of the
following three components.
–Dustbag
–Exhaust filter
–Dust compartment filter
Each of these components must be
changed periodically to maintain the
vacuum cleaner’s efficiency.
Only use Miele dustbags, filters and
accessories with the "Original Miele"
logo. Only then can the suction
power of the vacuum cleaner reach
its optimum potential creating the
best possible cleaning results.
,The use of dustbags made of
paper or a similar material, or
dustbags with a cardboard retaining
plate can lead to serious damage to
the vacuum cleaner and possibly
voiding the warranty, just as with the
use of dustbags without the "Original
Miele" logo.
Purchasing new dustbags and
filters
Original Miele dustbags and filters can
be purchased from an authorized Miele
vacuum dealer or by visiting the Miele
store at http://store.miele.com.
Which dustbags and filters are
the right ones?
This vacuum cleaner uses Original
Miele dustbags Type G/N and an
Original Miele filters, the "Original Miele"
Logo will appear on the packaging or
directly on the dustbag.
An "Air clean" exhaust filter and a dust
compartment filter are supplied with
every box of Miele dustbags.
If you would like to purchase additional
Miele filters separately, contact your
vacuum dealer or Miele, please quote
the model number of your Miele
vacuum cleaner to ensure correct parts
are ordered. These parts are also
available to order from the online Miele
store.
The exhaust filter supplied with the
vacuum cleaner can be exchanged
with another type of Original Miele filter
(see "Exchanging exhaust filters").
Maintenance and care
17

When to change the dustbag
Change the dustbag when the colored
marker in the airflow indicator fills the
display.
Miele dustbags are disposable and
made to be used only once. Do not
attempt to reuse.
Checking the airflow indicator
^Attach the floor brush to the vacuum
cleaner. Perform this test with the
floor brush only, since other
attachments can affect the function of
the airflow indicator.
^Turn the vacuum cleaner on and
select the highest power setting.
^Lift the floor brush slightly off the
floor. If the marker completely fills the
indicator window, the dustbag needs
to be changed.
How the airflow indicator works
The airflow indicator is designed to
show when the bag is full of common
household dust and measures the
amount of air flow through the dustbag.
Normal household dust is a mixture of
dust, hair, carpet fluff, threads, sand,
etc.
However, if fine dust, such as drill dust,
sand, plaster or flour is vacuumed, the
pores of the dustbag may become
blocked. The marker will indicate that
the bag is "full" even when it is not. The
dustbag should be changed as the
suction power is greatly reduced.
If the bag is bulging with pet fur, hair,
carpet fluff, etc. the indicator may not
register "full". This is because the air
flow of the dustbag may still be high
enough not to activate the marker to
show maximum. The dustbag should
still be changed.
Maintenance and care
18

Replacing the dustbag
^Open the dust compartment lid and
raise until it clicks into place.
The dustbag has a closing flap which
closes automatically when the dust
compartment lid is raised to prevent
any dust from escaping.
^Grasp the finger grip and pull athe
dustbag out of the holder.
^Insert bthe new dustbag as far as it
will go into the dustbag holder. Do
not unfold the dustbag when taking it
out of the box.
^Unfold the dustbag in the dust
compartment.
^Push the dust compartment lid
closed until it clicks into place. Take
care not to jam the dustbag in the lid.
,An empty-operation-barrier
blocks the dust compartment lid
from closing if no dustbag is
inserted. Do not force it closed.
Maintenance and care
19

When to change the dust
compartment filter (Pre-motor
filter)
Change the filter each time you open a
new box of genuine Miele dustbags. A
dust compartment filter is supplied with
each box.
Replacing the dust
compartment filter (Pre-motor
filter)
^Open the dust compartment lid.
^Open the filter frame, remove the old
filter, and insert a new filter.
^Close the filter frame.
^Close the dust compartment lid.
When to replace the Air Clean
exhaust filter
Each time a new box of Miele dustbags
is opened, this filter should be
changed. A new Air Clean exhaust filter
is included in every box of Miele
dustbags.
Replacing the Air Clean filter
Do not use more than one filter at a
time.
^Open the dust compartment lid.
^Open the filter frame until it clicks,
grasp the clean corner (see arrow)
and remove the used filter a.
^Insert the new filter b.
^Close the filter frame.
^Close the dust compartment lid.
Maintenance and care
20
