TECHNICAL INFORMATION
W1900 Series Clothes Washers
©2007 Miele USA

Technical Information
W1900 Series Clothes Washers
W1900 Series Clothes Washers - Table of Contents
1.0 Construction and Design.........................................................................6
1.1 Appliance Overview...................................................................................... 6
1.2 Overview of Controls .................................................................................... 7
1.3 Technical Data ........................................................................................... 11
1.4 Dispenser Assembly................................................................................... 13
1.5 Layout of Electrical Components W1903, W1918, W1926 & W1930....... 15
1.6 Layout of Electrical Components W1966 & W1986.................................. 16
2.0 Installation ..............................................................................................17
2.1 Electrical Requirements ............................................................................. 17
2.2 Plumbing Requirements ............................................................................. 18
2.3 Installation Procedure................................................................................. 19
3.0 Commission and Operation ..................................................................23
3.1 General Operation ...................................................................................... 23
3.2 Additional Function Pushbuttons ................................................................ 23
4.0 Description of Function .........................................................................25
4.1 Casing Assembly........................................................................................ 25
4.2 Electro-Mechanical Door Lock.................................................................... 25
4.3 Miele Eco Wash System ............................................................................26
4.4 Drum Suspension ....................................................................................... 27
4.5 Heating Circuit Information .........................................................................28
4.6 Water Level Switch..................................................................................... 29
4.7 Water Control System – Intake................................................................... 29
4.8 Water Control System – Rinses ................................................................. 30
4.9 Inlet Hose(s) Filters .................................................................................... 30
4.10 Inlet Valves................................................................................................. 30
4.11 Dispenser Assembly................................................................................... 30
4.12 Non-Return Valve & Drain Venting............................................................. 31
4.13 Main Motor ................................................................................................. 32
4.14 Motor Speed Control .................................................................................. 32
4.15 Tachogenerator .......................................................................................... 32
4.16 Imbalance Monitoring ................................................................................. 33
4.17 Motor Circuit ............................................................................................... 33
4.18 Program Control ......................................................................................... 34
4.19 Heater Relays............................................................................................. 34
5.0 Service and Maintenance ......................................................................35
5.1 Dispenser Drawer – Removal..................................................................... 35
5.2 Appliance Lid – Removal............................................................................ 36
5.3 Front Service Panel – Access .................................................................... 36
5.4 Door Seal – Replacement ..........................................................................37
5.5 Air Trap – Replacement.............................................................................. 38
5.6 Heater Element(s) – Replacement ............................................................. 39
2

Technical Information
W1900 Series Clothes Washers
W1900 Series Clothes Washers - Table of Contents (continued)
5.7 Inlet Valve – Replacement.......................................................................... 39
5.8 Manual Draining and Filter Removal ..........................................................40
5.9 Drain Pump - Replacement ........................................................................ 41
5.10 Main Motor – Carbon Brush Replacement ................................................. 42
5.11 Control Electronic – Removal..................................................................... 43
5.12 Power Supply Electronic - Removal ........................................................... 44
5.13 Determining Which Electronic Requires Replacement (Electronic Test
Procedure).................................................................................................. 45
5.14 Water Level Switch - Replacement ............................................................ 47
5.15 Heater Relays - Access.............................................................................. 48
6.0 Fault Diagnosis ......................................................................................49
6.1 Service Mode - W1903, W1918, W1926 & W1930 ....................................49
6.2 Service Mode - W1966 and W1986 ........................................................... 50
6.3 Fault Codes ................................................................................................ 51
6.3.1 Fault Code – Definitions (W1966 & W1986 Only) ........................... 52
6.4 Programming Mode .................................................................................... 54
6.5 Description of Programmable Options........................................................ 57
6.6 Special Features ........................................................................................ 61
6.6.1 Electronic Program Lock ................................................................. 61
6.6.2 Child Safety Lock............................................................................. 61
6.6.3 Demonstration Mode ....................................................................... 62
6.7 Fault Indicators ........................................................................................... 63
6.8 Porthole Door is locked / unable to access service door ........................... 67
6.9 Customer reports water leaks from front left side of the appliance. .......... 67
6.10 W1966 & W1986 not functioning correctly, after Control Electronic
Replacement .............................................................................................. 67
6.11 W1900 series not functioning correctly, after Control Electronic
Replacement .............................................................................................. 68
3

Technical Information
W1900 Series Clothes Washers
W1900 Series Clothes Washers – List of Figures
Figure 1-1: Appliance Overview (typical W1900 series washer).................................... 6
Figure 1-2: Overview of Controls (W1903 & W1918)..................................................... 7
Figure 1-3: Overview of Controls (W1926 & W1930)..................................................... 8
Figure 1-4: Overview of Controls (W1966)..................................................................... 9
Figure 1-5: Overview of Controls (W1986)................................................................... 10
Figure 1-6: 5 Kilogram Dispenser (W1903, W1918, W1930 & W1930i) ...................... 13
Figure 1-7: 6 Kilogram Dispenser (W1966 & 1986) ..................................................... 14
Figure 1-8: Overview of Components (W1903, W1918, W1930 & W1926) ................. 15
Figure 1-9: Overview of Components (W1966 & W1986)............................................ 16
Figure 2-1: Turning the left Shipping Strut counterclockwise.......................................19
Figure 2-2: Turning the right Shipping Strut clockwise................................................. 19
Figure 2-3: Removing the Strut Support Assembly...................................................... 20
Figure 2-4: Plugging the Shipping Strut Holes. ............................................................ 20
Figure 2-5: Adjusting the legs to level the appliance.................................................... 21
Figure 4-1: Eco Wash System ..................................................................................... 26
Figure 4-2: Drum Suspension Components.................................................................27
Figure 4-3: Increased in water volume = increased pressure against the
Level Switch. .............................................................................................. 29
Figure 4-4: Dispenser Assembly .................................................................................. 30
Figure 4-5: Non-return valve ........................................................................................ 31
Figure 4-6: Main Motor Assembly ................................................................................ 32
Figure 4-7: Motor circuit ............................................................................................... 33
Figure 5-1: Removing the dispenser drawer ................................................................ 35
Figure 5-2: Service Access .......................................................................................... 36
Figure 5-3: Replacing the door seal............................................................................. 37
Figure 5-4: Air Trap and Level Switch Components .................................................... 38
Figure 5-5: Heater Element.......................................................................................... 39
Figure 5-6: Drain pump removal .................................................................................. 41
Figure 5-8: Removing Control Electronic ..................................................................... 43
Figure 5-9: Removing the Power electronic ................................................................. 44
Figure 5-10: Ribbon Cable with pin 1 position noted. .................................................... 45
Figure 5-11: Water level switch...................................................................................... 47
Figure 5-12: Heater relays with bracket ......................................................................... 48
4

Technical Information
W1900 Series Clothes Washers
W1900 Series Clothes Washers – List of Tables
Table 1-1: Technical Data (Continued on Table 1-2)................................................... 11
Table 1-2: Technical Data (Continued from Table 1-1) ............................................... 12
Table 4-1: NTC Temperature Sensor - Resistance ..................................................... 28
Table 4-2: Imbalance Monitoring ................................................................................. 33
Table 6-1: Service Mode Functions (W1903, W1918, W1926 & W1930).................... 49
Table 6-2: Service Mode Functions (W1966 & W1986) .............................................. 50
Table 6-3: Fault Codes (W1966 & W1986).................................................................. 51
Table 6-4: Programming Mode Functions for W1966 & W1986 (Continued on
Table 6-5) ................................................................................................... 55
Table 6-5: Programming Mode Functions for W1966 & W1986 (Cont. from Table 6-5,
Cont. on Table 6-6)..................................................................................... 56
Table 6-6: Programming Mode Functions for W1966 & W1986 (continued from Table
6-5) ............................................................................................................. 57
Table 6-7: Fault Indicators (Continued on Table 6-8).................................................. 63
Table 6-8: Fault Indicators (Continued from Table 6-7) (Continued on Table 6-8)...... 64
Table 6-9: Fault Indicators (Continued from Table 6-8) (Continued on Table 6-10).... 65
Table 6-10: Fault Indicators (Continued from Table 6-9)............................................... 66
5

Technical Information
W1900 Series Clothes Washers
1.0 Construction and Design
1.1 Appliance Overview
1 Supply Cable 5 Control Panel
2 High Pressure Intake Hoses 6 Drum Door
3 Flexible Drain Hose, With Detachable 7 Access Panel for Lint Filter and
SwivelElbow DrainPump
4 Detergent Dispenser Drawer 8 Four Height Adjustable Legs
Figure 1-1: Appliance Overview (Typical W1900 Series Washer)
6

Technical Information
W1900 Series Clothes Washers
1.2 Overview of Controls
W1903
W1918
Figure 1-2: Overview of Controls (W1903 & W1918)
7

Technical Information
W1900 Series Clothes Washers
W1926
W1930
Figure 1-3: Overview of Controls (W1926 & W1930)
8

Technical Information
W1900 Series Clothes Washers
Figure 1-4: Overview of Controls (W1966)
W1966
9

Technical Information
W1900 Series Clothes Washers
W1986
Figure 1-5: Overview of Controls (W1986)
10

Technical Information
W1900 Series Clothes Washers
1.3 Technical Data
W1903 W1918 W1926 W1930
W1966
W1986
Height 331/4” –
337/8”
331/4 –
337/8”
331/2” +
1/2”/-1/4”
(850mm +
10/-0,5 mm)
331/4 –
337/8”
(845mm +
860mm)
331/2” +
1/2”/-1/4”
(850mm
+10/-0,5 mm)
Width
23 5/8”
(600 mm)
23 5/8”
(600 mm)
23 5/8”
(600 mm)
23 5/8”
(600 mm)
23 5/8”
(600 mm)
Depth (inc.
distance
from wall)
24”
(610 mm)
24”
(610 mm)
28 1/4”
(715 mm)
24”
(610 mm)
28 1/4”
(715 mm)
Weight 220 lbs.
(100 kg)
220 lbs.
(100 kg)
252 lbs. (114
kg)
220 lbs. (100
kg)
252 lbs. (114
kg)
Capacity
11 lbs.
(5 kgs.)
dry
laundry
11 lbs.
(5 kgs.)
dry
laundry
13 lbs.
(6 kgs.)
dry laundry
11 lbs.
(5 kgs.)
dry laundry
13 lbs.
(6 kgs.)
dry laundry
Rated Load
2.8 kW 2.8 kW 2.8 kW 2.8 kW 2.8 kW
Circuit
Breaker
15 amp 15 amp 15 amp 15 amp 15 amp
Water
Pressure
15-145 psi
(1–10 bar)
15-145 psi
(1–10 bar)
15-145 psi
(1–10 bar)
15-145 psi
(1–10 bar)
15-145 psi
(1–10 bar)
Water
Connection
¾” in.
hose
thread
Cold Only
¾” in.
hose
thread
Hot & Cold
¾” in. hose
thread
Hot & Cold
¾” in. hose
thread
Hot & Cold
¾” in. hose
thread
Hot & Cold
Table 1-1: Technical Data (Continued on Table 1-2)
11

Technical Information
W1900 Series Clothes Washers
W1903 W1918 W1926 W1930 W1966
W1986
Drain
Connection
5’ hose
1 ¼” OD
1” ID
5’ hose
1 ¼” OD
1” ID
5’ hose
1 ¼” OD
1” ID
5’ hose
1 ¼” OD
1” ID
5’ hose
1 ¼” OD
1” ID
Maximum
Drain Height
4’ 4’ 4’ 4’ 4’
Power
Requirement
s
120 V/240
(208) V
single
phase
60 Hz
120
V/240
(208) V
single
phase
60 Hz
120 V/240
(208) V
single
phase
60 Hz
120 V/240
(208) V
single phase
60 Hz
120 V/240
(208) V single
phase
60 Hz
Power Cord /
Plug
5’ cable
NEMA 15-
30 plug
5’ cable
NEMA
15-30
plug
5’ cable
NEMA 15-
30 plug
5’ cable
NEMA 15-30
plug
5’ cable
NEMA 15-30
plug
Spin Speed
600-1200
rpm
400-1600
rpm
600-1200
rpm
400-1600
rpm 400-1200 rpm
Temperature
Control
Cold to
190º
Cold to
190º
Cold to
190º
Cold to
170º
Cold to
190º
Floor Load 360 lbs 360 lbs 682 lbs 360 lbs 682 lbs
Table 1-2: Technical Data (continued from Table 1-1)
12

Technical Information
W1900 Series Clothes Washers
1.4 Dispenser Assembly
5 Kilogram Models (W1903, W1918, W1930 & W1930i)
Detergent dispenser drawer
Compartment - for the pre-wash
Compartment - for the main wash.
Compartment - (with lid) for fabric softener or starch.
Figure 1-6: 5 Kilogram Dispenser (W1903, W1918, W1930 & W1930i)
13

Technical Information
W1900 Series Clothes Washers
6 Kilogram Models (W1926, 1966, & 1986)
Detergent dispenser drawer
Compartment - for the pre-wash
Compartment - for the main wash.
Compartment - (with lid) for fabric softener or starch.
Figure 1-7: 6 Kilogram Dispenser (W1966 & 1986)
Note:
The largest compartment is always the Main Wash.
14

Technical Information
W1900 Series Clothes Washers
1.5 Layout of Electrical Components
W1903, W1918, W1926 & W1930
A2 Door Lock R30 Temperature sensor
B1 Level switch S1 Selector switches – Additional functions
K1/1 Relay – Heating S16 Selector switch – Spin Speed
M5 Motor – Drum drive X3/1 Mains terminal strip
M8 Motor – Drain pump Y1-Y3 Inlet valves
1N1 Power module Y12 Hot water valve
2N1 Control module Z1-Z3 Interference suppressor
R1, R2 Heating
Figure 1-8: Overview of Components (W1903, W1918, W1930 & W1926)
15

Technical Information
W1900 Series Clothes Washers
1.6 Layout of Electrical Components
W1966&W1986
1 Hot Water Valve 7 Heater NTC
2 Cold Water (Triple) Valve 8 Heater Relays
3 Main Motor & Interference Capacitor 9 Control Electronic
4 Main Motor 10 Input Board
5 Drain Pump 11 Power Electronic
6 Heating Element (2) 12 Door Lock
Figure 1-9: Overview of Components (W1966 & W1986)
16

Technical Information
W1900 Series Clothes Washers
2.0 Installation
 The Shipping Struts must be completely removed prior to any
operation and / or testing.
 Ensure the appliance is being installed on a suitable surface.
 Chlorine Bleach is not recommended.
 Only detergent carrying an “H.E.” (High Efficiency) designation should
be used.
 The appliance comes equipped to operate using only powder
detergent; to use liquid detergents an optional detergent drawer insert
is required - call Miele Technical Support to order.
 The machine must be perfectly level to ensure safe and proper
operation.
 To perform a stacked installation an approved Miele Stacking Kit that
matches the exact model numbers must be used. The washer must
be the lower appliance and installed first.
Note:
A Laundry Stand and a Stacking Kit cannot be used together.
2.1 Electrical Requirements
 120/240 (208) Volt, 60Hz., 15 Amp breaker
Washers are equipped with a 4 wire power cord consisting of L1, L2,
N and Ground; equipped with a NEMA 14-30 plug, for connection to a
NEMA 14-30 receptacle.
Note:
For proper appliance operation a Neutral is required.
Note:
If you do not have a dedicated 15 Amp circuit for this appliance, but have
a NEMA 14-20 or NEMA 14-30, 240V, 30 Amp outlet, you may be able to
use a Miele “Easy Installation Kit” to simplify the electrical connection.
For further information refer to Electrical Information pages in the
Installation Manual.
 Do not cutoff / remove the plug from the power cord.
17

Technical Information
W1900 Series Clothes Washers
2.2 Plumbing Requirements
Water Inlet
All W1900 series washer (except the W1903) are equipped with two
Water Inlet Hoses. Connect the Cold Water Intake Hose (blue mark)
to the Cold Water Valve and the Hot Water Intake Hose (red mark) to
the Hot Water Valve.
 The W1903 is equipped with a single Inlet Hose; that must be
connected to a cold water supply.
 The water pressure must be within 15-145 psi (1-10 bar). If the water
pressure is greater than 145 psi (10 bar), a Pressure Reducer must
be installed. If the water pressure is below 15 psi (1 bar), insufficient
water may be available for a complete fill. The Water Intake Hoses
are equipped with Screen Filters - do not remove these filters.
Note:
For customers requesting a “cold water only connection” on washers
equipped with Dual Inlet Hoses a “Y” adapter (available at most hardware
stores) can be utilized. Both Inlet Hoses (hot and cold) should be
connected to the adapter.
Drain Connection
The appliance is equipped with a 5 ft. (1.5 m) drain hose with a maximum
delivery height of 4ft. (1.2 m) which can be connected as follows:
1. Directly into a sink: hook the hose over the edge of the sink and
secure it firmly (i.e. by tying the hose to the water faucet etc...).
2. To a stand pipe: place the Drain Hose into a 1 1 /2" (38 mm) stand
pipe and secure in place.
3. To a floor drain: The machine is equipped with an Airgap/Anti-
Siphoning System so that no minimum drain height is required.
Important!
Ensure all connections are secure & hoses are free from sharp bends
and kinks.
18

Technical Information
W1900 Series Clothes Washers
2.3 Installation Procedure
1. Lift the machine from the shipping pallet and move it to the installation
site. Do not lift the machine by the Drum Door.
Note:
Ensure that the machine feet and the floor are dry to prevent slippage
during the spin cycle.
2. REMOVE THE SHIPPING STRUTS - by performing the following:
 Turn the left Shipping Strut 90° counterclockwise
Figure 2-1: Turning the left Shipping Strut Counter Clockwise.
 Turn the right Shipping Strut 90° clockwise.
Figure 2-2: Turning the right Shipping Strut Clockwise.
19

Technical Information
W1900 Series Clothes Washers
 Remove the two Struts and Support Plate Assembly.
Figure 2-3: Removing the Strut Support Assembly
Figure 2-4: Plugging the Shipping Strut Holes
20
