Miele PWM 507 Hygiene User manual

Operating and installation instructions
Washing machine
To avoid the risk of accidents or damage to the machine, it is essential
to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 11 116 540

Contents
2
Caring for the environment .................................................................................. 6
Warning and safety instructions .......................................................................... 7
Operating the washing machine ........................................................................ 15
Fascia panel .......................................................................................................... 15
Symbols on the fascia panel ................................................................................. 16
Symbols on the display ......................................................................................... 17
Sensor controls and touch display with sensor controls ...................................... 18
Main menu............................................................................................................. 18
Examples of how to operate the appliance........................................................... 19
Before using for the first time ............................................................................ 20
1. Preparing the laundry...................................................................................... 24
2. Loading the washing machine ....................................................................... 25
3. Selecting a programme .................................................................................. 26
4. Selecting programme settings....................................................................... 27
5. Adding detergent............................................................................................. 29
Adding fabric conditioner or liquid starch separately....................................... 30
Adding starch separately.................................................................................. 30
6. Starting the programme – the end of the programme ................................. 33
Delay start ............................................................................................................ 34
Programme chart ................................................................................................ 35
Special programmes ............................................................................................. 37
Programme packages ........................................................................................... 39
Extras.................................................................................................................... 45
Pre-wash ......................................................................................................... 45
Soak ................................................................................................................ 45
Pre-rinse .......................................................................................................... 45
Pre-ironing ........................................................................................................ 45
Rinse plus ....................................................................................................... 45
Special features in the programme sequence.................................................. 46
Spinning ................................................................................................................ 46
Anti-crease ............................................................................................................ 46

Contents
3
Changing the programme sequence................................................................. 47
Changing a programme......................................................................................... 47
Cancelling a programme ....................................................................................... 47
Switching on the washing machine after an interruption to the power supply ..... 47
Adding or removing laundry .................................................................................. 48
Cleaning and care ............................................................................................... 49
Cleaning the casing and fascia panel ................................................................... 49
Cleaning the detergent drawer.............................................................................. 49
Cleaning the drum, suds container and drainage system..................................... 51
Cleaning the water inlet filters ............................................................................... 51
Problem solving guide ........................................................................................ 53
The wash programme does not start .................................................................... 53
Programme cancellation and error message......................................................... 54
A fault message appears in the display ................................................................ 55
An unsatisfactory wash result ............................................................................... 56
General problems .................................................................................................. 57
The door will not open........................................................................................... 59
Opening the door in the event of a blocked drain outlet and/or power cut .......... 60
Miele Service ....................................................................................................... 63
Contact in case of malfunction ............................................................................. 63
Optional accessories............................................................................................. 63
Installation............................................................................................................ 64
Front view .............................................................................................................. 64
Rear view............................................................................................................... 65
Installation locations.............................................................................................. 66
Installation notes ................................................................................................... 66
Transporting the washing machine to its installation site...................................... 67
Installation surface ................................................................................................ 68
Removing the transit bars ..................................................................................... 68
Refitting the transit bars ........................................................................................ 70
Levelling the washing machine ............................................................................. 70
Securing the washing machine against slippage ............................................. 71
External control equipment ................................................................................... 71
Payment system ............................................................................................... 71
Water connection .................................................................................................. 72
Cold water connection .................................................................................... 72
Hot water connection*...................................................................................... 73

Contents
4
Drainage ................................................................................................................ 74
Drain valve........................................................................................................ 74
Drain pump....................................................................................................... 74
Electrical connection ............................................................................................. 75
Technical data...................................................................................................... 77
Supervisor level ................................................................................................... 78
Code-based access .............................................................................................. 78
Changing the code................................................................................................ 78
Opening the Supervisor level ................................................................................ 78
Exiting the Supervisor level ................................................................................... 78
Language............................................................................................................... 79
Brightness ............................................................................................................. 79
Clock display......................................................................................................... 79
Finish tone volume ................................................................................................ 79
Keypad tone volume ............................................................................................. 79
Welcome tone volume........................................................................................... 79
Fault alarm............................................................................................................. 79
Memory ................................................................................................................. 79
Anti-crease ............................................................................................................ 80
Suds cooling.......................................................................................................... 80
Delay start ............................................................................................................. 80
Programme name.................................................................................................. 80
Pre-wash water ..................................................................................................... 81
Main wash water ................................................................................................... 81
First rinse water..................................................................................................... 81
Final rinse water .................................................................................................... 81
Low water pressure ............................................................................................... 82
Empty sensor ........................................................................................................ 82
Early warning counter............................................................................................ 82
Water level Cottons ............................................................................................... 82
Water level Minimum iron ...................................................................................... 82
Cottons Pre-wash temp ........................................................................................ 82
Wash time Pre-wash ............................................................................................. 83
Wash time Cottons................................................................................................ 83
Wash time Minimum iron....................................................................................... 83
Pre-rinse Cottons .................................................................................................. 83

Contents
5
Pre-rinse Minimum iron ......................................................................................... 83
Pre-wash Cottons/Min. iron .................................................................................. 83
Cottons rinses ....................................................................................................... 83
Min. iron rinses ...................................................................................................... 84
Disinfection rinse................................................................................................... 84
Programme packages ........................................................................................... 84
Temp reduction...................................................................................................... 85
Disinfection prog. code ......................................................................................... 85
Auto load control ................................................................................................... 85
CapDosing............................................................................................................. 85
Pre-ironing............................................................................................................. 85
Automatic dispensing............................................................................................ 86
Peak load signal .................................................................................................... 86
Peak load prevention............................................................................................. 86
Alternating current ................................................................................................. 86
Heating .................................................................................................................. 86
Payment system .................................................................................................... 87
Settings for payment systems.......................................................................... 87
Feedback signal to pay system........................................................................ 87
Payment system lock ....................................................................................... 88
Delete paid signal............................................................................................. 88
FOC programmes............................................................................................. 88

Caring for the environment
6
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible (by law, depending on country) for
deleting any personal data that may be
stored on the appliance being disposed
of. Please ensure that your old appli-
ance poses no risk to children while be-
ing stored prior to disposal.

Warning and safety instructions
7
This washing machine complies with all current local and national
safety requirements. However, inappropriate use can lead to per-
sonal injury and damage to property.
Read the operating instructions carefully before using the washing
machine. They contain important information on safety, installa-
tion, use and maintenance. This prevents both personal injury and
damage to the washing machine.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the washing machine as well as the safety in-
structions and warnings.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
When instructing other people how to use the washing machine,
they must be made aware of these safety and warning instruc-
tions.
Appropriate use
 The washing machine is only suitable for washing fabrics with a
care label stating that they are suitable for machine washing. Any
other applications may be dangerous. The manufacturer cannot be
held liable for damage resulting from incorrect or improper use or
operation of the machine.
 This washing machine must be used as described in the operating
instructions and must be checked on a regular basis to make sure it
is functioning correctly. Maintenance must be carried out when ne-
cessary.
 The washing machine is not suitable for outdoor use.
 This washing machine may also be operated in public areas.

Warning and safety instructions
8
 This washing machine can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are supervised whilst using it or have been shown
how to use it in a safe way and understand and recognise the con-
sequences of incorrect operation.
 Children under the age of 8 must not be allowed near the washing
machine unless they are constantly supervised.
 Children over the age of 8 may only use the washing machine
without supervision if its operation has been clearly explained to
them and they are able to use it safely. Children must be able to un-
derstand and recognise the possible dangers caused by incorrect
operation.
 Children may not carry out cleaning or maintenance on the wash-
ing machine unsupervised.
 Always supervise any children in the vicinity of the washing ma-
chine. Never allow children to play with the washing machine.
 Disinfection programmes must not be interrupted, as this can
have a limiting effect on the disinfection result. It is the operator's re-
sponsibility to ensure that the standard of disinfection in thermal as
well as chemo thermal procedures is maintained by carrying out suit-
able validation tests.

Warning and safety instructions
9
Technical safety
 Before setting up the washing machine, check it for any externally
visible damage. Do not set up or use a damaged washing machine.
 The electrical safety of the washing machine can only be guaran-
teed when correctly earthed.
It is most important that this basic safety requirement is tested and
in case of any doubt the on-site wiring system should be inspected
by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system.
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
should only be undertaken by a Miele approved service technician,
otherwise any subsequent damage will not be covered by the war-
ranty.
 Do not make any alterations to the machine, unless authorised to
do so by Miele.
 The machine must be isolated from the electricity supply when
cleaning and maintaining the machine and in the event of a fault:
– switch off at the wall and disconnect the plug from the socket, or
– disconnect the fuse at the mains circuit board, or
– unscrew the on-site screw-in fuse.
See “Installation – Electrical connection”.

Warning and safety instructions
10
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 The washing machine must only be connected to the on-site wa-
ter supply using a new hose kit. Old hoses must not be re-used.
Check the hose regularly for signs of wear. Replace it in good time to
avoid the risk of leaks and subsequent damage.
 Faulty components must only be replaced by genuine Miele ori-
ginal spare parts. Miele can only guarantee the safety standards of
the machine when Miele replacement parts are used.
 For reasons of safety, do not connect the machine to the mains
electricity supply by an extension lead, multi-socket adapter, or sim-
ilar. These can overheat and are a fire hazard.
 In the case of commercial use, all relevant national provisions and
regulations (DGUV in Germany) relating to accident insurance are ap-
plicable to this machine. It is recommended to carry out testing in
accordance with national regulations (e.g. the regulatory framework
described in DGUV100-500/Chapter 2.6/Section 4). The test book
required for the documentation is available from Miele.
 The machine must not be used in a non-stationary location (e.g.
on a ship).
 Please observe the instructions in “Installation” and “Technical
data”.
 If the washing machine is equipped with an electrical plug con-
nection, it must be easily accessible after installation so that the ma-
chine can be disconnected from the electricity supply if necessary.

Warning and safety instructions
11
 If the appliance is hard wired, an on-site all pole circuit breaker
must always be accessible to disconnect the washing machine from
the mains.
 This washing machine is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical res-
istance, abrasion resistance and vibration). This special lamp must
only be used for the purpose it is intended for. It is not suitable for
room lighting. Replacement lamps may only be fitted by a Miele au-
thorised person or the Miele Service Department.
 Reliable and safe operation of this washing machine can only be
assured if it has been correctly connected to the mains electricity
supply.
Correct use
 The maximum dry laundry weight is 7.0kg. The maximum recom-
mended loads for individual programmes are given in the Programme
chart.
 Do not install your washing machine in a room where temperat-
ures below freezing may occur. Frozen hoses may burst or split. The
reliability of the electronic control unit may be impaired at temperat-
ures below freezing point.
 Before using the machine for the first time, check that the transit
bars at the rear of the washing machine have been removed (see “In-
stallation – Removing transit bars”). During spinning, transit bars
which are still in place may result in damage to both the machine
and adjacent furniture or appliances.
 Close the stopcock if the machine is to be left for any length of
time (e.g. while on holiday), especially if there is no floor drain (gully)
in the immediate vicinity.

Warning and safety instructions
12
 Danger of flooding! If hooking the drain hose into a wash basin,
check that the water can drain off quickly enough to prevent the sink
from overflowing. Hook the hose over the edge and secure. If the
hose is unsecured, the force of the water flowing out of it can dis-
lodge it from the basin.
 Take care to ensure that foreign objects (e.g. nails, pins, coins, pa-
per clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds con-
tainer, drum). Damaged components can damage the laundry.
 If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
it, only use special non-corrosive descaling agents and strictly ob-
serve the instructions on the packaging. Special descaling agent is
available from your Miele dealer or from Miele Service. Strictly ob-
serve the instructions for the descaling agent.
 For textiles that have been treated with solvent-based detergents,
always check whether they can be washed in a washing machine. To
check whether this is possible, refer to safety notes, information con-
cerning the product's environmental properties, and other informa-
tion.
 Never use solvent based detergents, e.g. those containing ben-
zine, in this machine. Doing so may result in damage to component
parts and create toxic fumes. Risk of fire and explosion.
 Benzine, petrol, paraffin, or any easily flammable liquid must not
be stored or used near the machine. Risk of fire and explosion

Warning and safety instructions
13
 Only use dyes suitable for use in a washing machine. Always ob-
serve the manufacturer's instructions carefully.
 Colour run and dye removers contain sulphur compounds which
can cause damage such as corrosion. Do not use these products in
this washing machine.
 Avoid contact between stainless steel surfaces (front, lid, casing)
and liquid detergents or disinfecting agents which contain chlorine or
sodium hypochlorite. These agents can have a corrosive effect on
stainless steel. Aggressive vapours containing chlorine can also be
corrosive. Do not store open containers of these agents near the ma-
chine.
 Do not use a pressure washer or hose to clean the washing ma-
chine.
 It is particularly important to observe manufacturer's instructions
when using a combination of cleaning agents and special application
products. Products must only be used for applications approved by
the manufacturer to avoid any material damage or the occurrence of
strong chemical reactions.
 If detergent has come into contact with the eyes, rinse out imme-
diately with plenty of lukewarm water. If detergent has accidentally
been ingested, seek medical advice immediately. People with dam-
aged or sensitive skin should avoid contact with detergent.

Warning and safety instructions
14
Accessories
 Accessory parts may only be fitted when expressly approved by
Miele. If other parts are used, warranty, performance, and product li-
ability claims will be invalidated.
 Miele tumble dryers and Miele washing machines can be installed
as a washer-dryer stack. This requires a Miele washer-dryer stacking
kit which can be purchased separately. Please ensure that the
washer-dryer connection kit is suitable for the Miele tumble dryer
and the Miele washing machine.
 If installing the machine on a Miele plinth (available as an optional
accessory), please make sure you order the correct one for this
washing machine.
Miele cannot be held liable for damage caused by non-compliance
with these warning and safety instructions.

Operating the washing machine
15
Fascia panel
aLanguage sensor
For selecting the current user lan-
guage.
The operating language is displayed
again at the end of the programme.
bTouch display with sensors
Displays the selected programme.
The programme settings are selected
using the sensors in the touch dis-
play.
cBack sensor
For going back one level in the menu.
dStart/Stop sensor
For starting the selected programme
and cancelling a programme once it
has started.
eProgramme selector
For selecting the wash programme.
The programme selector can be
turned clockwise or anti-clockwise.
fButton
For switching the washing machine
on and off.
The washing machine switches itself
off automatically to save energy. It is
switched off 15minutes after the end
of the programme/Anti-crease phase,
or after being switched on if no fur-
ther selection is made.

Operating the washing machine
16
Symbols on the fascia panel
Cottons
PRO Cottons PRO
Special programmes
Express
Minimum iron
Delicates
Cottons ECO
/Drain/Spin

Operating the washing machine
17
Symbols on the display

Temperature: use the Temperaturesensor to set the temperature of the
wash programme.

Spin speed: use the Spin speedsensor to set the spin speed of the wash
programme.

Extras: use the Extrassensor to add Extras to a wash programme.

Pre-wash: use the Pre-washsensor to select the Pre-washExtra for a
wash programme.

Pre-ironing: use the Pre-ironingsensor to select the Pre-ironingExtra for
a wash programme.

Soak: use the Soaksensor to can select the SoakExtra for a wash pro-
gramme.

Rinse plus: use the Rinse plussensor to add an additional rinse cycle to
a wash programme.

Further choices: use the Further choicessensor to set further options.

CapDosing: use the CapDosingsensor to dispense detergent via a cap-
sule.

Supervisor level: use the Supervisor levelsensor to alter the washing
machine's settings.

Delay start: use the Delay startsensor to set the starting time of a wash
programme...

...or the finish time

...or the time until the programme starts.

Operating the washing machine
18
Sensor controls and touch dis-
play with sensor controls
The sensor controls ,  and
Start/Stop and the sensor controls in
the display respond to finger tip con-
tact. Every touch of a sensor is con-
firmed with an audible tone. You can
adjust the volume of the keypad tone or
switch it off (see information on “Super-
visor level”).
The control panel with sensor con-
trols and the touch display can be
scratched by pointed or sharp ob-
jects, e.g. pens.
Only touch the display with your fin-
gers.
Main menu
The main menu displays different values
depending on the programme.
For programmes with a fixed temperat-
ure setting:

1600  
Coloured items
60°C h
0:59
– Selected programme with the set
temperature
– Programme duration
– Spin speed set
– Selectable Extras
– Further available options and the set-
tings on the Supervisor level
For programmes with a variable temper-
ature setting:

1000  
Sportswear 0:37 h

60°C
– Selected programme
– Programme duration
– Temperature set
– Spin speed set
– Selectable Extras
– Further available options and the set-
tings on the Supervisor level

Operating the washing machine
19
Examples of how to operate
the appliance
Option lists
The andarrows on the right of the
display indicate that choices are avail-
able.

Language


deutsch
čeština
english
(AU)
dansk
The list scrolls down when the
sensor is touched. The list scrolls up
when the sensor is touched.
The scroll bar indicates that further op-
tions follow.
The currently selected value is marked
with a frame.
Touch the required value to select it.
Easy selection
If there are no arrows, the selection is
limited to the displayed values.

Spin speed
800
1000
400
0
1200 1600
The currently selected value is marked
with a frame.
Touch the required value to select it.
Setting numerical values
To change a numerical value, use the
andarrows above or below the
numbers you want to change.
Finish
(today)


10
OK


25:
Touch theandarrows and confirm
with the OK sensor.
Exiting a sub-menu
Select the Backsensor to exit a sub-
menu.
If you select a value in a sub-menu, but
do not confirm with OK, you can dis-
card this value by touching the
sensor.

Before using for the first time
20
Damage resulting from incorrect
installation and connection.
Installing and connecting the wash-
ing machine incorrectly will cause
serious property damage.
See “Installation”.
Emptying the drum
A swivel elbow for the drain hose and/
or assembly material may be stored in
the drum.
Pull open the door.
Remove the swivel elbow and as-
sembly material.
Shut the door with a gentle swing.
Switching on the washing ma-
chine
Press the control.
The welcome screen will light up.
When commissioning the washing
machine for the first time, you will
have to define settings for daily use
of the appliance. Some settings can
only be configured during the initial
commissioning process. After that,
they must be changed by Miele Ser-
vice.
Complete the initial commissioning
process.
These settings are also described under
“Supervisor level”.
Setting the language
You will be asked to select the language
you require for the display. You can
change the language at any time (see
“Language” under “Supervisor level”).

Language


deutsch
čeština
english
(AU)
dansk
Touch the orsensor until the
language you want appears in the
display.
Touch the sensor for the language
you want.
The selected language is marked with a
frame and the display will change to
next setting.
