Mightymast Leisure RAINBOW User manual

1
RAINBOW
TABLE FOOTBALL GAME
ASSEMBLY INSTRUCTIONS
Please keep for future reference
Adult Assembly Required
(0316)

2
ASSEMBLY INSTRUCTIONS
Please keep these instructions for future reference. Adult assembly required.
This table is not a toy & is intended for use by or under the supervision of adults.
Please do not sit, climb or lean on the table.
A waterproof cover (sold separately) will enhance the life of the table if it is to be used outside all
year round.
Parts Identifier
1. Find a clean & level place to begin the assembly of your RAINBOW table football game. You
will need a Phillips screwdriver, a 13mm & a 17mm spanner & a hammer. Remove all parts
from the box & save all packing materials until the parts have been inspected & the table is
assembled.
2. Attaching the legs – place the table onto the floor facing the correct way up. Open the table,
lift the lid & use the metal lid prop provided to keep the top open. Remove the poles, slopes,
legs & plastic parts bag from inside the table. Close the table & stand it up on its end so that
it can be opened 90 degrees like a book. Important – this should be carried out by 2 adults.
3. Make sure the legs are the correct way round (see below) & then attach the legs into the
slots underneath the table using the bolts, washers & nuts provided. Fit the rubber feet to
the bottom of each of the 4 legs.

3
Insert the coach bolts into the sides of the table & secure on the inside with a large star washer
& then a large nut. The flat head bolts should be inserted underneath the table & secured on
the inside with a washer, then a small star washer & then a small nut. The square neck of the
coach bolt will not fit into the round hole. Tighten the nut so that the neck breaks into the
laminate but do not over-tighten – this will not cause the laminate to crack. The mushroom
head of the coach bolt should just touch the laminate surface.
4. Stand the table up on its legs & prepare to fit the poles. Remove the glass by unscrewing the
3 bolts (use the allen key) at one end of the top. Using gloves to protect your hands, slide out
the glass top. This should be carried out by 2 adults for safety’s sake. The black plastic seals
around the 4 edges of the glass will need to be removed in order for the glass to slide out. If
this is tight the screws on the 2 aluminium side rails (which hold the glass in place) may need
to be removed.
5. Next, slide the thin bars into the thick bars as shown below:
6. Push the bars into the table, pushing the handle-end of the pole through the hole first from
the inside. Do not fit the handles onto the poles at this stage.

4
Then starting from the green score counters end of the table insert the poles as follows:
-Green 1-man pole
-Green 2-man pole
-Silver 3-man pole
-Green 5-man pole
-Silver 5-man pole
-Green 3-man pole
-Silver 2-man pole
-Silver 1-man pole
There should now be 4 poles on each side of the table with the green & silver teams facing
each other.
7. Next, put the rubber washers into the 8 flat-end plastic caps. Push the bearing fitted to the
thin rod into the hole & fit the flat cap from outside, making sure that the ‘legs’ on the inside
bearing line up with the screw holes on the end cap. Secure with 2 screws but do not over-
tighten.
At the handle end of the pole put 2 half-bearings on to the bar from the inside & push into the
hole. Then slide the large bearing onto the end of the pole & line up the ‘legs’ of both the half-
bearings & the large bearing. Insert screws & tighten. Finally hammer on the handles to the
ends of the poles.
8. Carefully put back the glass top & screw down the flat top ends again using the allen key
provided. Ensure the black plastic seals are pushed back into place on all 4 sides of the glass
top. If not already fitted, attach the green & silver score cubes into the flat top ends with the
screws provided. Make sure the ball slopes are fitted inside the table. Finally, fix the ball
catcher to the long side of the table as shown below:

5
You are now ready to play
Cleaning & Maintenance
Use everyday household glass cleaner for both the glass & the laminate surface. A waterproof cover
(sold separately) will enhance the life of the table if it is to be used outside all year round.
