mikroElektronika mikroProg User manual

mikroProg™
mikroProg™is a fast USB programmer with hardware
debugger support. Smart engineering allows mikroProg™to
support all FT90x microcontrollers in a single programmer.
for FT90x

I want to express my thanks to you for being interested in our products and for
having condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic
products and to constantly improve the performance thereof in order to better
suit your needs.
To our valued customers
Nebojsa Matic
General Manager

v

Page 5
Table of Contents
Introduction to mikroProg™6
Key features 7
1. Driver installation 8
step 1 – Start installation 9
step 2 – Accept EULA 9
step 3 – Installing the drivers 10
step 4 – Finish installation 10
2. Connecting to a PC 11
3. mikroProg Suite for FT90x software 12
Software installation wizard 13
4. Connecting with a target device 14
5. Connector Pinout 15
6. Connection schematic example 16

Page 6
mikroProg™for FT90x is a fast programmer and hardware
debugger. Smart engineering allows mikroProg™to support all
FT90x devices in a single programmer! Outstanding performance,
easy operation, elegant design and low price are its top features.
It is supported in all three MikroElektronika compilers for FT90x
(mikroC, mikroBasic, mikroPascal)
Introduction to mikroProg™

Page 7
1Flat cable
2 USB MINIB connector
3 DATA transfer indication LED
4 ACTIVE indication LED
5 LINK indication LED
6 POWER indication LED
Hardware Debugging
No need for rmware update
New microcontrollers
supported via latest version
of mikroProg Suite™for
FT90x software
What you see
Key features
1
2
3
4
5
6
∫
∫
∫

Page 8
1. Driver installation
NOTE: Make sure to disconnect mikroProg™before installing drivers.
When you download the drivers, please extract les from the ZIP
archive. Folder with extracted les contains folders with drivers
for dierent operating systems. Depending on which operating
system you use, choose the adequate folder and open it.
When you locate the drivers, please extract the setup le from the
ZIP archive. You should be able to locate the driver setup le. Double
click the setup le to begin installation of the programmer drivers.
On-board mikroProg™requires drivers in order to work.
Drivers can be found on the link bellow:
www.mikroe.com/downloads/get/2216/
mikroprog_suite_for_ft90x_drivers.zip
mikroprog_suite_for_ft90x_drivers.zip
WinRAR ZIP archive

Page 9
step 1 – Start installation step 2 – Accept EULA
1In welcome screen click the Next> button 2 Accept EULA and click Next
1 2

Page 10
step 3 – Installing the drivers step 4 – Finish installation
3Drivers are installed automatically 4Click the Finish button to end installation process
4
