mikroElektronika Ready for XMEGA User manual

Ready for XMEGA®
Best solution for fast and simple development
of applications using ATxmega128A1 device.
With special white plastic casing you can
quickly turn your Ready for XMEGA project
into a nal product.
™

Page 3
I want to express my thanks to you for being interested in our products and for having
condence in MikroElektronika.
The primary aim of our company is to design and produce high quality electronic products
and to constantly improve the performance thereof in order to better suit your needs.
TO OUR VALUED CUSTOMERS
Nebojsa Matic
General Manager
The AVR®, XMEGA® and Windows® logos and product names are trademarks of Atmel® and Microsoft® in the U.S.A. and other countries.

Page 3
Introduction 4
Package Contains 5
Key Features 6
1. Power supply 8
2. ATxmega128A1 Microcontroller 10
Key microcontroller features 10
3. Programming the microcontroller 11
Programming with mikroBootloader 12
mikroBootloader software 12
Identifying device COM port 13
step 1 – Choosing COM port 13
step 2 – Establishing connection 14
step 3 – Browsing for .hex le 14
step 4 – Selecting .hex le 15
step 5 – Uploading .hex le 15
step 6 – Progress bar 16
step 7 – Finish upload 16
Programing with JTAG programmer 17
Programing with PDI 18
4. USB-UART 20
5. Prototyping area 21
6. Pin headers 22
7. Reset button 23
8. Piezo buzzer 24
9. Integrating with the casing 25
10. Dimensions 26
Table of Contents

Page 4
Page 5
Ready for XMEGA Board is the best
solution for fast and simple development
of various microcontroller applications.
It comes with ATxmega128A1, and
contains double-row smart headers for all
available microcontroller ports. We have
groupped pins according to their functions,
so you have everything on the silkscreen.
You don’t even have to browse through the
datasheet. Board also contains USB-UART
module, prototyping area and a power
supply circuit. Board is specially designed
to t into special white plastic casing so
you can turn your XMEGA project into a
nal product.
Introduction

Page 4
Page 5
Package Contains
Copyright ©2011 Mikroelektronika.
Allrightsreserved.Mikroelektronika,Mikroelektronika logoandother
Mikroelektronikatrademarks arethepropertyof Mikroelektronika.
Allother tradmarks aretheproperty oftheirrespectiveowners.
Unauthorised copying, hiring, renting, public performance and
broadcasting of this DVD prohibited.
20122011
www.mikroe.com
01 02
04 05
03
06
Damage resistant
protective box
Ready for XMEGA board with
double row male pin headers
Ready for XMEGA
user’s guide
Ready for XMEGA
schematic
DVD with documentation
and examples
USB cable

Page 6
Page 7
Key Features
01
02
03
04
05
06
07
08
09
10
11
12
12
13
14
JTAG connector
Power LED indicator
UART communication LEDs (RX, TX)
Power regulator
FTDI chip
USB UART connector
Power connector
Power screw terminals
Reset button
Double-row pin headers
PDI connection
Prototyping area
ATxmega128A1 microcontroller
Piezo Buzzer
System Specication
power supply
Via AC/DC connector 7-23V AC
or 9-32V DC
board dimensions
141 x 84mm (5.55 x 3.3 inch)
weight
~67g (0.15 lbs)
power consumption
50mA in idle state
(when on-board modules are o)

Page 6
Page 7
01
09
02
10 11 12
03
10
0504 06 07
13
08
10 14

Page 8
Page 9
1. Power supply
Ready for XMEGA board can be powered in two ways: via USB connection, or using external power sources such as adapters and
laboratory power supplies. USB connection can provide up to 500mA of current which is more than enough for every on-board module
and for operation of the microcontroller. If you decide to use external power supply, you can choose between AC/DC adapter connector
or power screw terminals. Voltage values must be within 7-23V AC or 9-32V DC ranges. Power LED (GREEN) will indicate the presence
of power supply. Use only one of suggested methods for powering the board.
Figure 1-1:
AC/DC adapter power supply
connected
Figure 1-2:
laboratory power supply
connected to screw terminals
Figure 1-3:
USB power
supply connected

Page 8
Page 9
8
7
6
5
1
2
3
4
VCC-5V
POWER
R56
2K2
LD1
SWC
SWE
CT
GND
DRVC
IPK
VIN
CMPR
U1
MC34063A
R12
0.22
R10
3K
C21
220pF
D6
MBRS140T3
L2 220uH
E1
330uF/35V
VCC-EXT
R11
1K
VCC-5V
+ -
D1
1N4007
D4
1N4007
D3
1N4007
D5
1N4007
CN4 CN2
E2
330uF/6V
5V SWITCHING POWER SUPPLY
VCC-5V
1
2
3
5
4
VREF-1.8V
C22
2.2uF
VCC-3.3V
E6
10uF
IN
GND
OUT
ENADJ
U5
AP7331-ADJ
R15
120K
R13
22K
R14
12K1
1
3
2
C2
100nF
VCC-5VGND
Vout
Vin
REG1
MC33269DT3.3
E5
10uF
VCC-3.3V
E4
10uF
C1
100nF
C19
100nF
VCC-3.3V AVCC
FP2
FERRITE
C18
100nF
1
2
3
4
VCC
GND
CN3
USB B
VCC-USB
VCC-5V
D2
MBRS140T3
FP1
FERRITE
C10
100nF
1.8V VOLTAGE REGULATOR 3.3V VOLTAGE REGULATOR
Figure 1-4: Power supply schematics

Page 10
Page 11
Ready for XMEGA development system comes with the
ATxmega128A1 microcontroller. Having lots of MIPS power, ash
and RAM, and rich set of inegrated modules, ATxmega128A1 is ideal
choice for both beginners and professionals.
Key microcontroller features
- Up to 32 MIPS Operation;
- 8/16-bit architecture;
- 128KB of Flash memory;
- 8KB of SRAM memory;
- 2048Bytes of EEPROM;
- 78 I/O pins;
- 32kHz RTC;
- 1.6V to 3.6V Operating Voltage (VCC);
- UART, SPI, TWI;
- ADC, DAC, AC; etc.
EVENT ROUTING NETWORK
DATA BUS
DATA BUS
Power/
Reset
Control
AES/DES
Crypto
Support
DMA
Controller
Event
System
Controller
Debug/Prog. interface
BOD
Temp sensor RTC
FLASH
RAM
EEPROM
OSC/CLK
Interrupt Controller EBI
Watchdog Timer
VREF OCD
ADC
DAC
AC
TIMERS/COUNTERS UART/SPI/TWI/ COMMUNICATION
I/O
PORTS
AVR
CPU
2. ATxmega128A1 microcontroller

Page 10
Page 11
Via USB-UART mikroBootloader
Using JTAG external programmer
Using PDI external programmer
Figure 3-1:
ATxmega128A1
3. Programming the microcontroller
01
02
03
The microcontroller can be programmed in three ways:

Page 12
Page 13
Programming with mikroBootloader
You can program the microcontroller with bootloader which is
preprogrammed into the device by default. To transfer .hex le
fromaPC to MCUyou need bootloadersoftware(mikroBootloader
USB HID) which can be downloaded from:
After software is downloaded, unrar it to a desired location, and
start mikroBootloader USB HID software.
http://www.mikroe.com/eng/downloads/get/1271/
mikrobootloader_xmega_v101.zip
note
Figure 3-2: mikroBootloader window
mikroBootloader software
01 When you start mikroBootloader software, a window
shown on Figure 3-2 should appear.
Before starting mikroBootloader software, connect Ready for
XMEGA with a PC using USB cable provided with the package
This version of mikroBootloader is specialized
for ATxmega128A1 chip.
note

Page 12
Page 13
step 1 – Choosing COM port
Figure 3-4: Choosing COM port
01
02
01
Identifying device COM port
Figure 3-3: Identifying COM port
01 Open Device Manager window and expand
Ports section to see which COM port is assigned
to Ready for XMEGA board (in this case COM34)
01
02
03
Click the ”Change Settings” button.
From the drop down list, select appropriate COM port
which is used for communication with a PC
Click OK.
03

Page 14
Page 15
step 2 - Establishing Connection step 3 - Browsing for .HEX le
01
01
Figure 3-5: Connecting with mikroBootloader Figure 3-6: Browse for HEX
01 01
Press ”Reset” button on Ready for XMEGA board and
click ”Connect” button within 5s, otherwise existing
microcontroller program will execute. If connected,
caption on a button will be changed to ”Disconnect”.
Click the ”Browse for HEX” button and from a
pop-up window (Figure 3.7) choose .HEX le
which will be uploaded to MCU memory
note: Baud rate is set to 115200bps by default.

Page 14
Page 15
step 4 - Selecting .HEX le step 5 - Uploading .HEX le
Figure 3-7: Locating and Selecting .hex le Figure 3-8: Begin uploading
01 01
02
Select .HEX le using open dialog window.
Click the ”Open” button.
To start .HEX le bootloding click the
”Begin uploading” button.
01
02 01

Page 16
Page 17
step 7 - Finish upload
01
01
Figure 3-9: Progress bar Figure 3-10: Restarting MCU
01 01
02
You can monitor .HEX le uploading via progress bar. Click ”OK” button after uploading is nished.
Press ”Reset” button on Ready for XMEGA board
and wait for 5 seconds. Your program will execute
automatically.
step 6 - Progress bar

Page 16
Page 17
Ready for XMEGA board contains JTAG connector pads so you can program the board and debug your code using external programer/
debugger. Before connecting the programmer you have to solder the provided IDC10 2x5 male header onto the board’s JTAG connector
pads. If bootloader program is accidentally erased, you can upload it again via AVR JTAG or PDI programmer. Ready for XMEGA Bootloader
Firmware.hex can be found under Firmware folder (see page 12).
Figure 3-12:
connecting JTAG
programmer
Figure 3-11:
placing 10 pin header
Programming with JTAG programmer

Page 18
Page 19
The board is also equipped with PDI connector
pads, which allow you to program the microcontroller
using external serial PDI programmer. Before attaching the
programming connector, you have to solder the provided 2x3 male
header to the board’s PDI connector pads.
Figure 3-14:
Connecting
PDI programmer
Programming with PDI programmer
Figure 3-13:
placing 6 pin header

Page 18
Page 19
PDI
RESET#
VCC-3.3V
PDI
CN8
0 9
8
7
4
3
6
6
5
2
3
4
5 7 0
8 9
2
8
9
0 1
7
1 6
58
57
56
55
54
53
52
72
69
68
67
66
65
64
63
62
61
60
59
71
51
70
75
74
73
78
77
79
80
76 81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
10
9
11
12
4
3
24
23
18
17
16
15
14
13
5
6
7
8
10
1
2
22
21
20
19
25
PB0
PB1
PB2
PB3
PB4/TMS
PB5/TDI
PB6/TCK
PB7/TDO
PC0
PC1
PC2
PC3
PC4
PD1 PD2 PD3 PD4 PD6
PD0
PE0 PE1 PE2
PE3
PE4
PE5 PE6 PE7
PF0
PF1 PF2 PF3
PF4
PF5
PF7
PF6
PH7
PH6
PH5
PH4
PH3
PH2
PH1
PH0
PJ7
PJ6
PJ5
PJ4
PJ3
PJ2
PJ1
PJ0
PK7
PK6
PK5 PK4
PK3
PK2
PK1
PK0
PR1 PR0
RESET#
PDI
PQ3 PQ2
PQ1/TOSC2
PQ0/TOSC1
PA5
VREF-1.8V
PA4 PA1 PA3 PA2
PA6
PA7
PC6
R1 27 R2 27
R3
27
R4
27
PD5 PD7
PC5
PC7
3 2 2 2 3 3 4 3 3 4 4 4 4 3 5 4 4 3 3 3 4 4 4 3 2
ATxmega128A1
0
PE0 VCC GND
PD7
PE7 PE6
PB0
PB1
PB2
PB3
PJ4
PJ3
PJ2
PH2
VCC GND
GND
VCC
PH0
PH1
PF0
PF1
XTAL2/PR0
RESET/PDI
PDI
GND
PQ3 PQ2
GND
VCC
AVCC
GND
PA3 PA2 PA1 PA0
AVCC
XTAL1/PR1
PB7
PD3
GND
PC7
PC6
PC5
PC4
PC3
PJ6
PJ5
PF7
PF6
VCC
PB6
PB5
PE3
PA4
PA5
PA6
PA7
PD2
PD1
PD0
VCC
PF4
PF5
PJ1
PH6
PF2
PF3
PH3
PE4 PE2
PH4
PH7
TOSC2/PQ1
PC2
PC1
PC0
PE1 PE5
PH5
PJ0
TOSC1/PQ0
PD6 PD5 PD4
GND
PB4
GND
VCC
PJ7
PK3
PK1
GND
VCC
PK0
PK2 PK4 PK5
PK6
PK7
U4
VCC-3.3VAVCC
JTAG
CN6
RESET#
PB6/TCK
PB7/TDO
PB4/TMS
PB5/TDI
VCC-3.3VVCC-3.3V
X2
32.768kHz
C422pF
C322pF
PQ1/TOSC2
PQ0/TOSC1
VCC-3.3V VCC-3.3V VCC-3.3V VCC-3.3V
VCC-3.3V VCC-3.3V VCC-3.3V VCC-3.3V
C6
100nF
C11
100nF
C12
100nF
C13
100nF
C14
100nF
C15
100nF
C16
100nF
C17
100nF
Decoupling
capacitors
Figure 3-15: PDI & JTAG programmer connection schematics

Page 20
Page 21
1
2
3
4
5
6
7
8
9
10
11
12
13
14 15
16
17
18
19
20
21
22
23
24
25
26
27
28
C10
100nF
C8
100nF
VCC-5VVCC-5VVCC-5V
RX-LED
TX-LED
PC2
PC3
RX-MCU
TX-MCU
VCC-FTDI
D2
MBRS140T3
FP1
FERRITE
VCC-3.3V
LD2 LD3
R57
2K2
R58
2K2
RX TX
1
2
3
4
VCC
GND
D-
D+
CN3
USB B
TXD
DTR#
RTS#
VCCIO
RXD
RI#
GND
NC
DSR#
DCD#
CTS#
CBUS4
CBUS2
CBUS3
CBUS0
CBUS1
OSCO
OSCI
TEST
AGND
NC
GND
GND
VCC
RESET#
3V3OUT
USBDM
USBDP
FT232RL
U2
FT232RL
VCC-USB
USBDP
USBDM
J2
J3
DATA BUS
C5
100nF
C9
100nF
E3
10uF
VCC-3.3V VCC-FTDIVCC-FTDI
4. USB-UART
Figure 4-2:
USB-UART schematics
Fast on-board FTDI® chip allows you to communicate
with a PC or other UART devices using USB-UART connection.
USB-B connector (CN3) is used for connecting the USB cable. RX
(receive) and TX (transmit) LEDs will indicate communication status.
Before conecting the board with the PC, make sure to have the
appropriate FTDI drivers installed on your operating system.
Drivers can be found at following URL: Figure 4-1:
USB-UART connected
http://www.ftdichip.com/Drivers/VCP.htm
