mikroElektronika microSD Click User manual

1. Introduction
Need more additional memory? We’ve got
just the thing for you. microSD Click is an
accessory board in mikroBus™form factor. It
features a microSD card slot for microSD cards
used as a mass storage media for portable
devices. Industry standard SPI interface
ensures simple communication at high data
rates. Use it for reading or storing data like
music, text les, videos and more. Board is
designed to use 3.3V power supply only.
On board ferrite voltage supply lter ensures
stable operation.
Once you have soldered the headers your
board is ready to be placed into desired
mikroBUS™ socket. Make sure to align the
cut in the lower-right part of the board
with the markings on the silkscreen at the
mikroBUS™ socket. If all the pins are aligned
correctly, push the board all the way
into the socket.
3. Plugging the board in
2 3
2. Soldering the headers
1
4. Using microSD Cards
Board contains the slot for standard
microSD cards. Once power is turned on,
power LED will indicate that board is in
operation. Data is read and written to the
card using industry standard SPI interface.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down, so that
bottom side is facing you upwards. Place
shorter parts of the header pins in the
both soldering pad locations.
microSD click
Front and back side appearance
of the microSD click Board
Before using your click board, make sure
to solder the provided 1x8 male headers
to both sides of the board. Two 1x8 male
headers are included with the board in
the package.
click
BOARD
www.mikroe.com
microSD click Manual
ver. 1.00
0 100000 019979
Downloaded from Arrow.com.

8. Support
MikroElektronika oers Free Tech Support
(www.mikroe.com/esupport) until the
end of product lifetime, so if something goes
wrong, we are ready and willing to help!
7. Code Examples
.com
Once you have done all the necessary
preparations, it’s time to get your click
board up and running. We have provided
the examples for mikroC, mikroBasic and
mikroPascal compilers on our Libstock
website. Just download them and you are
ready to start.
6. Power supply - 3.3V only
Board is designed to use
3.3V power supply only. If
you need to add MMC/SD
feature to your 5V prototype
or development board, we recommend you
to use other boards such as the MMC/SD
Accessory Board:
http://www.mikroe.com/eng/products/
view/138/mmc-sd-board/
5. microSD click Board Schematics
C1
100nF
R3
2K2
E1
100uF/20V
CD#
CS
1
Din
2
+3.3V
4
SCK
5
GND
6
Dout
7
CD
G
CS
Din
+3.3V
SCK
GND
Dout
CD
GND
CN2
R1 100K R2 100K
PWR
VCC
FP1
FERRITE
+3V3
AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
SDO
SCK
SDI
CS#
CD#
+3V3
SDO
SCK
SDI
CS#
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specication and information contained in the present schematic are subject to change at any time without notice. Copyright © 2012 MikroElektronika. All rights reserved.
