Millennium USB-RS485 ISO User manual

USB TO SERIAL CONVERTER
MODEL: USB-RS485 ISO
USER MANUAL
VER 1.0
MILLENNIUM TECHNOLOGIES
440, MASTER MIND 1,
ROYAL PALMS ESTATE’
AAREY MILK COLONY,
GOREGAON (EAST),
MUMBAI –400065,
INDIA.
PH: - 91-22-65229736,
91-22-28794703

TABLE OF CONTENTS
1. INTRODUCTION...........................................................................................................................1
1.1. PRODUCT DESCRIPTION.......................................................................................... 1
1.2. FEATURES.................................................................................................................. 1
1.3. SPECIFICATIONS....................................................................................................... 1
1.4. CONNECTION DETAILS............................................................................................. 2
2. DRIVER INSTALLATION...........................................................................................................3
3. HARDWARE INSTALLATION...................................................................................................6

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 1
1. INTRODUCTION
1.1. PRODUCT DESCRIPTION
The USB-RS485 ISO converter allows you to connect legacy serial devices with RS485
half-duplex interface to the USB port. It adds COM port to your computer. It provides
isolated output with 2-pin terminal block connector for RS485 communications and USB-A
plug is provided for USB communications.
1.2. FEATURES
USB 2.0 compatible.
WHQL Certified device drivers
Installs as standard Windows COM port
Windows support includes XP / Server 2003 / Vista / Server 2008 / Windows 7 /
Windows 8 / Windows 8.1 (32/ 64-bit), Server 2008 R2 and Server 2012
Bus Powered –no external power supply required
Hot swap function supported
TX and RX LEDs to provide a visual indication of data traffic
1.3. SPECIFICATIONS
Serial Communication
Interface
RS485
No. of Ports
1
Connector
2-pin Terminal block
Signals
TX+, TX-
Baud-rate
300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 14400,
19200, 38400, 57600, 115200, 230400, 460800, 921600
Flow-control
XON/XOFF, None
Data bit
7, 8
Stop bit
1, 2
Parity
None, Odd, Even, Mark, Space
Protection
2.5kV Isolation
USB
No. of Ports
1
Connector
Type A

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 2
LED Indication
TX
Blinks when converter is transmitting the data
RX
Blinks when converter is receiving the data
Dimensions
L x W x H
89x23x17 mm
1.4. CONNECTION DETAILS
Connector
Description
USB
To connect Device to Computer using Standard USB
cables
TX+ TX-
Terminal block
Terminal block signal details
Pin No.
Signal Name
Description
1
TX+
Data+
2
TX-
Data-

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 3
2. DRIVER INSTALLATION
When setting up this converter for the first time, you have to install the device drivers before
connecting the converter to your computer.
Please proceed with the following steps to install the device driver:
1. Please insert the CD as bound with USB-RS485 ISO converter into your CD/DVD ROM,
and run the "CDM v (latest version) WHQL Certified.exe" file locate within the CD driver.
Run as administrator. Click ‘Extract’ button to proceed.

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 4
2. Click ‘Next’ to proceed.
3. Wait while the device drivers are being installed.

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 5
4. Once installation is complete, Windows will notify you that it has finished installing the
software. Click ‘Finish’ to close the installation wizard.
Checking the device driver installation
1. Connect the USB-RS485 ISO converter to the USB port of computer.
2. Go to “Control Panel” “Device Manager”. You can see the list of all hardware devices
installed on your computer.
3. If you see “USB Serial Port” listed under “Ports (COM & LPT)” and “USB Serial
Converter” listed under “Universal Serial Bus Controllers”, Installation is complete!

USB-RS485-ISO User Manual V1.0 Millennium Technologies
March 30, 2016 6
3. HARDWARE INSTALLATION
Step 1: Connect USB port of the converter to the USB port of computer.
After connecting the USB to serial converter, then a message as “Installing
Device Driver Setup” will pop-up on screen. However, the device driver needs to
be installed in computer in advance.
Step 2: Connect the Serial device to the converter using serial cable.
