Miller Edge MLC-K36 User manual

2-1. Unpack the tube and identify which stick is the Emitter (2
wires) and which is the Receiver (4 wires). The Receiver
typically mounts on the same side as the operator.
2-2. Identify the preferred location, usually close to the door
tracks on the inside of the door opening.
2-3. Attach the brackets to any available mounting points, using
the screws provided or other appropriate hardware. One
bracket should go approximately 6” below the top and another
6”above the bottom of the sticks. For the 6-foot sticks, an
additional bracket should be added in the middle.
2-4. Make sure the brackets are all in-line. The functional
operating distance between Emitter and Receiver is
between 6 feet and 33 feet.
2-5. Press the sticks into the brackets. The flat surface should
be facing across the door opening so that the sticks are
pointing at each other and the bottoms are resting on the floor.
2-6. Wire the sticks to the operator. A total of six (6) wires need to
connect at the operator, 2 run from the Emitter and 4 from the
Receiver. The black and red wires from both sticks will connect
to the accessory power (usually 24VAC or 12VDC). The
Green and White wires will connect to the photo-eye input (ex:
LMEP & Common). Refer to the electrical connection diagram.
2-7. ote that only one device can be connected to the photo-eye
input on the operator.
2-8. Confirm that the Green LED is O at the bottom of both sticks.
2-9. The Red LED on the receiver indicates either an obstruction or
a mis-alignment. The light curtains have a wide acceptance
angle and should align easily. Test proper operation of the
sticks by standing in the opening and observing the Red LED
turning O .
2-10. Test for proper operation with the operator and door.
P.O. Box 159 • West Grove, PA 19390 • 800-220-3343 • 610-869-4422 • Fax: [phone] • www.milleredge.com
6809 South Harl Ave., Suite A • Tempe, AZ 85283 • 800-887-3343 • 480-755-3565 • Fax: [phone]
MLC-K36/K72_Inst_20150521
Model # MLC-K36/K72
INSTALLATION INSTRUCTIONS
IMPORTANT:
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION.
Pa ts List
Kit Contents:
1. Light Curtain Emitter: 36” or 72”
2. Light Curtain Receiver: 36” or 72”
3. Four or Six Mounting Brackets
4. Hardware Bag
5. Installation Instructions
1-
PART NUMBER MLC-K36 / MLC-K72
2- Installation
The MLC-K36/K72 Light Curtain is a UL approved light curtain that can be used in place of a monitored photo-eye.
It provides additional protection for the area above the floor, protecting people and vehicles more effectively than
a single-beam eye.
Monitored Light Curtain
Receive (left) Emitte ( ight)
Mounting B ackets
Emitter Receiver
ELECTRICAL CONNECTION:
Light Curtain
12/24 VAC/DC
12/24 VAC/DC
Photo Eye
Low Volt.
Common
Red
Black
Green
White
Red
Black
Operator
MLC-K36_K72_Inst_20150521.qxp_WPE Instuctions 5/21/15 8:57 AM Page 1

3- Technical Specifications
Po er Requirements: 12-24V (10VDC minimum), 100mA max
Pulse Output: 325Hz, 15%, nominal
Range: 33 feet max., 6 feet min
Detector Wavelength: 880nm (Infrared)
Indicator Lights: Green LED for Power, Red LED for Fault
Dimensions: 1.0” x 1.1”, 38” or 74” tall
4- UL-325 Compliance
The MLC-K36 and MLC-K72 are approved for use as external entrapment
protection devices for garage doors. When installed as directed, they meet the
UL-325 requirements.
P.O. Box 159 • West Grove, PA 19390 • 800-220-3343 • 610-869-4422 • Fax: [phone] • www.milleredge.com
6809 South Harl Ave., Suite A • Tempe, AZ 85283 • 800-887-3343 • 480-755-3565 • Fax: [phone]
MLC-K36/K72_Inst_20150521
5- FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which may be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
1- Re-orient or relocate the receiver antenna
2- Increase the separation between the equipment and the receiver
3- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4- Consult the dealer or an experienced radio/TV technician for help.
Changes or Modifications ot Expressly Approved By The Party Responsible For Compliance Could Void
The User’s Authority To Operate The Equipment.
