Miller ENPAK User manual

)
EnPak
Description
OM-240 113S
2012−10
Visit our website at
www.EnPak.com
File: Mobile Utility
Mobile Utility Unit With Air Compressor,
Hydraulic Pump, And Auxiliary Power
Capability
)

Miller Electric manufactures a full line
of welders and welding related equipment.
For information on other quality Miller
products, contact your local Miller distributor to receive the latest full
line catalog or individual specification sheets. To locate your nearest
distributor or service agency call 1-800-4-A-Miller, or visit us at
www.MillerWelds.com on the web.
Thank you and congratulations on choosing EnPak®by Miller. Now
you can get the job done and get it done right. We know you don’t have
time to do it any other way.
That’s why when Niels Miller first started building arc welders in 1929,
he made sure his products offered long-lasting value and superior
quality. Like you, his customers couldn’t afford anything less. Miller
products had to be more than the best they could be. They had to be the
best you could buy.
Today, the people that build and sell Miller products continue the
tradition. They’re just as committed to providing equipment and service
that meets the high standards of quality and value established in 1929.
This Owner’s Manual is designed to help you get the most out of your
Miller products. Please take time to read the Safety precautions. They
will help you protect yourself against potential hazards on the worksite.
We’ve made installation and operation quick
and easy. With Miller you can count on years
of reliable service with proper maintenance.
And if for some reason the unit needs repair,
there’s a Troubleshooting section that will
help you figure out what the problem is. The
parts list will then help you to decide the
exact part you may need to fix the problem.
Warranty and service information for your
particular model are also provided.
Miller is the first welding
equipment manufacturer in
the U.S.A. to be registered to
the ISO 9001 Quality System
Standard.
From Miller to You
EnPak_Thank 2011−09

TABLE OF CONTENTS
SECTION 1 −SAFETY PRECAUTIONS −READ BEFORE USING 1................................
1-1. Symbol Usage 1.......................................................................
1-2. Engine Hazards 1.....................................................................
1-3. Hydraulic Hazards 2...................................................................
1-4. Compressed Air Hazards 3..............................................................
1-5. Additional Symbols For Installation, Operation, And Maintenance 4............................
1-6. California Proposition 65 Warnings 5......................................................
1-7. Principal Safety Standards 5............................................................
SECTION 2 −CONSIGNES DE SÉCURITÉ −LIRE AVANT UTILISATION 6..........................
2-1. Signification des symboles 6............................................................
2-2. Dangers existant en relation avec le moteur 6..............................................
2-3. Dangers liés à l’hydraulique 7............................................................
2-4. Dangers liés à l’air comprimé 8..........................................................
2-5. Dangers supplémentaires en relation avec l’installation, le fonctionnement et la maintenance 9.....
2-6. Proposition californienne 65 Avertissements 10..............................................
2-7. Principales normes de sécurité 10.........................................................
SECTION 3 −DEFINITIONS 12.................................................................
3-1. Symbol Definitions 12...................................................................
SECTION 4 −SPECIFICATIONS 12..............................................................
4-1. Auxiliary Power And Engine Specifications 12...............................................
4-2. Air Compressor Specifications 12.........................................................
4-3. Hydraulic Specifications (Models With Hydraulic Power Source) 12.............................
4-4. Sound Level Table 12...................................................................
4-5. Dimensions, Weights, and Operating Angles 13..............................................
4-6. Fuel Consumption Curves 14.............................................................
4-7. Auxiliary Power Curves 15...............................................................
4-8. Alternator Power Curve 15...............................................................
4-9. Air Compressor Curves 16...............................................................
4-10. Hydraulic Pressure Curves (Models With Hydraulic Power Source) 17..........................
SECTION 5 −PRESTART CHECKS 18...........................................................
5-1. Hydraulic System Prestart Checks (Models With Hydraulic Power Source) 18....................
5-2. Engine Prestart Checks 18...............................................................
5-3. Compressor Prestart Checks 19..........................................................
SECTION 6 −OPERATION 20..................................................................
6-1. Remote Panel (Use With Section 6-2) 20...................................................
6-2. Remote Panel Operation (Use With Section 6-1) 21..........................................
6-3. Safety Interlock 21......................................................................
6-4. Operation And Error Messages 22.........................................................
6-5. Auto Start/Stop Operation 23.............................................................
6-6. Cold Weather Starting And Operation 24...................................................
6-7. Service Panel 26.......................................................................
6-8. Hydraulic Pump Operation (Models With Hydraulic Power Source) 27...........................
SECTION 7 −COMPRESSOR OPERATION 28....................................................
7-1. Air Compressor Controls 28..............................................................
7-2. Compressor Blow Down 29..............................................................
SECTION 8 −MAINTENANCE 30...............................................................
8-1. Maintenance Label 30...................................................................
8-2. Routine Maintenance 31.................................................................
8-3. Servicing Engine Air Cleaner 33...........................................................
8-4. Safety Interlock Monthly Check (Models With Hydraulic Power Source) 33.......................

TABLE OF CONTENTS
8-5. Changing Engine Oil, Oil Filter, And Fuel Filters 34...........................................
8-6. Engine Sensors And Governor Locations 35................................................
8-7. Changing Compressor Oil, Air Cleaner, And Air/Oil Separator 36...............................
SECTION 9 −TROUBLESHOOTING 37..........................................................
9-1. Generator Power Troubleshooting 37......................................................
9-2. Engine Troubleshooting 37...............................................................
9-3. Compressor Troubleshooting 38..........................................................
9-4. Hydraulic Troubleshooting (Models With Hydraulic Power Source) 39...........................
SECTION 10 −AUTHORIZED DEALER INSTALLATION INFORMATION 41...........................
10-1. Serial Number And Rating Label Location 41................................................
10-2. Installing Unit 41........................................................................
10-3. Mounting Unit 42.......................................................................
SECTION 11 −HYDRAULIC SYSTEM PREPARATION (MODELS WITH HYDRAULIC POWER SOURCE) . . .
43
11-1. Hydraulic System Integration 43...........................................................
11-2. Hydraulic Hose Connections 45...........................................................
11-3. Priming Hydraulic Pump 46...............................................................
11-4. Load Sense Line Bleeding (Closed Center Systems Only) 47..................................
SECTION 12 −ENGINE PREPARATION 48.......................................................
12-1. Connecting the Battery 48................................................................
12-2. Installing Exhaust Pipe 49................................................................
12-3. Fuel Connections 50....................................................................
SECTION 13 −AIR COMPRESSOR SYSTEM PREPARATION 51....................................
13-1. Air Compressor System Integration 51.....................................................
13-2. Compressor Connections 52.............................................................
13-3. Compressor Safety Valve Testing 53.......................................................
SECTION 14 −REMOTE DEVICES CONNECTIONS 54............................................
14-1. Remote Devices Connections 54..........................................................
SECTION 15 −AUXILIARY POWER SYSTEM CONNECTIONS 55...................................
15-1. Grounding Auxiliary Power System To Truck Frame 55.......................................
15-2. Auxiliary Power System Connections And Overload Protection 56..............................
SECTION 16 −DIAGRAMS 58..................................................................
SECTION 17 −GENERATOR POWER GUIDELINES 65............................................
SECTION 18 −PARTS LIST 72.................................................................

OM-240 113 Page 1
SECTION 1 −SAFETY PRECAUTIONS −READ BEFORE USING
Enpak_2011−10
Protect yourself and others from injury — read, follow, and save these important safety precautions and operating instructions.
1-1. Symbol Usage
DANGER! −Indicates a hazardous situation which, if
not avoided, will result in death or serious injury. The
possible hazards are shown in the adjoining symbols
or explained in the text.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury. The possible
hazards are shown in the adjoining symbols or ex-
plained in the text.
NOTICE −Indicates statements not related to personal injury.
.Indicates special instructions.
This group of symbols means Warning! Watch Out! ELECTRIC
SHOCK, MOVING PARTS, and HOT PARTS hazards. Consult sym-
bols and related instructions below for necessary actions to avoid the
hazards.
1-2. Engine Hazards
The symbols shown below are used throughout this manual
to call attention to and identify possible hazards. When you
see the symbol, watch out, and follow the related instructions
to avoid the hazard. The safety information given below is
only a summary of the more complete safety information
found in the Safety Standards listed in Section 1-7. Read and
follow all Safety Standards.
Only qualified persons should install, operate, maintain, and
repair this unit.
During operation, keep everybody, especially children, away.
BATTERY EXPLOSION can injure.
DAlways wear a face shield, rubber gloves, and
protective clothing when working on a battery.
DStop engine before disconnecting or connect-
ing battery cables, battery charging cables (if
applicable),or servicing battery.
DDo not allow tools to cause sparks when working on a battery.
DDo not use this unit to charge batteries or jump start vehicles un-
less it has a battery charging feature designed for this purpose.
DObserve correct polarity (+ and −) on batteries.
DDisconnect negative (−) cable first and connect it last.
DKeep sparks, flames, cigarettes, and other ignition sources
away from batteries. Batteries produce explosive gases during
normal operation and when being charged.
DFollow battery manufacturer’s instructions when working on or
near a battery.
BATTERY CHARGING OUTPUT can injure.
(Battery charging feature not present on all models.)
DHave only qualified persons do battery charging work.
DCharge lead-acid batteries only. Do not use battery charger to
supply power to an extra-low-voltage electrical system or to
charge dry cell batteries.
DDo not charge a frozen battery.
DDo not use damaged charging cables.
DDo not charge a battery that has loose terminals or one showing
damage such as a cracked case or cover.
DBefore charging battery, select correct charger voltage to match
battery voltage.
DSet battery charging controls to the Off position before connect-
ing to battery. Do not allow battery charging clips to touch each
other.
DKeep charging cables away from vehicle hood, door, or moving
parts.
FUEL can cause fire or explosion.
DStop engine and let it cool off before checking or
adding fuel.
DDo not add fuel while smoking or if unit is near
any sparks or open flames.
DDo not overfill tank — allow room for fuel to expand.
DDo not spill fuel. If fuel is spilled, clean up before starting engine.
DDispose of rags in a fireproof container.
DAlways keep nozzle in contact with tank when fueling.
MOVING PARTS can injure.
DKeep away from moving parts such as fans,
belts, and rotors.
DKeep all doors, panels, covers, and guards
closed and securely in place.
DStop engine before installing or connecting unit.
DHave only qualified persons remove doors, panels, covers, or
guards for maintenance and troubleshooting as necessary.
DTo prevent accidental starting during servicing, disconnect
negative (−) battery cable from battery.
DKeep hands, hair, loose clothing, and tools away from moving
parts.
DReinstall doors, panels, covers, or guards when servicing is
finished and before starting engine.
DBefore working on generator, remove spark plugs or injectors to
keep engine from kicking back or starting.
DBlock flywheel so that it will not turn while working on generator
components.
EXHAUST SPARKS can cause fire.
DDo not let engine exhaust sparks cause fire.
DUse approved engine exhaust spark arrestor in
required areas — see applicable codes.
HOT PARTS can burn.
DDo not touch hot parts bare handed.
DAllow cooling period before working on equip-
ment.
DTo handle hot parts, use proper tools and/or
wear heavy, insulated welding gloves and
clothing to prevent burns.

OM-240 113 Page 2
STEAM AND HOT COOLANT can burn.
DIf possible, check coolant level when engine is
cold to avoid scalding.
DAlways check coolant level at overflow tank, if
present on unit, instead of radiator (unless told
otherwise in maintenance section or engine
manual).
DIf the engine is warm, checking is needed, and there is no over-
flow tank, follow the next two statements.
DWear safety glasses and gloves and put a rag over radiator cap.
DTurn cap slightly and let pressure escape slowly before
completely removing cap.
BATTERY ACID can BURN SKIN and EYES.
DDo not tip battery.
DReplace damaged battery.
DFlush eyes and skin immediately with water.
Using a generator indoors CAN KILL
YOU IN MINUTES.
DGenerator exhaust contains carbon monoxide.
This is a poison you cannot see or smell.
DNEVER use inside a home or garage, EVEN IF
doors and windows are open.
DOnly use OUTSIDE and far away from windows, doors, and
vents.
ENGINE HEAT can cause fire.
DDo not locate unit on, over, or near combustible
surfaces or flammables.
DKeep exhaust and exhaust pipes way from
flammables.
1-3. Hydraulic Hazards
HYDRAULIC EQUIPMENT can injure
or kill.
DIncorrect installation or operation of this unit
could result in equipment failure and personal
injury. Only qualified persons should install, op-
erate, and service this unit according to its
Owner’s Manual, industry standards, and na-
tional, state, and local codes.
DDo not exceed the rated output or capacity of the hydraulic pump
or any equipment in the hydraulic system. Design hydraulic sys-
tem so failure of any hydraulic component will not put people or
property at risk.
DBefore working on hydraulic system, turn off and lockout/tagout
unit, release pressure, and be sure hydraulic pressure cannot be
accidentally applied.
DDo not work on hydraulic system with unit running unless you are
a qualified person and following the manufacturer’s instructions.
DDo not modify or alter hydraulic pump or manufacturer-supplied
equipment.Do not disconnect, disable, or override any safety
equipmentin the hydraulic system.
DUse only components/accessories approved by the manufac-
turer.
DKeep away from potential pinch points or crush points created by
equipmentconnected to the hydraulic system.
DDo not work under or around any equipment that is supported
only by hydraulic pressure. Properly support equipment by
mechanical means.
MOVING PARTS can injure.
DKeep away from moving parts such as fans,
belts and rotors.
DKeep all doors, panels, covers, and guards
closed and securely in place.
DKeep hands, hair, loose clothing, and tools away from moving
parts.
DBefore working on hydraulic system, turn off and lockout/tagout
unit, release pressure, and be sure hydraulic pressure cannot be
accidentally applied.
DHave only qualified people remove guards or covers for maint-
enance and troubleshooting as necessary.
DReinstall doors, panels, covers, or guards when servicing is
finished and before starting engine.
HYDRAULIC FLUID can injure or kill.
DBefore working on hydraulic system, turn off and
lockout/tagoutunit, release pressure, and be sure
hydraulic pressure cannot be accidentally applied.
DRelieve pressure before disconnecting or con-
necting hydraulic lines.
DCheck hydraulic system components and all con-
nections and hoses for damage, leaks, and wear
before operating unit.
DWear protective equipment such as safety
glasses, leather gloves, heavy shirt and trousers,
high shoes, and a cap when working on hydraulic
system.
DUse a piece of paper or cardboard to search for leaks−−never use
bare hands. Do not use equipment if leaks are found.
DHYDRAULIC FLUID is FLAMMABLE−−do not work on hydraulics
near sparks or flames; do not smoke near hydraulic fluid.
DReinstall doors, panels, covers, or guards when servicing is
finished and before starting unit.
DIf ANY fluid is injected into the skin, it must be surgically removed
within a few hours by a doctor familiar with this type of injury or gan-
grene may result.
HOT PARTS AND FLUID can burn.
DDo not touch hot parts bare handed or allow hot
fluid to contact skin.
DAllow cooling period before working on equip-
ment.
DTo handle hot parts, use proper tools and/or wear heavy, insu-
lated welding gloves and clothing to prevent burns.
READ INSTRUCTIONS.
DRead and follow all labels and the Owner’s Manu-
al carefully before installing, operating, or servic-
ing unit. Read the safety information at the begin-
ning of the manual and in each section.
DUse only genuine replacement parts from the manufacturer.
DPerform maintenance and service according to the Owner’s
Manuals, industry standards, and national, state, and local
codes.

OM-240 113 Page 3
1-4. Compressed Air Hazards
COMPRESSED AIR EQUIPMENT can
injure or kill.
DIncorrect installation or operation of this unit
could result in equipment failure and personal
injury. Only qualified persons should install, op-
erate, and service this unit according to its
Owner’s Manual, industry standards, and na-
tional, state, and local codes.
DDo not exceed the rated output or capacity of the compressor or
any equipment in the compressed air system. Design compressed
air system so failure of any component will not put people or prop-
erty at risk.
DBefore working on compressed air system, turn off and lockout/
tagout unit, release pressure, and be sure air pressure cannot be
accidentally applied.
DDo not work on compressed air system with unit running unless
you are a qualified person and following the manufacturer’s in-
structions.
DDo not modify or alter compressor or manufacturer-supplied
equipment. Do not disconnect, disable, or override any safety
equipmentin the compressed air system.
DUse only components and accessories approved by the manufac-
turer.
DKeep away from potential pinch points or crush points created by
equipment connected to the compressed air system.
DDo not work under or around any equipment that is supported only
by air pressure. Properly support equipment by mechanical
means.
HOT METAL from air arc cutting and
gouging can cause fire or explosion.
DDo not cut or gouge near flammables.
DWatch for fire; keep extinguisher nearby.
COMPRESSED AIR can injure or kill.
DBefore working on compressed air system,
turn off and lockout/tagout unit, release pres-
sure, and be sure air pressure cannot be acci-
dentally applied.
DRelieve pressure before disconnecting or con-
necting air lines.
DCheck compressed air system components
and all connections and hoses for damage,
leaks, and wear before operating unit.
DDo not direct air stream toward self or others.
DWear protective equipment such as safety glasses, hearing pro-
tection, leather gloves, heavy shirt and trousers, high shoes, and
a cap when working on compressed air system.
DUse soapy water or an ultrasonic detector to search for
leaks−−neveruse bare hands. Do not use equipment if leaks are
found.
DReinstall doors, panels, covers, or guards when servicing is
finished and before starting unit.
DIf ANY air is injected into the skin or body seek medical help im-
mediately.
BREATHING COMPRESSED AIR can in-
jure or kill.
DDo not use compressed air for breathing.
DUse only for cutting, gouging, and tools.
TRAPPED AIR PRESSURE AND WHIPPING
HOSES can injure.
DRelease air pressure from tools and system be-
fore servicing, adding or changing attach-
ments, or opening compressor oil drain or oil fill
cap.
MOVING PARTS can injure.
DKeep away from moving parts such as fans,
belts and rotors.
DKeep all doors, panels, covers, and guards
closed and securely in place.
DKeep hands, hair, loose clothing, and tools away from moving
parts.
DBefore working on compressed air system, turn off and lockout/
tagout unit, release pressure, and be sure air pressure cannot be
accidentally applied.
DHave only qualified people remove guards or covers for maint-
enance and troubleshooting as necessary.
DReinstall doors, panels, covers, or guards when servicing is
finished and before starting engine.
HOT PARTS can burn.
DDo not touch hot compressor or air system
parts.
DAllow cooling period before working on equip-
ment.
DTo handle hot parts, use proper tools and/or wear heavy, insu-
lated welding gloves and clothing to prevent burns.
READ INSTRUCTIONS.
DRead and follow all labels and the Owner’s
Manual carefully before installing, operating, or
servicing unit. Read the safety information at
the beginning of the manual and in each
section.
DUse only genuine replacement parts from the manufacturer.
DPerform maintenance and service according to the Owner’s
Manuals, industry standards, and national, state, and local
codes.

OM-240 113 Page 4
1-5. Additional Symbols For Installation, Operation, And Maintenance
Touching live electrical parts can cause fatal shocks or
severe burns. Machine internal circuits are live when
power is on. Incorrectly installed or improperly
grounded equipment is a hazard.
ELECTRIC SHOCK can kill.
DDo not touch live electrical parts.
DDo not use AC output in damp areas, if movement is confined, or if
there is a danger of falling.
DDisconnect input power or stop engine before installing or
servicing this equipment. Lockout/tagout input power according to
OSHA 29 CFR 1910.147 (see Safety Standards).
DProperly install, ground, and operate this equipment according to
its Owner’s Manual and national, state, and local codes.
DTurn off all equipment when not in use.
DUse only well-maintained equipment. Repair or replace damaged
parts at once. Maintain unit according to manual.
DKeep all panels and covers securely in place.
FIRE OR EXPLOSION hazard.
DDo not install or place unit on, over, or near
combustible surfaces.
DDo not install unit near flammables.
DDo not overload building wiring −be sure power supply system is
properly sized, rated, and protected to handle this unit.
FALLING EQUIPMENT can injure.
DUse lifting eye to lift unit and properly installed
accessories only, NOT gas cylinders. Do not
exceed maximum lift eye weight rating (see
Specifications).
DUse equipment of adequate capacity to lift and
support unit.
DIf using lift forks to move unit, be sure forks are long enough to
extend beyond opposite side of unit.
DKeep equipment (cables and cords) away from moving vehicles
when working from an aerial location.
DFollow the guidelines in the Applications Manual for the Revised
NIOSH Lifting Equation (Publication No. 94−110) when manu-
ally lifting heavy parts or equipment.
OVERHEATING can damage motors.
DTurn off or unplug equipment before starting or
stopping engine.
DDo not let low voltage and frequency caused by
low engine speed damage electric motors.
DDo not connect 50 or 60 Hertz motors to the 100 Hertz receptacle
where applicable.
FLYING SPARKS can injure.
DWear a face shield to protect eyes and face.
DShape tungsten electrode only on grinder with
proper guards in a safe location wearing proper
face, hand, and body protection.
DSparks can cause fires — keep flammables away.
MOVING PARTS can injure.
DKeep away from moving parts.
DKeep away from pinch points such as drive
rolls.
OVERUSE can cause OVERHEATING.
DAllow cooling period; follow rated duty cycle.
DDo not block or filter airflow to unit.
STATIC (ESD) can damage PC boards.
DPut on grounded wrist strap BEFORE handling
boards or parts.
DUse proper static-proof bags and boxes to
store, move, or ship PC boards.
TILTING OF TRAILER can injure.
DUse tongue jack or blocks to support weight.
DProperly install welding generator onto trailer
according to instructions supplied with trailer.
READ INSTRUCTIONS.
DRead and follow all labels and the Owner’s
Manual carefully before installing, operating, or
servicing unit. Read the safety information at
the beginning of the manual and in each
section.
DUse only genuine replacement parts from the manufacturer.
DPerform maintenance and service according to the Owner’s
Manuals, industry standards, and national, state, and local
codes.

OM-240 113 Page 5
1-6. California Proposition 65 Warnings
Welding or cutting equipment produces fumes or gases
which contain chemicals known to the State of California to
cause birth defects and, in some cases, cancer. (California
Health & Safety Code Section 25249.5 et seq.)
Battery posts, terminals and related accessories contain lead
and lead compounds, chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
This product contains chemicals, including lead, known to
the state of California to cause cancer, birth defects, or other
reproductive harm. Wash hands after use.
For Gasoline Engines:
Engine exhaust contains chemicals known to the State of
California to cause cancer, birth defects, or other reproduc-
tive harm.
For Diesel Engines:
Diesel engine exhaust and some of its constituents are
known to the State of California to cause cancer, birth
defects, and other reproductive harm.
1-7. Principal Safety Standards
National Electrical Code, NFPA Standard 70, from National Fire Protec-
tion Association, Quincy, MA 02269 (phone: [phone], website:
www.nfpa.org and www. sparky.org).
Safe Handling of Compressed Gases in Cylinders, CGA Pamphlet P-1,
from Compressed Gas Association, 14501 George Carter Way, Suite
103, Chantilly, VA 20151 (phone: [phone], website:
www.cganet.com).
Battery Chargers, CSA Standard C22.2 NO 107.2−01, from Canadian
Standards Association, Standards Sales, 5060 Spectrum Way, Suite
100, Ontario, Canada L4W 5NS (phone: [phone], website:
www.csa-international.org).
Safe Practice For Occupational And Educational Eye And Face Protec-
tion, ANSI Standard Z87.1, from American National Standards Institute,
25 West 43rd Street, New York, NY 10036 (phone: [phone], web-
site: www.ansi.org).
For Standards about hydraulic systems, contact the National Fluid
Power Association, Publications Department, 3333 North Mayfair
Road, Suite 211, Milwaukee, WI 53222-3219 (phone: [phone],
website: www.nfpa.com).
OSHA, Occupational Safety and Health Standards for General Indus-
try, Title 29, Code of Federal Regulations (CFR), Part 1910, Subpart Q,
and Part 1926, Subpart J, from U.S. Government Printing Office, Super-
intendentof Documents, P.O. Box 371954, Pittsburgh, PA 15250-7954
(phone: [phone]) (there are 10 OSHA Regional Offices—
phone for Region 5, Chicago, is 312-353-2220, website:
www.osha.gov).
Portable Generators Safety Alert, U.S. Consumer Product Safety Com-
mission (CPSC), 4330 East West Highway, Bethesda, MD 20814
(phone: [phone], website: www.cpsc.gov/cpscpub/pubs/port-
gen.pdf
Applications Manual for the Revised NIOSH Lifting Equation, The Na-
tional Institute for Occupational Safety and Health (NIOSH), 1600
Clifton Rd, Atlanta, GA 30333 (phone: [phone], website:
www.cdc.gov/NIOSH).

OM-240 113 Page 6
SECTION 2 −CONSIGNES DE SÉCURITÉ −LIRE AVANT
UTILISATION
Enpak_2011−10_fre
Pour écarter les risques de blessure pour vous−même et pour autrui — lire, appliquer et ranger en lieu sûr ces consignes relatives
aux précautions de sécurité et au mode opératoire.
2-1. Signification des symboles
DANGER! −Indique une situation dangereuse qui si on
l’évite pas peut donner la mort ou des blessures graves.
Les dangers possibles sont montrés par les symboles
joints ou sont expliqués dans le texte.
Indique une situation dangereuse qui si on l’évite pas
peut donner la mort ou des blessures graves. Les dan-
gers possibles sont montrés par les symboles joints ou
sont expliqués dans le texte.
NOTE −Indique des déclarations pas en relation avec des blessures
personnelles.
.Indique des instructions spécifiques.
Ce groupe de symboles veut dire Avertissement! Attention! DANGER
DE CHOC ELECTRIQUE, PIECES EN MOUVEMENT, et PIECES
CHAUDES. Consulter les symboles et les instructions ci-dessous y
afférant pour les actions nécessaires afin d’éviter le danger.
2-2. Dangers existant en relation avec le moteur
Les symboles présentés ci-après sont utilisés tout au long du
présent manuel pour attirer votre attention et identifier les ris-
ques de danger. Lorsque vous voyez un symbole, soyez
vigilant et suivez les directives mentionnées afin d’éviter tout
danger. Les consignes de sécurité présentées ci-après ne
font que résumer l’information contenue dans les normes de
sécurité énumérées à la section 2-7. Veuillez lire et respecter
toutes ces normes de sécurité.
L’installation, l’utilisation, l’entretien et les réparations ne
doivent être confiés qu’à des personnes qualifiées.
Au cours de l’utilisation, tenir toute personne à l’écart et plus
particulièrementles enfants.
L’EXPLOSION DE LA BATTERIE
peut provoquer des blessures.
DToujours porter une protection faciale, des
gants en caoutchouc et vêtements de protec-
tion lors d’une intervention sur la batterie.
DArrêter le moteur avant de débrancher ou de brancher des câbles
de batterie, des câbles de chargeur de batterie (le cas échéant) ou
de batterie d’entretien.
DEviter de provoquer des étincelles avec les outils en travaillant sur
la batterie.
DNe pas utiliser l’appareil pour charger des batteries ou faire dé-
marrer des véhicules à l’aide de câbles de démarrage, sauf si
l’appareildispose d’une fonctionnalité de charge de batterie desti-
née à cet usage.
DObserver la polarité correcte (+ et −) sur les batteries.
DDébrancher le câble négatif (–) en premier lieu. Le rebrancher en
dernier lieu.
DLes sources d’étincelles, flammes nues, cigarettes et autres
sources d’inflammation doivent être maintenues à l’écart des
batteries. Ces dernières produisent des gaz explosifs en
fonctionnementnormal et en cours de charge.
DRespecter les consignes du fabricant de la batterie pour
travailler sur une batterie ou à proximité.
Le COURANT DE CHARGE DE BATTERIE peut
provoquer des blessures (la fonctionnalité de charge de
batterie n’est pas disponible sur tous les modèles).
DLes opérations de charge de batterie ne doivent être effectuées
que par des personnes qualifiées.
DNe charger que des batteries plomb−acide. Ne pas utiliser le
chargeur de batterie pour alimenter un autre circuit électrique
basse tension ou pour charger des batteries sèches.
DNe pas charger une batterie gelée.
DNe pas utiliser de câbles de charge endommagés.
DNe pas charger une batterie dont les bornes sont desserrées ou
présentant une détérioration comme par exemple un boîtier ou un
couvercle fissuré.
DAvant de charger une batterie, sélectionner la tension de charge
correspondant à la tension de la batterie.
DRégler les commandes de charge de batterie sur la position d’arrêt
avant de brancher la batterie. Veiller à ce que les pinces de charge
ne se touchent pas.
DRanger les câbles de charge à distance du capot, des portes et
des pièces mobiles du véhicule.
LE CARBURANT MOTEUR peut pro-
voquer un incendie ou une explosion.
DArrêter le moteur avant de vérifier le niveau de
carburant ou de faire le plein.
DNe pas faire le plein en fumant ou proche d’une source d’étincel-
les ou d’une flamme nue.
DNe pas faire le plein de carburant à ras bord; prévoir de l’espace
pour son expansion.
DFaire attention de ne pas renverser de carburant. Nettoyer tout
carburant renversé avant de faire démarrer le moteur.
DJeter les chiffons dans un récipient ignifuge.
DToujours garder le pistolet en contact avec le réservoir lors du
remplissage.
Les PIÈCES MOBILES peuvent causer
des blessures.
DS’abstenir de toucher des parties mobiles telles
que des ventilateurs, courroies et rotors.
DMaintenir fermés et verrouillés les portes, panneaux,
recouvrements et dispositifs de protection.
DArrêter le moteur avant d’installer ou brancher l’appareil.
DLorsque cela est nécessaire pour des travaux d entretien et de
dépannage, faire retirer les portes, panneaux, recouvrements ou
dispositifs de protection uniquement par du personnel qualifié.
DPour empêcher tout démarrage accidentel pendant les travaux
d’entretien,débrancher le câble négatif (−) de batterie de la borne.
DNe pas approcher les mains, cheveux, vêtements lâches et outils
des organes mobiles.
DRemettre en place les portes, panneaux, recouvrements ou
dispositifs de protection à la fin des travaux d’entretien et avant de
mettre le moteur en marche.
DAvant d’intervenir, déposer les bougies ou injecteurs pour éviter la
mise en route accidentelle du moteur.
DBloquer le volant moteur pour éviter sa rotation lors d’une
interventionsur le générateur.
