Miller Ag-Bag G6170 User manual

MILLER-ST.NAZIANZ,INC.
P.O. BOX 127
ST. NAZIANZ, WI 54232
920/773-2121
FAX:[phone]
OPERATOR'S MANUAL
DO NOT OPERATE THIS EQUIPMENT UNTIL THIS
MANUAL HAS BEEN READ AND UNDERSTOOD.
Part Number: 42.0901734C
February 2013
MODEL: G6170

SOME PHOTOGRAPHS USED HEREIN MAY SHOW DOORS, GUARDS AND
SHIELDS OPENED OR REMOVED. BE SURE THAT ALL DOORS, GUARDS
AND SHIELDS ARE FASTENED IN THEIR PROPER POSITION BEFORE
MACHINE IS OPERATED!
WARNING
INTRODUCTION
This Operator's Manual is provided to acquaint the operator with the safety and operation of the Miller
Ag-Bag 6170 bagger. Complete Assembly, Operation, Lubrication and Maintenance procedures are pro-
vided. Following the recommended procedures will help you achieve many years of dependable service.
This manual is considered part of your machine and should remain with the machine at all times.
Make sure the operator reads and understands the manual before placing the bagger into operation.
Failure to follow the recommended procedures may result in injury and equipment damage, and could
void the warranty.
MACHINE SERIAL NUMBER
The machine serial number is located on the rear frame next to the bag boom tube For your convenience
refer to this number and your product model number when requiring service or parts information. Record
the machine serial number, model number, date of purchase and dealership name in the space provided
below.
Date Purchased
Model No. Serial No.
Right and Left Hand sides are determined from a position standing at the rear (tunnel side) of the unit
looking toward the hitch when in the operating position.
This Operator's Manual uses the term "Tractors" when identifying the power source for the bagger.
The Warranty Registration must be completed by the dealer online to validate your warranty protection.
You must read and understand the places where you attest to having received instructions as to care,
adjustments, safe operation and applicable warranty policy. The terms and conditions of the warranty are
specified on the rear cover of this manual.
Dealership

1
Table Of Contents
AG-BAGGER CHECK LISTS ............................................................................................................. 4
SAFETY PRECAUTIONS................................................................................................................... 5
Power Source Shutdown Procedure............................................................................................. 5
SAFETY DECALS .............................................................................................................................. 8
Reflective Decals.............................................................................................................................. 13
AG-BAGGER COMPONENT LOCATIONS ...................................................................................... 14
SET-UP AND ASSEMBLY ................................................................................................................ 15
Assemble Bag Boom .................................................................................................................. 15
Assemble Tunnel Extension........................................................................................................ 15
Assemble Bag Pan ..................................................................................................................... 16
Prepare the Backstop ................................................................................................................. 17
OPERATION..................................................................................................................................... 19
Pre-Operation Checklist.............................................................................................................. 19
Set The Backstop In Position...................................................................................................... 20
Changing Wheels and Hitch To Bagging Position....................................................................... 22
Hook Tractor To Tow Hitch........................................................................................................... 26
Assemble PTO Shaft To Bagger and Tractor .............................................................................. 26
Connect The Inoculant Applicator (Units so equipped) .............................................................. 28
Bag Identification ........................................................................................................................ 28
Bag Installation ........................................................................................................................... 29
Seal The Beginning End Of The Bag.......................................................................................... 32
Attaching The Backstop.............................................................................................................. 33
Lower Conveyor to Operating Position........................................................................................ 34
Bagging Operation...................................................................................................................... 36
Remove Bagger From Bag ......................................................................................................... 38
Venting The Bag ......................................................................................................................... 39
Changing Bagger To Transport Position...................................................................................... 40
AG-BAGGING INSTRUCTIONS................................................................................................. 49
Bag Information .......................................................................................................................... 52
ADJUSTMENTS............................................................................................................................... 55
Conveyor Chain .......................................................................................................................... 55
Conveyor Drive Chain................................................................................................................. 57
Hydraulic Pump Drive Chain....................................................................................................... 58
Rotor Drive Chain ....................................................................................................................... 59
Continued On Next Page

2
LUBRICATION AND MAINTENANCE .............................................................................................. 60
Tire Air Pressure......................................................................................................................... 60
Wheel Lug Nut Torque ................................................................................................................ 60
Rotor Bearings............................................................................................................................ 60
Rotor Drive Jackshaft Bearings .................................................................................................. 61
Cable Drum Shaft Bearings........................................................................................................ 62
Upper Conveyor Apron Shaft Bearings....................................................................................... 62
Center Conveyor Apron Shaft Bearings...................................................................................... 63
Lower Conveyor Apron Shaft Bearings....................................................................................... 64
Lower Conveyor Clean Out......................................................................................................... 64
PTO Shaft ................................................................................................................................... 65
Bag Boom Pivot .......................................................................................................................... 65
Wheel Bearings .......................................................................................................................... 66
Rotor Drive Chain ....................................................................................................................... 67
Hydraulic Pump Drive Chain....................................................................................................... 67
Gearbox Output Shaft Coupler Chain......................................................................................... 68
Conveyor Drive Chain................................................................................................................. 69
Conveyor Drive Coupler Chain ................................................................................................... 70
Hydraulic Oil ............................................................................................................................... 71
Hydraulic Oil Filter ...................................................................................................................... 74
Gearbox Oil................................................................................................................................. 74
Cable Drum Brake Pads ............................................................................................................. 76
Rotor Tooth Tine Caps ................................................................................................................ 77
Cables......................................................................................................................................... 78
Shear Bolts ................................................................................................................................. 78
Hydraulic Hand Pump................................................................................................................. 79
TROUBLESHOOTING...................................................................................................................... 80
TROUBLESHOOTING (CONTINUED)............................................................................................. 81
STORAGE ........................................................................................................................................ 82
TORQUE SPECIFICATIONS............................................................................................................ 83
Tightening Hydraulic Fittings ...................................................................................................... 84
MACHINE SPECIFICATIONS........................................................................................................... 85
LUBRICATION SPECIFICATIONS ................................................................................................... 86
WARRANTY ..................................................................................................... INSIDE BACK COVER
Table of Contents - continued

3
This Page Intentionally Left Blank

4
Pre-Delivery and Delivery Check Lists (customer and dealer copies) follow this page.
Customer copies can remain with this manual.
Dealer copies can be removed along perforation and remain with dealer.
Ag-Bagger Check Lists

G6170 Ag-Baggers
Dealer Pre-Delivery Check List
After the Bagger has been completely set-up, the following inspections Must be made before delivery to
the customer. Check off each item after prescribed action is taken.
No parts of the unit have been damaged in
shipment. Check for such things as dents, loose or
missing parts and scratches: touch up or replace
components as required.
Wheels are properly attached and tires are
properly inflated:
LT 265 / 75R16 @ 80 PSI
All bolts and fasteners are in place and tightly
secured.
As applicable, the cylinders, hoses and fittings
are NOT damaged, leaking or loosely connected.
The gear box oil is filled to proper level.
Hydraulic oil reservoir is filled to proper level.
Make sure conveyor slides properly, grease if
necessary.
All grease fittings have been properly lubricated
and drive chains oiled; see lubrication chapter in the
owner’s manual.
All guards, shields and decals are in place and
securely attached.
Make sure hitch fits properly in both the transport
and operating positions.
 All chains are properly tightened:
Conveyor drive and driven chain
Rotor drive chain
Hydraulic pump drive chain
 All drive & driven sprockets aligned properly:
Conveyor drive chain sprockets
Rotor drive chain sprockets
Hydraulic pump drive chain sprockets
Brake system properly tightens and releases.
Clean brake rotor before delivery.
Install bungee cord on tunnel & bag pan.
Install back stop hook assembly –see operator’s
manual.
String backstop –see operator’s manual
Bag boom works properly (If so equipped)
Hook the Bagger to the appropriate RPM tractor and test run while checking that proper operation
is exhibited by all components.
Check that:
Transport lights work properly.
PTO Shield turns freely.
All drives and mechanisms are operating
smoothly and properly adjusted.
All hydraulic system components are functioning
properly.
I acknowledge that pre-delivery was performed on this unit as outlined.
___________________________________ ___________________________________
Dealership’s Name Dealer Representative’s Name Date
___________________________________ ___________________________________
Customer’s Signature Delivery Date
___________________________________
Model Number Serial Number (Customer Copy)

G6170 Ag-Baggers
Delivery Check List
The following check list is an important reminder of valuable information that MUST be passed
on to the customer at the time the unit is delivered. Check off each item as you explain it to the
customer.
Give customer their Operator’s Manual.
Instruct them to be sure to read and completely
understand its contents BEFORE attempting to
operate the unit.
Direct the customer on how to use the Table
of Contents of the owner’s manual as a quick
page locating guide.
Review the warranty.
Explain and review with customer the safety
information in the owner’s manual.
Explain and review with the customer the
controls and safety equipment on the Bagger.
Explain that regular lubrication and proper
adjustments are required for continued proper
operation and long life.
Review with the customer the lubrication
and maintenance chapters of the owner’s
manual.
Explain and review with the customer the
proper Tractor / Bagger preparation for safe
operation.
Explain and review with customer the PTO
Driveline information in the separate manual
provided.
Have the dealer complete the warranty
registration online.
I acknowledge that above points were reviewed with me at the time of delivery.
_______________________________________
Customer’s Signature
_______________________________________
Date Delivered
(Customer Copy)

G6170 Ag-Baggers
Dealer Pre-Delivery Check List
After the Bagger has been completely set-up, the following inspections Must be made before delivery to
the customer. Check off each item after prescribed action is taken.
No parts of the unit have been damaged in
shipment. Check for such things as dents, loose or
missing parts and scratches: touch up or replace
components as required.
Wheels are properly attached and tires are
properly inflated:
LT 265 / 75R16 @ 80 PSI
All bolts and fasteners are in place and tightly
secured.
As applicable, the cylinders, hoses and fittings
are NOT damaged, leaking or loosely connected.
The gear box oil is filled to proper level.
Hydraulic oil reservoir is filled to proper level.
Make sure conveyor slides properly, grease if
necessary.
All grease fittings have been properly lubricated
and drive chains oiled; see lubrication chapter in the
owner’s manual.
All guards, shields and decals are in place and
securely attached.
Make sure hitch fits properly in both the transport
and operating positions.
 All chains are properly tightened:
Conveyor drive and driven chain
Rotor drive chain
Hydraulic pump drive chain
 All drive & driven sprockets aligned properly:
Conveyor drive chain sprockets
Rotor drive chain sprockets
Hydraulic pump drive chain sprockets
Brake system properly tightens and releases.
Clean brake rotor before delivery.
Install bungee cord on tunnel & bag pan.
Install back stop hook assembly –see operator’s
manual.
String backstop –see operator’s manual
Bag boom works properly (If so equipped)
Hook the Bagger to the appropriate RPM tractor and test run while checking that proper operation
is exhibited by all components.
Check that:
Transport lights work properly.
PTO Shield turns freely.
All drives and mechanisms are operating
smoothly and properly adjusted.
All hydraulic system components are functioning
properly.
I acknowledge that pre-delivery was performed on this unit as outlined.
___________________________________ ___________________________________
Dealership’s Name Dealer Representative’s Name Date
___________________________________ ___________________________________
Customer’s Signature Delivery Date
___________________________________
Model Number Serial Number (Dealer Copy)

G6170 Ag-Baggers
Delivery Check List
The following check list is an important reminder of valuable information that MUST be passed
on to the customer at the time the unit is delivered. Check off each item as you explain it to the
customer.
Give customer their Operator’s Manual.
Instruct them to be sure to read and completely
understand its contents BEFORE attempting to
operate the unit.
Direct the customer on how to use the Table
of Contents of the owner’s manual as a quick
page locating guide.
Review the warranty.
Explain and review with customer the safety
information in the owner’s manual.
Explain and review with the customer the
controls and safety equipment on the Bagger.
Explain that regular lubrication and proper
adjustments are required for continued proper
operation and long life.
Review with the customer the lubrication
and maintenance chapters of the owner’s
manual.
Explain and review with the customer the
proper Tractor / Bagger preparation for safe
operation.
Explain and review with customer the PTO
Driveline information in the separate manual
provided.
Have the dealer complete the warranty
registration online.
I acknowledge that above points were reviewed with me at the time of delivery.
_______________________________________
Customer’s Signature
_______________________________________
Date Delivered
(Dealer Copy)

5
Safety Precautions
This symbol is used to call your attention to instructions concerning your
personal safety. Be sure to observe and follow these instructions. Take time
to be careful!
DANGER
“DANGER” indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
“WARNING” indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
“CAUTION” indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also alert against
unsafe practices.
BEFORE you attempt to operate this machine, read and study the following safety informa-
tion. In addition, MAKE SURE that every individual who operates or works with this equip-
ment, whether family member or employee, is familiar with these safety precautions. Miller-
St. Nazianz provides guards for exposed moving parts for the operator’s protection; however,
some areas cannot be guarded or shielded in order to assure proper operation. The OPERA-
TOR’S MANUAL AND DECALS on the machine itself warn you of dangers and SHOULD BE
READ AND OBSERVED CLOSELY.
Power Source Shutdown Procedure
Before cleaning, unclogging, adjusting, lubricating or servicing this machine:
1. Disengage the tractor PTO.
2. Deactivate tractor hydraulic controls.
3. Shut off the tractor engine, remove the starter key and take it with you.
4. Wait for all machine motion to stop.
5. Remove the telescoping PTO drive line and ALL power connections from
the tractor.
Failure to follow these precautions could result in death or serious injury.

6
Safety Precautions - continued
Know how to stop bagger operation BEFORE starting it.
BE ALERT for people and/or animals in front of or around machine, before you start operat-
ing the machine.
DO NOT enter the conveyor or hopper when machine is operating.
KEEP hands, feet and clothing away from conveyor when operating.
DO NOT wear loose or baggy clothing when operating this unit.
DO NOT allow people other than a qualified operator near the unit.
DO NOT allow minors to be near the machine unless properly supervised.
KEEP riders off bagger.
DO NOT unclog, adjust, lubricate or service your bagger until you disengage the tractor
PTO, tractor hydraulics and shut off the tractor engine. Remove the starter key from the
tractor and take it with you and wait for all machine motion to stop. Remove the telescoping
power driveline and all power connections from he tractor. Failure to follow this procedure
may result in serious bodily injury.
AVOID high pressure fluids. Escaping fluid under pressure can penetrate skin causing seri-
ous injury.
DO NOT exceed a maximum towing speed of 20 MPH (32 KPH) while transporting the bag-
ger.
REDUCE speed on rough or hilly ground.
BE EXTRA careful when going through fence gates or nearing confined quarters.
ALWAYS follow state and local regulations regarding use of a safety chain, slow moving
vehicle signs and transport lighting, when towing farm equipment on public highways.
ONLY operate the bagger on level ground.

7
BE SURE the tractor is in NEUTRAL and the parking brake released before beginning any
bagging operation.
BE SURE tractor wheels are pointed in a straight ahead position while bagging.
BE SURE the hitch jack locking pin is completely engaged and that the machine is properly
blocked and prevented from rolling BEFORE disconnecting the bagger from the tractor.
DO NOT stand between tractor and bagger when hitching or unhitching bagger unless en-
gine is stopped and parking brake is engaged.
STAY CLEAR of cables and cable drums at all times. Cables are under tension during bagging
operations.
ALWAYS stop bagger operation and shut off tractor between loads if bagger is to be left unattended.
NEVER use a spline adaptor.
Match the right tractor PTO spline and speed with the PTO driveshaft provided with the implement.
This will assure proper geometry and operating speed.
NEVER operate 540 rpm implements at 1,000 rpm.
NEVER operate 1,000 rpm implements at 540 rpm.
Use of adaptors will void warranty due to damage caused to the tractor PTO, PTO driveshaft or
implement.

8
Safety Decals
The decals are for your protection. If your safety decals are not readable or are missing, con-
tact your dealer for replacements.
16.20181 Warning
(Located on side of upper
conveyor deflector)
340248B1 Caution
(Located on top side of hitch
near jackstand)
16.20179 Warning
(Located on side of conveyor
under drive chain guard)
17.01155 Warning
(One located on each side of
hitch in front of jackstand)

9
Safety Decals - continued
16.20178 Warning
(Located on control side of hopper)
16.20177 Danger
(Located on each side of
PTO shield)
21.09024 Warning
(Located on frame above
hand pump)
01.77800 Warning
(Located on top of PTO shield)
WARNING
NO STEP

10
Safety Decals - continued
42.0900820 Danger (Lo-
cated on front and side
of hopper)
42.0900821 Danger (Located on
each side of conveyor)
DANGER
MOVING CONVEYOR
KEEP AWAY DURING OPERATION
DISCONNECT POWER BEFORE SERVICING
FAILURE TO HEED WILL RESULT ฀
IN DEATH OR PERSONAL INJURY
42-0900821
01.77800 Warning
(Located on top of jackshaft shield)
WARNING
NO STEP

11
Safety Decals - continued
42.0900823 Important
(Located on frame next to each wheel)
42.0900837 Important
(Located next to each rotor
bearing grease fitting)
16.20179 Warning
Under Rotor Drive Chain
Shield
Underside of PTO Shield
On Top Of Hydraulic Oil
Reservoir

12
Safety Decals - continued
42.0901739 Important
(Located on frame tube below each
cable drum)
42.0900822 Warning
(Located on frame tube below
each cable drum)

13
Reflective Decals
Yellow Reflectors
Red Reflectors and SMV Sign
907220 Yellow
Reflector
907220 Yellow
Reflector
907219 Red
Reflector
907219 Red
Reflector
907225 SMV
Sign

14
Ag-Bagger Component Locations
Right Side
Left Side
Tunnel
Tow Hitch
PTO Driveline
Lift Jack
Conveyor
Tunnel Extension
Hopper Rotor Drive
Cover
Cable Drum
Tail Lights
Bagger Shown In Bagging Configuration Without Bag Boom, Back Stop & Bag Cradle
PTO Shield
