Milnor 30015C4A User manual

Published Manual Number/ECN: MAI30VXXAE/2016293A
• Publishing System: TPAS2
• Access date: 07/12/2016
• Document ECNs: Latest
Installation
30015 and 30022
Cxx, Jxx, Txx, Vxx Rigid
Washer-Extractors
PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

Table of Contents
MAI30VXXAE/16293A
Page Description Document
1 Limited Standard Warranty BMP720097/2008272A
2 How to Get the Necessary Repair Components BIUUUD19/20081231
3 Trademarks of Pellerin Milnor Corporation BIUUUD14/20140821
4 Safety—Rigid Washer Extractors BIUUUS27RU/20051111
9 About the Forces Transmitted by Milnor® Washer-extractors BIWUUI02/20001108
11 Understanding Tag Guidelines BIUUUI02RC/20160711
14 Understanding Tag Guidelines BIUUUI02RM/20160711
17 Avoiding Damage from Allied Remote Chemical Delivery
Systems BIWUUI03/20030306
23 1. Installation
24 Handling and Setting Procedures for Rigid Mount 30015 &
30022 Washer-Extractors MSIN0703BE/2001036V
28 Service Connections BIRQVI01AB/20050228
33 2. Dimensional Drawings
35 Dimensional Drawing - 30015C4E BD3015C4CE/2011413D
37 Dimensional Drawing - 30022C4E BD3022C4CE/2011413D
39 Dimensional Drawing - 30015V7J, T5E, T5J, & T5X BD3015V7BE/2011413D
40 Dimensional Drawing - 30015V7J, T5E & T5X (Options) BD3015V7BB/2002475D
41 Dimensional Drawing - 30022V6J, T5E, T5J & T5X BD3022V6BE/2011413D
42 Dimensional Drawing - 30022V6J, T5E & T5X (Options) BD3022V6BB/2006412D
43 Dimensional Drawing - 30022VRJ BD3022VRJAE/2013166D
44 Dimensional Drawing - 30022VRJ Options BD3022VRJAB/2013105D
45 Dimensional Drawing - 30022V8Z BD3022V8BE/2013395D
46 Dimensional Drawing - 30022V8Z Options BD3022V8BB/2013105D
47 Dimensional Drawing - 30015J4P BD3015J4AE/2001064D
48 Dimensional Drawing - 30015J4P (Options) BD3015J4AB/2001064D
49 Dimensional Drawing - Pedestal Base 3015V7J, 3022V6J,
3022T5 BD30VBASAE/2014044D
51 Dimensional Drawing - Pedestal Base 3022V8Z, 3022VRJ BD30V8ZBASAE/2013053D

PELLERIN MILNOR CORPORATION
LIMITED STANDARD WARRANTY
We warrant to the original purchaser that MILNOR machines including electronic
hardware/software (hereafter referred to as “equipment”), will be free from defects in material and
workmanship for a period of one year from the date of shipment (unless the time period is specifically
extended for certain parts pursuant to a specific MILNOR published extended warranty) from our
factory with no operating hour limitation. This warranty is contingent upon the equipment being
installed, operated and serviced as specified in the operating manual supplied with the equipment,
and operated under normal conditions by competent operators.
Providing we receive written notification of a warranted defect within 30 days of its discovery, we
will at our option repair or replace the defective part or parts, FOB our factory. We retain the right to
require inspection of the parts claimed defective in our factory prior to repairing or replacing same.
We will not be responsible, or in any way liable, for unauthorized repairs or service to our equipment,
and this warranty shall be void if the equipment is tampered with, modified, or abused, used for
purposes not intended in the design and construction of the machine, or is repaired or altered in any
way without MILNOR's written consent.
Parts damaged by exposure to weather, to aggressive water, or to chemical attack are not covered by
this warranty. For parts which require routine replacement due to normal wear such as gaskets,
contact points, brake and clutch linings, belts, hoses, and similar parts the warranty time period is 90
days.
We reserve the right to make changes in the design and/or construction of our equipment (including
purchased components) without obligation to change any equipment previously supplied.
ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON
THE EXPRESS UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR
PURPOSE
. MILNOR WILL NOT BE RESPONSIBLE FOR ANY COSTS OR
DAMAGES ACTUALLY INCURRED OR REQUIRED AS A RESULT OF: THE FAILURE OF
ANY OTHER PERSON OR ENTITY TO PERFORM ITS RESPONSIBILITIES, FIRE OR
OTHER HAZARD, ACCIDENT, IMPROPER STORAGE, MIS-USE, NEGLECT, POWER OR
ENVIRONMENTAL CONTROL MALFUNCTIONS, DAMAGE FROM LIQUIDS, OR ANY
OTHER CAUSE BEYOND THE NORMAL RANGE OF USE. REGARDLESS OF HOW
CAUSED, IN NO EVENT SHALL MILNOR BE LIABLE FOR SPECIAL, INDIRECT,
PUNITIVE, LIQUIDATED, OR CONSEQUENTIAL COSTS OR DAMAGES, OR ANY COSTS
OR DAMAGES WHATSOEVER WHICH EXCEED THE PRICE PAID TO MILNOR FOR THE
EQUIPMENT IT SELLS OR FURNISHES.
THE PROVISIONS ON THIS PAGE REPRESENT THE ONLY WARRANTY FROM MILNOR
AND NO OTHER WARRANTY OR CONDITIONS, STATUTORY OR OTHERWISE, SHALL
BE IMPLIED.
WE NEITHER ASSUME, NOR AUTHORIZE ANY EMPLOYEE OR OTHER PERSON TO
ASSUME FOR US, ANY OTHER RESPONSIBILITY AND/OR LIABILITY IN CONNECTION
WITH THE SALE OR FURNISHING OF OUR EQUIPMENTTOANYBUYER.
OR ANY OTHER WARRANTY IMPLIED BY LAW INCLUDING BUT NOT
LIMITED TO REDHIBITION
BMP720097/2008272A
1

How to Get the Necessary Repair Components
PELLERIN MILNOR CORPORATION
BIUUUD19 (Published) Book specs- Dates: 20081231 / 20081231 / 20081231 Lang: ENG01 Applic: UUU
How to Get the Necessary Repair Components
This document uses Simplified Technical English.
Learn more at http://www.asd-ste100.org.
You can get components to repair your machine from the approved supplier where you got this
machine. Your supplier will usually have the necessary components in stock. You can also get
components from the Milnor®factory.
Tell the supplier the machine model and serial number and this data for each necessary component:
• The component number from this manual
• The component name if known
• The necessary quantity
• The necessary transportation requirements
• If the component is an electrical component, give the schematic number if known.
• If the component is a motor or an electrical control, give the nameplate data from the used
component.
To write to the Milnor factory:
Pellerin Milnor Corporation
Post Office Box 400
Kenner, LA 70063-0400
UNITED STATES
Telephone: [phone]
Fax: [phone]
Email: [email protected]
— End of BIUUUD19 —
2

Trademarks of Pellerin Milnor Corporation
PELLERIN MILNOR CORPORATION
BIUUUD14 (Published) Book specs- Dates: 20140821 / 20140821 / 20140821 Lang: ENG01 Applic: UUU
Trademarks of Pellerin Milnor Corporation
These words are trademarks of Pellerin Milnor Corporation:
Table 1: Trademarks
AutoSpot™
E-P Plus® Linear Costa Master™ MilTouch™ Ram Command™
CBW®
ExactXtract® Linear Costo™ MilTouch-EX™ RecircONE®
Drynet™
Gear Guardian® Mentor® Miltrac™ RinSave®
E-P Express®
GreenTurn™ Mildata® MultiTrac™ SmoothCoil™
E-P OneTouch®
GreenFlex™ Milnor® PBW™ Staph Guard®
Hydro-cushion™ MilMetrix® PulseFlow®
— End of BIUUUD14 —
3

Safety—Rigid Washer Extractors
PELLERIN MILNOR CORPORATION
BIUUUS27 (Published) Book specs- Dates: 20051111 / 20051111 / 20060322 Lang: ENG01 Applic: RUU
Safety—Rigid Washer Extractors
1. General Safety Requirements—Vital Information for
Management Personnel [Document BIUUUS04]
Incorrect installation, neglected preventive maintenance, abuse, and/or improper repairs, or
changes to the machine can cause unsafe operation and personal injuries, such as multiple
fractures, amputations, or death. The owner or his selected representative (owner/user) is
responsible for understanding and ensuring the proper operation and maintenance of the machine.
The owner/user must familiarize himself with the contents of all machine instruction manuals.
The owner/user should direct any questions about these instructions to a Milnor® dealer or the
Milnor® Service department.
Most regulatory authorities (including OSHA in the USA and CE in Europe) hold the owner/user
ultimately responsible for maintaining a safe working environment. Therefore, the owner/user
must do or ensure the following:
• recognize all foreseeable safety hazards within his facility and take actions to protect his
personnel, equipment, and facility;
• work equipment is suitable, properly adapted, can be used without risks to health or safety,
and is adequately maintained;
• where specific hazards are likely to be involved, access to the equipment is restricted to those
employees given the task of using it;
• only specifically designated workers carry out repairs, modifications, maintenance, or
servicing;
• information, instruction, and training is provided;
• workers and/or their representatives are consulted.
Work equipment must comply with the requirements listed below. The owner/user must verify
that installation and maintenance of equipment is performed in such a way as to support these
requirements:
• control devices must be visible, identifiable, and marked; be located outside dangerous zones;
and not give rise to a hazard due to unintentional operation;
• control systems must be safe and breakdown/damage must not result in danger;
• work equipment is to be stabilized;
• protection against rupture or disintegration of work equipment;
• guarding, to prevent access to danger zones or to stop movements of dangerous parts before
the danger zones are reached. Guards to be robust; not give rise to any additional hazards; not
be easily removed or rendered inoperative; situated at a sufficient distance from the danger
zone; not restrict view of operating cycle; allow fitting, replacing, or maintenance by
restricting access to relevant area and without removal of guard/protection device;
• suitable lighting for working and maintenance areas;
• maintenance to be possible when work equipment is shut down. If not possible, then
protection measures to be carried out outside danger zones;
• work equipment must be appropriate for preventing the risk of fire or overheating; discharges
of gas, dust, liquid, vapor, other substances; explosion of the equipment or substances in it.
4

Safety—Rigid Washer Extractors
PELLERIN MILNOR CORPORATION
1.1. Laundr
y
Facilit
y
—Provide a supporting floor that is strong and rigid enough to support–with
a reasonable safety factor and without undue or objectionable deflection–the weight of the fully
loaded machine and the forces transmitted by it during operation. Provide sufficient clearance fo
r
machine movement. Provide any safety guards, fences, restraints, devices, and verbal and/or
posted restrictions necessary to prevent personnel, machines, or other moving machinery from
accessing the machine or its path. Provide adequate ventilation to carry away heat and vapors.
Ensure service connections to installed machines meet local and national safety standards,
especially regarding the electrical disconnect (see the National Electric Code). Prominently post
safety information, including signs showing the source of electrical disconnect.
1.2. Personnel—Inform personnel about hazard avoidance and the importance of care and
common sense. Provide personnel with the safety and operating instructions that apply to them.
Verify that personnel use proper safety and operating procedures. Verify that personnel
understand and abide by the warnings on the machine and precautions in the instruction manuals.
1.3. Safety Devices—Ensure that no one eliminates or disables any safety device on the machine
or in the facility. Do not allow machine to be used with any missing guard, cover, panel or door.
Service any failing or malfunctioning device before operating the machine.
1.4. Hazard Information—Important information on hazards is provided on the machine safety
placards, in the Safety Guide, and throughout the other machine manuals. Placards must be kept
clean so that the information is not obscured. They must be replaced immediately if lost or
damaged. The Safety Guide and other machine manuals must be available at all times to
the appropriate personnel. See the machine service manual for safety placard part numbers.
Contact the Milnor Parts department for replacement placards or manuals.
1.5. Maintenance—Ensure the machine is inspected and serviced in accordance with the norms of
good practice and with the preventive maintenance schedule. Replace belts, pulleys, brake
shoes/disks, clutch plates/tires, rollers, seals, alignment guides, etc. before they are severely
worn. Immediately investigate any evidence of impending failure and make needed repairs (e.g.,
cylinder, shell, or frame cracks; drive components such as motors, gear boxes, bearings, etc.,
whining, grinding, smoking, or becoming abnormally hot; bending or cracking of cylinder, shell,
frame, etc.; leaking seals, hoses, valves, etc.) Do not permit service or maintenance by
unqualified personnel.
2. Safety Alert Messages—Internal Electrical and Mechanical
Hazards [Document BIUUUS11]
The following are instructions about hazards inside the machine and in electrical enclosures.
WARNING 1 : Electrocution and Electrical Burn Hazards—Contact with electric powe
r
can kill or seriously injure you. Electric power is present inside the cabinetry unless the main
machine power disconnect is off.
• Do not unlock or open electric box doors.
• Do not remove guards, covers, or panels.
• Do not reach into the machine housing or frame.
• Keep yourself and others off of machine.
• Know the location of the main machine disconnect and use it in an emergency to remove
all electric power from the machine.
5

Safety—Rigid Washer Extractors
PELLERIN MILNOR CORPORATION
WARNING 2 : Entangle and Crush Hazards—Contact with moving components normally
isolated by guards, covers, and panels, can entangle and crush your limbs. These components
move automatically.
• Do not remove guards, covers, or panels.
• Do not reach into the machine housing or frame.
• Keep yourself and others off of machine.
• Know the location of all emergency stop switches, pull cords, and/or kick plates and use
them in an emergency to stop machine motion.
3. Safety Alert Messages—Cylinder and Processing Hazards
[Document BIUUUS13]
The following are instructions about hazards related to the cylinder and laundering process.
DANGER 3 : Entangle and Sever Hazards—Contact with goods being processed can
cause the goods to wrap around your body or limbs and dismember you. The goods are normally
isolated by the locked cylinder door.
• Do not attempt to open the door or reach into the cylinder until the cylinder is stopped.
• Do not touch goods inside or hanging partially outside the turning cylinder.
• Do not operate the machine with a malfunctioning door interlock.
• Know the location of all emergency stop switches, pull cords, and/or kick plates and use
them in an emergency to stop machine motion.
• Know the location of the main machine disconnect and use it in an emergency to remove
all electric power from the machine.
WARNING 4 : Crush Hazards—Contact with the turning cylinder can crush your limbs. The
cylinder will repel any object you try to stop it with, possibly causing the object to strike or stab
you. The turning cylinder is normally isolated by the locked cylinder door.
• Do not attempt to open the door or reach into the cylinder until the cylinder is stopped.
• Do not place any object in the turning cylinder.
• Do not operate the machine with a malfunctioning door interlock.
WARNING 5 : Confined Space Hazards—Confinement in the cylinder can kill or injure
you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,
biological contamination, electrocution, and crushing.
• Do not attempt unauthorized servicing, repairs, or modification.
WARNING 6 : Explosion and Fire Hazards—Flammable substances can explode or ignite
in the cylinder, drain trough, or sewer. The machine is designed for washing with water, not any
other solvent. Processing can cause solvent-containing goods to give off flammable vapors.
• Do not use flammable solvents in processing.
• Do not process goods containing flammable substances. Consult with your local fire
department/public safety office and all insurance providers.
6

Safety—Rigid Washer Extractors
PELLERIN MILNOR CORPORATION
4. Safety Alert Messages—Unsafe Conditions [Document BIUUUS14]
4.1. Damage and Malfunction Hazards
4.1.1. Hazards Resulting from Inoperative Safety Devices
DANGER 7 : Entangle and Sever Hazards—Cylinder door interlock—Operating the
machine with a malfunctioning door interlock can permit opening the door when the cylinder is
turning and/or starting the cycle with the door open, exposing the turning cylinder.
• Do not operate the machine with any evidence of damage or malfunction.
WARNING 8 : Multiple Hazards—Operating the machine with an inoperative safety device
can kill or injure personnel, damage or destroy the machine, damage property, and/or void the
warranty.
• Do not tamper with or disable any safety device or operate the machine with a
malfunctioning safety device. Request authorized service.
WARNING 9 : Electrocution and Electrical Burn Hazards—Electric box doors—
Operating the machine with any electric box door unlocked can expose high voltage conductors
inside the box.
• Do not unlock or open electric box doors.
WARNING 10 : Entangle and Crush Hazards—Guards, covers, and panels—Operating
the machine with any guard, cover, or panel removed exposes moving components.
• Do not remove guards, covers, or panels.
4.1.2. Hazards Resulting from Damaged Mechanical Devices
WARNING 11 : Multiple Hazards—Operating a damaged machine can kill or injure
personnel, further damage or destroy the machine, damage property, and/or void the warranty.
• Do not operate a damaged or malfunctioning machine. Request authorized service.
WARNING 12 : Explosion Hazards—Cylinder—A damaged cylinder can rip apart during
extraction, puncturing the shell and discharging metal fragments at high speed.
• Do not operate the machine with any evidence of damage or malfunction.
WARNING 13 : Explosion Hazards—Clutch and speed switch (multiple motor
machines)—A damaged clutch or speed switch can permit the low speed motor to engage during
extract. This will over-speed the motor and pulleys and can cause them to rip apart, discharging
metal fragments at high speed.
• Stop the machine immediately if any of these conditions occur: • abnormal whining sound
during extract • skidding sound as extract ends • clutches remain engaged or re-engage
during extract
7

Safety—Rigid Washer Extractors
PELLERIN MILNOR CORPORATION
4.2. Careless Use Hazards
4.2.1. Careless Operation Hazards—Vital Information for Operator Personnel
(
see also
operator hazards throughout manual)
WARNING 14 : Multiple Hazards—Careless operator actions can kill or injure personnel,
damage or destroy the machine, damage property, and/or void the warranty.
• Do not tamper with or disable any safety device or operate the machine with a
malfunctioning safety device. Request authorized service.
• Do not operate a damaged or malfunctioning machine. Request authorized service.
• Do not attempt unauthorized servicing, repairs, or modification.
• Do not use the machine in any manner contrary to the factory instructions.
• Use the machine only for its customary and intended purpose.
• Understand the consequences of operating manually.
4.2.2. Careless Servicing Hazards—Vital Information for Service Personnel (see also
service hazards throughout manuals)
WARNING 15 : Electrocution and Electrical Burn Hazards—Contact with electric
power can kill or seriously injure you. Electric power is present inside the cabinetry unless the
main machine power disconnect is off.
• Do not service the machine unless qualified and authorized. You must clearly understand
the hazards and how to avoid them.
• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in
the service instructions. Outside the USA, abide by the OSHA standard in the absence of
any other overriding standard.
WARNING 16 : Entangle and Crush Hazards—Contact with moving components
normally isolated by guards, covers, and panels, can entangle and crush your limbs. These
components move automatically.
• Do not service the machine unless qualified and authorized. You must clearly understand
the hazards and how to avoid them.
• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in
the service instructions. Outside the USA, abide by the OSHA standard in the absence of
any other overriding standard.
WARNING 17 : Confined Space Hazards—Confinement in the cylinder can kill or injure
you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,
biological contamination, electrocution, and crushing.
• Do not enter the cylinder until it has been thoroughly purged, flushed, drained, cooled,
and immobilized.
— End of BIUUUS27 —
8

PELLERIN MILNOR CORPORATION
BIWUUI02 (Published) Book specs- Dates: 20001108 / 20001108 / 20100609 Lang: ENG01 Applic: WUU
About the Forces Transmitted by Milnor
®
Washer-extractors
During washing and extracting, all washer-extractors transmit both static and dynamic (cyclic)
forces to the floor, foundation, or any other supporting structure. During washing, the impact of
the goods as they drop imparts forces which are quite difficult to quantify. Size for size, both
rigid and flexibly-mounted machines transmit approximately the same forces during washing.
During extracting, rigid machines transmit forces up to 30 times greater than equivalent flexibly-
mounted models. The actual magnitude of these forces vary according to several factors:
• machine size,
• final extraction speed,
• amount, condition, and type of goods being processed,
• the liquor level and chemical conditions in the bath preceding extraction, and
• other miscellaneous factors.
Estimates of the maximum force normally encountered are available for each Milnor
®
model and
size upon request. Floor or foundation sizes shown on any Milnor
®
document are only for on-
grade situations based only on previous experience without implying any warranty, obligation, or
responsibility on our part.
1. Rigid Machines
Size for size, rigid washer-extractors naturally require a stronger, more rigid floor, foundation, or
other supporting structure than flexibly-mounted models. If the supporting soil under the slab is
itself strong and rigid enough and has not subsided to leave the floor slab suspended without
support, on grade installations can often be made directly to an existing floor slab if it has enough
strength and rigidity to safely withstand our published forces without transmitting undue
vibration. If the subsoil has subsided, or if the floor slab itself has insufficient strength and
rigidity, a deeper foundation, poured as to become monolithic with the floor slab, may be
required. Support pilings may even be required if the subsoil itself is “springy” (i.e., if its
resonant frequency is near the operating speed of the machine). Above-grade installations of rigid
machines also require a sufficiently strong and rigid floor or other supporting structure as
described below.
2. Flexibly-mounted Machines
Size for size, flexibly-mounted machines generally do not require as strong a floor, foundation, or
other supporting structure as do rigid machines. However, a floor or other supporting structure
having sufficient strength and rigidity, as described in Section 3, is nonetheless vitally important
for these models as well.
3. How Strong and Rigid?
Many building codes in the U.S.A. specify that laundry floors must have a minimum live load
capacity of 150 pounds per square foot (732 kilograms per square meter). However, even
compliance with this or any other standard does not necessarily guarantee sufficient rigidity. In
any event, it is the sole responsibility of the owner/user to assure that the floor and/or any other
supporting structure exceeds not only all applicable building codes, but also that the floor and/or
any other supporting structure for each washer-extractor or group of washer-extractors actually
has sufficient strength and rigidity, plus a reasonable factor of safety for both, to support the
weight of all the fully loaded machine(s) including the weight of the water and goods, and
including the published 360º rotating sinusoidal RMS forces that are transmitted by the
machine(s). Moreover, the floor, foundation, or other supporting structure must have sufficient
9

About the Forces Transmitted by Milnor
®
Washer-extractors
PELLERIN MILNOR CORPORATION
rigidity (i.e., a natural or resonant frequency many times greater than the machine speed with a
reasonable factor of safety); otherwise, the mentioned 360º rotating sinusoidal RMS forces can be
multiplied and magnified many times. It is especially important to consider all potential vibration
problems that might occur due to all possible combinations of forcing frequencies (rotating
speeds) of the machine(s) compared to the natural frequencies of the floor and/or any other
supporting structure(s). A qualified soil and/or structural engineer must be engaged for this
purpose.
Figure 1: How Rotating Forces Act on the Foundation
Typical Machine
Legend
A. Direction of force
B. Load
C. Rotation (Frequency = RPM / 60)
.
Figure 1 above is intended to depict both on-grade and above-grade installations and is equally
applicable to flexibly-mounted washer-extractors, as well as to rigid models installed either
directly on a floor slab or on a foundation poured integrally with the slab. Current machine data is
available from Milnor
®
upon request. All data is subject to change without notice and may have
changed since last printed. It is the sole responsibility of every potential owner to obtain written
confirmation that any data furnished by Milnor
®
applies for the model(s) and serial number(s) of
the specific machines.
— End of BIWUUI02 —
10

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
BIUUUI02RC (Published) Book specs- Dates: 20160711 / 20160711 / 20160711 Lang: ENG01 Applic: RMC
Tag Guidelines for the Models Listed Below
30010CGE 30015C4A 30015C4E 30015C4T 30015CGE 30022C4A 30022C4E
30022C4T
Notice 1 : This information may apply to models
in addition to those listed above. It applies to
paper tags. It does not apply to the vinyl or metal safety placards, which must remain
permanently affixed to the machine and replaced if no longer readable.
Paper tags on the machine provide installation guidelines and precautions. The tags can be tie-on
or adhesive. You can remove tie-on tags and white, adhesive tags after installation. Yellow
adhesive tags must remain on the machine.
11

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
The following entries explain the installation tags. Each entry includes: 1) the tag illustration, 2)
the tag part number displayed st the bottom of the tag, and 3) the meaning of the tag.
Display or Action Explanation
Read the manuals before proceeding. This symbol appears on
most tags. The machine ships with safety, operator, and routine
maintenance guides for customer use. Milnor dealer manuals for
installing, servicing, and commissioning this machine are also
available from the Milnor Parts department.
B2TAG88005: This carefully built product was tested and
inspected to meet Milnor
®
performance and quality standards by
(identification mark of tester).
B2TAG93013: This bearing housing was lubricated at the
Milnor factory before shipment.
B2TAG94081: Motor must rotate in this direction. On single
motor washer-extractors and centrifugal extractors, the drive
motor must turn in this direction during draining and extraction.
Th
is tag is usually wrapped around a motor housing. If the motor
turns in the opposite direction when the machine is first tested,
the electrical hookup is incorrect and must be reversed as
explained in the schematic manual.
B2TAG94097: The cylinder must rotate counterclockwise
during draining and extraction (spin) when viewed from here
(rear of machine). Otherwise, reverse the electric power
connections, as explained in the schematic manual.
B2TAG94118: Do not strike shipping container during fork-
lifting. Fragile components inside.
B2T2001013: Hot water connection.
12

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
Display or Action Explanation
B2T2001014: Cold water connection.
B2T2001016: Flushing water connection. This is the water that
goes into the supply compartment or pumped chemical manifold
to flush chemicals into the machine.
B2T2003001: Hold the side of the connection stationary with a
wrench as you tighten the connection with another wrench.
Otherwise, you may twist components, such as valves, damaging
them.
— End of BIUUUI02 —
13

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
BIUUUI02RM (Published) Book specs- Dates: 20160711 / 20160711 / 20160711 Lang: ENG01 Applic: RMV
Tag Guidelines for the Models Listed Below
30015T5E 30015T5J 30015T5X 30015T6X 30015V7J 30015V8Z 30015VRJ
30022T5E 30022T5J 30022T5X 30022T6X 30022V6J 30022V8Z 30022VRJ
Notice 1 :
This information may apply to models in addition to those listed above. It applies to
paper tags. It does not apply to the vinyl or metal safety placards, which must remain
permanently affixed to the machine and replaced if no longer readable.
Paper tags on the machine provide installation guidelines and precautions. The tags can be tie-on
or adhesive. You can remove tie-on tags and white, adhesive tags after installation. Yellow
adhesive tags must remain on the machine.
14

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
The following entries explain the installation tags. Each entry includes: 1) the tag illustration, 2)
the tag part number displayed st the bottom of the tag, and 3) the meaning of the tag.
Display or Action Explanation
Read the manuals before proceeding. This symbol appears on
most tags. The machine ships with safety, operator, and routine
maintenance guides for customer use. Milnor dealer manuals for
installing, servicing, and commissioning this machine are also
available from the Milnor Parts department.
B2TAG88005: This carefully built product was tested and
inspected to meet Milnor®performance and quality standards by
(identification mark of tester).
B2TAG93013: This bearing housing was lubricated at the
Milnor factory before shipment.
B2TAG94081: Motor must rotate in this direction. On single
motor washer-extractors and centrifugal extractors, the drive
motor must turn in this direction during draining and extraction.
Th
is tag is usually wrapped around a motor housing. If the motor
turns in the opposite direction when the machine is first tested,
the electrical hookup is incorrect and must be reversed as
explained in the schematic manual.
B2TAG94097: The cylinder must rotate counterclockwise
during draining and extraction (spin) when viewed from here
(rear of machine). Otherwise, reverse the electric power
connections, as explained in the schematic manual.
B2TAG94118: Do not strike shipping container during fork-
lifting. Fragile components inside.
B2T2001013: Hot water connection.
15

Tag Guidelines for the Models Listed Below
PELLERIN MILNOR CORPORATION
Display or Action Explanation
B2T2001014: Cold water connection.
B2T2001015: Reuse (third) water connection.
B2T2001016: Flushing water connection. This is the water that
goes into the supply compartment or pumped chemical manifold
to flush chemicals into the machine.
B2T2003001: Hold the side of the connection stationary with a
wrench as you tighten the connection with another wrench.
Otherwise, you may twist components, such as valves, damaging
them.
B2T2004027: Steam connection (optional)
B2T2006012: Retain the motor mount spring adjustment sleeve
provided with certain machine models. This sleeve is used to
increase drive belt tension as the belt wears. Instructions are
provided in the maintenance guide. (Used only on 30022V8Z &
VRJ models.)
— End of BIUUUI02 —
16
