5
EXTENSION CORDS
Grounded tools require a three wire extension
cord. Double insulated tools can use either a two
or three wire extension cord. As the distance from
the supply outlet increases, you must use a heavier
gauge extension cord. Using extension cords with
inadequately sized wire causes a serious drop in
voltage, resulting in loss of power and possible tool
damage. Refer to the table shown to determine the
required minimum wire size.
The smaller the gauge number of the wire, the greater
the capacity of the cord. For example, a 14 gauge
cord can carry a higher current than a 16 gauge cord.
When using more than one extension cord to make
up the total length, be sure each cord contains at
least the minimum wire size required. If you are using
one extension cord for more than one tool, add the
nameplate amperes and use the sum to determine
the required minimum wire size.
Guidelines for Using Extension Cords
•If you are using an extension cord outdoors, be sure
it is marked with the sufx “W-A” (“W” in Canada) to
indicate that it is acceptable for outdoor use.
•Be sure your extension cord is properly wired and in
good electrical condition. Always replace a damaged
extension cord or have it repaired by a qualied
person before using it.
• Protect your extension cords from sharp objects,
excessive heat and damp or wet areas.
Recommended Minimum Wire Gauge
For Extension Cords*
Nameplate Amps
Extension Cord Length
25' 50' 75' 100' 150'
0 - 2.0
2.1 - 3.4
3.5 - 5.0
5.1 - 7.0
7.1 - 12.0
12.1 - 16.0
16.1 - 20.0
18
18
18
18
16
14
12
18
18
18
16
14
12
10
18
18
16
14
12
10
--
18
16
14
12
10
--
--
16
14
12
12
--
--
--
* Based on limiting the line voltage drop to ve volts at 150%
of the rated ampere.
FUNCTIONAL DESCRIPTION
3
7
6
2
8
9
5
1
1. Side handle
2. Spindle lock
3. Handle
4. Paddle switch
5. Switch lock-on/lock-off
6. Side handle socket
7. Type 27 guard
8. Accessory
9. Guard lock lever
10.Trigger switch
11. Slide switch
11
5
10
4
Cat. No. Volts Amps RPM Spindle
Thread Size Max
Capacity Switch
Type Lock-On Guard
Type Speed
Dial
6117-30
6117-31
6117-31B
6117-33
6117-33D
6121-30
6121-31
6121-31A
6124-30
6124-31
6146-30
6146-31
6146-33
6147-30
6147-31
6161-30
6161-31
6161-33
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC/DC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
120 AC
13
13
13
13
13
11
11
11
13
13
11
11
11
11
11
13
13
13
11,000
11,000
11,000
11,000
2,800-11,000
12,000
12,000
12,000
9,000
9,000
12,000
12,000
12,000
12,000
12,000
10,000
10,000
9,000
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5/8"-11
5"x1/4"
5"x1/4"
5"x1/4"
5"x1/4"
5"x1/4"
4-1/2"x1/4"
4-1/2"x1/4"
5"x1/4"
5"x1/4"
5"x1/4"
4-1/2"x1/4"
4-1/2"x1/4"
4-1/2"x1/4"
4-1/2"x1/4"
4-1/2"x1/4"
6"x1/4"
6"x1/4"
6"x1/4"
Paddle
Paddle
Paddle
Slide
Slide
Trigger
Trigger
Trigger
Trigger
Trigger
Paddle
Paddle
Slide
Paddle
Paddle
Paddle
Paddle
Slide
Yes
No
No
Yes
Yes
Yes
No
No
Yes
No
Yes
No
Yes
Yes
No
Yes
No
Yes
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 27
Type 1
Type 1
Type 1
No
No
No
No
Yes
No
No
No
No
No
No
No
No
No
No
No
No
No
SPECIFICATIONS
