DL100 BLACK BOX
DATA LOGGING MONITOR
pH/Temperature
Set Up / Operation Manual

2
DL100 MENU MAP
**Menu**
>Basic Setup
pH
DataLog Setup
Last Logged
Wi-Fi Settings
Exit
**BasicSetup**
>Date & Time
Temperature
pH Resolution
Exit
Date and Time
>05/09/15 Date
9:25 Time
Exit
**BasicSetup**
Date& Time
>Temperature
pH Resolution
Exit
Temperature
>Fahrenheit
Celsius
Exit
**Basic Setup**
Date& Time
Temperature
>pHResolution
Exit
pH Resolution
Tenths .0
>Hundredths .00
Thousandths .000
Exit
**pH Menu**
>pH Calibration
pH Probe Diagnostic
pH Below Alert
pH Above Alert
Manual Temp Comp
Exit
**pH Calibration**
1 Point Calibration
>2 Point Calibration
3 Point Calibration
Last Calib./GLP
Exit
**pH Calibration**
1 Point Calibration
2 Point Calibration
3 Point Calibration
> Last Calib./GLP
Exit
** Last Calib./GLP **
05/04/15 9:25:36
2 Point Calibration
7.01 & 4.01
Exit
7.01 & 4.01 Calibration
“Follow Instructions
Given Here”
Exit
**Menu**
Basic Setup
> pH
Data Log Setup
Last Logged
Wi-Fi Settings
Exit
**pH Menu**
pH Calibration
pH Probe Diagnostic
>pH Below Alert
**pH Menu**
pH Calibration
pH Probe Diagnostic
pH Below Alert
>pH Above Alert
Manual Temp Comp
Exit
*pH Below Alert*
>pH Caution **.**
pH Critical **.**
Exit
*pH Above Alert*
>pH Caution**.**
pH Critical **.**
Exit
*pH Above Alert*
>pH Caution**.**
Exit
*pH Below Alert*
>pH Caution **.**
Exit
**pHMenu**
pH Calibration
>
pH Probe Diagnostic
**pH Menu**
pH Calibration
pH Probe Diagnostic
pH Below Alert
pH Above Alert
>Manual Temp Comp
Exit
**Menu**
BasicSetup
pH
>Data LogSetup
Last Logged
Wi-Fi Settings
Exit
*Data Logger*
>Set TimeInterval
Start Time
Exit
Set Time Interval
xx:xx:xx
*DataLogger*
Set TimeInterval
>Start Time
Exit
Start Time
xx:xx:xx
**Menu**
Basic Setup
pH
Data Log Setup
Last Logged
> Wi-Fi Settings
Exit
**Wi-Fi Settings**
>Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
View Device IP
Upload Interval
Portal Sync
Portal Service
Exit
**Wi-Fi Enable**
> Enable
Disable
**Wi-Fi Settings**
Wi-Fi Enable
>Security Type
Network Name/SSID
Pre-shared Key
View Device IP
Upload Interval
Portal Sync
Portal Service
Exit
**Wi-Fi Security**
Open
WEP
>WPA
Exit
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
>Network Name/SSID
Pre-shared Key
View DeviceIP
Upload Interval
Portal Sync
Portal Service
Exit
Network Name
XXXXXXXXXXXXX
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
Network Name/SSID
>Pre-shared Key
View DeviceIP
Upload Interval
Portal Sync
Portal Service
Exit
Network Password
XXXXXXXXXXXXX
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
>View DeviceIP
Upload Interval
Portal Sync
Portal Service
Exit
Device IP Address
IP: 196.162.3.***
MAC: 18fe351e79cd
Exit
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
View DeviceIP
>Upload Interval
Portal Sync
Portal Service
Exit
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
View DeviceIP
Upload Interval
>Portal Sync
Portal Service
Exit
Set Upload Interval
05 minutes
Portal Sync
**Menu**
Basic Setup
pH
DataLog Setup
>Last Logged
Wi-Fi Settings
Exit
**Last Logged**
01/05/16 08:06:07
pH: 7.00
Temp: 22.56º C
pH Below Alert
pH Above Alert
Manual Temp Comp
Exit
pH Above Alert
Manual Temp Comp
Exit
**Probe Diagnostic**
Follow instructions
given here.
Exit
*Manual Temperature*
Compensation
025.50º C
**Wi-Fi Settings**
Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
View DeviceIP
Upload Interval
>
Portal Sync
Portal Service
Exit
Do Not Enter
Any Data

1
Please make sure you have all the components
listed below. If not, call your dealer.
• DL100 Data Logging Monitor
• #MA911B/2 pH probe with 2m cable
• #RJ11 temperature probe with 3m cable
• 9VDC power supply
• 4GB SD card
• International power supply kit
DL100 Quick-Start Hardware Setup
1) Plug the pH probe into the BNC connector on the controller.
2) Insert the 4GB SD card (included), printed side down, making
certain that it snaps into place.
3) Connect RJ11 temperature probe.
4) Connect 9VDC power supply into unit rst, then plug into
120VAC wall outlet.
Note: To enable Wi-Fi, you will need to know your Wi-Fi network
Security Type, Name, and Password.
Milwaukee Instruments, designer and manufacturer of the
DL100, recommends you read this manual from start-to-
nish, without skipping sections. Many of the instructions in
later sections are based on knowledge you will acquire in the
earlier sections of this manual.
Getting to know the DL100
Once you have connected all the cords, inserted the SD card, and
plugged the DL100 into a wall socket, please read this section,
taking a few moments to learn about the screen and keypad.
Note there is no ON/OFF switch; the unit is ON as soon as it is
plugged in. The only way to deactivate the unit is to unplug it.
Recorded data on the SD card will remain intact when the unit is
unplugged.
THE SCREEN When the unit is rst powered up, you will see a
WELCOME message. In a few seconds, the unit will automatically
switch to the primary display screen. This screen gives the date,
time, and real-time readings of pH and Temperature. If activated,
the word Wi-Fi will appear in the upper right corner. Unless you
are changing settings, this is the screen that should always be
displaying.
Primary Display Screen
If temperature probe is plugged in, ATC (Automatic Temperature
Compensation) will appear in the lower right portion of screen.
If not, MTC (Manual Temperature Compensation) will display.
On the menu screens, only four lines will be visible at a time.
To see more options, scroll the list by using up/down arrows
on the keypad. When the cursor (>) appears beside the
appropriate function or setting, press SELECT.
THE KEYPAD Pressing the Menu button brings up a screen
featuring the full menu. At the bottom of all menu screens,
there will be an“Exit” option. The“Exit” option, when selected,
takes you back to the previous screen you were viewing. For
informational screens, there is no“Exit” option. Press SELECT to
return to previous screen.
Pressing the Menu button takes you all the way back to the
primary display screen, bypassing other screens you may have
used. Pressing the Menu button also allows you to toggle
between the primary display screen and the full menu screen.
The left/right arrows ( )allow you to move the blinking cursor
horizontally through a line of settings to the numbers you want
to reset, while the up/down arrows ( )allow you to move
through the function listings and numbers, and toggle between
yes/no options. When new settings are entered, press SELECT,
there will be a short pause and the screen will read SAVED! In just
a moment, the unit will revert to the previous screen.
The Lights button allows you to turn o the screen and status
lights (lights to the left and right of screen, behind grills). The
unit is still functional when lights are o. Pressing Lights again
will reactivate all lights.
IMPORTANT: When in the Lights OFF mode, the status lights
(caution and critical) will not activate on the unit; however,
since the unit is still operational, it will continue to log data
and, if web portal is activated, send text or email alerts, or
both. The only way to turn o data logging and the alerts
system is to unplug the unit.
The Snap Shot button allows you to instantly log a real-time
reading on both the SD card and the portal. When you press
the Snap Shot button on the keypad,“Snap Shot” will appear
for a few seconds in the lower right corner of the screen,
indicating the real-time data has been logged.
11/30/15 11:45 Wi-Fi
pH: 7.10
Temp: 22.56ºC ATC
Wi-Fi will display
here, if enabled.
ATC or MTC will
display here.

2
Getting Started with Basic Setup
This is a very important step, allowing you to enter
the correct Date and Time, select Fahrenheit or Celsius
Temperature readings, and calibrate for pH.
This unit comes with factory presets, but before using you must
reset to meet your specic requirements. If you ever wish to
revert to factory settings (a factory reset), simply unplug unit,
then plug back in while holding the Lights button down for 3
seconds.
Breadcrumbs, or the navigation path, shown at the beginning
of each section of this manual, will take you from the Menu
screen to the screen where you will be entering changes.
Setting Date and Time
Menu Button>Basic Setup>Date and Time
1) Press the Menu button on the keypad and the full menu will
appear on screen.
2) The cursor appears beside the rst option on each new
screen, and since“Basic Setup” is the rst option listed, you can
press the SELECT button on the keypad.
Please note that the Full Menu lists six options, but only three will
be visible on the screen. To see other options, scroll with the down
arrow to bring other options into view.
3) The **Basic Setup** screen will appear and the cursor will be
beside the rst option, which is “Date and Time.” Press SELECT.
4) The“Date and Time”screen will now appear. Both the date
and the time will be shown, but they may not be correct.
5) To change the date, make sure cursor is beside the Date line
and press SELECT.
6) To set the “Date,” use the left/right arrows on the keypad to
move the blinking cursor through the line. Be sure to skip over
slashes. Use the up/down arrows to nd the correct numbers
for the month, day, and year. Once you have set all numbers to
match today’s date, press the SELECT button and the SAVED!
screen should appear for a few moments. It will then go back to
the “Date and Time”screen.
7) Now you are ready to set the time. Scroll down to the next
option, which is “Time.” Press SELECT.
8) Again, work across the Hours:Minutes (00:00) using left/right
arrows, picking the number you want to change, then using
up/down arrows to select the appropriate number.
Note that this unit displays in military time (24-hour); there is
no am/pm option, that is, 9AM is 09:00 and 2:05PM is 14:05.
10:30PM is 22:30.
9) Once complete, press SELECT to enter the new time. A
screen will appear indicating that your change has been SAVED!
10) Scroll to“Exit” and press SELECT to return to **Basic
Setup** screen, or press the Menu button to return to the
primary display screen.
Important: When utilizing portal, date on monitor and portal
dashboard must be the same, and times should be set as close
as possible (within ten minutes).
Setting Temperature – Fahrenheit or
Celsius
Menu Button>Basic Setup>Temperature
Work your way to the“Temperature” screen and, using
up/down arrows, select Fahrenheit or Celsius, then press
SELECT. The SAVED! screen will appear, then go back to the
“Temperature”screen. Scroll to “Exit” and press SELECT to
return to **Basic Setup** screen, or press the Menu button to
return to the primary display screen.
Setting “pH Resolution” – Tenths,
Hundredths, or Thousandths
Menu Button>Basic Setup>pH Resolution
On the “pH Resolution”screen, use up/down arrows to select
tenths, hundredths, or thousandths, and press SELECT. The
SAVED! screen will appear, then go back to the “pH Resolution”
screen. Scroll to“Exit” and press SELECT to return to **Basic
Setup** screen, or press the Menu button to return to the
primary display screen.
This completes the Basic Setup of your DL100.
******************************************
Setting Up for pH Readings
The **pH Menu**, as shown below:
• allows you to set for 1, 2, or 3 point calibration
• allows you to check the last calibration – date, time,
number of points, and which points
• provides pH probe diagnostic
• allows you to set caution and critical alerts for readings
getting too high or too low
• allows you to manually enter temperature of solution
** Menu **
> Basic Setup
pH
Data Log Setup
Last Logged
Wi-Fi Settings
Exit
Please be sure to read Getting to Know the DL100, previous page, before beginning Basic Setup.
** pH Menu **
> pH Calibration
pH Probe Diagnostic
pH Below Alert
pH Above Alert
Manual Temp. Comp.
Exit

3
Replace
Probe
Clean
Probe
Acceptable Slope
Performance
Probe
Clean
Probe
Replace
Probe
Setting Calibration Points
Menu Button>pH>pH Calibration
Before selecting calibration point(s), you may want to review the
**Last Calib./GLP** screen. Scroll down to the “Last Calib./GLP” option
and press SELECT. (Menu Button>pH>pH Calibration>Last Calib./
GLP) The **Last Calib./GLP** screen will then give you the date and
time of the last calibration; indicate 1, 2, or 3 point calibration; and
give you the calibration points, as shown below.
In accordance with GLP (Good Laboratory Practices), you can
scroll down on this screen to view Acid Slope and Base Slope
once calibration is complete.
1) On **pH Calibration** screen, select 1, 2, or 3 point calibration.
2) Depending on your selection, the **1 Pt Calibration**,
**2 Pt Calibration**, or **3 Pt Calibration** screen will appear.
Each of these screens lists the calibration points - various
combinations of 4.01, 7.01, and 10.01. Place the cursor beside
your desired point or combination of points and press SELECT.
As an example, if you select 2 Point Calibration, a new screen
will appear listing 7.01 & 4.01 Calib and 7.01 & 10.01 Calib. If
you SELECT 7.01 & 4.01 Calib, another screen will appear which
will take you through the calibration process.
•You will be instructed to“Place probe in 7.01 calibration
solution. Press Select.”
•A “Please Wait...” message will appear on screen.
•Once the probe calibrates in the 7.01 solution, you will then
be instructed to “Place probe in 4.01 calibration solution.
Press Select.”
•Once the probe has calibrated in the 4.01 solution,
calibration is complete.
Using Acid/Base Slopes
to Assess pH Probe Performance
In addition to displaying date, time, number of calibration
points and specic points, the **Last Calib./GLP** screen
provides readings for Acid Slope and Base Slope. Slopes are
given as percentages and tell you how closely your freshly
calibrated pH probe is reading as compared with an“ideal”
probe.
A new probe can get very close to “ideal” probe readings, but
with aging and coating becomes less accurate. The following
graph shows the acceptable range and indicates what should
be done if the reading falls outside this range. If your probe is
good in one range (acid or base), but bad in the other, it should
be replaced.
90% 95% 102% 105%
A 3-point calibration will always give you an acid and a
base slope: however, when using 1- or 2-point calibration,
depending on points chosen, you may get an acid OR a base
slope reading. In this case, the other reading will show as a
default 99.9.
pH Probe Diagnostic
Menu Button>pH>pH Probe Diagnostic
pH probes have a limited lifetime and must be replaced
periodically to maintain accurate readings. If you suspect
incorrect readings, work your way to the pH Probe Diagnostic
screen. Press SELECT. Follow instructions on the screen and
the unit will run a diagnostic test, then a message will appear
on the screen, such as“Probe or solution is bad!”Replace
your solution, run diagnostic again, and if you get the same
message, replace the probe.
Understanding pH Alerts (Caution and Critical)
The DL100 is designed to eciently monitor the pH value of
a solution and generate caution and critical alerts as needed.
The status lights located beside the screen will change color to
signal these alerts and, if you have enabled Wi-Fi and subscribe
to the interface portal, the monitor will send out your choice of
emails or text messages, or both, to alert you. See “Setting up
Wi-Fi” section for details on connecting to the interface portal.
A Caution is intended to alert you when the pH reading is
getting too high or too low. A Critical Alert is to let you know
that a reading has reached a critical level and you have a
serious problem needing immediate attention.
It is your responsibility to set the pH alerts for your specic
requirements. This is a balancing act and may require some
experimentation on your part. You want to receive the alerts
when needed, but you don’t want the DL100 to be sending out
alerts too frequently. See the diagram below for a typical setup.
5.60 6.30 7.00 7.70 8.40
Critical Caution Caution Critical
Red | Lime | Blue | Lime | Red
Below Alert Above Alert
If the value for pH is within the Caution parameters you have set,
the status lights on both sides of the screen will remain blue.
If the blue changes to lime, this signals that the value has
reached the Caution level. If the reading continues to drift
further from the target value and reaches the Critical level, the
lime lights will turn red, indicating a critical condition.
** Last Calib./GLP **
O5/04/15 9:25
2 Point Calibration
7.01 & 4.01
Acid Slope: 000.0
Base Slope: 000.0
>Exit

4
Setting pH Below Alerts (Caution & Critical)
Menu Button>pH>pH Below Alert
1) Work your way to the *pH Below Alert* screen. You will see
two options: “pH Caution” and “pH Critical.”If the settings shown
beside each are the desired settings, you may“Exit”the screen.
2) If you want to change the Caution setting, place the cursor
beside “pH Caution”and press SELECT.
3) On this screen, use the keypad arrows to create the new
setting, and press SELECT. The SAVED! screen will appear and
you will be taken back to the *pH Below Alert* screen.
4) Move the cursor to the“pH Critical”option; press SELECT,
then enter the new setting.
5) Press SELECT and you have completed the setup for the pH
Below Alerts. Scroll down and select “Exit” to go back to **pH
Menu** screen or press Menu button to go back to primary
display screen.
Setting pH Above Alerts (Caution & Critical)
Menu Button>pH>pH Above Alert
1) Work your way to the *pH Above Alert* screen. You will see
two options: “pH Caution” and “pH Critical.”If the settings shown
beside each are the desired settings, you may“Exit”the screen.
2) If you want to change the Caution setting, place the cursor
beside “pH Caution”and press SELECT.
3) On this screen, use the keypad arrows to create the new
setting, and press SELECT. The SAVED! screen will appear and
you will be taken back to the *pH Above Alert* screen.
4) Move the cursor to the“pH Critical”option; press SELECT,
then enter the new setting.
5) Press SELECT and you have completed the setup for the pH
Above Alerts. Scroll down and select“Exit”to go back to **pH
Menu** screen or press Menu button to go back to primary
display screen.
Setting Manual Temperature
Compensation
Menu Button>pH>Manual Temp. Comp.
Work your way to the *Manual Temperature Compensation*
screen. Using left/right arrows to scroll blinking cursor through
temperature and up/down arrows to change numbers, enter
the temperature of your solution, being sure to note if it is set
for Fahrenheit or Celsius scale. When complete, press SELECT
and the SAVED! screen will appear.
When manual temperature compensation has been set, MRC will
appear in the lower right corner of the primary display screen.
Setting up the Data Logger
(Time Interval & Start Time)
Please note that if you remove the SD card when the unit is ON,
the unit will remain operational. However, before re-inserting
the SD card, disconnect the unit from its power source. Once
you have the SD card snapped back in place, restore power
to the unit. If you re-insert the SD card while the unit is
operational, you must still momentarily disconnect from power,
then reconnect, allowing the unit to properly communicate
with the SD Card.
Also note that the internal SD card is xed at two-minute
logging intervals. The following instructions refer to the portal
only.
Example of Logged Data on SD Card
Menu Button>Data Log Setup>Data Logger
1) Work your way to the **Data Logger** screen. The cursor will
appear beside “Set Time Interval.”Press SELECT.
2) On the “Set time interval”screen, using the keypad
arrows, enter the amount of time between logs, in Hours:
Minutes:Seconds (00:00:00). Logging is restricted to a 5-minute
minimum upload interval (except for Snap Shots); however,
Milwaukee Instruments recommends a wider interval,
typically 00:10:00 to 00:15:00. For most applications, this 10- to
15-minute interval is frequent enough to gather meaningful
data without collecting too much data, which can often make
evaluation cumbersome.
3) Press SELECT to save this interval. Screen will read SAVED!
and go back to the **Data Logger** screen with the cursor
beside “Start Time.”
4) Press SELECT to advance to the Start Time screen. Using the
keypad arrows, enter the start time and press SELECT to save.
5) Press the Menu button to return to the primary display screen.
Note: To capture a real-time reading, press the Snap Shot button.
A snap shot will not interfere with scheduled data logging. When
you press the Snap Shot button on the keypad, “Snap Shot”will
appear for a few seconds in the lower right corner of the screen,
indicating the real-time data has been logged.
Checking Last Logged Screen
Place cursor beside“Last Logged” and press SELECT. The **Last
Logged** screen will appear. Press Menu button to return to
primary display screen.
Setting up Wi-Fi
In addition to displaying real-time data, the Wi-Fi and portal
provide email and text alerts, store redundant data, and oer
remote control of unit.
Use of Wi-Fi and portal is optional; it is not required. Not utilizing
** Last Logged **
01/05/16 08:06:07
pH: 7.105
Temperature: 77.56º F
Date Time pH Temperature

5
the portal will not aect operation of the unit.
Your DL Monitor is set up to transmit in the 2.4GHz frequency
range only. If you are using a wireless router with two or more
channels, please be sure to enter the“Network Name / SSID” that
will access the 2.4GHz frequency channel only. The unit will not
communicate at 5.0GHz.
Before beginning Wi-Fi setup, make sure you have the following:
• Wi-Fi Network Security Type (Open, WEP, or WPA)
• Wi-Fi Name, and
• Wi-Fi Password
IMPORTANT: Although “Wi-Fi Enable”is the rst option listed,
you should enter all Wi-Fi information with the unit in Wi-Fi
Disabled mode. Enable Wi-Fi as the last step, otherwise the unit
may begin uploading information before you nish entering it.
Menu Button>Wi-Fi Settings>Wi-Fi Enable
1) Work your way to the **Wi-Fi Enable** screen.
2) On the **Wi-Fi Enable** screen, place cursor beside“Enable”
and press SELECT.
3) Use the same procedure to Disable Wi-Fi.
Menu Button>Wi-Fi Settings>Security Type
1) Work your way to the **Wi-Fi Security** screen and press
SELECT.
2) On the **Wi-Fi Security** screen, you will have the following
options: Open, WEP, and WPA. WPA is the most common. Place
cursor beside the appropriate security type and press SELECT.
Menu Button>Wi-Fi Settings>Network Name/SSID
(Remember to use 2.4 GHz only)
1) Work your way to the“Network Name/SSID” screen and press
SELECT.
2) When the “Network Name/SSID”screen opens, ll in your Wi-
Fi name using the keypad arrows, and press SELECT.
Menu Button>Wi-Fi Settings>Pre-shared Key (Password)
1) Work your way to the **Pre-shared Key** screen and press
SELECT.
2) When the screen opens, the heading will read “Network
Password.”
3) Fill in your Wi-Fi password using the keypad arrows, and
press SELECT.
Menu Button>Wi-Fi Settings>View Device IP
When Wi-Fi is set up and you have logged in, you will be able to
view the Device IP and MAC Addresses.
Menu Button>Wi-Fi Settings>Upload Interval
This screen will show upload interval, that is, how often the
DL100 sends new information to the portal. Five minutes is the
minimum upload interval.
Menu Button>Wi-Fi Settings>Portal Sync
Menu Button>Wi-Fi Settings>Portal Service
IMPORTANT: Do not open the Portal Service screen unless
you are instructed to do so by Milwaukee Instruments. If you
accidentally open this screen, press MENU to back out. Do NOT
enter any data! Doing so will permanently disconnect you
from the portal.
** Wi-Fi Settings **
> Wi-Fi Enable
Security Type
Network Name/SSID
Pre-shared Key
View Device IP
Upload Interval
Portal Sync
Portal Service
Exit

6
Manufactured/Assembled
in the USA
Range .001 pH to 14.000 pH
Resolution - User Select Tenths (0.1 pH); Hundredths (0.01 pH); Thousandths (0.001) pH
Accuracy @ 77°F 0.02 pH
Setpoint Range 0.01 pH to 14.00 pH
Activation Parameter User Select above or below activation setpoint
Visual Alerts LED backlight blue = normal; lime = caution; red = critical
Probe Protection On Master Board GLP chipset ( Ground Loop Preventer )
Circuit Board Protection On Master Board RJ45 Backfeed Prevention Chipset
Operational Environment 15°F to 180°F (-10°C to 85°C)
Temperature Accuracy 0.5°F
Power Supply International Plug Set - No Converter Needed
pH Electrode MA911B/2
Main Board Atmel SAM3X8E ARM Cortex-M3 CPU
Operating Voltage 3.3 volts
Clock Speed 84 MHz clock
S Ram 96 KBytes of SRAM (two banks: 64KB and 32KB)
Flash Memory 512 KB
Data Retention 100 years at 25° C
Station and Access Point, Wi-Fi 802.11 b/g/n Roles with Integrated Radio, Baseband, and MAC
TCP/IP Embedded TCP/IP stack
Circuit Board Protection RJ45 Back Feed Protection with Short Circuit Protection
GLP (Ground Loop Prevention) Dual Ground Loop Prevention Circuit and Chipset
Input Power Supply 7V to 12VDC Recommended --- International Plug Set - No Converter Needed
Input Min. & Max. 6V to 20VDC
Logic Load Shifter Provides Higher LCD Screen Resolution and Fast Response Time
DL100 BLACK BOX SPECIFICATIONS
