MIMAKI CJV300-130 User manual

MIMAKI ENGINEERING CO., LTD.
URL: http://eng.mimaki.co.jp/
You can also download the latest manual from our website.
D202746-10
Original instructions

i
CAUTION .......................................................................................vii
DISCLAIMER OF WARRANTY ...........................................................vii
Requests .............................................................................................vii
FCC Statement (USA) .........................................................................vii
Interference to televisions and radios ..................................................vii
Foreword ........................................................................................vii
About usable ink ..................................................................................vii
On This Operation manual ..................................................................vii
Safety Precautions ........................................................................ viii
Symbols ..............................................................................................viii
Safety interlock .................................................................................... xi
Warning labels ...............................................................................xii
EC DECLARATION OF CONFORMITY .............................................xiv
Chapter 1 Before Use
Moving This Machine ................................................................... 1-2
Where to Install This Machine........................................................... 1-2
Working Environmental Temperature................................................ 1-2
Moving This Machine ........................................................................ 1-2
Names of Parts and Functions .................................................... 1-3
Front Side of the Machine ................................................................. 1-3
Rear Side and Right Side of the Machine ......................................... 1-4
Operation Panel ................................................................................ 1-5
Media sensor..................................................................................... 1-7
Carriage............................................................................................. 1-7
Cutter blade and slot for cutting ........................................................ 1-7
Capping station ................................................................................. 1-7
Pinch Rollers and Grit Rollers ........................................................... 1-7
Connecting Cables ...................................................................... 1-8
Connecting USB2.0 Interface Cable ................................................. 1-8
Connecting the power cable.............................................................. 1-8
Inserting ink cartridges ................................................................. 1-9
Caution in handling of ink cartridges ............................................... 1-10
Media ......................................................................................... 1-10
Usable sizes of media ..................................................................... 1-10
Caution in handling of medias......................................................... 1-10
Menu mode ................................................................................ 1-11
Chapter 2 Basic Operations
Workflow of printing ..................................................................... 2-2
Turning the Power ON/OFF ......................................................... 2-3
Turning the Power ON....................................................................... 2-3
Turning the Power OFF..................................................................... 2-3
Setting a Media ............................................................................ 2-4
Adjusting the Head Height................................................................. 2-4
Adjusting the Position of the Pinch Roller According to the State
of a Media.......................................................................................... 2-5
Table of Contents

ii
Maximum Print Area/Cut Area........................................................... 2-8
Notes When Using media Holder ...................................................... 2-8
Setting a roll media............................................................................ 2-9
Take-up device................................................................................ 2-12
Setting leaf media............................................................................ 2-12
Changing the printing origin ............................................................ 2-14
Preparing for the Heaters ...........................................................2-14
Changing the Temperature Settings for the Heaters....................... 2-14
Test Printing ...............................................................................2-15
Test Printing .................................................................................... 2-15
Head Cleaning ...........................................................................2-16
About head cleaning........................................................................ 2-16
Perform head cleaning depending on the test printing result .......... 2-16
Setting of Media Correction ........................................................2-16
Setting of Media Correction............................................................ 2-16
If the Positions of Dots Shift... ....................................................2-17
Printing Data ..............................................................................2-17
Starting a Printing Operation ........................................................... 2-17
Stopping a Printing Operation ......................................................... 2-18
Deleting Received Data (Data Clear) .............................................. 2-18
Cutting a media ..........................................................................2-18
Workflow of cutting .....................................................................2-19
Installing Tools ...........................................................................2-20
When a Cutter Is Used .................................................................... 2-20
How to Install a Ballpoint Pen.......................................................... 2-21
Setting the tool conditions ..........................................................2-23
Kinds of the Tool Conditions ........................................................... 2-23
Select the tool condition .................................................................. 2-24
Set the Tool Conditions ................................................................... 2-24
Test Cutting ................................................................................2-25
Cutting Data ...............................................................................2-25
Setting the origin ............................................................................. 2-25
Start cutting ..................................................................................... 2-26
Stopping a Cutting Operation (Data Clear) ..................................... 2-26
Cutting a media ..........................................................................2-26
Chapter 3 Setup
About SETUP MENU ...................................................................3-2
SETUP MENU table .......................................................................... 3-3
Setting of Media Correction............................................................... 3-4
If the Positions of Dots Shift... ........................................................... 3-4
Setting the HEATER.......................................................................... 3-5
Setting of Logical Seek...................................................................... 3-5
Setting of Drying Time....................................................................... 3-6
Setting of Left and Right Margins ..................................................... 3-6
Setting of VacuumFan....................................................................... 3-6
Setting of Feed Speed....................................................................... 3-7
Setting Auto Cleaning........................................................................ 3-7
Setting Interval wiping ....................................................................... 3-7

iii
About MACHINE SETUP MENU ................................................. 3-8
MACHINE SETUP MENU table ........................................................ 3-9
Setting a AUTO Power-off............................................................... 3-10
Setting Take-up unit ........................................................................ 3-10
Setting the Display of Media Residual............................................. 3-10
Setting a LANGUAGE ..................................................................... 3-11
Setting Time .................................................................................... 3-11
Setting Unit (Temperature/ Length)................................................. 3-11
Setting a KEY BUZZER................................................................... 3-11
Setting the CONFIRM. FEED.......................................................... 3-11
Set the network ............................................................................... 3-12
Setting event mail function .............................................................. 3-12
Initializing the Settings..................................................................... 3-16
About NOZZLE CHECK MENU ................................................. 3-17
INFORMATION MENU table........................................................... 3-17
Printing Check Flow ........................................................................ 3-18
Printing Operations at “Nozzle Missing” Judgment and Error
Occurrence...................................................................................... 3-18
Setting the Printing Check............................................................... 3-19
Setting the NOZZLE RECOVERY................................................... 3-19
Setting the Judgement Condition .................................................... 3-19
About INFORMATION MENU .................................................... 3-20
INFORMATION MENU table........................................................... 3-21
Displaying the Information............................................................... 3-21
Chapter 4 Cutting Funcion
Cut Out Data with Registration Mark ........................................... 4-2
The Flow of Cutting out the Registered Data .................................... 4-2
Enter the registration mark detection mode ...................................... 4-2
Precautions in inputting data with registration marks........................ 4-2
Setting of Detecting the Registration Marks ...................................... 4-5
Method of detecting registration marks ............................................. 4-6
About CUTTING MENU ............................................................... 4-7
Cutting MENU table........................................................................... 4-8
Setting the CUT MODE ............................................................... 4-9
Set the distance compensation .................................................... 4-9
Find compensation value .................................................................. 4-9
Setting procedures ............................................................................ 4-9
perform multiple Cuttings (Copy function) ................................. 4-11
SETUP SUB MENU ................................................................... 4-11
Setting the DIVISION CUT .............................................................. 4-11
Make the media without uncut area (OVER CUT function)............. 4-13
Other SETUP SUB MENU .............................................................. 4-13
SETUP RESET ............................................................................... 4-14
Maintenance Function ............................................................... 4-14
Maintenance of Mark Sensor .......................................................... 4-14
Perform SAMPLE CUT to Find out the Cause of Cutting Error....... 4-17
Cutting a Medium into Multiple Pieces with a Certain Length ......... 4-17
Cutting out Data without Register Marks (ORIGIN OFFSET) ......... 4-18

iv
Chapter 5 Maintenance
Maintenance ................................................................................5-2
Precautions for Maintenance............................................................. 5-2
About Cleaning Solution ....................................................................5-2
Cleaning the Exterior Surfaces.......................................................... 5-2
Cleaning the Platen ........................................................................... 5-2
Cleaning the Media Sensor ............................................................... 5-3
Cleaning the Media Press ................................................................. 5-3
About MAINTENANCE MENU .....................................................5-4
MAINTENANCE MENUs at-a-glance................................................ 5-5
Maintaining the Capping Station ..................................................5-6
Cleaning the Wiper and Cap ............................................................. 5-6
Washing the Head Nozzle................................................................. 5-7
Washing the Ink Discharge Passage ................................................ 5-8
When the Machine Is Not Used for a Long Time .............................. 5-8
Cleaning the Ink Head and the Area around It ...........................5-10
Nozzle Recovery Function .....................................................................5-11
Reset the set value.......................................................................... 5-12
Automatic Maintenance Function ...............................................5-13
Setting the Refreshing Intervals ...................................................... 5-13
Setting the Tube Wash Intervals ..................................................... 5-13
Setting the Cleaning Intervals and Type ......................................... 5-13
Fill up Ink ....................................................................................5-14
White Ink Maintenance ...............................................................5-14
Replacing consumables .............................................................5-15
Replacing the wiper......................................................................... 5-15
If a Waste Ink Tank Confirmation Message Appears ...................... 5-15
Replacing the waste ink tank before the waste ink tank
confirmation message is displayed ................................................. 5-17
Replacing the Cutter Blade ............................................................. 5-17
Replacing and Adjusting the Cutter Blade .................................5-18
Replacing the cutter ........................................................................ 5-18
Adjusting the Cutter Blade............................................................... 5-18
Replacing the cutter other than supplied one.................................. 5-18
Adjusting blade edge of cutter other than supplied one .................. 5-19
Chapter 6 Troubleshooting
Troubleshooting ...........................................................................6-2
Power does not turn on ..................................................................... 6-2
The machine does not start printing .................................................. 6-2
Media get jammed / media is soiled .................................................. 6-2
The heater’s temperature will not rise to the set level ....................... 6-3
Image quality is poor ......................................................................... 6-3
Nozzle is clogged .............................................................................. 6-3
Ink cartridge warning appears ........................................................... 6-3
Warning / Error Messages ...........................................................6-5
Warning messages............................................................................ 6-5
Error messages ................................................................................. 6-8

v
Chapter 7 Appendix
Specifications ............................................................................... 7-2
Printer Section Specifications............................................................ 7-2
Cutter Section Specifications ............................................................ 7-2
Common Specifications..................................................................... 7-3
Ink specifications............................................................................... 7-4
Setting orders depending on ink type .......................................... 7-5
Sheet for inquiry ........................................................................... 7-6

vi

CAUTION
vii
CAUTION
DISCLAIMER OF WARRANTY
THIS LIMITED WARRANTY OF MIMAKI SHALL BE THE SOLE
AND EXCLUSIVE WARRANTY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS, AND MIMAKI NEITHER
ASSUMES NOR AUTHORIZES DEALER TO ASSUME FOR IT
ANY OTHER OBLIGATION OR LIABILITY OR MAKE ANY
OTHER WARRANTY OR MAKE ANY OTHER WARRANTY IN
CONNECTION WITH ANY PRODUCT WITHOUT MIMAKI’S
PRIOR WRITTEN CONSENT.
IN NO EVENT SHALL MIMAKI BE LIABLE FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR
LOSS OF PROFITS OF DEALER OR CUSTOMERS OF ANY
PRODUCT.
Requests
• This Operation manual has been carefully prepared for
your easy understanding.
However, please do not hesitate to contact a distributor
in your district or our office if you have any inquiry.
• Description contained in this Operation manual are
subject to change without notice for improvement.
FCC Statement (USA)
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the Operation manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
In the case where MIMAKI-recommended cable is not used for
connection of this device, limits provided by FCC rules can be
exceeded.
To prevent this, use of MIMAKI-recommended cable is essential
for the connection of this printer.
Interference to televisions and radios
The product described in this manual generates high frequency
when operating.
The product can interfere with radios and televisions if set up or
commissioned under improper conditions.
The product is not guaranteed against any damage to specific-
purpose radio and televisions.
The product’s interference with your radio or television will be
checked by turning on/off the power switch of the product.
In the event that the product is the cause of interference, try to
eliminate it by taking one of the following corrective measures or
taking some of them in combination.
• Change the orientation of the antenna of the television set or
radio to find a position without reception difficulty.
• Separate the television set or radio from this product.
• Plug the power cord of this product into an outlet which is
isolated from power circuits connected to the television set or
radio.
Foreword
Congratulations on your purchase of MIMAKI color ink jet
printer "CJV300-130/160" .
“CJV300-130/160” is a color inkjet printer that can print on
1.9m-width media with solnent ink (4-color, 6-color and 8-
color) and sublimation dye ink (4-color and 6-color)
realizing high image quality.
About usable ink
You can use solvent ink (SS21) and sublimation dye ink
(Sb53) for this machine.
On This Operation manual
• This Operation manual is describing the operations
and maintenance of "Color inkjet printer CJV300-130/
160" (called as this machine hereafter)
• Read this Operation manual carefully and understand
them thoroughly to use.
• It is also necessary to keep this Operation manual on
hand.
• This Operation manual has been carefully prepared for
your easy understanding, however, please do not
hesitate to contact a distributor in your district or our
office if you have any inquiry.
• Descriptions contained in this Operation manual are
subject to change without any notice for improvement.
• In the case when this Operation manual should be
illegible due to destruction or lost by fire or breakage,
purchase another copy of the Operation manual from
our office.
• You can also download the latest manual from our
website.
Reproduction of this manual is strictly prohibited.
All Rights Reserved.Copyright
© 2014 MIMAKI ENGINEERING Co., Ltd.

viii
Safety Precautions
1
2
2
2
2
2
1
Safety Precautions
Symbols
Symbols are used in this Operation Manual for safe
operation and for prevention of damage to the machine.
The indicated sign is different depending on the content of
caution.
Symbols and their meanings are given below. Please
follow these instructions as you read this manual.
Examples of symbols
Warning for Use
Meaning
Failure to observe the instructions given with this
symbol can result in death or serious injuries to
personnel. Be sure to read it carefully and use it
properly.
Failure to observe the instructions given with this
symbol can result in injuries to personnel or
damage to property.
Important notes in use of this machine are given
with this symbol. Understand the notes thoroughly
to operate the machine properly.
Useful information is given with this symbol. Refer
to the information to operate the machine
properly.
Indicates the reference page for related contents.
The symbol " " indicates that the instructions
must be observed as strictly as the CAUTION
instructions (including DANGER and WARNING
instructions). A sign representing a precaution
(the sign shown at left warns of hazardous
voltage) is shown in the triangle.
The symbol " " indicates that the action
shown is prohibited. A sign representing a
prohibited action (the sign shown at left prohibits
disassembly) is shown in or around the circle.
The symbol " " indicates that the action
shown must be taken without fail or the
instructions must be observed without fail. A sign
representing a particular instruction (the sign
shown at left instructs to unplug the cable from the
wall outlet) is shown in the circle.
WARNING
• The set of power cables provided with this machine
is for use with this machine only, and cannot be
used with other electrical devices. Do not use any
power cables other than the ones provided with the
machine. Failure to observe those instructions may
result in fire or electric shocks.
• Take care not to damage, break or work upon the
power cable. If a heavy material is placed on the
power cable, or if it is heated or pulled, the power
cable can break, thus resulting in fire or electric
shocks.
• Do not use this machine in an environment where
humidity is high or the machine may get wet. Using
the machine under such environment may result in
fire or electric shock, or cause malfunction.
• Use of the machine under an abnormal condition
where it produces smoke or strange smell can
result in fire or electric shocks. If such an
abnormality is found, be sure to turn off the power
switch immediately and unplug the cable from the
wall outlet. Check first that the machine no longer
produces smoke, and then contact your distributor
or a sales office of MIMAKI for repair.
• Never repair your machine by yourself since it is
very dangerous for you to do so.
• Never disassemble or remodel the main unit of the
machine or the ink cartridge. Disassembly or
remodeling can result in an electric shock or
breakdown of the machine.
• Take care that no dust or dirt sticks to Media
Transfer Surface heaters. Dust and dirt sticking
heaters can cause fire.
• Do not use extension cords. Doing so may result in
fire or electric shocks.
• Keep the power plug prong clear of any foreign
object such as a piece of metal. Failure to do so
may result in a fire or electric shocks.
• Do not plug too may leads into a single socket.
Doing so may result in fire or electric shocks.
• Do not use the machine if the power cord or plug is
damaged. Using the machine with damaged power
cord may result in fire or electric shocks. Contact
your service representative for replacement cord.
• Do not handle the power plug with wet hands.
Doing so may result in electric shocks.
• Grasp by holding the plug itself when removing the
power plug from wall outlet, and never hold by the
cord. Holding and pulling the cord may damage the
cord, leading to fire or electric shocks.

Safety Precautions
ix
Precautions in Use
Hazardous Moving Parts
• Keep Fingers and Other Body Parts Away
• If a foreign object such as a small piece of metal or
a liquid such as water gets inside the machine, turn
off the machine and unplug the power cord
immediately, then consult your service
representative. Continuing to use the machine
without proper maintenance or repair may result in
fire or electric shocks.
• Do not use a flammable spray or solvent inside or
around the machine. Doing so may result in fire or
electric shocks.
• Do not place a vase, flower pot, water glass,
container with liquid such as water or chemicals
inside, or small metallic object near or on top of this
machine. Liquid or foreign object may get inside the
machine, leading to fire or electric shocks.
WARNING
CAUTION
Handling of the power cable
• Connect to a socket-outlet with determinate
polarity.
• For Inlet 1 and 2, be sure to supply power from
the outlet of the same voltage.
• for PLUGGABLE EQUIPMENT, the socket-
outlet shall be installed near the equipment
and shall be easily accessible.
• Unplug the cord from the wall outlet and
remove dust from the power plug periodically,
at least once a year. Failure to do so may
result in fire or electric shocks.
• Do not use the machine unless it is connected
to a power supply that satisfies the displayed
voltage condition.
• Check the voltage of the wall outlet and the
capacity of the circuit breaker before you plug
the power cords. Plug each power cord to
different outlet that has independent circuit
breaker. If you plug more than one power cord
to wall outlets that share the same circuit
breaker, the power may be cut off by the
breaker.
Power supply
• Leave the breaker turned ON.
• Do not turn off the main power switch on the
right side of this machine.
Heater
• Do not spill liquid on the Media Transfer
Surface as this may cause failure of the heater
or firing.
• Do not touch Media Transfer Surface heaters
with bare hand while it is hot; otherwise, you
can get burned.
Note on maintenance
• When cleaning the ink-station or the heads,
make sure to wear the attached goggles and
gloves.
• The gloves supplied with the machine are
disposable. When all the gloves are
expended, purchase an equivalent product on
the market.
• Keep ink away from an open flame. Also keep
the room well ventilated when you use or
handle ink.
Be careful with the movable parts
• Do not touch the rolling grit roller; otherwise,
you may hurt your fingers or tear off your
finger nails.
• Keep your head and hands away from any
moving parts during cutting (plotting)
operation; otherwise, you may get your hair
caught in the machine or get injuries.
• Wear proper clothes. (Do not wear loose-fit
clothes or accessories). Bind a long hair.

x
Safety Precautions
1
2
2
2
2
2
1
CAUTIONS and NOTES
Caution with cutters
• Do not touch the cutter blade, which is very
sharp.
• Do not shake or swing the cutter holder;
otherwise, the blade may come off.
Handling of ink
• Keep ink away from an open flame. Also keep
the room well ventilated when you use or
handle ink.
• If you get ink in your eyes, immediately wash
your eyes with a lot of clean water for at least
15 minutes. In doing so, also wash eyes to
rinse ink away completely. Then, consult a
doctor as soon as possible.
• If anyone drinks ink by mistake, keep him or
her quiet and see a doctor immediately. Do not
allow him or her to swallow the vomit.
Then contact the emergency number written in
MSDS.
• If you inhale a lot of vapor and feel bad,
immediately move to a location of fresh air
and then keep yourself warm and quiet. Then,
consult a doctor as soon as possible.
• Store ink cartridges in a place that is out of the
reach of children.
• If the ink adheres to your skin, use a large
amount of water and soap or special detergent
for skin to remove the ink.
CAUTION
Warning
Clump lever
• Never raise the lever during printing. Raising the lever will
abort printing.
Protection of media from dust
• Store media in a bag. Wiping off dust accumulated on media
will adversely affect the media due to static electricity.
• When leaving the workshop after the working hours, do not
leave any media on the roll hanger. If any media is left on the
roll hanger, it can get dusty.
Periodic replacement parts
• Some parts of this machine must be replaced with a new
one periodically by service personnel. Be sure to make a
contract with your distributor or dealer for After sale service
to ensure a long life of your machine.
Disposition of this machine
• Consult your sales or service representative for proper
disposal of this machine. Otherwise, commission an
industrial waste disposal company.
Protection of media from dust
• Store media in a bag. Wiping off dust accumulated on media
will adversely affect the media due to static electricity.
• When leaving the workshop after the working hours, do not
leave any media on the roll hanger. If any media is left on the
roll hanger, it can get dusty.
Handling of ink cartridges
• The safety evaluation of this machine assumes that the ink
recommended by this company is used. For safe usage of
this machine, use the ink recommend by this company
• Never refill the ink pack and white ink cartridge with ink.
Refilled ink cartridge can cause a trouble. Remember that
MIMAKI assumes no responsibility for any damage caused
by the use of the ink cartridge replenished with ink.
• If the ink cartridge is moved from a cold place to a warm
place, leave it in the room temperature for three hours or
more before using it.
• Open the ink cartridge just before installing it in the machine.
If it is opened and left for an extended period of time, normal
printing performance of the machine may not be ensured.
• Make sure to store ink cartridges in a cool and dark place.
• Store ink cartridges and waste ink bottle in a place that is out
of the reach of children.
• Be sure to thoroughly consume the ink in the ink cartridge,
once it is opened, within three months. If an extended period
of time has passed away after opening the cartridge tank,
printing quality would be poor.
• Neither pound the cartridge nor shake it violently, as doing
so can cause leakage of ink.
• Do not touch or stain the contacts of the ink cartridge, as
doing so may cause damage to the print circuit board.
• Consult your sales or service representative for proper
disposal of ink cartridge, ink pack, and waste ink.
When you dispose them by yourself, follow the regulations
stipulated by the industrial waste disposer or the country or
region you live in
• Make sure that you shake the white
and silver ink
cartridges before printing.

Safety Precautions
xi
Cautions on Installation
Safety interlock
This machine is equipped with interlocks to terminate the
operation for your safety when the cover opens during
printing etc. (red circle parts in the figure below).
Protection of media from dust
• Store media in a bag. Wiping off dust accumulated on media
will adversely affect the media due to static electricity.
• When leaving the workshop after the working hours, do not
leave any media on the roll hanger. If any media is left on the
roll hanger, it can get dusty.
Notes on maintenance
• It is strongly recommended to use the machine in a room
that is not dusty.
• Keep the front cover closed even when the machine is not
printing. If not, dust can accumulate on the nozzles in the
heads.
• Dust in the heads can also cause drops of ink to fall
suddenly down on the media during printing. In such a case,
be sure to clean up the heads. ( P.5-10)
• When cleaning the ink-station or the heads, make sure to
wear the attached gloves. Further, when the solvent ink is
used, it is necessary to wear the attached goggles.
• Perform wiping (removal of dust and paper powder) of the
capping station and wiper frequently.
Handling of media
• Use media recommended by MIMAKI to ensure reliable,
high-quality printing.
• Set the heater temperature to meet the characteristics of the
media. (Model with a built-in heater)
Set the temperature of the Pre-heater, Print heater and Post-
heater according to the type and characteristics of the media
used. Automatic temperature setting can be made on the
operation panel by setting the profile on the dedicated RIP.
For setting on the RIP, refer to the instruction manual for
your RIP.
• Pay attention to the expansion and contraction of the media.
Do not use media immediately after unpacking. The media
can be affected by the room temperature and humidity, and
thus it may expand and contract.The media have to be left in
the atmosphere in which they are to be used for 30 minutes
or more after unpacked.
• Do not use curled media.
The use of curled media can not only cause a media jam but
also affect print quality.
Straighten the sheet of media, if significantly curled, before
using it for printing. If a regular-sized coated sheet of media
is rolled and stored, the coated side has to face outside.
• Do not leave the media with the heater ON for a long time.
Warning
CAUTION
A place exposed to direct
sunlight On an inclined surface
A place that vibrates
A place exposed to direct air
flow from an air conditioner
or the like.
A place where temperature or
humidity varies significantly
Around a place where fire
is used
• Use the machine under the
following environmental
conditions:
• Operating environment:
20 to 30 °C
(68 to 86 °F)
35 to 65 % (Rh)

xii
Warning labels
1
2
2
2
2
2
1
Warning labels
Warning labels are stuck on the machine. Be sure to fully understand the warning given on the labels.
If a warning label is illegible due to stains or has come off, purchase a new one from a distributor or our sales office.
Around the caridge
When the maintenance cover is open

xiii
Warning labels
No. Reorder Label
1M903239
2M903330
3M903405
4M906144
5M907935
6M905811
7M906031
8M905935

xiv
Warning labels
1
2
2
2
2
2
1
EC DECLARATION OF CONFORMITY
We hereby declare that the following our product conforms with the essential health and safety requirements of EC
Directives.
Product Inkjet Printer
Model No. CJV300-160
CJV300-130
Manufacturer MIMAKI ENGINEERING CO.,LTD.
2182-3, Shigeno-otsu, Tomi, Nagano,
389-0512, JAPAN
Authorised Compiler in the Community
MIMAKI EUROPE B.V.
Stammerdijk 7E 1112 AA Diemen,
The Netherlands
Directives Machinery Directive2006/42/EC
Low Voltage Directive2014/35/EU
EMC Directive2014/30/EU
RoHS Directive2011/65/EU
The above product has been evaluated for conformity with above directives using the following European standards. The
technical construction file (TCF) for this product is retained at the above Manufacturer’s location.
Machinery Directive / Low Voltage Directive
ENISO12100:2010, EN60204-1:
2006+A1,EN60950-1:
2006+A11+A1+A12
EMC Directive EN55022:2010, EN61000-3-2:
2006+A1+A2, EN61000-3-3:2008, EN55024:2010
RoHS Directive EN50581:2012

xv
Warning labels

This chapter
describes the items required to understand before use, such as the name of each part of
the machine or the installation procedures.
Moving This Machine .................................... 1-2
Where to Install This Machine ..................... 1-2
Working Environmental Temperature ......... 1-2
Moving This Machine .................................. 1-2
Names of Parts and Functions...................... 1-3
Front Side of the Machine ........................... 1-3
Rear Side and Right Side of the Machine ... 1-4
Operation Panel .......................................... 1-5
Media sensor ............................................... 1-7
Carriage ...................................................... 1-7
Cutter blade and slot for cutting .................. 1-7
Capping station ........................................... 1-7
Pinch Rollers and Grit Rollers ..................... 1-7
Connecting Cables........................................ 1-8
Connecting USB2.0 Interface Cable ............1-8
Connecting the power cable ........................1-8
Inserting ink cartridges .................................. 1-9
Caution in handling of ink cartridges ..........1-10
Media .......................................................... 1-10
Usable sizes of media ................................1-10
Caution in handling of medias ...................1-10
Menu mode ................................................. 1-11
Chapter 1
Before Use

Chapter 1 Before Use
1-2
Moving This Machine
Where to Install This Machine
Secure a suitable installation space before assembling
this machine.
The place of installation must have enough space for not
only this machine itself, but also for the printing operation.
Working Environmental Temperature
Use this machine in an environment of 20 to 30°C to
ensure reliable printing.
Moving This Machine
Move this machine according to the following steps when
this machine needs to be moved on the same step-free
floor.
1Remove the caster blocks.
2Move this machine as shown in the figure.
• For safety, be sure to operate it with 4 people or
more.
• Do not push the cover to move this machine since
the cover may be broken.
3Reinstall the caster blocks.
Model Width Depth Height Gross
weight
CJV300-130 2525mm 700mm 1392mm 157kg
CJV300-160 2775mm 700mm 1392mm 168kg
500 mm or more
3525 mm or more (130 model)
3775 mm ormore (160 model)
2700mmormore
500 mm or more
1000mmormore
1000mmormore
• When the machine is moved to any place other
than on the same step-free floor, contact your
distributor or our service office.
If you move it by yourself, failure or damage may
occur. Be sure to request your distributor or our
service office to move this machine.
• When moving this machine, take care that it does
not receive a significant impact.
• Be sure to lock the casters after moving of this
machine.

1-3
Chapter 1 Before Use
1
2
2
2
2
Names of Parts and Functions
Front Side of the Machine
Operation panel
This panel has the operation keys
required for operating the machine and
the LCDs for displaying setting items,
etc.
Clamp lever (front)
Moves the pinch rollers up and down to hold or
release the media.
Waste ink tank
Waste ink gathers in this tank.
Stand
Supports the main body of the machine. It is
provided with casters that are used to move
this machine.
Platen
The printed media is sent out, sliding on the
platen.
Ink cartridges
Each cartridge contains an ink of a particular
color.
Cartridge protection cover
This prevents an injury or breakage of the
machine due to a protrusion of the ink
cartridge.
(It is located under the ink cartridge.)
Take-up device
Automatically winds up the roll media printed.
Carriage
Move the print head unit from side to side.
Maintenance cover
Open the cover in maintenance.
Even when the power switch is off, keep all covers
closed.
CleaningSolutionCartridge slot
Insert the cleaning solution cartridge.

1-4
Chapter 1 Before Use
Rear Side and Right Side of the Machine
AC inlet
Connect the power cable to the AC inlet.
Clamp lever (rear)
Interlocks with the clamp lever
in the font of this machine.
USB 2.0 connector
This is USB2.0 interface connector.
Main power switch (INLET 1)
Turns on/off the main power for this machine. Leave
the main power turned on to prevent ink clogging.
Blowdown fan filter
Suppress upward
floating of the ink mist
that occurs during
printing.
Vent filter box
Vents the ink mist that
occurs during printing.
Roll holders
Putting this into the paper core
(right and left) of a roll media, hold
the media. It supports the paper
core of 2 inch and 3 inch.
Power switch for heater (INLET 2)
Turns on/off the heater for this machine.
LAN connector
Please use this connector when you use netwark
