Daily Care Manual
D201579
Request for daily care
Inkjet printer is the precision machine that has highly delicate mechanism. Especially, little dust and
paper powder may have effect on a head nozzle firing ink, and may not get normal printing.
To use the inkjet printer in good condition, we recommend the following daily care.

2
Table of contents
In Case Sefective Printing Is Not Resolved ............................................ 5
Cleaning Flushing Tray ............................................................................ 8
When The Waste Ink Tank Becomes Full.............................................. 10
Replacing Water In Water Heater Tank ................................................. 11
Regular Maintenance For White Ink ...................................................... 17
Cleaning Or Replacing Filter ................................................................. 19
Cleaning The Undersurface Of The Carriage........................................ 20
Storage Of Antifreezing Liquid And Washing Liquid.............................. 22
Storage Of Media .................................................................................. 22
Storage Of Ink Cartridge ....................................................................... 22

3
Installation environment and Notes on cleaning
•Use this printer in clean (less dust) environment. The use of fan and ventilator might be
cause of dusty environment.
They brow dust up dust around the printer.
•As using UV curing ink, install this printer in a well-ventilated area.
•Working environmental temperature is 15 to 30°C (59 to 86°F). Avoid using at lower or
higher than this.
Notes on cleaning
•Never disassemble the device. Disassembling the device can result in
electric shock hazards and breakage of the device.
•Prevent moisture from entering inside the device. If the inner part of the
device becomes wet, electric shock hazards and breakage of the device
can result.
•Conduct maintenance works after turning off the power switch and detach-
ing the power cable. If not, unexpected troubles can arise.
•Make maintenance after the UV lamp has been sufficiently cooled, or burn
injury may occur.
•Do not use benzine, thinner and chemical agents containing abrasives.
Such materials can deteriorate or deform the surface of the cover.
•Do not apply lubricating oil or the like inside the device. Such materials
can cause the printer mechanism to fail.
•UJF-605C is a printer that uses ultraviolet ray curing ink (UV ink).. When
implementing the daily care, must wear supplied goggles and gloves.
•In case water or alcohol mixed into the organic solvent ink, flocculation
would be occurred. Be sure that not adhere water or alcohol to not only the
nozzle and also near the head, the cap, wiper and so on.

4
Maintenance for frame components
If the frame components of the device have stained, dampen a piece of soft cloth with
water or neutral detergent diluted with water, squeeze it and wipe the frame components
clean.

5
In Case Sefective Printing Is Not Resolved
When the station interior is severely contaminated or defective printing is not resolved
after executing the head cleaning function ( Operation manual P.2-20).
Clean the suction nozzle and cap using the cleaning kit as follows,
Washing liquid, Gloves, Cleaning swab, goggles
•When cleaning the ink station and head, be sure to wear the supplied
goggle and gloves since you may get ink in your eyes.
•Do not use alcohol or water.
•Do not move the carriage out of the capping station by hand. Use the
appropriate operation key to move the carriage.
The examples of defective printing
These following examples indicate improper head (nozzle) firing by dust, which effect
printing. Confirm the nozzle condition periodically before or during outputting not to use in
such as this condition. The nozzle condition can be confirmed with [test print] in this plotter.
Deflection Nozzle out
Ink dropping Satellite

6
STEP
1. Press the [FUNCTION] key from the LO-
CAL mode.
2. Press the [ ] and [ ] keys until the display
gives the indication [MAINTENANCE].
3. Press the [ENTER] key.
4. Press the [ ] and [ ] keys until the display
gives the indication [STATION].
5. Press the [ENTER] key.
6. Press the [ENTER] key again.
Carriage moves to the table.
7. Open the right maintenance cover.
8. Clean the suction nozzle using the exclu-
sive cleaning swab which is containing
washing liquid.
•Carefully clean the suction nozzle.
•Suction nozzle severely contaminated
or bent should be replaced with a new
one. Contact your nearest sales
agency or Mimaki sales office.
•Contact your nearest sales agency or
Mimaki sales office to order the exclu-
sive cleaning swab.
<< LOCAL >>
STATION
CARRIAGE OUT : ent
MAINTENANCE
STATION < ent >
MAINTENANCE
LIST < ent >
FUNCTION
MAINTENANCE < ENT >
FUNCTION
DATA CLEAR < ENT >

7
9. Wipe the adherent ink which got on the
cap rubber or inside the suction nozzle
cover with the exclusive cleaning swab.
10. Close the maintenance cover and then press
the [ENTER] key.
The initial operation is performe, then the device
enters to the LOCAL mode.
How to recover improper nozzle firing
When not using this plotter for a long time or according to environmental temperature,
nozzle may be unstable in firing.
In the case of this, follow below procedures to recover nozzle.
In case the nozzle doesn't recover after implementing these procedures, contact with our
customer service or agency you purchased, and need to replace heads and so on.
1. Daily care
Implement all parts noted on this article.
2. Normal cleaning ( Operation manual
P.2-20)
Implement normal cleaning along the instruction
manual after daily care above-mentioned.
Repeat cleaning and test printing, and confirm the
nozzle still clogging or not.
•In case nozzle clogging is not resolved
with all these procedures, contact with
our customer service or make service
call to the agency you purchased.
Suction nozzle cover
STATION
COMPLETED : ent
PLEASE WAIT
<< LOCAL >>

8
Cleaning Flushing Tray
Wipe off waste ink from the flushing tray.
Tools necessary for cleaning: Washing liquid, Gloves, goggles, paper towel
•When cleaning the ink station and head, be sure to wear the supplied
goggle and gloves since you may get ink in your eyes.
•Do not move the carriage out of the capping station by hand. Use the
appropriate operation key to move the carriage.
•Make sure to remove the waste ink in the flushing tray frequently. Other-
wise the waste ink dried out solidly under the UV light and may not remove.
STEP
1. Press the [FUNCTION] key from the LO-
CAL mode.
2. Press the [ ] and [ ] keys until the display
gives the indication [MAINTENANCE].
3. Press the [ENTER] key.
4. Press the [ ] and [ ] keys until the display
gives the indication [STATION].
5. Press the [ENTER] key.
6. Press the [ENTER] key.
Carriage moves to the table.
<< LOCAL >>
STATION
CARRIAGE OUT : ent
MAINTENANCE
STATION < ent >
MAINTENANCE
LIST < ent >
FUNCTION
MAINTENANCE < ENT >
FUNCTION
DATA CLEAR < ENT >

9
7. Open the left maintenance cover.
8. Wipe off the waste ink from the flushing
tray with the paper towel containing wash-
ing liquid. Take the caked ink off by pat-
ting the tray.
•Make sure to take the caked ink off
completely, or it may cause head
damage by the remaining caked ink.
The UV ink dried out solidly under the
UV light. In case unable to get rid of
the caked ink, the tray should be
replaced with a new one. Please
contact your local dealer for purchas-
ing a new tray.
9. Close the station cover and then press the
[ENTER] key.
The initial operation is performe, then the device
enters to the LOCAL mode.
STATION
COMPLETED : ent
PLEASE WAIT
<< LOCAL >>

10
When The Waste Ink Tank Becomes Full
Waste ink used for cleaning the heads will gather in the waste ink tank.
•Contact your local MIMAKI distributor or call a local MIMAKI office if you
need a spare waste ink tank.
•Prepare a polyethylene tank for emptying waste ink.
•If ink is dripping, wait until it stops dripping.
When the tank is filled with waste ink, the following error message is indicated:
STEP
1. Open the waste ink tank box cover.
2. Pull out the waste ink tank while pressing
it downward.
•When pulling out the waste ink tank,
hold the opening of the waste ink tank
with paper and then slowly pull it out to
prevent waste ink from spattering.
•Before replacing ink, put paper on the
floor to prevent it from being stained
with ink.
3. Dump waste ink into a separate polyethyl-
ene tank.
•Discard the waste ink according to the
local regulations of the area this unit is
used.
4. Put the empty waste ink tank back into the
device.
Close the Waste ink box cover.
•To avoid hurt hands at the corner of
the tank cover, be careful to set the
tank.
5. Press the [ENTER] key to complete the
procedure.
The device enters to the LOCAL mode.
! INK TANK
WASTE TANK FULL
WASTE TANK
TANK READY :ent
<< LOCAL >>

11
ERROR 70
WATER LACK
Replacing Water In Water Heater Tank
In order to keep the ink at an appropriate temperature, operate the water heater. Supply
antifreezing liquid and water to the hot-water tank in the water heater.
Precautions for replacing or exchanging
•Water cannot be added.
•Be sure to use Soft water for replacing or exchanging.
•Soft Water and antifreezing liquid compound ratio should be
2 (Soft water) : 1 ( Antifreezing liquid). When performing complement or
replacement later, make a compound liquid in same proporion of 2 : 1.
•When only Soft Water is supplied to the hot-water tank without antifreezing
liquid, it may damage the head.
•Check the water heater once a half year for the water level required and
cleanliness inside the hot-water tank.
•If Soft Water in the hot-water tank frequently becomes insufficient, contact
your nearest sales agency or Mimaki sales office.
•Discard the waste water mixed with Anti-freezing liquid according to the
local regulations of the area this unit is used.
Precautions in handling the Anti-freezing liquid
• Be sure to wear goggles and gloves for handling the Anti-freezing liquid.
•Use the exclusive Anti-freezing liquid by Mimaki , or the heater may be
damaged.
•If the Anti-freezing liquid gets on the skin or clothes, immediately wash it off
with soap. If you gets the Anti-freezing liquid in your eyes, immediately
wash your eyes with a lot of clean water. Then, consult a doctor as soon as
possible.
•Be sure to store the Anti-freezing liquid in a cold and dark place.
•Store the Anti-freezing liquid in a place that is out of the reach of children.
•When unused the Anti-freezing liquid, entrust them to an industrial waste
disposal contractor, clarifying their contents.
•Before using the Anti-freezing liquid, be sure to read the Material Safety
Data Sheet (MSDS).
•When purchasing a hot-water tank for spare, contact your nearest sales
agency or Mimaki sales office.
•Prepare a polyethylene tank for moving waste the water from hot-water
tank.
•When water in the hot-water tank is insufficient, the error message shown
below is indicated. In this case, replace water.

12
Replacing antifreezing liquid
1. Press the [FUNCTION] key from the LO-
CAL mode.
2. Press the [ ]XYnd [ ] keys until the dis-
play gives the indication [MAINTENANCE].
3. Press the [ENTER] key.
4. Press the [ ] and [ ] keys until the display
gives the indication [WATER CHNGE].
5. Press the [ENTER] key.
6. Start cooling down for the water heater
after pressing the [ENTER] key.
•Do not touch the water heater until
[WASTE AF] is displayed to avoid from
burn injury. In case using the device
before the water heater replacement ,
it may take approx. 20minutes until
[WASTE AF] is displayed.
7. Press the [ENTER] key when the [WASTE
AF] is displayed.
8. Open the water heater cover.
<< LOCAL >>
WATER CHANGE
START :ent
MAINTENANCE
WATER CHNG < ent >
FUNCTION
MAINTENANCE < ENT >
FUNCTION
DATA CLEAR < ENT >
WATER CHANGE
PLEASE WAIT
WATER CHANGE
WASTE AF :ent
MAINTENANCE
LIST < ent >

13
9. Unlock catch clips on both sides of the
cover.
10. Engage the water heater handle with the
hook.
•When engaging the handle with the
hook, take care to avoid bending the
cables or tubes or pulling them with
excessive force, or it may cause
malfunction of the water heater.

14
12. Move waste water in the hot-water tank to
a polyethylene tank.
•When moving water, take care not to
spill it. If spilled, be sure to wipe it off.
•Discard the waste water from the hot-
water tank according to the local
regulations of the area this unit is
used.
13. Set the empty hot-water tank into the
water heater.
14. Lock the catch clips and close the cover.
15. Press the [ENTER] key.
Discharge of the anti freezing liquid in the device
is started.
16. Press the [ENTER] key when the [WASTE
AF] is displayed.
WATER CHANGE
SET TANK :ent
WATER CHANGE
PLEASE WAIT
WATER CHANGE
WASTE AF :ent
11. Remove the water heater tank.
•When moving water, take care not to
spill it. If spilled, be sure to wipe it off.

15
Ratio of soft water with
antifreezing liquid
1500cc
1000cc
500cc
Antifreezing liquid
500cc
Water 1000cc
17. Open the water heater cover again and
then remove the water heater tank.
18. Again, move waste water in the hot-water
tank to a polyethylene tank.
•When moving water, take care not to
spill it. If spilled, be sure to wipe it off.
•Discard the waste water from the hot-
water tank according to the local
regulations of the area this unit is
used.
19. Wash the hot-water tank.
•If neutral detergent is used for wash-
ing the tank, sufficiently rinse the tank
with water.
20. Supply soft water and antifreezing liquid
in the water heater tank.
Supply 500 cc of antifreezing liquid, followed by
1000 cc of soft water.
•The optimum volume of soft water is
1000 cc. Do not supply excessive
water, or water leakage may occur
when closing the water heater cover.
21. Return the hot-water tank to its original
position, lock the catch clips and close the
cover.

16
22. Press the [ENTER] key.
23. Press the [END] key and the replacement
for the water heater was completed.
WATER CHANGE
SET AF :ent
MAINTENANCE
WATER CHNG < ENT >

17
Regular Maintenance For White Ink
White ink is easier precipitate than other inks.
In case without plotting more than two weeks, white ink may cause precipitate in ink car-
tridge or inside of the device. And nozzle clogging has occurred and the normal plotting
result is not able to obtain by precipitation. Make sure to perform regular maintenance to
avoid precipitating and to keep good condition for white ink.
•Use the specified ink.
•Regular maintenance must be done once in a week to avoid having white
ink precipitate. Shake the ink cartridge up and down about 10 times slowly.
STEP
1. Press the [FUNCTION] key from the LO-
CAL mode.
2. Select [MAINTENANCE] by pressing the
[] and [ ] keys.
3. Press the [ENTER] key.
4. Select [WHITE MANT] by pressing the [ ]
and [ ] keys.
5. Press the [ENTER] key.
6. Remove White ink cartridge from the ink
station.
7. Press the [ENTER] key.
<< LOCAL >>
**DISCHARGE**
PLEASE WAIT
WHITE MAINTE.
REMOVE CARTRIDGE
MAINTENANCE
WHITE MANT < ent >
MAINTENANCE
LIST < ent >
FUNCTION
MAINTENANCE < ENT >
FUNCTION
DATA CLEAR < ENT >

18
8. Shake the ink cartridge up and down
about 10 times slowly.
9. Put the ink cartridge back to the ink sta-
tion.
10. Press the [ENTER] key and then start
[FILL UP INK].
The FILL UP INK was completed. MAINTENANCE
WHITE MANT < ent >
**INK FILL UP**
PLEASE WAIT
WHITE MAINTE.
SET CARTRIDGE

19
Cleaning Or Replacing Filter
This unit contains a filter for the table.
When the filter is clogged, the media absorbability will be weakened.
If filter is soiled with dusts, clean it with vacuum cleaner, etc.
If the filter is clogged by ink adhesion, replace the filter.
STEP
1. Turn the vacuum switch OFF.
2. Remove the filter holder from the filter
unit.
3. From the filter holder, remove the filter
and replace with a new filter.
Position the filter folded in four and fix it with its all
circumference held.
4. Install the filter holder on the filter unit.
Return the filter holder to the filter unit.

20
Cleaning The Undersurface Of The Carriage
Ink drops may appears on the head guard plate on the undersurface of the carriage, result
in inferior printing or ink blot on the media. Make sure to perform cleaning regularly the
undersurface of the carriage.
For Cleaning: Washing liquid, Maintenance cleaning liquid, glove, goggles
•Turn off the device before cleaning.
•To avoid burn injury, clean the undersurface of the carriage after the UV
irradiation device cools down completely.
Steps
1. Make sure that the LOCAL mode is dis-
played.
2. Press [ ] key on the Sub panel to let the
table down.
3. Press the [ ] key to move the table to the
back side.
①
②
Sub panel
Jog key
<< LOCAL >>
