Mini-Circuits SSG-15G-RC User manual

AN-49-003 Rev.: E (September 6, 2019) M175867(R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
User guide
USB/Ethernet Synthesized Signal Generators
SSG-6000RC
25 to 6000 MHz: -65 to +14 dBm
Wideband, fine frequency resolution
SSG-6001RC
1 to 6000 MHz: -70 to +15 dBm
Wideband, fine frequency resolution
SSG-15G-RC
10 to 15000 MHz: -50 to +15 dBm
Ultra Wideband, very fine freq. resolution

Page 2 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Important Notice
This guide is owned by Mini-Circuits and is protected by copyright, trademark and other
intellectual property laws.
The information in this guide is provided by Mini-Circuits as an accommodation to our
customers and may be used only to promote and accompany the purchase of Mini-
Circuits’Parts. This guide may not be reproduced, modified, distributed, published, stored
in an electronic database, or transmitted and the information contained herein may not be
exploited in any form or by any means, electronic, mechanical recording or otherwise,
without prior written permission from Mini-Circuits.
This guide is subject to change, qualifications, variations, adjustments or modifications
without notice and may contain errors, omissions, inaccuracies, mistakes or deficiencies.
Mini-Circuits assumes no responsibility for, and will have no liability on account of, any of
the foregoing. Accordingly, this guide should be used as a guideline only.
Trademarks
Microsoft, Windows, Visual Basic, Visual C# and Visual C++ are registered trademarks of
Microsoft Corporation. LabVIEW and CVI are registered trademarks of National
Instruments Corporation. Delphi is a registered trademark of Delphi Technologies, Inc.
MATLAB is a registered trademark of The MathWorks, Inc. Agilent VEE is a registered
trademark of Agilent Technologies, Inc. Linux is a registered trademark of Linus Torvalds.
Mac is a registered trademark of Apple Inc. Python is a registered trademark of Python
Software Foundation Corporation.
All other trademarks cited within this guide are the property of their respective owners.
Neither Mini-Circuits nor the Mini-Circuits Synthesized Signal Generators are affiliated
with or endorsed or sponsored by the owners of the above referenced trademarks.
Mini-Circuits and the Mini-Circuits logo are registered trademarks of Scientific
Components Corporation.
Mini-Circuits
13 Neptune Avenue
Brooklyn, NY 11235, USA
Phone: [phone]
Email: [email protected]
Web: www.minicircuits.com

Page 3 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Table of Contents
Chapter 1 –General Information......................................................5-11
1.1 Scope of the User Guide .....................................................................................5
1.2 Warranty..............................................................................................................5
1.3 Definitions............................................................................................................5
1.4 General Safety Precautions.................................................................................5
1.5 Introduction ..........................................................................................................6
1.6 Service and Calibration........................................................................................6
1.7 Contact Information .............................................................................................6
1.8 Model Selection...................................................................................................7
1.8.1 Available Models in SSG series: ............................................................................. 7
1.9 Model Description...........................................................................................7-11
1.9.1 SSG Series Features .............................................................................................. 7
1.9.2 SSG-15G-RC front and rear panels......................................................................... 8
1.9.3 Intended Applications.............................................................................................. 8
1.9.4 SSG-6xxx series front and rear panels................................................................... 9
1.9.5 Conformity............................................................................................................. 10
1.9.6 Supported Software Environments........................................................................ 11
1.9.7 Included Accessories and Options ........................................................................ 11
Chapter 2 –Installation and Setup.................................................12-16
2.1 Software Setup.............................................................................................12-13
2.2 Installation.....................................................................................................14-15
2.3 SSG Series Physical Setup ...............................................................................16
Chapter 3 –Using Mini-Circuits Generator GUI Program............17-49
3.1 Starting the Generator Software in USB control ...........................................17-19
3.2 Starting the Generator Software in Ethernet control..........................................20
3.3 Main Screen..................................................................................................22-24
3.3.1 Top Row (Fig 3.3):................................................................................................. 22
3.3.2 Frequency (Fig 3.3):.............................................................................................. 22

Page 4 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Table of Contents
3.3.3 Power (Fig 3.3):..................................................................................................... 22
3.3.4 Bottom Row (Fig 3.3): .......................................................................................... 23
3.3.5 Right side of screen (Fig 3.3.5):........................................................................ 23-24
3.4 Frequency Scroll Bar Step Size screen.............................................................24
3.5 Power Scroll Bar Step Size screen....................................................................25
3.6 Sweep & Hop Mode......................................................................................26-30
3.6.1 Common functions: ............................................................................................... 26
3.6.2 Power sweep:........................................................................................................ 27
3.6.3 Frequency sweep:................................................................................................. 28
3.6.4 Hop Mode: ............................................................................................................ 29
3.6.5 Save or open a prepared sweep:........................................................................... 30
3.7 Pulse Mode:..................................................................................................31-36
3.7.1 Free Run Pulse Source :....................................................................................... 32
3.7.2 Triggered Pulse Source :....................................................................................... 33
3.7.3 Square Pulse Source : .......................................................................................... 33
3.7.4 External Modulation Pulse Source :....................................................................... 34
3.7.5 Dynamic pulse mode (SSG-15G-RC only) :........................................................... 35
3.7.6 Pulse width limits :................................................................................................. 36
3.7.7 Pulse rate limit :..................................................................................................... 36
3.8 Multi Generator Control: ...............................................................................37-39
3.8.1 Top of Screen:....................................................................................................... 37
3.8.2 Bottom of screen:............................................................................................. 38-39
3.8.3 Save or Open a prepared sweep:.......................................................................... 39
3.9 Updating Generator Firmware: .....................................................................40-44
3.10 Tracking Calibration status: .............................................................................45
3.11 Power Up state configuration(For SSG-6000RC only):....................................47
3.12 Using Reference and Trigger Signals:........................................................48-49
Chapter 4 –Revision History...............................................................50

Page 5 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
1Chapter 1 –General Information
1.1 Scope of the User Guide
This user guide provides general introduction, installation instructions and operating information for the Mini-
Circuits Synthesized Signal Generator series and its Graphical User Interface (GUI) application
measurement software.
1.2 Warranty
See Mini-Circuits website http://www.minicircuits.com/support/ordering.html for warranty information.
1.3 Definitions
Note: A note advises on important information you may need to ensure proper operation of the equipment. This
information does not indicate risk to either the equipment or the user.
A caution advises about a condition or procedure which can cause damage to the equipment
(no danger to users).
A warning alerts to a possible risk to the user and steps to avoid it. DO NOT proceed until you
are sure you understand the warning.
1.4 General Safety Precautions
Please observe the following safety precautions at all times when using Mini-Circuits SSG
Synthesized Signal Generators.
Ensure that all instruments using mains power supply are properly grounded to prevent risk of
electrical shock.
1. Use the power cord provided with the generator.
2. Ensure the generator air vents are clear
3. Do not provide inputs to the generator exceeding the limits specified in the datasheet
CAUTION
WARNING
WARNING
CAUTION

Page 6 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
1.5 Introduction
Figure 1: SSG-15G-RC
1.6 Service and Calibration
The only user-performed service possible for the SSG models is external cleaning of the case and
connectors as needed. Do not use any detergents or spray cleaning solutions to clean the SSG unit. To
clean the connectors use an alcohol solution and to clean the SSG case a soft, damp cloth.
The recommended calibration cycle for Mini-Circuits SSG series Synthesized Signal Generators is once
every two years or every 4160 operating hours (See section 3.10 on automatic tracking of operation time).
Calibration service is available from Mini-Circuits, for details; see the Ordering, Pricing & Availability
Information link from individual model pages on the website.
1.7 Contact Information
Mini-Circuits inc.
13 Neptune Ave
Brooklyn, NY 11235
Phone: [phone]
General Fax: [phone]
Sales / Customer Service Fax: [phone]
[email protected]om
For regional offices and tech support see http://www.minicircuits.com/contact/offices.html
The Mini-Circuits SSG wideband synthesized signal generator series covers the frequency
range of 1 MHz to 15,000 MHz with up to 85dB dynamic range. All models feature a 50ΩRF
out, 10 MHz reference in and out connections and LVTTL trigger in and out ports, making
them a low cost replacement for conventional RF/Microwave signal generators. The provided
user-friendly software and USB cable connect the generator to a notebook or a PC with a USB
port, providing the additional benefits of frequency and power sweeps, pulse mode output,
GUI, easy interface with most lab test software, and much more. SSG models are powered by
supplied by an included AC/DC adapter.

Page 7 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
1.8 Model Selection
Mini-Circuits’ generators are capable of CW, pulsed RF, and both frequency and power sweeps up,
down or bi-directionally.
The generators are supplied with Graphical User Interface (GUI) software and DLL files to allow
control through third party applications on both 32 and 64 bit operating systems.
Mini-Circuits' control software (included) can manage multiple generators simultaneously including
synchronized frequency or power sweeps.
1.8.1 Available Models in SSG series:
Parameter
SSG-15G-RC
SSG-6000RC
SSG-6001RC
Frequency Range (MHz)
10 –15000
25 –6000
1 –6000
Power Range (dBm)
-50 to +15
-65 to +14
-70 to +15
Frequency Resolution (Hz)
0.1
3
3
Power Res. (dBm)
0.5 (0.1)*
0.25
0.25
Minimum Dwell Time (ms)
20
20
20
Maximum Pulse Rate (kHz)
500
90.909
33.333
DC Power Supply (V)
6
12
12
Ethernet speed
100 Mbps
10 Mbps
10 Mbps
*Power resolution of 0.1 dB is possible, however spec is only guaranteed at 0.5 dB steps.
For detailed data sheets, performance data and graphs, outline drawings and environmental ratings click on the
individual part number or check out our website at https://www.minicircuits.com/WebStore/PortableTestEquipment.html
1.9 Model Description
1.9.1 SSG Series Features
• Synthesized Signal Generator
• Wide Dynamic range
• Wide frequency range
•RF Out port, ports for Ref In, Ref Out, Trigger In and Trigger Out
• USB HID, no driver required (Plug and Play operation)
• HTTP and Telnet control
• Frequency and power sweep and hop modes (up, down, or bi-directional)
• Synchronized multi-generator sweep mode (up, down, or bidirectional)
• Pulse modulation
• Easy installation and operation
• Internal 10 MHz reference signal (external reference also accepted).
• Compatible with 32/64-bit Windows® or Linux® operating systems, as well as LabVIEW®, Delphi®, C++, C#, Visual
Basic®, and more (see programming handbook and application note AN-49-001 for details)
• User-friendly Graphical User Interface for any Windows® 32 or 64 bit computer. Command line support for Linux®
computers.
• AC/DC Power adapter included

Page 8 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Figure 1.9.2a SSG front panel
Figure 1.9.2b SSG rear panel
1.9.2 SSG-15G-RC front and rear panels
#
Name
Description
1
Front ventilation
holes
Front and rear ventilation holes must be kept clear to allow airflow
2
RF Output
SMA Female connector for RF output
3
Power LED
Static LED indicates model is on
Blinking LED indicates model power or temperature exceeds the specified
limits
4
Power Switch
On/Off Switch
5
Rear ventilation
holes
Front and rear ventilation holes must be kept clear to allow airflow
6
Reference
Output
Output for the generator's internal 10MHz reference (BNC female).
7
Reference Input
External reference input, if no signal is detected the generator will default to
internal reference (see section 3.12 for details)
8
Trigger Input
Trigger input, see model datasheets for voltage levels (SMB Jack)
9
Trigger Out
Trigger output, see model datasheets for voltage levels (SMB Jack)
10
Power supply
Power supply connection, 6V power.
9
USB socket
USB type Mini-B socket for USB control of generator
11
LAN socket
Provides Ethernet control of Generator (see section 3.2 for details)
1.9.3 Intended Applications
Mini-Circuits Synthesized Signal Generators are intended for indoor use in the following applications:
Lab and test equipment setups for both manual and automated measurement.
Production line testing
Field testing
The SSG series models can be used by anyone familiar with the basics of electronics measurements.

Page 9 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Figure 1.9.4a SSG front panel
1.9.4 SSG-6xxx series front and rear panels
#
Name
Description
1
Model name and
frequency range
Label showing the model name and frequency range
2
RF Output
N-Type Female connector for RF output
3
Power LED
Static LED indicates model is on
Blinking LED indicates model power or temperature exceeds the specified
limits
4
Power Switch
On/Off Switch
5
Reference Input
External reference input, if no signal is detected the generator will default to
internal reference (see section 3.12 for details)
6
Reference
Output
Output for the generator's internal 10MHz reference (BNC female).
7
Trigger Out
Trigger output, see model datasheets for voltage levels (BNC female)
8
Trigger Input
Trigger input, see model datasheets for voltage levels (BNC female)
9
USB socket
USB type B socket for USB control of generator
10
LAN socket
Not available in SSG-4000xx models. Provides Ethernet control of
Generator (see section 3.2 for details)
11
Power supply
Power supply connection, note power supply specifications for each model.
12
Fan Cover
Fan cover and slots on the side of the generator must be kept clear to allow
airflow
Figure 1.9.4b SSG rear panel
5.
6.
9.
10
7. Trigger Out
8. Trigger In
12

Page 10 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
1.9.5 Conformity
Mini-Circuits Synthesized Signal Generators conform to all requirements for the following international
standards:
RoHS –The models comply with EU directive for Restriction of Hazardous Substances for 6
substances.
USB 2.0 –The models meet the specifications of the Universal Serial Bus Ver. 2.0 communication
standard as described by USB-IF.
USB HID –The models meet the requirements for Universal Serial Bus Human Interface Devices
according to USB-IF’s Device Class Definition for Human Interface Devices firmware
rev. 1.11
TCP/IP –Ethernet communication complies with the specifications of the Transmission Control
Protocol (TCP) and Internet Protocol (IP) as defined in RFC 791 and RFC 793.
HTTP –SSG models support all requirements for communicating with the Hypertext Transfer
Protocol (HTTP) as defined in RFC 1945.
Telnet –SSG models support all requirements for communicating with the Telnet protocol, as
defined in RFC 854.
SSH –The SSG-15G-RC also supports the requirements for SSH protocol, as defined by RFCs
4250-4253, 4419, 5647, 5656 and 6668.
1.9.6 Supported Software Environments
Mini-Circuits SSG series synthesized signal generators have been tested in the following operating
systems:
32 bit systems: Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP Windows 98
64 bit systems: Windows 10, Windows 8, Windows 7, Windows Vista, Linux
The signal generators will work with almost any software environment that supports ActiveX or .Net
including: C++, C#, CVI®, Delphi®, LabVIEW®8 or newer, MATLAB®7 or newer, Python, Agilent VEE®,
Visual Basic®, AutoIT, Visual Studio®6 or newer, and more
For more information see the Synthesized Signal Generator Programming Manual and application note
AN-49-001 on our website.

Page 11 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
1.9.7 Included Accessories and Options
SSG-15G-RC comes with the following accessories included:
6.6 ft. USB mini-B to USB A cable
6V AC/DC power adaptor
2 x BNC(M)-SMB(M) cables for Trigger and Reference
110-220V power cord suitable for one of: US, Europe, UK, China & Australia, Israel
Additional options available:
2.7 ft USB mini-B to USB A cable
5 ft Ethernet cable
Calibration service.
SSG-6000RC & SSG-6001RC come with the following accessories included:
2.7 ft. USB B to USB A cable
12V AC/DC power adaptor
110-220V power cord suitable for one of: US, Europe, UK, China & Australia, Israel
5 ft Ethernet cable
Additional options available:
6.6 ft USB B to USB A cable
11 ft USB B to USB A cable
Bracket mounting kit
Calibration service.
For additional details and ordering information see specific model datasheet.

Page 12 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
2Chapter 2 –Installation and Setup
This chapter provides information on installing the operating software and setting up Mini-Circuits’
Generators. System requirements for USB control are a computer (Pentium II or better) with support for
USB HID and a power source of 110-220V (a power cord matching the required power supply should be
selected when ordering the SSG unit).
For Ethernet control an Ethernet port with support for HTTP or Telnet, and a suitable power source are
needed.
To run the GUI program (described in chapter 3) a Windows operating system (either 32 or 64 bits) is also
needed.
2.1 Software Setup
If you have had any problems installing the software, we’re here to help.
Try following these complete step-by-step instructions. If you still experience problems,
give us a call at Mini-Circuits Worldwide Technical support. It’s [phone], or e-mail
[email protected] for North America, or go to minicircuits.com/contact/worldwide_
tech_support.html for other regional numbers and addresses.
2.1.1 First, save all work in progress and close any other programs that may be running.
2.1.2 Next, download the full CD software from minicircuits.com. Unzip the downloaded files to a
temporary folder on your desktop or C: drive, then open the file folder you created and double-click the
“Install” icon.
Figure 2.1.2 CD file listing window

Page 13 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
2.1.3 Alternatively, you may just download and open without saving the setup files, from
https://www.minicircuits.com/softwaredownload/SG_Setup.zip. Then double click on the setup.exe icon.
Figure 2.1.3 Setup file listing window

Page 14 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Figure 2.2.2 Installation window
Figure 2.2.3 License agreement
2.2 Installation
2.2.1The installation start window should now appear. Click the “Install Now” button (if you
downloaded only the setup files skip to 2.2.2).
Figure 2.2.1 Installation start window
2.2.2The installer window will appear. Click “Next”.
2.2.3The license agreement should now appear. To proceed, click “Yes” to accept the agreement.

Page 15 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
Figure 2.2.4 Installation program window
2.2.4The installation program will install (will take a few seconds). Click the “Exit”
button to close the installer.
2.2.5 The signal generator program will be located in the C:\Program Files (x86)\Mini-
Circuits\SSG folder, with shortcuts placed on the Windows Start Menu (under Mini-Circuits -> Signal
Generator) and on your desktop.

Page 16 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
2.3 SSG Series Physical Setup
2.3.1 Before connecting the SSG unit, ensure the power switch is in the OFF position and the control
software (either the supplied GUI software or a customer-written application) is shut down.
Ensure the 110-220V mains power supply socket you use to power the Signal Generator is intact
and connected to a proper ground.
Ensure the power adapter matches the generator. Connecting an SSG unit to an incorrect power
supply may cause damage or incorrect operation.
2.3.2 For USB control, connect the Signal Generator as follows:
–Connect RF out port to load.
–Connect the supplied power adapter to 110-220V mains power supply with the supplied power cord.
–Connect the DC connector of the power adaptor to the SSG unit’s DC power socket.
–Connect USB cable between SSG unit USB port and computer USB port
–Turn on the SSG unit, note that the LED lights up (For SSG-15G-RC you will also hear the fan start
up with a sharp whistle, then settle down after a few seconds).
2.3.3 For Ethernet control, connect the Signal Generator as follows:
–Connect RF out port to load.
–Connect the supplied power adapter to 110-220V mains power supply with the supplied power cord.
–Connect the DC connector to SSG power socket.
–Turn on the SSG unit, note that the LED lights up (For SSG-15G-RC you will also hear the fan start
up with a sharp whistle, then settle down after a few seconds).
–Connect the Ethernet cable to SSG LAN port and to available network port - note the SSG port
lights up with one light steady and the other blinking (may take a few seconds, depending on your
network)
2.3.4 Connecting Reference and Trigger signals
–To use External reference connect the SSG unit REF IN port to an external signal of power
matching the levels specified in the datasheets.
–In order to use SSG internal reference to synchronize with other devices, simply connect the REF
OUT port of the SSG to the devices in question –the SSG constantly produces a 10 MHz,
reference signal (see datasheets for power levels).
–The trigger in and trigger out of the SSG generator can be used simultaneously. Connect
whichever you wish to use and set the operation mode in the software (See section 3.5 and 3.6 for
using Mini-Circuits GUI, or the programming handbook for setting the trigger option in your own
software).
See section 3.12 for further details.
1. Check Maximum safe input power for Reference In and Trigger In ports in the individual
model datasheets. Exceeding these levels may cause permanent damage to the SSG unit’s
reference or Trigger port circuitry.
2. Keep SSG air vents unobstructed. Prolonged operation of the SSG with obstructed air vents
may result in the unit over-heating and eventual damage to the SSG unit.
Note: connecting a signal which does not match the specified reference frequency may result in incorrect
operation of the SSG.
CAUTION
WARNING
CAUTION

Page 17 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
3Chapter 3 –Using Mini-Circuits Generator GUI Program
3.1 Starting the Generator Software in USB control
3.1.1 Go to the Start menu and select All Programs>Mini-Circuits Generator (default), or go to the
other destination address you selected earlier. The “Mini-Circuits Generator”icon should be waiting
there for you. Click on it, and get started!
Figure 3.1.1: Startup screen
3.1.2 The startup screen allows you to select the control method you wish to use for the SSG,
USB or Ethernet control. For USB control click on the USB button, for Ethernet control see
section 3.2.
3.1.3 If multiple generators are connected via USB the initial screen will show a list of S/N for
connected units. Select the unit you wish to start with and click OK, or click Cancel to exit the program.
The program can handle up to 24 units connected simultaneously.
Figure 3.1.3: Unit selection screen

Page 18 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
3.1.4 If USB control, or DC power are not properly connected when you start the program or
are interrupted during operation, a pop-up window will appear advising you to check power and USB
connections. Clicking on ‘Retry’ after the problem has been resolved will cause the pop-up to disappear,
allowing you to operate the generator. Clicking ‘Cancel’ will cause the program to shut down.
Figure 3.1.4: Interrupted Power error
3.1.5 The Ethernet configuration can only be accessed from the USB control main screen
Click on the Ethernet-Config button shown in the figure below and the Ethernet configuration screen will
appear.
Figure 3.1.5: Ethernet Config button
3.1.6 The Ethernet Configuration screen will open showing the current configuration. Fig
3.1.6 is showing the factory default of the generators. If these settings fit your local network, you do not
need to access the setup before connecting the generator to the network.
Figure 3.1.6: Ethernet Config. screen (showing factory default state)
Note: If you are using a proxy server for your LAN connections you may need to define a name for the
generator IP address, or disable the proxy server to connect to the generator via Ethernet.
3.1.7The Ethernet Configuration Settings are:
8
4
2
6
11
3
5
7
9
10
12
1

Page 19 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
#
Name
Description
1
MAC Address
Media Access Control Address –a unique, unchanging identifier for the
generator unit.
2
Network
gateway
IP address of the network gateway. When DHCP is selected this is assigned
automatically by the server.
3
Subnet Mask
The Network's Subnet Mask. When DHCP is selected this is assigned
automatically by the server.
4
IP Address
The IP address of the unit in your Network. When DHCP is selected this is
assigned automatically by the server.
5
Use DHCP
Use Dynamic Host Control Protocol. When selected the Generator will
automatically query the server for appropriate parameters (IP Address, Subnet
Mask and Network gateway); otherwise these must be entered manually.
6
Refresh
Request IP address, Gateway and Subnet mask from Server.
7
Copy state
Copies the current dynamic IP settings to the static configuration section (not
available when DHCP is selected).
8
Static
Configuration
When DHCP is not selected the User must specify the IP Address, Subnet
Mask and Network gateway values manually.
9
Telnet Port
Port to be used for Telnet communication. Cannot be changed by User
10
Store
Save all user changes to the Ethernet configuration.
11
Password
Limit user access to the generator by selecting "Use Password" and entering
the desired password (up to 20 characters).
12
HTTP Port
Specify the port to use for HTTP communication with the Network (default is
port 80). Note: Port address does not get assigned by the Server when
DHCP is selected. Port 23 is reserved for Telnet and cannot be used for
HTTP communication.
3.1.8After making the changes you want, click on "Store" and the changes will be saved
to the generator's memory. See section 3.2 for working with Ethernet control.

Page 20 of 50
AN-49-003 Rev.: E (September 6, 2019) M175867 (R95153) File: AN49003.doc
This document and its contents are the property of Mini-Circuits
3.2 Starting the Generator Software in Ethernet control
3.2.1starting the GUI (section 3.1.1) you can select the control method you wish to use for the
SSG, USB or Ethernet control. All models support USB control. To start operation with USB see section
3.1. For Ethernet control either type the IP address and port of the generator, or click on the search icon.
Figure 3.2.1: Startup screen (search icon)
