Mini Gadgets BB2Dog Boy User manual

1 Version 2.1
BB2 DOG
SKU: BB2Dog(Boy)(Girl)

2 Version 2.1
THANK YOU FOR PURCHASING THE BB2 DOG
Please read this manual before operating the camera and keep it
handy.
The Bush Baby 2 Dog is the perfect device to protect your young
ones. This dog is tan with blue ears. Whether you are making sure
your child is staying out of trouble or keeping an eye on the
babysitter, no one should suspect that this harmless stuffed dog is
watching them! It looks like a typical stuffed dog. Even if the
camera is handled by someone curious, the electronics are
indistinguishable from the original electronics for making the dog
talk. Please note however, that while the dog retains all of its
original electronic functions, it is not a toy and is designed to be
used as a security device.
Motion detection
Looks just like a plush talking dog
Original talking functions completely intact
Your purchase should include:
1 x Bush Baby Dog
1 x Remote Control
1 x USB Cable
1 x User Manual

3 Version 2.1
GET FAMILIAR WITH YOUR BB2 DOG
Note: the USB port and Indicator light are attached directly to the
fabric lining of the dog. The USB port referenced is not the port on
the plastic box, which is part of the original toy electronics.
Camera Lens
Remote
Sensor
USB Port
and Indicator
light

4 Version 2.1
OPERATING THE CAMERA
NOTICE: Allow the device to charge 4 –6 hours before using.
HOW TO TURN ON THE CAMERA
1. Point the remote control at the dog’s right eye (remote
sensor) and press the “Power button.” (The Green
Indicator Light on the back of the unit will turn on)
2. The camera is now in Standby Mode
HOW TO TURN OFF THE CAMERA
1. Press the “Power Button” on the remote control. (The
Green Indicator Light will turn off)
2. The camera is now off.
HOW TO RECORD VIDEO
1. When the camera is in Standby Mode press the “Video
Button” one time (The Green Indicator Light will flash
three times)
2. Once the Green Indicator Light turns off the camera is
now recording video.
3. To stop recording, press the “Video Button” once and the
device will enter back in to standby mode.
HOW TO TAKE PICTURES
1. When the camera is in Standby Mode press the “Photo
Button”. (The Green Indicator Light will flash once)
2. Once the Green indicator light flashes once the picture
has been taken.

5 Version 2.1
HOW TO RECORD MOTION DETECTION
1. When the camera is in Standby Mode press the “Motion
Detection Button”. (The Green Indicator Light will flash
several times then turn off)
2. Once the blue indicator light is done flashing, the camera
is now recoding motion detection.
3. To stop recording, press the “Motion Detection” button
one time.
RETRIEVE THE FILES TO YOUR PC
1. Plug the device into your PC using the USB cable
2. Power on the device using the remote and wait for your
computer to recognize it
3. Locate “Removable Disk” inside the (My) Computer folder
AutoPlay Removable Disk > Open folder to view
files
Or… Go to Start > Computer > Removable Disk

6 Version 2.1
4. Open the Removable Disk drive
5. Open the [folder name] folder
6. Double click the file you want to view
VLC Player is recommended for watching videos
TROUBLESHOOTING
THE DEVICE WON’T TURN ON
Charge the device for at least 4 hours before the first use
Make sure the charging cable is securely inserted into the
device and into the power source
THE DEVICE ISN’T CHARGING
Replace the battery or charging cable
If you are charging via a wall power source, you may need
to charge via your PC. The AC adapter might be bad
MY COMPUTER DOESN’T RECOGNIZE THE DEVICE
Unplug the device from your PC and reboot the device
Unplug the device from your PC and reboot your PC
Try using a different USB slot on your PC
Replace the USB cable
OTHER PROBLEMS
Call our technical support at 770–694–6923

7 Version 2.1
SPECIFICATIONS
Video Resolution
1280 x 960
Video Format
.AVI
Frames per Second
Up to 30 fps
Recording Time
10 Hours
Vision Angle
72 degrees
Motion Detection
6 meters for straight-line distance
Photo Resolution
1600 x 1200
Photo Format
.JPG
Audio Quality (Optional)
64 kbps
Audio Format (Optional)
.WAV
Water Resistant
No
Battery Life
10 or 30 Hours
Type of Memory
Internal Memory
Memory Capacity
16 GB or 32 GB
Recording Capacity
2GB ≈ 1 hour
4GB ≈ 2 hours
8GB ≈ 4 hours
16GB ≈ 8 hours
32GB ≈ 16 hours
USB Interface
2.0 USB
Player Software
VLC recommended
Operating Systems
Windows XP & Up
Mac 10.6 & Up
Linux

8 Version 2.1
QUALITY CONTROL CHECKLIST
☐Remote
☐Wall AC Adapter
☐USB to Mini-B Cable
☐MicroSD Card Reader
☐Charging Adapter with Indicator Light
☐Bush Baby 2 Dog
☐With Audio
☐Without Audio
QC Tech Name:
______________________________________________
Date: ______________________________
