Mini Robot Metal Fighter User manual

Metal Fighter & ROBONOVA Ⅱ Operating Notice (v 1.1)
zTo assemble the MF tool like +type no.1 driver can be used.
zThe MF assembling method is using a screw bolt (jointed to servo motor). Screw of motor doesn’t
have to be removed completely. But some of screw bolts would be used for some of brackets.
zCabling should be clean according to MF manual after assembling the MF
zEvery motor cable ports should be connected to assignment port on MRC-3024 MF.
zIt can’t be able to service as free of charge when user mistake.
zIf you have any question about the assembly or zero point method, Please call MINIROBOT
(tel.[phone], fax:[phone]) or connect hompage Q&A(http://www.minirobot.co.kr)
zMF kit could be worked only after assembling and setting zero point through robobasic MF version.
Basically, robobasic commands and operating method can be known though application course
through robobasic can’t be explained.
(because of many of motion sources to be known, please refer to them)
zCharging time should be 1 hour, after full of charge, user can operate MF during 5min to 40 min
depending of every motion.
( If the robot running time is to be short, that’s condition need to charge)
zThe MF battery is 6V-NIMH 1000mA with high discharge rate.
zThe charge is for 6V-NIMH with a charging current 1A. Honest battery have to be used.
zThe charge would be red lamp during charging, and it would be appear green lamp after full of
charge, the lamp appears to be on end off or put out the light when it has some some problem.
zEven if the charge appears green lamp, any charge cannot full. In this case the safe status to
protect the battery and charger. Please reconnect.
zIf the charge would be green lamp after retrying one or two, this condition is full of charged
condition.
zIf the condition of charge would be flickering, that would be over electric charged or impossible
condition.
zRemote controller shoud be operated by shooting against to MF head part. Also, as operating
system of the remote controller is an infrared rays, it might be unstable under fluorescent lamp or
outdoor.
zThe MF controller loading basic source program, user can operate various motion. The kind of
motions are entertainment mode, fighter mode, game mode, soccer mode, hurdle mode. User can
operate 120 type of motions.
zEnclosed CD would include a user’s program source, user can programming through robobasic MF
version.
zIncluded Battery inner kit would not be charged , user should charge it.
zUser should operate MF motion on the hard flat floor. It could not operate on a lot of frictionized
floor like carpets or rubber floor
zIf you have any problem, Please check encloused CD
Metal Fighter
(ROBONOVA Ⅱ)
Metal Fighter Quick Guide (v1.1)
Mini Robot Corp.

We would appreciate your purchasing for "metal fighter", and we hope that users will enjoy with
"metal fighter"robot. Every user would feel an interesting as much as a pet. and we hope so, users
could bring up a fantastic goods make a programming at the robot through user’s idea.
1. Users should check all parts of the robot without a lack. after purchase, please make reference
attached file to enclosed user's manual CD.
- construction manual file : metal_fighter_assembly manual (kor).pdf
- construction movie file : metal_fighter assembly drawing.wmv
2. After finishing the robot assembly, please install " robobasic MF. v 2.8" on user's PC.
(if users find some problem on loading programming for windows vista version , users
can reloading robobasic file at enclosed CD as authority of administrator)
3. After finished installing robobasic, connect download cable to serial port at users PC.
occasionally, notebook or netbook PC users need download cable for usb port. (option)
Robobasic program Down load cable PC port Down load port on PC
4. Please set communication port on robobasic pull down menu. (normally desktop pc, should be
com1 port)
Port Set Zero Point Set Remote Controller Charge of Battary
5. If the robot would be finished assembly with zero setting, it can be move after full charge of battary.
6. Metal fighter basically has over various 120 motions.
7. Users easily can choice the motion theme kind of dance mode, soccer mode, hurdle racing mode
and so on. Especially 4 users can enjoy game at the same time, only set ID remote controller as
push P1 button with another remote controller 1,2, 3, 4 button during three seconds
simultaneously.
8. Every mode can change to push B,C,D,E,F,G after push red button, finally push ■ button.
BT CODE DANCE MODE(D) FIGHTER
MODE(F)
GAME MODE
(G)
SOCCER
MODE(B)
HUDDLE
RACING
MODE(E)
CAMERA
POSE
MODE(C)
1 1 Bow_1 Bow_1 scissors Keeper_left Stair_left_up_3c
m flying Pose
2 2 cheer Bow_2 Rock Keeper_front Front_narrow_w
alk Fighter Pose
3 3
Right_foot_sit_st/u
p
Left_foot_sit_ st/up
Come_on_
action cloth Keeper_right Stair_right_up_3 cm
Side attack
Pose
4 4 flying Win_ceremony_1 Left_up Drawing_left Stair_left_down_
3cm
Foot up
Pose
5 5 Old_dance Win_ceremony_2 Blue_white_g
ame_pose Drawing_front Dice game Ball kick Pose
6 6 Back_dance Win_ceremony_3 Right_up Drawing_right Stair_right_down
_3cm Future Pose
7 7 Breath_action Lose_action_1 Left_down Left_turn_10 Crawlleft_turn Old dance
Pose
8 8 L_R_back_lift_danc
e Huge Dice_game Front_walk_50 Crawl Walk Pose
9 9 Flying_standup Lose_action_2 Right_down Right_turn_10 Crawlright_turn Sorry Pose
0 10 Poop_poop_dance Front_both_hand
s_punch
Cup_throw_g
ame
Front_narrow_w
alk
Thing_chack &
thing_put
▲ 11 Front_walk_50 Front_run_50 Front_run_50 Front_run_50 Front_run_50
▼ 12 Back_walk50 Back_run_40 Back_run_40 Back_run_40 Back_run_40
▶ 13 Slow_right_walk50 Right_walk70 Right_walk70 Right_walk70 Right_walk70
◀ 14 Slow_left_walk50 Left_walk70 Left_walk70 Left_walk70 Left_walk70
A 15 Left_turn_20 Left_front_attack Left_ball_kick Left_ball_kick Left_ball_kick
p/w 16 Motor_off,
Change Mode
Motor_off,
Change Mode Motor_off Motor_off Motor_off
C 17 Continue-dance_1 Left_side_back_
attack
Shoot_out_lef
t Left_shoot Shoot_out_left
E 18 Total_dance_1 Left_walk20 Left_hand_up Shoot_out_left Back_standup
P2 19 Right_turn_45 Right_turn_60 Right_turn_45 Right_turn_45 Right_turn_45
B 20 Right_turn_20 Right_front_attac
k
Right_ball_kic
k Right_ball_kick Right_ball_kick
△ 21 Front_tumbling Front_lift_attack Front_run_30 Front_narrow_w
alk Front_tumbling
* 22 Hand_standing Left_turn_20 Left_turn_10 Left_turn_20 Left_turn_20
G 23 Total_dance_3 Right_walk20 Right_hand_u
p Shoot_out_right Front_standup
# 24 Arm_action_copy Right_turn_20 Right_turn_10 Right_turn_20 Right_turn_20
P1 25 Left_turn_45 Left_turn_60 Left_turn_45 Left_turn_45 Left_turn_45
■ 26 Stand_pose Stand_pose Stand_pose Stand_pose Stand_pose
D 27 Continue_dance_2 Right_side_back
_attack
Shoot_out_rig
ht Right_shoot Shoot_out_right
◁ 28 Left_tumbling Left_side_attack Left_walk20 Left_walk20 Left_walk20
□29 standstill Sit_pose &
stand_pose
Sit_pose &
stand_pose
Sit_pose &
stand_pose
Sit_pose &
stand_pose
▷ 30 Right_tumbling Right_side_attac
k Right_walk20 Right_walk20 Right_walk20
▽ 31 Back_tumbling Back_lift_attack Crawl Back_narrow_wa
lk Back_tumbling
F 32 Total_dance_2 Back_narrow_wa
lk
Back_narrow_
walk Back_shoot Back_narrow_wa lk
*Above every motion program would changeable without notice.
