Installation & Setup
zLAN Connection
Connect an Ethernet cable from your PC's Ethernet port to the LAN port of the VoIP ATA.
zWAN Connection
Connect an Ethernet cable from the router to the WAN port of the VoIP ATA.
zVoIP Connection
Connect the telephone to PHONE port and your PSTN line to LINE port.
Hardware Installation
This section describes how to connect and configure the device.
Step 1.
Connect to DSL/Cable Modem or Broadband Router.
Connect the ATA WAN port directly to the LAN port of these devices.
Step 2.
Connect a Phone to the RJ-11 Phone Port.

2
Step 3.
Connect the PSTN line to the RJ-11 Line port.
Step 4.
Connect the power adapter to the Router.
Connect the power adapter to the port labeled POWER on the rear panel of router.
Power Adapter Connection
Connect the power adapter to the power inlet.
Configuring VoIP ATA with Web Browser
Open web browser and type http://192.168.3.1 in the browser's address box. This number is the default IP
address for this device.
A user name and password prompt will appear. The username is admin and password is admin.

3
•Setup Wizard – WAN Settings
The Setup Wizard is an easy way to set up the VoIP ATA quickly.
In the first step, you can set the LAN mode and WAN IP type. When you are finished changing the settings, click
the Next button to move to the next page.
•Setup Wizard – SNTP Settings
In this page, you can set up the SNTP server for maintaining the time of day clock.
Click the Next button to move to the next page.

4
•Setup Wizard – Service Domain Settings
In this page, you set up the SIP server settings. You need to input the account details as provided by your VSP or
SIP provider. You can register up to three VSP/SIP accounts (Realms).
Click the Next button to move to the next page.
•Setup Wizard – Completion
After you finish the setup wizard, please ensure that you click the Save button to save the settings into the device
memory. The device will reboot after saving the settings.

5
Browse the User's Manual
1. Insert the CD into your CD-ROM, and the CD will Auto-Run.
Package Contents
•VOIP ATA unit
•AC Power Adaptor
•RJ-11/RJ-45 cable
•User Guide on CD
•Quick Installation Guide
