Mio Spirit 7700 Series Instructions for use

Hardware
User Manual
Spirit 7700 Series

2
Important safety information
PLEASE READ CAREFULLY BEFORE INSTALLING PRODUCT IN VEHICLE
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Removing original equipment, adding accessories or modifying your vehicle could affect the vehicle’s safety or make it illegal to
operate in some jurisdictions.
Follow all product instructions and all instructions in your vehicle owner’s manual regarding accessories or modifications.
Consult your country’s and/or state’s laws regarding operation of a vehicle with any accessories or modifications.
It is your sole responsibility to place, secure and use your Mio in a manner that will not cause accidents, personal injury or
property damage. Always observe safe driving practices.
Do not mount your Mio in a way that may interfere with the safe operation of the vehicle, the deployment of air bags or other
safety equipment.
Do not operate your Mio while driving.
Before you use your Mio for the first time, familiarize yourself with your device and its operation.
On main roads, the distance to an exit calculated by your Mio may be further than the distance shown on road signs. Road signs
show the distance to the start of an exit while your Mio shows the distance to the next intersection, i.e., the end of the exit
ramp or road. To prepare to exit a road, always follow distance information on road signs.
The use of information regarding safety or speed camera locations may be subject to local laws in the country of use. You are
responsible for checking that you can legally use the information in your country or in the country where the information will
be used.
Do not handle your Mio while it is hot. Let the product cool, out of direct sunlight.
At full power, prolonged listening to your Mio via headphones or earphones can damage the ear of the user.
Do not expose your Mio to direct sunlight in an unattended vehicle for prolonged periods. Overheating may damage the unit.
To discourage theft, do not leave your Mio, mounting bracket or any cables in plain view in an unattended vehicle.
Warning Notice to Drivers in the United States
State law may prohibit drivers in states such as Arizona, California and Minnesota from mounting objects on their windshields
while driving. Please make sure you research and follow your most current State laws. An alternative mounting option may be
provided in the box with your product; or see our website for additional mounting alternatives. Mio does not take any
responsibility for any fines, penalties, or damages that may be incurred as a result of disregarding this notice.

3
Home charger-specific safety information
To charge your Mio from the mains power, use the home charger (Input: 100-240V AC 50-60Hz; Output: 5V DC 2A Max)
supplied by Mio as an accessory (may be sold separately). Using other home chargers with your Mio could result in serious
injury or property damage.
Never use the charger if the plug or cord is damaged.
Do not expose the charger to moisture or water. Do not use the charger in a high moisture environment. Exposure to water may
cause electrical sparks or fires.
Never touch the charger when your hands or feet are wet.
Allow adequate ventilation around the charger when using it to operate your Mio or charge the internal battery. Do not cover
the charger with paper or other objects that will reduce ventilation. Do not use the charger while it is inside a carrying case or
other container.
Ensure that the charger is connected to a power source with the correct fitting and voltage requirements. The voltage
requirements can be found on the home charger casing and/or packaging.
Do not attempt to service the charger as this could result in personal injury. Replace the charger if it is damaged or exposed to
excess moisture.
Internal battery-specific safety information
Your Mio contains a non-replaceable internal lithium-ion battery. The battery may burst or explode if mishandled, releasing
hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush or puncture the battery.
Recycle or dispose of the battery safely and properly according to local laws and regulations. Do not dispose of the battery in
fire or water.
About the battery
Use a specified battery in the equipment.

CAUTION:
The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not
disassemble, crush, puncture, or dispose of in fire or water.
Important instructions (for service personnel only)

Caution:
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructions.
Replace only with the same or equivalent type recommended by the manufacturer.
The battery must be recycled or disposed of properly.
Use the battery only in the specified equipment.
Only use the correct home charger (may be sold separately) or in-car charger supplied by Mio to charge your Mio internal
battery.
Only use your Mio internal battery with your Mio unit.
The Mio battery will stop charging when the ambient temperature is less than 0ºC (32ºF) or more than 40ºC (104ºF).
Failure to adhere to these warnings and cautions may lead to death, serious injury or property damage. Mio disclaims all
liability for installation or use of your Mio that causes or contributes to death, injury or property damage or that
violates any law.

4
Compliance
WARNING
This product, its packaging and its components contain chemicals known to the State of California to cause
cancer, birth defects or reproductive harm. This Notice is being provided in accordance with California’s Proposition 65.
For regulatory identification purposes: Mio Spirit 7700 Series is assigned a model number of N602.
Marking labels located on the exterior of your Mio indicate the regulations that your model complies with. Please check
the marking labels on your Mio and refer to the corresponding statements in this chapter. Some notices apply to
specific models only.
Products with the CE marking comply with the Radio Equipment Directive (RED) (2014/53/EU), the Electromagnetic
Compatibility Directive (2014/30/EU) and the Low Voltage Directive (2014/35/EU) - issued by the Commission of the European
Community. Compliance with these directives implies conformity to the following European Standards:
EN 301 489-1
EN 301 489-19
EN 303 413
EN 55024:2010 + A1:2015
EN 55032:2015
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
The manufacturer cannot be held responsible for modifications made by the User and the consequences thereof, which may
alter the conformity of the product with the CE Marking.
Declaration of conformity
Hereby, MiTAC declares that this Mio Spirit 7700 series is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
WEEE
This product must not be disposed of as normal household waste, in accordance with the EU directive for waste
electrical and electronic equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by returning it to the
point of sale, or to a municipal recycling collection point.

5
Contents
Important safety information.........................................................................................................................2
Home charger-specific safety information .............................................................................................3
Internal battery-specific safety information...........................................................................................3
Compliance...................................................................................................................................................4
WEEE..............................................................................................................................................................4
Welcome.............................................................................................................................................................6
Important information for using the manual .........................................................................................6
Disclaimer .....................................................................................................................................................6
Mounting your Mio in a vehicle ...................................................................................................................... 7
Getting to know your Mio ...............................................................................................................................8
How do I turn on my Mio?...............................................................................................................................9
Using the power button..............................................................................................................................9
Resetting the device....................................................................................................................................9
How do I charge the battery? .......................................................................................................................10
How do I charge the battery in a vehicle?.............................................................................................10
How do I charge the battery at home or work?...................................................................................10
How do I connect the device to my computer? .........................................................................................11
Reference..........................................................................................................................................................12
What is GPS?.............................................................................................................................................. 12
How does my Mio receive GPS signals? ................................................................................................12
Caring for your Mio ...................................................................................................................................12
Troubleshooting.........................................................................................................................................13

6
Welcome
Thank you for purchasing this Mio. Please read this manual carefully before using your Mio for the first time.
Keep this manual in a safe place and use as your first point of reference.
Important information for using the manual
It is important to understand the terms and typographical conventions used in this manual.
Formatting
The following formatting in the text identifies special information:
Convention
Type of Information
Bold
Components or items displayed on screen, including buttons, headings, field names and
options.
Italics Indicates the name of a screen.
Icons
The following icons are used throughout this manual:
Icon
Description
Note
Tip
Warning
Terms
The following terms are used throughout this manual to describe user actions.
Term
Description
Press Press and release a button quickly.
Tap Press and release an item displayed on the touch screen.
Select Tap an item in a list or tap a command from a menu.
Disclaimer
Not all models are available in all regions.
Depending on the specific model purchased, the colour and look of your device and accessories may not exactly
match the graphics shown in this document.
Mio operates a policy of ongoing development. Mio reserves the right to make changes and improvements to
any of the products described in this document without prior notice. Mio does not warrant that this document
is error-free. The screenshots and other presentations shown in this manual may differ from the actual screens
and presentations generated by the actual product. All such differences are minor and the actual product will
deliver the described functionality as presented in this User Manual in all material respects.
Revision: R00
(4/2018)

7
Mounting your Mio in a vehicle
CAUTION:
Never mount your Mio where the driver’s field of vision is blocked.
If the windscreen is tinted with a reflective coating, it may be athermic and impact the GPS reception. In
this instance, please mount your Mio where there is a “clear area” - usually just beneath the rear-view
mirror.

8
Getting to know your Mio
❶
Power button
❷
Power indicator
❸
Slot for MicroSD memory card
❹Touch screen
❺
Microphone (not on all models)
❻
Magnetic connectors
❼
Speaker
❽
Reset button
❾
Connector for in-car charger, USB cable* and home charger*
*may be sold separately

9
How do I turn on my Mio?
Using the power button
For the initial start-up, press and hold the power button for 2 seconds to turn on your device.
For normal operation, turn off the device by briefly pressing the power button. Your Mio will enter a suspended
state. When you next briefly press the power button, your Mio will return to the Main Menu.
To turn off your Mio, press and hold the power button for 2 seconds.
Resetting the device
Occasionally, you may need to perform a hardware reset when your Mio stops responding; or appears to be
“frozen” or “locked-up.” Insert a small rod, such as a straightened paperclip, into the reset button of your
device.

10
How do I charge the battery?
The battery may not be fully charged when you use your Mio for the first time.
CAUTION:
For optimal performance of the battery, note the following:
Do not charge the battery when the temperature is high (e.g. in direct sunlight).
There is no need to fully discharge the battery before charging.
When leaving your Mio for long periods, turn off your Mio to save battery power.
How do I charge the battery in a vehicle?
To charge your Mio in a vehicle, plug the in-car charger into on the mount and the other end into the
vehicle power socket.
How do I charge the battery at home or work?
You can use an optional home charger to charge the battery.
To charge your Mio using a mains power socket, plug the home charger cable into on the mount and the
mains power charger into the power socket.
The home charger is not included with all models and may be purchased separately (see www.mio.com for
details).

11
How do I connect the device to my
computer?
1. Turn on your computer.
2. Plug the large end of the USB cable (may be sold separately) directly into a USB port on your computer
(not a USB hub) and plug the small end into on the device.
CAUTION:
When your Mio is turned on and connected to a computer, it is recognized as an external
mass-storage device. Do NOT delete any files that are pre-installed on your Mio. Deleting the files can cause
your Mio to crash.

12
Reference
What is GPS?
The Global Positioning System (GPS) is available at any time, free of charge, and is accurate to within 5m (15ft).
GPS navigation is made possible by a network of satellites that orbit the Earth at around 20,200km (12,552mi).
Each satellite transmits a range of signals which are utilized by GPS receivers, such as your Mio, to determine an
exact location. Although a GPS receiver can detect signals from up to 12 satellites at any time, only four signals
are required to provide a position or "GPS fix" (latitude and longitude), for vehicle navigation systems.
How does my Mio receive GPS signals?
Your Mio receives GPS signals via the internal GPS antenna. To guarantee the optimum GPS signal strength,
ensure your Mio is outdoors, or in a vehicle outdoors, and has an unobstructed view of the sky. GPS reception is
not usually affected by weather, however, very heavy rain or snow may have a negative effect on your
reception.
Caring for your Mio
Taking good care of your Mio will ensure trouble-free operation and reduce the risk of damage to your Mio:
Keep your Mio away from excessive moisture and extreme temperatures.
Avoid exposing your Mio to direct sunlight or strong ultraviolet light for extended periods of time.
Do not place anything on top of your Mio or drop objects on your Mio.
Do not drop your Mio or subject it to severe shock.
Do not subject your Mio to sudden and severe temperature changes. This could cause moisture
condensation inside the unit, which could damage your Mio. In the event of moisture condensation, allow
your Mio to dry out completely before use.
The screen surface can easily be scratched. Avoid touching it with sharp objects. Non-adhesive generic
screen protectors designed specifically for use on portable devices with LCD panels may be used to help
protect the screen from minor scratches.
Never clean your Mio when it is turned on. Use a soft, lint-free cloth to wipe the screen and the exterior of
your Mio.
Do not use paper towels to clean the screen.
Never attempt to disassemble, repair or make any modifications to your Mio. Disassembly, modification
or any attempt at repair could cause damage to your Mio and even bodily injury or property damage and
will void any warranty.
Do not store or carry flammable liquids, gases or explosive materials in the same compartment as your
Mio, its parts or accessories.

13
Troubleshooting
If you encounter a problem you cannot solve, contact an authorized service centre for assistance.
Problems
Solutions
Your Mio does not turn on when using
battery power.
The remaining battery power may be too low to operate your Mio.
Charge the battery using the in-car charger, home charger (may be
sold separately) or USB cable (may be sold separately), then try again.
Screen responds slowly. The remaining battery power may be too low to operate your Mio. If
the problem still persists, reset your Mio.
Screen freezes. Reset your Mio.
Screen is hard to read. Increase the screen brightness.
Cannot establish a connection with a
computer.
Ensure that your Mio and your computer are both turned on before
trying to establish a connection.
Make sure that the cable is securely plugged into the USB port on your
computer and on your Mio. Connect the USB cable (may be sold
separately) directly to your computer, not a USB hub.
Reset your Mio before connecting the USB cable (may be sold
separately). Always disconnect your Mio before you restart your
computer.

14

Software
User Manual
Spirit 7700 Series

2
Contents
Welcome.............................................................................................................................................................4
Important information for using the manual .........................................................................................4
Disclaimer .....................................................................................................................................................4
How do I get started?.......................................................................................................................................5
How do I use the touch screen? .....................................................................................................................6
Navigating on the screen............................................................................................................................6
Main Menu ....................................................................................................................................................6
How do I navigate through the menu screens?...................................................................................... 7
How do I use the Keyboard screen?......................................................................................................... 7
How do I go from A-B?.....................................................................................................................................9
How do I use the FIND wizard?.................................................................................................................9
How do I plan my first trip?.....................................................................................................................10
How do I preview the destination on map?...........................................................................................11
How do I preview a route? ........................................................................................................................11
Truck mode ................................................................................................................................................. 12
Pedestrian mode ........................................................................................................................................13
How do I view my route?...............................................................................................................................14
How do I select the route type?..............................................................................................................14
The driving map..........................................................................................................................................14
How do I change the route configuration? ...........................................................................................15
How do I view my route statistics? ........................................................................................................16
How do I adjust the volume? ..................................................................................................................16
How do I zoom in/out the map?............................................................................................................. 17
Advanced routing functions..................................................................................................................... 17
How do I create a trip with multiple stops? ...............................................................................................19
How do I capture a location or a journey? .................................................................................................21
How do I capture the GPS coordinates of my location? .................................................................... 21
How do I capture a journey?....................................................................................................................21
How do I navigate to a location I have captured?...............................................................................22
How do I navigate to the saved car location? ......................................................................................22
How to view a journey I have captured?...............................................................................................22
My Places..........................................................................................................................................................23
How do I save a location as My Place or Home? .................................................................................23
How do I navigate to a location I have saved?.....................................................................................23
How do I navigate to Home?.................................................................................................................. 24
How do I navigate to a recent place?.................................................................................................... 24
How do I edit a saved location in My Places?...................................................................................... 24
How do I navigate to a NavPix™? ..........................................................................................................25
How do I search for a POI?............................................................................................................................27
How do I find the nearest POIs using Near Me?..................................................................................27
How do I find the POIs using EXPLORE? ...............................................................................................29
How do I search for a POI by type?........................................................................................................31
How do I search for a POI by keyword? ................................................................................................32
What can I customise?...................................................................................................................................33

3
Audio............................................................................................................................................................33
Screen ..........................................................................................................................................................33
Safety.......................................................................................................................................................... 34
Route options.............................................................................................................................................35
Map display................................................................................................................................................ 36
My Maps..................................................................................................................................................... 36
Language .................................................................................................................................................... 36
Units.............................................................................................................................................................37
Time Zone ...................................................................................................................................................37
Trip Meter....................................................................................................................................................37
Device ..........................................................................................................................................................37
Demo .......................................................................................................................................................... 38
Help............................................................................................................................................................. 38
What is MioMore Desktop?.......................................................................................................................... 39
How do I install MioMore Desktop onto my computer?................................................................... 39
Loading the data ISO file as a DVD ....................................................................................................... 40
My Subscriptions....................................................................................................................................... 40
My Maps......................................................................................................................................................41
Custom POIs.............................................................................................................................................. 44
Photo Album.............................................................................................................................................. 46
Image Search ..............................................................................................................................................50
Application Gallery....................................................................................................................................51
Unlock Features .........................................................................................................................................
52
Redeem........................................................................................................................................................53
MY PLACES..................................................................................................................................................53
TRIP PLANNER ...........................................................................................................................................55
MY MIO .......................................................................................................................................................57
For more information .....................................................................................................................................61
Point of Interest categories......................................................................................................................61
Online support .......................................................................................................................................... 64
Registration................................................................................................................................................ 64
Speed limit ................................................................................................................................................. 64
Safety camera POIs.................................................................................................................................. 64
Copyright ................................................................................................................................................... 64

4
Welcome
Thank you for purchasing this Mio. This manual has been prepared to guide you through the operation of your
Mio from first set-up through to continuous use. Please read this manual carefully before using your Mio for the
first time. Keep this manual in a safe place and use as your first point of reference.
Important information for using the manual
It is important to understand the terms and typographical conventions used in this manual.
Formatting
The following kinds of formatting in the text identify special information:
Convention
Type of Information
Bold
Mio components or items displayed on screen, including buttons, headings, field names and
options.
Italics Indicates the name of a screen.
Icons
The following icons are used throughout this manual:
Icon
Description
Note
Tip
Warning
Disclaimer
Mio operates a policy of ongoing development. Mio reserves the right to make changes and improvements to
any of the products described in this document without prior notice. Mio does not warrant that this document
is error-free. The screenshots and other presentations shown in this manual may differ from the actual screens
and presentations generated by the actual product. All such differences are minor and the actual product will
deliver the described functionality as presented in this User Manual in all material respects.

5
How do I get started?
The first time you use your Mio it may take several minutes to establish a GPS connection.
How do I turn my Mio on for the first time?
To get started for the first time, complete the following steps:
1.
Read the Important Safety Information
2.
Position your Mio in your vehicle
Follow the instructions in the Quick Start Guide.
CAUTION:
Ensure that your Mio does not obstruct the driver's view, or interfere with the operation of
the vehicle airbags and safety devices.
3.
Turn your Mio on
Your Mio will turn on and display the Language screen.
4.
Select your preferred language
From the Select Language screen, tap your preferred language.
You can change your preferred language while using your Mio.
5.
Read the warning message
The Safety Agreement screen will display after you have selected your preferred language. Read the Safety
Agreement message. To confirm that you have read and understood the message, tap
Accept
.
6.
View the Tutorial
To move forward through the Tutorial screen, tap
Next
. To view the previous screen, tap .
To skip the Tutorial screen, tap
Skip
.
To prevent the Tutorial from displaying on each start-up, tap the
Show tutorial on start-up
option to
deselect it. To enable the tutorial again, select the option from
Main Menu
 
Help

View
Tutorial
.
7.
Customise the device
Follow the on screen instructions to select your preferred distance unit, date format, and time format.
8.
Unlock your Mio
Depending on your Mio model, you may need to enter a Startup Key (which is printed on the side of the
box) and then tap
OK
to unlock the device. You will only have to do this the first time you use your Mio.
It is recommended that you keep a copy of the Startup Key in a safe place.
9.
Set up Home
The Home setup wizard only appears on the first time you start your Mio.
Tap
OK
to set up your home immediately using the address-entry wizard.
You can tap
Cancel
to skip the wizard, and then select you home later in My Places.
When you have finished the steps above, the Main Menu screen will display. If you have a GPS fix, you can start
to use Mio to plan your trip.

6
How do I use the touch screen?
Navigating on the screen
To operate your Mio, touch the screen with your fingertip. You can perform the following actions:

Tap
Press and release an item displayed on the touch screen.

Select
Tap an item in a list or tap a command from a menu.
Main Menu
The Main Menu is your starting point for searching for a destination. The Main Menu also allows you to
customise your Mio, view saved locations as My Place/Home, and search for POIs nearby, and so on.
Main Menu screen options and the order of the options may differ from the above, depending on your
region, maps installed or model of Mio.
Tap to show the next page of Main Menu.
❶Search for places, areas and streets to help plan
your route.
❷
Display the Map screen.
❸
Access your saved locations.
❹
Configure your Mio to enhance your navigation
experience.
❺
Explore the area around your current position or
destination.
❻
Add or begin a planned trip with multiple
waypoints.
❼
Display the calculated route in simulation mode.
❽
Record GPS coordinates of a location or a
journey.
❾
Select your navigation mode.
❿
Set or navigate to your home address.
⓫Search for Points of Interest nearby.
