Miracle M100 User manual

BLUETOOTH DYNAMIC MICROPHONE & HIFI SPEAKER
☎ [phone]
Yeomgwang na-dong, 27, Mangu-ro 81-gil, Jungnang-gu, Seoul, Republic of Korea
www.doorskorea.com
USER GUIDE
Please read this manual carefully and follow directions.
Please keep this manual for future use.
Miracle M100

01
Directions
For more detailed directions see enclosed instructions.
Turn ON : Press Power button 2-3 seconds, then MIC will turn on with LED light on.
Bluetooth Pairing: You can pair using Bluetooth.
(Please check the description on the right)
Play Music: You can play music through a Smartphone APP.
Volume Control: You can control Volume and Echo on demand.
Lyrics Elimination Mode: This mode significantly lowers recorded singer’s voice.
Duet Mode: Connect two mics together so you can sing with others.
Turn ON / OFF : Press POWER button 2-3 seconds.
Press SOUND EFFECT : button quickly and you will hear the applaud sound and
press again for 2-3 sec for fanfare sound.
Sound Modification : 5 kinds of Echo effects / 3 kinds of Voice Modifications.
FM Connection : In case you want to connect MIC by FM, Press this button and
tune the frequency as shown on MIC.
Recharge cable antenna :
Recharge cable can also be used as an antenna when
you use FM connection.
App : You can use any Smartphone APP to use this product.
AUX OUT : Expand your sound by using AUX out port.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
Recharge
The included battery [in the package] is not fully charged. You may use the device
after it is fully charged.
Microphone must be turned off when charging.
Plug the micro USB port cable into the MIC Port, and another port into a USB
charger receptacle.
Full charge usually take 1~4 hours.
A fully charged Battery can be used for 1~4 hours.
A.
B.
C.
D.
E.
*
Please note that charging times can vary depending on outside circumstance or
battery condition.
* You can check the battery status on your M100 MIC.
Note : The MIC will automatically turn off when the battery charge is low .
Note : The MIC will automatically turn off when the battery charge is low .
English 日本語 한국어

02
Before Bluetooth Pairing
Distance between MIC and Smartphone should be 6 ft.(2M) for effective pairing.
If pairing fails, turn your MIC off and try it again.
Important conditions below :
- Check your Smartphone connection with other Bluetooth devices.
- Do not use this device in prohited areas. (hospital, air plane)
- Partitions, walls or other obstacles can cause interference or malfunction.
·
·
·
Press M100 POWER button 3 sec, MIC will turn on with confirmation sound.
(When you turn on the MIC, it will automatically reconnect with former bluetooth device)
Choose M100 MIC on your Smartphone Bluetooth device list.
Confirmation sound when Bluetooth connected.
2
1
3
Bluetooth Pairing
On LED Light ON
By pressing POWER button for 3 sec, the MIC will
automatically search for bluetooth CONNECTION
Caution
When feedback occurs, please reduce the volume of the ECHO feature on the microphone.
When using the Bluetooth function, the connection distance of the device should
not exceed 10m.
Do not lick products, and do not use them in wet or humid places. If the product is
dropped from on high, it may cause product damage or malfunction.
Stay away from Excessive heat and hot air, this may cause explosion of battery, degrades
performance or decreased longevity.
Do not keep the product inside a hot car, there is a possibility of explosion.
When charging, the proper temperature is between -10°C and 40°C.
★For best results use a USB memory of 8GB or less.
·
·
·
·
·
·
Sound Effect
· Echo Effect :
: Pick 5 kinds Echo effects from the Echo Menu, also you can pick 3 kinds of interesting
voice modification as shown below.
Original Pro POP K-TV Electro
· Voice Mode : Voice.1
Female voice
Voice.3
Baby voice
Voice.2
Male voice
English 日本語 한국어

03
Cable connection Info
Speaker to
AUX IN Port
MIC to
AUX OUT Port
AUX Cable ↔AUX Port
Our AUX to AUX cable can be applied to
Bluetooth: speakers, headphone,
earphone and CD players
Connect MIC to your Speaker
to receive dynamic sounds!
You can use your
own earphone.
Monitor your Voice
Connect to
earphone port
You can monitor your voice by connecting
your earphones or headphones
to your MIC
Monitor your voice
with Earphone or Headphone!
Earphone or Headphone ↔ Earphone Port
Lyric Elimination Mode
How to use Lyric Elimination Mode
: This mode significantly lowers reorded
singer’s voice.
You do not need an additional APP
when using Lyric Elimination Mode.
Lyrics Elimination Mode cannot completely remove
the recorded singers’ voice, it will vary depending
on the condition of the MP3 file.
GOOD
Mode
DSP FM
Duet
Vol
Press quickly
while Power is on.
Pair your MIC and Smartphone then play
music you liike.
Press quickly POWER button, then Lyric
Elimination Mode starts.
Press POWER button quickly then Lyric
Elimination Mode will be turned off.
※ This feature needs bluetooth paired MIC with your Smartphone.
1.
2.
3.
What is Lyric Elimination mode?
English 日本語 한국어

04
Turn on M-100.
Tune your FM Radio to FM (88.1MHz) or FM (108.0MHz)
On the control panel Push FM to channel FM or FM
You can turn ON/OFF your MIC Speaker by pressing.
YOU MUST Plug an AUX Cable into the AUX OUT on the M-100.
Cable should be about 2M or 6 feet long [works as an antenna].
FM Radio start and ending frequencies very from country to country.
Check your FM Raido's frequencies before purchasing this M-100 unit.
1.
2.
3.
4.
5.
6.
FM Connetion
: Connect MIC to your radio by using FM frequency.
How to use
FM Connection
Duet Mode
How to use Duet Mode
Duet Mode and Lyric Elimination
Mode can not be used together.
You need to have two MIC
to use Duet Mode.
When you use Duet Mode, the two
MICs distance should be 6.5 ft(2M).
: Connect two MICs together so you can
sing with others.
What is Duet Mode?
Turn on both MICs.
Connect your Smartphone to one of your MIC. (Connected MIC with Smartphone
is your MAIN MIC)
Press DUET MODE button on your main MIC. ( Press 2-3 sec)
Main MIC will search pairabe MIC and will be connected with sound.
Duet Mode LED light will be on.
1.
2.
3.
4.
5.
How to use
: You can use some interesting reaction sounds by pressing Audience Sound Effect.
Audience Sound Effect
Press SOUND EFFECT button quickly and you will hear the applaud sound and
press again for 2-3 sec for fanfare sound.
When you press SOUND EFECT button while playing music, you will only hear the
Sound Effect.
1.
2.
English 日本語 한국어

05
M100 Pouch
Composition
User’s Manual
USB Recharge Cable (5pin↔USB) 1ea
Input Cable (5pin↔AUX) 1ea
Output Cable (AUX↔AUX) 1ea
Specification
English 日本語 한국어
Made in China
Coutry Orgin
(주)도어스코리아
Distributer
Small musical instrument
Miracle M100
Model
White / Black
Category
Color
Doors China
Manufaturer
27207-MIRACLEM100
IC ID
Bluetooth V5.0
Bluetooth Ver
Output 10W (5W×2)
Reception
Distance 10M
Usage/
Recharge hr 1~4 hr / 1~4 hr
Aluminium Alloy
Material
Frequency 40HZ-16KHZ
Battery
Volume 2600mAh
Size
(W)100 x (D)75 x (H)275mm
Weight About 485g
R-R-DOr-Miracle-M100
2AXWO-MIRACLEM-M100
KC
FCC
TCT200117B022
PSE
022-210006
R

06
M100 MIC
6Volume Down 7
Volume Up Play / Pause
8
5Power
Press 2-3 sec : Power ON/OFF. Press quickly : Lyric Elimination Mode.
9Preious/Next
Press 2-3 sec : Previous Song. Press quickly : Next Song.
1
SOUND/MODE
Sound Modification. Press 2-3 sec: Mode modification (USB↔Bluetooth).
2
VOLUME/DUET MIC, ECHO, MUSIC Volume Modification. Press 2-3 sec : Duet Mode.
3FM/MUTE
MIC to FM Connection ON/OFF & Frequency Modification.
(FM : 87.5MHz or 88.1MHz / FM : 108.0MHz or 107.9MHz)
It depends on the region you are using.
Press 2-3 Sec : MIC Speaker Mute - FM Speaker only.
Press quickly : Applaud sound.
Press 2-3 sec : Fanfare sound.
4Sound Effect
GOOD
Mode
DSP FM
Duet
Vol
17
3
8
7
5
6
9
4
18
19
20
13
1
2
14
15
16
10 11 12
Front Display
AUX OUT
EARPHONE /
AUX OUT
5 Pin Cable
Port
LED Disco Ball
Port
Buttom Cable Ports
20
FM Connetion Frequency
17
Bluetooth Mode
18
Mute
19
USB
10
Lyric Elimination Mode
11
Duet Mode
12
Battery Status
13
MIC Volume
16
Sound Effect (5 Echo Sounds,3 Voice modifications)
14
Echo Volume
15
Music Volume
LED Display Information (LED display and Feature Information)
English 日本語 한국어

FAQ
English 日本語 한국어
What is Mode modification? AUX Feature Information
What is Lyric Elimination Mode?
Access MP3 Player :
1
. Connect MIC USB to MP3
deivce’s
USB.
2.
Activate Bluetooth and press
Mode Modification. to swith
between Blue tooth and USB.
This mode significantly
lowers reorded
singer’s voice.
: To connect to external speakers\
/headphones.
*Plug speaker/headphone plug
to AUX output.
*
When you press MUTE only MIC
speaker mutes.
07
Bluetooth cannot
be paired
Distant Bluetooth connection
or already paired
with another phone.
Get closer to Smartphone
or reconnect with
other Smartphone.
Microphone
not working
No
Reverberation Unable to turn up Echo volume.
Presence
of noise
Environmental noise mobile
phone signal interference.
Poor Recording
Phone does not match.
Phone chip processing
ability that is too weak.
When
Playing music,
staccato appears
Too Distant to Bluetooth
connection or obstructions
between phone and device.
Weak
accompaniment
sound
Low phone volume
or bad-quality music.
Can’t be turned on or the voice
volume can’t be adjusted.
Switch to Echo Volume
and press VOL+
Adjust the distance between
Microphone and Cellphone
Restart the Smartphone
to try again or try
another Smartphone.
Move closer to SmartPhone,
keep away from obstructions.
Turn up phone volume or
download high-quality music.
Change the MIC, press
POWER button 2-3 seconds and
adjust the volume.
STATUS REASONS SOLUTIONS
