Mircom BPS-1002 User manual

Rev. 101413
BPS-1002
NAC Power Extender
Installation Guide
(See Application Guide for additional information)
firealarmresources.com

- 2 - BPS-1002
Agency Listings:
• UL Listed Control Units for Fire Protective
Signaling Systems (UL 864).
• MEA - NYC Department of Buildings Approved.
• CSFM - California State Fire Marshal Approved.
• FM - Factory Mutual Approved.
• NFPA 72 Compliant.
Input:
• Power input 120VAC 60 Hz, 5.0 amp.
• Two (2) Class A, Style Z or two (2) Class B,
Style W, Y FACP inputs.
• Two (2) NC dry contact trigger inputs.
Output:
• Class 2 Rated power-limited outputs.
• 24VDC @10 amp max total alarm current.
• 2.5 amp max current per output.
• Separate 1.0 amp auxiliary output.
• Programmable supervised indicating circuit outputs:
Four (4) Class B, Style W, Y or Two (2) Class A,
Style Z or One (1) Class A, Style Z and Two (2) Class B,
Style W, Y (see Application Guide).
• Thermal and short circuit protection with auto reset.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery when
AC Fails.
• Zero voltage drop when switching over to
battery backup.
Supervision:
• AC fail supervision (form “C” contact, 1 amp / 28VDC).
Factory set for 1.5 hours with optional 30 seconds
delay setting (field selectable).
• Instant local AC trouble reporting relay
(form “C” contact, 1 amp / 28VDC).
• Battery presence and low battery supervision
(form “C” contact, 1 amp / 28VDC).
Visual Indicators:
• Input and output status LED indicators.
Special Features:
• 2-wire horn/strobe Sync mode allows audible
notification appliances (horns) to be silenced
while visual notification appliances (strobes)
continue to operate.
• Sync protocols include Potter/Amseco, Faraday,
Gentex®,System Sensor®, and CooperWheelock®.
• Temporal Code 3, Steady Mode, Input to Output
Follower Mode (maintains synchronization of
notification appliances circuit).
• Compatible with 12VDC or 24VDC fire panels.
• Output loop supervision steered to input 1 or input 2.
• Signal circuit trouble memory (helps identify
intermittent loop problems).
• Common trouble input and output.
• Ground fault detection.
• Unit includes power supply, red enclosure, cam lock,
and battery leads.
Enclosure Dimensions (approx. H x W x D):
15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm).
Overview:
Mircom BPS-1002 is an extremely cost effective 10 amp remote power supply/battery charger. It may be connected to any
12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such
as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system
accessories. The unit delivers electronically regulated and filtered 24 volt power to Class B, Style W, Y or Class A, Style
Z NAC loop circuits. Additionally, a separate 1.0A auxiliary output for four (4)-wire smoke detectors is available. The 10
amp max. alarm current can be divided between the four (4) outputs for powering NAC devices. Each output is rated at
2.5 amp max., and can be independently programmed for Steady, Temporal Code 3 or Strobe Synchronization. All outputs
may be programmed for Input to Output Follower Mode (output will follow input). In non-alarm condition independent
loop supervision for Class A, Style Z and/or Class B, Style W, Y FACP NAC circuits is provided. In the event of a loop
trouble, the FACP will be notified via the steered input (input 1 or input 2). In addition, there are common trouble output
terminals (NC, C, NO) which are used to indicate general loop/system trouble. A common trouble input is provided for
optional NC (normally closed) devices to report trouble to the FACP. Two (2) FACP signaling outputs can be employed
and directed to control supervision and power delivery to any combination of the four (4) outputs.
Specifications:
BPS-1002 - NAC Power Extender
firealarmresources.com

BPS-1002 - 3 -
Power Supply Specifications:
AC Input: 120VAC 60Hz, 5 amp.
Output:
Four (4) regulated supervised NAC output circuits, 24VDC, 2.5 amp maximum current.
One (1) aux. special application 24VDC power output circuit 1 amp, non-supervised
total output current must not exceed current 10 amp in Alarm Condition.
Battery: Use two (2) 12VDC / 12AH or two (2) 12VDC / 7AH batteries connected in series.
Stand-by/Alarm Current
Consumption: 130mA/300mA
EOL Resistor
(end of line): 2.2K (2200 ohm).
Ground fault maximum
test impedance: 1000 ohm.
Stand-by Specifications:
Stand-by Batteries Stand-by Time Total Amp/Minutes Alarm Output Current Aux. Output
24VDC/7AH 24 Hours 10 amp/5 minutes ---
24VDC/12AH
(use two (2) 12VDC batteries in series) 24 Hours 10 amp/5 minutes 50mA
24VDC/36AH 24 Hours 10 amp/5 minutes 1 amp
Note: Unit is equipped with 1 amp max. auxiliary output: “AUX” will remain battery backed up during power out-
age. For loads connected to “AUX” please refer to battery “Stand-by Specifications” above for ratings. When loads
are connected to “AUX” output during alarm condition, the remaining outputs may not exceed 10 amp total alarm
current (example: AUX = 1 amp, outputs up to 9 amp).
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA
72/ANSI, and with all local codes and authorities having jurisdiction.
Product is intended for indoor use only.
Carefully review:
Application Guide for BPS-602, BPS-802, BPS-1002
Power Supply Specifications (pg. 3)
Stand-by Specifications (pg. 3)
Output Programming Selection Table (pg. 4)
Sync Mode Selection Table (pg. 4)
Terminal Identification Table (pgs. 5-6)
LED Status Indication Table (pg. 6)
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the
enclosure’s upper keyholes over the two upper screws, level and secure. Mark the position of the lower two holes.
Remove the enclosure. Drill the lower holes and install the two fasteners. Place the enclosure’s upper keyholes over
the two upper screws. Install the two lower screws and make sure to tighten all screws
(Enclosure Dimensions, pg. 16).
2. Connect green lead to earth ground (Fig 1). Connect the line [L] and neutral [N] terminals to a separate unswitched
AC circuit (120VAC, 60Hz) dedicated to the Fire Alarm System.
3. Measure output voltage before connecting devices. This helps avoiding potential damage.
4. Connect battery to the terminals marked [+ BAT -- ] on the Power Supply Board (battery leads included).
Note: If batteries being used in your installation do not fit into the BPS-1002 unit, it is required to install a
separate enclosure, UL Listed for appropriate application. Separate battery enclosure is required to have 50 cubic inches
of additional open space. All wiring methods shall be in accordance with the National Electrical Code NFPA 70/
NFPA 72/ANSI and with all local codes and authorities having jurisdiction. Battery circuits are not power-limited;
provide 0.25” spacing from power-limited circuits and use separate knockout. If additional battery enclosure
is required, it must be UL Listed for the application and mounted within 5’ of the BPS-1002 enclosure in the
same room; minimum 12 AWG wire in appropriate conduit is required for connection. When using conduit, make
sure it is installed in a matter where it can not turn.
5. Set output selection switches marked [OUT1 through OUT4] to follow corresponding input [IN1] & I[N2] and
desired output signal type (Output Programming Selection Table, pg. 4).
L N
line
ground
neutral
Fig. 1
firealarmresources.com

- 4 - BPS-1002
6. Connect FACP output to desired AL800LGK logic board inputs, and notification appliances to desired AL800LGK
logic board outputs (see Application Guide).
Note: The 2-wire horn/strobe sync mode will only synchronize horns, horn/strobes, strobes with
synchronization capability.
7. For connection of smoke detectors, digital dialer see Optional Hookup Diagram, pg. 8.
Class A, Style Z Class B, Style W, Y, SW1 & SW2 Settings:
• For all Class B, Style W, Y, hookups SW1 & SW2 on the AL800LGK logic board must be open.
For all Class A, Style Z hookups SW1 & SW2 on the AL800LGK logic board must be closed.
Output Programming Selection Table:
Outputs must be programmed independently (OUT1 - OUT4)
Function Switch Positions Descriptions
ON OFF
Input to Output
Follower Mode 12, 3 Output follows signal it receives from the corresponding input (i.e. FACP
Sync module - maintains synchronization of notification appliance circuit).
Temporal
Code 3 Mode 31, 2 Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.
Steady Mode 1, 2, 3 A steady output signal will be generated.
This mode will accept steady or pulsing input.
For the above modes Dip Switch 4 determines which Input controls
the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by input 1.
Switch 4 in the OFF position causes output(s) to be controlled by input 2.
Sync Mode Selection Table:
Function Switch Positions Descriptions
ON OFF
Amseco Sync
Mode*
1, 3,
42
This mode is designed to work with the Amseco series of horns, strobes, and
horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the flash timing of the strobe, and silencing the horns of the horn/
strobe combination over a two-wire circuit while leaving strobes active.
Faraday
Sync Mode* 2, 4 1, 3
This mode is designed to work with the Faraday series of horns, strobes, and horn/
strobes to provide a means of synchronizing the Temporal-coded horns, synchroniz-
ing the flash timing of the strobe, and silencing the horns of the horn/strobe combi-
nation over a two-wire circuit while leaving strobes active.
Gentex®
Sync Mode*
Gentex is a registered trademark
of Gentex Corporation.
1, 2,
3, 4
This mode is designed to work with the Gentex®series of horns, strobes, and horn/
strobes to provide a means of synchronizing the Temporal-coded horns, synchroniz-
ing the flash timing of the strobe, and silencing the horns of the horn/strobe combi-
nation over a two-wire circuit while leaving strobes active.
System Sensor®
Sync Mode*
System Sensor is a registered
trademark of Honeywell.
1, 2, 4 3
This mode is designed to work with the System Sensor®series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the one-second flash timing of the strobe, and silencing the horns of
the horn/strobe combination over a two-wire circuit while leaving strobes active.
CooperWheelock®
Sync Mode*
CooperWheelock is a
registered trademark of
Cooper Wheelock.
2, 3, 4 1
This mode is designed to work with the CooperWheelock series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the one-second flash timing of the strobe, and silencing the horns of
the horn/strobe combination over a two-wire circuit while leaving strobes active.
*Note: The BPS-1002 will only synchronize horns, horn/strobes and strobes that contain synchronization capability.
Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.
Note: It is required to control visual notification appliances (strobes) via input 1 (IN1) and audible notification
appliances (horns) via input 2 (IN2). This allows audible notification appliances (horns) to be silenced while
visual notification appliances (strobes) continue to operate.
(AL800LGK Board)
Output Dip Switches
INPUT SELECT
TEMPORAL
STROBE SYNC
IN>OUT SYNC
firealarmresources.com

BPS-1002 - 5 -
Amount of Notification Appliances per NAC:
Amseco 27 per NAC* System Sensor®32 per NAC*
Faraday 39 per NAC* CooperWheelock®32 per NAC*
Gentex®32 per NAC*
*Not to exceed a maximum of 2.5 amp per NAC.
Terminal Identification Table:
AL800LGK Logic Board
Terminal
Legend Function/Description
IN1+, IN1-
IN2+, IN2-
(Supervised)
These terminals connect to the 12VDC or 24VDC FACP notification appliance circuit outputs.
(Class A, Style Z or Class B, Style W, X, Y) Input trigger voltage is 8-33VDC @ 5mA min.
Terminal polarity is shown in alarm condition. During an alarm condition these inputs will cause
the selected outputs chosen to drive notification appliances. The designated outputs are set by output
switches [OUT1 through OUT4] (Output Programming Selection Table, pg. 4). A trouble condition on
an output loop will cause the corresponding input to trip the FACP by opening the FACP loop. An
alarm condition will always override trouble to drive notification appliances.
RET1+, RET1-
RET2+, RET2-
(Supervised)
For Class A, Style Z hookups these terminal pairs return to FACP NAC1 and/or NAC2. For
Class B, Style W, X, Y hookups the FACP EOL resistor from the NAC1 and/or NAC2 outputs
are terminated at these terminals.
C “DRY1” NC
C “DRY2” NC
(Dry input trigger)
An open across these inputs, will cause the selected outputs chosen to drive notification
appliances. The designated outputs are set by output switches [OUT1 through OUT4] (Output
Programming Selection Table, pg. 4). Note these inputs are unidirectional and will not report
a trouble condition to the FACP.
+ OUT1 --
+ OUT2 --
+ OUT3 --
+ OUT4 --
(Supervised)
Notification appliances are connected to these regulated outputs (see Application Guide pg. 2-4).
Each power-limited output will supply 2.5 amp. Two (2) outputs may be connected in parallel for a
maximum NAC output capability of 4 amp. Total supply current is 10 amp (see note below). Outputs
are controlled by designated input 1 [IN1] or input 2 [IN2] (Output Programming Selection
Table, pg. 4). Maximum line loss or voltage drop (tested with 2.5V).
C “FAULT” NC
(Common
trouble input)
An open circuit across this pair of terminals will cause [IN1 and IN2] to simultaneously signal a
trouble condition back to the FACP (Typically used to report AC or BAT Fail). (form “C” contact 1
amp / 28VDC) (Fig. 3, pg. 8).
NC, C, NO
(Common
trouble input)
These are dry contact trouble outputs that follow any general loop/system trouble conditions.
(Typically used to trigger a digital communicator or other reporting device).
(form “C” contact 1 amp / 28VDC 0.35 Power Factor) (Fig. 3, pg. 8).
-- AUX+ This separate 1 amp max. auxiliary Special Application Power output circuit is typically used to
power 4-wire smoke detectors. See attached list of devices (Appendix A, pgs. 10-11).
+ DC -- 24VDC from power supply.
Note: Unit is equipped with 1 amp max. auxiliary output: “AUX” will remain battery backed up during power out-
age. For loads connected to “AUX” please refer to battery “Stand-by Specifications” above for ratings. When loads
are connected to “AUX” output during alarm condition, the remaining outputs may not exceed 10 amp total alarm
current (example: AUX = 1 amp, outputs up to 9 amp).
firealarmresources.com

- 6 - BPS-1002
Terminal Identification Table:
Power Supply Board*
Terminal Legend Function/Description
L, N Connect 120VAC to these terminals: L to hot, N to neutral (Fig. 2, pg. 7).
- DC + 24VDC @ 10 amp in alarm non power-limited output (Fig. 2, pg. 7).
AC FAIL
NO, C, NC
Form “C” dry contacts used to instantaneously signal the loss AC to local annunciation devices,
with AC present terminals marked NO and C are open, NC and C are closed. When loss of AC
occurs terminals marked NO and C are closed, NC and C are open.
AC LOCAL
NC, NO, C
Form “C” dry contacts used to instantaneously signal the loss AC to local annunciation devices,
with AC present terminals marked NO and C are open, NC and C are closed. When loss of AC
occurs terminals marked NO and C are closed, NC and C are open.
BAT FAIL
NO, C, NC
Form “C” dry contacts used to signal low battery voltage or loss of battery voltage. Under normal
conditions terminals marked NO and C are open, NC and C are closed. During a trouble condition
terminals marked NO and C are closed, and NC and C are open (Fig. 3, pg. 8).
+ BAT - Stand-by battery input (leads provided) (Fig. 3, pg. 8).
*Power Board Parameter Specifications:
• AC Fail condition will report approximately 1.5 hours after loss of AC. To set AC Delay to 30 seconds, power the unit
down (AC supply and Battery) prior to changing switch position.
Open Switch “AC Delay” or close “AC Delay” switch, respectively.
• Low battery condition will report at approximately 20VDC.
• Battery presence detection will report with in 180 seconds after battery remains undetected (missing or removed).
A restored battery will report within 30 seconds.
LED Diagnostics:
Power Supply Board
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery is supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
AL800LGK - Logic Board
LED OFF ON BLINK (LONG)* BLINK (SHORT)**
ON Normal Alarm Condition Trouble Condition Trouble Condition Memory
ON Normal Alarm Condition Trouble Condition Trouble Condition Memory
OFF Normal Alarm Condition Trouble Condition Trouble Condition Memory
OFF Normal Alarm Condition Trouble Condition Trouble Condition Memory
Input 1 Normal Alarm Condition Trouble Condition ---
Input 2 Normal Alarm Condition Trouble Condition ---
Fault Normal Alarm Condition --- ---
* Indicates current trouble condition. When trouble (open, short or ground) occurs on a specific output, the
corresponding red output LED, [OUT1-OUT4] will blink. The corresponding green input LED will
blink as well. Loop trouble will report within 30 seconds.
** Indicates trouble condition memory. When a trouble condition restores, the unit’s red output LED [OUT1-OUT4]
will blink with a shorter and distinctly a different duration. The green input LEDs will be off (normal condition).
To reset the memory depress the reset button (Fig. 3c, pg. 8). The LED(s) will extinguish.
Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit.
firealarmresources.com

BPS-1002 - 7 -
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
NEC Power-Limited Wiring Requirements for BPS-1002 Models:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring
must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring
and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this
is shown below. Your specific application may require different conduit knockouts to be used. Any conduit knockouts may
be used. For power-limited applications use of conduit is optional. All field wiring connections must be made employing
suitable gauge CM or FPL jacketed wire (or equivalent substitute).
Optional battery enclosure must be mounted adjacent to the power supply via Class 1 wiring methods.
Note: Refer to wire handling drawing below for the proper way
to install the CM or FPL jacketed wire (Fig, 2a).
Fig, 2
Fig, 2a
120VAC Input
60Hz
(non power-
limited)
Supervisory Connections
(power-limited)
non-supervised
Battery
Connections
(non power-
limited)
supervised
Aux.
Output
(power-limited)
non-supervised
NAC
Circuits
(power-limited)
supervised
Signaling
Circuits
from FACP
(non power-
limited)
supervised
firealarmresources.com

- 8 - BPS-1002
Optional Hookups:
1- Battery and AC monitoring: AC or Battery Fail condition will cause the common trouble input [C “FAULT” NC] to
report back to the FACP via input 1 and input 2. The common trouble input may also be used for other optional
supervisory monitoring.
To report AC and Battery Trouble connect the battery and AC Fail relay output shown in (Fig. 3a, Pg. 8) to the
common trouble input.
2- Dry contact input (C “DRY1” NC) (C “DRY2” NC) can be used to alarm output from an
addressable module (these inputs are unidirection and cannot report back to trigger module).
Connection to triggering devices must be made within 20ft. of distance and using conduit for wiring.
3- Auxiliary output (-AUX+) 24VDC at 1 amp max.
4- AC Local [NC, NO, C] should connect to the host control panel for local annunciation of
the trouble condition.
Note: If common trouble input, terminals marked [C “FAULT” NC] are not used, these terminals must be
shorted (connect jumper) to remain inactive. For optional hookups (Fig. 3b, Pg. 8).
Optional Hookup Diagram:
Fig. 3
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level
(26.2-26.4VDC recommended range).
Battery Test: Under normal load conditions check that the battery is fully charged. Check specified voltage both at bat-
tery terminal and at the board terminals marked [+ BAT --] to ensure that there is no break in the battery connection wires.
Fuses: Check input and output fuses on the power supply board, replace if necessary. Input fuse rating is 6.3 amp@
250V, Output fuse rating is 15 amp @ 32V.
Note: Maximum charging current is 1.5 amp.
Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed.
These circuits are used to monitor AC and
Bat Fail and will cause a simultaneous trouble
condition to the FACP's IN1 and IN2 (Non-Supervised)
4-wire Smoke
Detector
+
--
+
--
4-wire Smoke
Detector
Fire Alarm
Control Panel
(FACP)
EOL Power
Supervision Relay
(Not Supplied)
EOL
Resistor
from FACP
SW1
-- DC +
SW2
+ OUT1 --
OUT1 OUT2 OUT3 OUT4
INP1 INP2
FAULT
NC CNOC"FAULT" NC
OUT1 OUT3
OUT2 OUT4
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
IN1+ IN1-- IN2--
IN2+ C "DRY1" NC
RET1+RET1-- RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
-- AUX +
UPPER TERMINALS
LOWER TERMINALS
Addressable Control
Module Trigger Output
See Note 2
(Non-Supervised)
RESET
Supervised
Non-Supervised Input from
Power Supply
BAT FAIL
AC FAIL
DC AC
AC DELAY
NC C NO NC C NO
AC LOCAL
NC C NO
L
N
6.3A 250V
Digital Communicator
or Local Annunciator
Dry output Contact
(Form "C" contacts)
Power-Limited Outputs
2.5 amp per output in alarm
Total = 10 amp
(Supervised)
These circuits are used to monitor AC and
Bat Fail and will cause a simultaneous trouble
condition to the FACP's IN1 and IN2 (Non-Supervised)
4-wire Smoke
Detector
+
--
+
--
4-wire Smoke
Detector
Fire Alarm
Control Panel
(FACP)
EOL Power
Supervision Relay
(Not Supplied)
EOL
Resistor
from FACP
SW1
-- DC +
SW2
+ OUT1 --
OUT1 OUT2 OUT3 OUT4
INP1 INP2
FAULT
NC CNOC"FAULT" NC
OUT1 OUT3
OUT2 OUT4
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
IN1+ IN1-- IN2--
IN2+ C "DRY1" NC
RET1+RET1-- RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
-- AUX +
UPPER TERMINALS
LOWER TERMINALS
Addressable Control
Module Trigger Output
See Note 2
(Non-Supervised)
RESET
Supervised
Non-Supervised Input from
Power Supply
BAT FAIL
AC FAIL
DC AC
AC DELAY
NC C NO NC C NO
AC LOCAL
NC C NO
L
N
6.3A 250V
Digital Communicator
or Local Annunciator
Dry output Contact
(Form "C" contacts)
Power-Limited Outputs
2.5 amp per output in alarm
Total = 10 amp
(Supervised)
Fig. 3a
These circuits are used to monitor AC and
Bat Fail and will cause a simultaneous trouble
condition to the FACP's IN1 and IN2 (Non-Supervised)
4-wire Smoke
Detector
+
--
+
--
4-wire Smoke
Detector
Fire Alarm
Control Panel
(FACP)
EOL Power
Supervision Relay
(Not Supplied)
EOL
Resistor
from FACP
SW1
-- DC +
SW2
+ OUT1 --
OUT1 OUT2 OUT3 OUT4
INP1 INP2
FAULT
NC CNOC"FAULT" NC
OUT1 OUT3
OUT2 OUT4
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
IN1+ IN1-- IN2--
IN2+ C "DRY1" NC
RET1+RET1-- RET2--
RET2+ C "DRY2" NC
+ OUT2 -- + OUT3 -- + OUT4 --
INPUT SELECT
TEMPORAL
STROBE SYNC
IN > OUT SYNC
-- AUX +
UPPER TERMINALS
LOWER TERMINALS
Addressable Control
Module Trigger Output
See Note 2
(Non-Supervised)
RESET
Supervised
Non-Supervised Input from
Power Supply
BAT FAIL
AC FAIL
DC AC
AC DELAY
NC C NO NC C NO
AC LOCAL
NC C NO
L
N
6.3A 250V
Digital Communicator
or Local Annunciator
Dry output Contact
(Form "C" contacts)
Power-Limited Outputs
2.5 amp per output in alarm
Total = 10 amp
(Supervised)
Fig. 3c
Trouble Memory
Reset Button
Fig. 3b
Common
trouble
Input/Output
NC CNOC"FAULT" NC
firealarmresources.com

BPS-1002 - 9 -
Battery Calculation Worksheet
Device Number of
Devices Current per Device Stand-by Current
Alarm
Current
For each device use this formula: This column x This column = Equals Current per number of devices.
BPS-1002
(Current draw from battery) 1Stand-by: 130mA 130mA
Alarm: 300mA 300mA
ABPS-1002 Current 130mA 300mA
Auxiliary Devices Refer to device manual for current ratings.
Alarm/Stand-by mA mA mA
Alarm/Stand-by mA mA mA
Alarm/Stand-by mA mA mA
BAuxiliary Devices Current (must not exceed 1 amp)
Refer to device manual for current ratings.
Alarm: mA 0mA mA
Alarm: mA 0mA mA
Alarm: mA 0mA mA
Alarm: mA 0mA mA
CNotification Appliances Current must not exceed 10 amp (10,000mA) 0mA mA
DTotal alarm current mA mA
ETotal current ratings converted to amperes (line D x 0.001) A A
FNumber of stand-by hours (24 for NFPA 72, Chapter 1, 1-5.2.5). H
GMultiply lines E and F. Total stand-by AH AH
HAlarm sounding period in hours.
(For example, 5 minutes = 0.0833 hours.) H
IMultiply lines E and H. Total alarm AH AH
JAdd lines G and I. Total stand-by and alarm AH AH
K
Multiply line J by 1.30.
(30% extra insurance to meet desired performance)
Total ampere - hours required
AH
Units are capable of recharging 36AH battery max. If total ampere - hour required exceeds 36AH,
decrease AUX current to provide enough stand-by time for the application.
firealarmresources.com

- 10 - BPS-1002
Appendix A - UL/cUL Listed Compatible Devices for Synchronization
A-1 Strobes, Horns and Horn/Strobes
Table A-1 below lists Strobes, Horns and Horn/Strobes compatible with BPS-1002 NAC outputs.
Gentex:
GCS24CR - UL GCCB24PCR / W - UL GEC24-15/75WR - UL
GCS24CW - UL GCCG24PCR / W - UL GEC24-15/75WW - UL
GCS24PCR - UL GCCR24PCR / W - UL SSPK24CLPR - UL
GCS24PCW - UL WGESA24-75PWR / W - UL SSPK24CLPW - UL
GCC24CR - UL WGESB24-75PWR / W - UL SSPK24WLPR - UL
GCC24PCR - UL WGESG24-75PWR / W - UL SSPK24WLPW - UL
GCC24CW - UL WGESR24-75PWR / G - UL SSPK24AWR - UL
GCC24PCW - UL WGECA24-75PWR / W - UL SSPK24AWW - UL
GES3-24WR - UL WGECB24-75PWR / W - UL SSPK24-15/75WLPR - UL
GEC3-24WR - UL WGECG24-75PWR / W - UL SSPK24-15/75WLPW - UL
GEH24-R - UL WGECR24-75PWR / G - UL SSPK24-15/75AWR - UL
GEH24-W - UL WGESA24-75PWLPR / W - UL SSPK24-15/75AWW - UL
WGES24-75WR / WW - UL WGESB24-75PWLPR / W - UL SSPKA24-15/75PWR - UL
WGES24-75PWR / PWW - UL WGESG24-75PWLPR / W - UL SSPKA24-15/75PWW - UL
WGES24-75WRLP / WWLP - UL WGESR24-75PWLPR / W - UL SSPKA24-15/75AWR - UL
WGEC24-75WR / WW - UL WGECA24-75PWLPR / W - UL SSPKA24-15/75AWW - UL
WGEC24-75PWR / PWW - UL WGECB24-75PWLPR / W - UL SSPKB24-15/75PWR - UL
WGEC24-75WRLP / WWLP - UL WGECG24-75PWLPR / W - UL SSPKB24-15/75PWW - UL
WGEC24-75PWRLP / WWLP - UL WGECR24-75PWLPR / W - UL SSPKG24-15/75PWR - UL
GESA24PWR / W - UL GX91-R / W - UL/cUL SSPKG24-15/75PWW - UL
GESB24PWR / W - UL GX91-PR / W - UL/cUL SSPKR24-15/75PWR - UL
GESG24PWR / W - UL GX93-R / W - UL/cUL SSPKR24-15/75PWW - UL
GESR24PWR / W - UL GX93-PR / W - UL/cUL WSSPKA24-15/75AWR - UL
GECA24PWR / W - UL WSSPK24-15/75WR / WW - UL WSSPKA24-15/75AWW - UL
GECB24PWR / W - UL WSSPK24-15/75PWR / PWW - UL WSSPKA24-15/75PWR - UL
GECG24PWR / W - UL WSSPK24-15/75AWR / AWW - UL WSSPKA24-15/75PWW - UL
GECR24PWR / W - UL GES24-177WR - UL WSSPKB24-15/75PWR - UL
GCSA24PCR / W - UL GES24-177WW - UL WSSPKB24-15/75PWW - UL
GCSB24PCR / W - UL GES24-15/75WR - UL WSSPKG24-15/75PWR - UL
GCSG24PCR / W - UL GES24-15/75WW - UL WSSPKG24-15/75PWW - UL
GCSR24PCR / W - UL GEC24-177WR - UL WSSPKR24-15/75PWR - UL
GCCA24PCR / W - UL GEC24-177WW - UL WSSPKR24-15/75PWW - UL
System Sensor:
CHSR - UL P4R-SP - UL PC4RH-P - UL SPSCW - UL SPSWK-CLR-ALERT - UL
CHSW - UL P4RH - UL PC4RH-SP - UL SPSCW-CLR-ALERT - UL SPSWK-P - UL
HR/HRK/HW - UL P4RH-P - UL PC4W - UL SPSCW-P - UL SPSWK-R - UL
MHR - UL P4RH-SP - UL PC4W-P - UL SPSCWH - UL SPSWV - UL
MHW - UL P4RK - UL PC4W-SP - UL SPSCWH-P - UL SPSWV-P - UL
P1224MC - UL P4RK-R - UL PC4WH - UL SPSCWHK - UL SR - UL
P2R - UL P4W - UL PC4WH-P - UL SPSCWHK-P - UL SR-P - UL
P2R-P - UL P4W-P - UL PC4WH-SP - UL SPSCWK - UL SR-SP - UL
P2R-SP - UL P4W-SP - UL PC4WHK - UL SPSCWK-CLR-ALERT - UL SRH - UL
P2RH - UL P4WH - UL PC4WK - UL SPSCWK-R - UL SRH-P - UL
P2RH-LF - UL P4WH-P - UL SCR - UL SPSCWV - UL SRH-SP - UL
P2RH-P - UL P4WH-SP - UL SCR-P - UL SPSCWV-P - UL SRHK - UL
P2RH-SP - UL P4WK - UL SCR-SP - UL SPSCWVH - UL SRHK-P - UL
P2RHK - UL PC2R - UL SCRH - UL SPSCWVH-P - UL SRHK-R - UL
P2RHK-P - UL PC2R-P - UL SCRH-P - UL SPSR - UL SRK - UL
P2RHK-R - UL PC2RH - UL SCRH-SP - UL SPSR-P - UL SRK-P - UL
P2RK - UL PC2RH-P - UL SCRHK - UL SPSRH - UL SRK-R - UL
P2RK-P - UL PC2RH-SP - UL SCRK - UL SPSRH-P - UL SW - UL
P2RK-R - UL PC2RHK - UL SCW - UL SPSRHK - UL SW-ALERT - UL
P2W - UL PC2RK - UL SCW-CLR-ALERT - UL SPSRK - UL SW-CLR-ALERT - UL
P2W-P - UL PC2W - UL SCW-P - UL SPSRK-P - UL SW-P - UL
P2W-SP - UL PC2W-P - UL SCW-SP - UL SPSRK-R - UL SW-SP - UL
P2WH - UL PC2W-SP - UL SCWH - UL SPSRV - UL SWH - UL
P2WH-LF - UL PC2WH - UL SCWH-P - UL SPSRV-P - UL SWH-ALERT - UL
P2WH-P - UL PC2WH-P - UL SCWH-SP - UL SPSW - UL SWH-P - UL
P2WH-SP - UL PC2WH-SP - UL SCWHK - UL SPSW-ALERT - UL SWH-SP - UL
P2WHK - UL PC2WHK - UL SCWK - UL SPSW-CLR-ALERT - UL SWHK - UL
P2WHK-P - UL PC2WK - UL SPSCR - UL SPSW-P - UL SWHK-P - UL
P2WK - UL PC4R - UL SPSCRH - UL SPSWH - UL SWK - UL
P2WK-P - UL PC4R-P - UL SPSCRV - UL SPSWH-P - UL SWK-P - UL
P4R - UL PC4R-SP - UL SPSCRVH - UL SPSWK - UL
P4R-P - UL PC4RH - UL
firealarmresources.com
