USER MANUAL
MiniSentry-2
TRANSPORTABLE
GAMMA PORTAL MONITOR
Ref: 108082
DECEMBER 2019

USER MANUAL
MiniSentry-2
TRANSPORTABLE
GAMMA PORTAL MONITOR
REF: 108082
December 2019

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
3 / 170
WARNING
MIRION TECHNOLOGIES (Canberra) SAS
cannot be held responsible for any damage incurred
by the buyer due to faulty use, connection to the wrong voltage, or non-
observance of the
instructions found in this manual.
This device is designed to be used exclusively in an industrial environment.
The information contained herein may be altered without notice.
Any full or partial reproduction of this document may only
be made after obtaining prior permission
from MIRION TECHNOLOGIES (Canberra) SAS.
Manufacturer :
MIRION TECHNOLOGIES (Canberra) S.A.S.
ZI de Vauzelles – BP 249
37602 Loches CEDEX

USER MANUAL
MINISENTRY-2
4 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
5 / 170
SUMMARY
1GENERAL SAFETY INSTRUCTIONS ..................................................................................................10
2SAFETY INSTRUCTIONS .....................................................................................................................10
3USE PRECAUTIONS.............................................................................................................................11
4DISPOSAL OF THIS EQUIMPENT ....................................................................................................... 12
5PACKING LISTS FOR MINISENTRY-2 ................................................................................................ 13
6OPTION LIST.........................................................................................................................................13
7PRESENTATION ................................................................................................................................... 14
8DESCRIPTION....................................................................................................................................... 15
8.1 PEDESTRIAN CONFIGURATION........................................................................................................... 15
8.2 VEHICLE OR EXTENDED PASSAGE CONFIGURATION (OPTIONAL)........................................................... 16
8.3 MINISENTRY CONTROL UNIT.............................................................................................................. 17
8.3.1 Front panel..........................................................................................................................17
8.3.2 Keyboard and menu bar functions...................................................................................18
8.3.3 Charging indicator .............................................................................................................19
8.3.4 FRISKER CSP probe LEDs................................................................................................20
8.3.5 Protal probe LED ................................................................................................................21
8.3.6 Loudspeaker .......................................................................................................................22
8.4 BOTTOM PANEL ................................................................................................................................22
9USE ........................................................................................................................................................ 23
9.1 MEASURE MODES .............................................................................................................................23
9.2 BACKGROUND MANAGEMENT ............................................................................................................24
9.3 ALARM MANAGEMENT .......................................................................................................................24
9.4 POWER ON .......................................................................................................................................24
9.5 WALK-THROUGH MODE .................................................................................................................... 28
9.5.1 Before measurement .........................................................................................................29
9.5.2 During measurement .........................................................................................................30
9.5.3 After measurement ............................................................................................................30
9.6 ENTER-WAIT MODE........................................................................................................................... 30
9.6.1 Before measurement ......................................................................................................... 32
9.6.2 During measurement .........................................................................................................32
9.6.3 After measurement ............................................................................................................32
9.7 COUNT-RATE MODE ......................................................................................................................... 32
9.7.1 Before measurement .........................................................................................................34
9.7.2 During measurement .........................................................................................................34
9.8 FRISKER PROBE OPTION....................................................................................................................34
9.9 MEASURE SETTINGS ......................................................................................................................... 35
9.9.1 Unit ...................................................................................................................................... 35
9.9.2 Walk through settings ....................................................................................................... 36
9.9.2.1Alarm management 38
9.9.3 Enter wait settings .............................................................................................................39
9.9.3.1 Auto count time management 41

USER MANUAL
MINISENTRY-2
6 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
9.9.3.2 Alarm management 41
9.9.4 Count rate settings.............................................................................................................42
9.9.4.1 Alarm management 43
9.9.5 Frisker settings...................................................................................................................44
9.9.5.1 Alarm management 45
9.9.6 Unit system .........................................................................................................................46
9.10 GENERAL SETTING ............................................................................................................................47
9.10.1Backlight adjustment .........................................................................................................47
9.10.2Simulated sound volume setting ......................................................................................48
9.10.3Contrast adjustment...........................................................................................................49
9.10.4Date and time ......................................................................................................................51
9.10.5Erasing Log files.................................................................................................................53
9.10.6Reset of settings.................................................................................................................54
9.10.7Internal memory format .....................................................................................................56
9.10.8Language setting................................................................................................................58
9.10.9Profile settings....................................................................................................................59
9.10.9.1 Password 59
9.10.9.2 Password resetting 61
9.10.9.3 Enabling/Disabling Profiles 62
9.10.10 Software version display ................................................................................................64
9.11 ADVANCED SETTINGS........................................................................................................................65
9.11.1Fault alarms ........................................................................................................................65
9.11.2Background noise ..............................................................................................................67
9.11.2.1 Low background noise 68
9.11.2.2 High background noise 68
9.11.2.3 Excessive background noise 68
9.11.3Monitor calibration .............................................................................................................69
9.11.3.1 Check of the calibration date 69
9.11.3.2 Performing the calibration 70
9.11.4Portal probe calibration check..........................................................................................72
9.11.5Frisker calibration check ...................................................................................................73
9.12 SELECTION OF USER PROFILES &DEFAULT PASSWORDS ....................................................................74
9.13 SHUTDOWN ......................................................................................................................................75
10 USER MESSAGES ................................................................................................................................75
11 DEFAULT USER PARAMETERS .........................................................................................................79
12 USB MODE ............................................................................................................................................80
12.1 COMPUTER CONNECTION...................................................................................................................81
12.2 DISCONNECTING A COMPUTER...........................................................................................................82
12.3 USB STICK CONNECTION ..................................................................................................................82
12.4 DISCONNECTING A USB STICK ..........................................................................................................83
13 PORTAL PROBE CALIBRATION .........................................................................................................84
13.1 HIGH VOLTAGE .................................................................................................................................84
13.2 DISCRIMINATOR ................................................................................................................................85
13.3 EFFICIENCY ......................................................................................................................................85
13.4 PC TO PORTAL PROBES CONNECTION................................................................................................85
13.5 FACTORY PRE-CALIBRATION PARAMETERS ........................................................................................87
13.6 HIGH VOLTAGE .................................................................................................................................90

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
7 / 170
13.7 ELECTRONIC DISCRIMINATION ...........................................................................................................93
13.8 BACKGROUND NOISE ........................................................................................................................96
13.9 COEFFICIENT CALCULATION ..............................................................................................................98
13.10COEFFICIENT VALIDATION..............................................................................................................102
14 LOG FILES ..........................................................................................................................................103
14.1 LOG FILE FORMAT........................................................................................................................... 103
14.2 EXPORTING LOG FILES TO USB STICK.............................................................................................105
14.3 BACKING UP AND BROWSING LOG FILES ON A COMPUTER .................................................................106
15 UPDATE OF MINISENTRY-2 .............................................................................................................. 106
15.1 UPDATE FROM A COMPUTER............................................................................................................106
15.2 UPDATE FROM USB STICK ..............................................................................................................107
16 CONFIGURATION FILE SETTING .....................................................................................................108
16.1 SAVING THE CONFIGURATION FILE ON USB STICK ............................................................................ 108
16.2 RESTORING THE CONFIGURATION FILE WITH A USB STICK ................................................................108
16.3 CONFIGURATION FILE BACKUP AND VIEWING ON COMPUTER .............................................................110
17 FRISKER CONNECTOR ..................................................................................................................... 110
18 NETWORK COMMUNICATION FUNCTION & DIGITAL I / O............................................................111
18.1 CONNECTORS PINOUT .....................................................................................................................111
18.2 NETWORKING .................................................................................................................................112
18.3 MODBUS SETTING ........................................................................................................................112
18.3.1ModBus data..................................................................................................................... 112
18.3.2Digital input/output ..........................................................................................................113
19 CARACTERISTICS OF THE MONITOR .............................................................................................114
19.1 DECLARATION OF CONFORMITY ....................................................................................................... 114
19.2 MECHANICAL CHARACTERISTICS .....................................................................................................114
19.3 ENVIRONMENTAL CHARACTERISTICS................................................................................................ 114
19.4 ELECTRICAL CHARACTERISTICS ...................................................................................................... 114
19.5 PERFORMANCE............................................................................................................................... 115
20 FRISKER PROBE COMPATIBILITY TABLES ...................................................................................116
21 STORAGE AND TRANSPORT ........................................................................................................... 117
21.1 STORAGE ....................................................................................................................................... 117
21.2 TRANSPORT ................................................................................................................................... 117
22 PREVENTIVE MAINTENANCE........................................................................................................... 117
22.1 PERIODIC TABLE.............................................................................................................................117
22.2 PROPERLY WORKING CHECK...........................................................................................................118
23 DECONTAMINATION AND CLEANING .............................................................................................119
23.1 DECONTAMINATION PROCEDURE......................................................................................................119
23.1.1Procedure for non-fixed contamination......................................................................... 119
23.1.2Operating mode for a fixed contamination.................................................................... 119
24 TROUBLESHOOTING......................................................................................................................... 120
24.1 DAMAGE MOST LIKELY ....................................................................................................................120
25 ASSEMBLY GUIDE, PEDESTRIAN CONFIGURATION .................................................................... 121
25.1 PART LIST ...................................................................................................................................... 121
25.2 ASSEMBLY INSTRUCTION.................................................................................................................122
26 ASEMBLY GUIDE, VEHICLE CONFIGURATION ..............................................................................124
26.1 PEDESTRIAN KIT.............................................................................................................................124
26.2 VEHICLE PART LIST ........................................................................................................................126

USER MANUAL
MINISENTRY-2
8 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
26.3 ASSEMBLY INSTRUCTION.................................................................................................................127
27 SPARE PARTS LIST FOR THE INITIAL PERIOD (1-2 YEARS) .......................................................129
28 SPARE PARTS FOR 3-5 YEARS OPERATION (ADDITIONAL QUANTITIES) ................................130
29 MONITOR SPARE PARTS..................................................................................................................132
29.1 FRONT PANEL .................................................................................................................................132
29.2 LABELS ..........................................................................................................................................133
29.3 DONGLE BOARD KIT -108334 .........................................................................................................134
29.4 MAIN POWER SUPPLY CONNECTOR KIT .............................................................................................135
29.5 SWITCH ON/OFF KIT........................................................................................................................136
29.6 BATTERY KIT ..................................................................................................................................137
29.7 INTEFACE BOARD KIT ......................................................................................................................138
29.8 MOTHER BOARD KIT -108337.........................................................................................................139
29.9 PROTECTION GLASS KIT ..................................................................................................................140
29.10READY TO MEASURE LIGHT KIT .......................................................................................................141
29.11LOUD-SPEAKER.............................................................................................................................141
29.12REAR COVER KIT -108340 ............................................................................................................142
30 DISASSEMBLING................................................................................................................................143
30.1 MONTOR REMOVAL/INSTALLATION...................................................................................................143
30.1.1Tools:.................................................................................................................................143
30.1.2Removal.............................................................................................................................143
30.1.3Installation.........................................................................................................................144
30.2 REAR COVER REMOVAL/INSTALLATION.............................................................................................146
30.2.1Tools:.................................................................................................................................146
30.2.2Preliminary operations: ...................................................................................................146
30.2.3Removal.............................................................................................................................146
30.2.4Installation.........................................................................................................................147
30.3 BATTERY REMOVAL/INSTALLATION ..................................................................................................147
30.3.1Tools:.................................................................................................................................147
30.3.2Preliminary operations: ...................................................................................................147
30.3.3Removal.............................................................................................................................147
30.3.4Installation.........................................................................................................................148
30.4 MOTHER BOARD REMOVAL/INSTALLATION........................................................................................149
30.4.1Tools:.................................................................................................................................149
30.4.2Preliminary operations: ...................................................................................................149
30.4.3Removal.............................................................................................................................149
30.4.4Installation.........................................................................................................................150
30.5 INTERFACE BOARD REMOVAL/INSTALLATION ....................................................................................152
30.5.1Tools:.................................................................................................................................152
30.5.2Preliminary operations: ...................................................................................................152
30.5.3Removal.............................................................................................................................152
30.5.4Installation.........................................................................................................................153
30.6 DONGLE BOARD REMOVAL/INSTALLATION ........................................................................................155
30.6.1Tools:.................................................................................................................................155
30.6.2Preliminary operations: ...................................................................................................155
30.6.3Removal.............................................................................................................................155

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
9 / 170
30.6.4Installation ........................................................................................................................156
30.7 MAIN POWER SUPPLY REMOVAL/INSTALLATION ................................................................................158
30.7.1Tools:.................................................................................................................................158
30.7.2Preliminary operations: ...................................................................................................158
30.7.3Removal ............................................................................................................................158
30.7.4Installation ........................................................................................................................159
30.8 BLUE LIGHTS REMOVAL/INSTALLATION ............................................................................................160
30.8.1Tools:.................................................................................................................................160
30.8.2Preliminary operations: ...................................................................................................160
30.8.3Removal ............................................................................................................................160
30.8.4Installation ........................................................................................................................161
30.9 POWER SWITCH REMOVAL/INSTALLATION.........................................................................................162
30.9.1Tools:.................................................................................................................................162
30.9.2Preliminary operations: ...................................................................................................162
30.9.3Removal ............................................................................................................................162
30.9.4Installation ........................................................................................................................163
30.10MAIN POWER SUPPLY CONNECTOR REMOVAL/INSTALLATION ...........................................................163
30.10.1 Tools: ..............................................................................................................................163
30.10.2 Preliminary operations: ................................................................................................163
30.10.3 Removal.......................................................................................................................... 163
30.10.4 Installation...................................................................................................................... 165
30.11USB CONNECTOR REMOVAL/INSTALLATION....................................................................................167
30.11.1 Tools: ..............................................................................................................................167
30.11.2 Preliminary operations: ................................................................................................167
30.11.3 Removal.......................................................................................................................... 167
30.11.4 Installation...................................................................................................................... 167
30.12DISPLAY PROTECTION REMOVAL/INSTALLATION ..............................................................................168
30.12.1 Tools: ..............................................................................................................................168
30.12.2 Preliminary operations: ................................................................................................168
30.12.3 Removal.......................................................................................................................... 168
30.12.4 Installation...................................................................................................................... 169

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S,BP249, ZI de Vauzelles, 37602
Loches Cedex
10 / 170
1 GENERAL SAFETY INSTRUCTIONS
Read these instructions carefully before using the device and keep them for future reference.
Observe all warning and recommendations marked on the device.
Never try to intervene yourself on the device, such as opening or removing covers that could expose
you to dangerous voltage or other hazards, and that would void the manufacturer's warranty. Refer to
the services of qualified people for the maintenance of the product.
Disconnect this product from all power supplies and refer to qualified personnel for the following cases:
−When the power cable or plug is damaged or cracked,
−If the unit does not operate normally and the operating instructions have been followed. Only
perform the checks that are covered by the operating instructions since improper performance
of other controls may result in damage and will often require additional work by a qualified
technician to restore the unit to its normal operating condition.
−If the device has dropped and its case has been damaged,
−If the device shows a significant change in performance, this indicates the need for qualified
service personnel to repair the device.
2 SAFETY INSTRUCTIONS
: Warning, risk of electric shock.
Indicates the presence of the mains and a risk of electric shock if the protections are removed.
Always disconnect the mains cable completely from the case whenever you use the device.
Only qualified personnel will be able to open the box.
: Caution, the accompanying documents must be consulted.

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
11 / 170
3 USE PRECAUTIONS
The intended use of Transportable Gamma Portal Monitors is for contamination monitoring for people.
Any other use is considered prohibited.
Do not touch the LCD screen as well as the function keys with sharp or hard objects
Do not use strippers, waxes or corrosive solvents to clean the front of the unit, use only a soft, dry or
damp cloth.
Only equipment and accessories recommended and sold by MIRION TECHNOLOGIES (Canberra)
SAS must be connected to the Minisentry-2.
: The replacement of the power cable must be done with a cable identical to that recommended
(See § 4).
: 12 VDC power supply option. Do not connect dangerous voltage to the terminals of the 12
VDC auxiliary power supply, voltage that may present a risk of electric shock or burn.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Any changes or modifications to this equipment not expressly approved by MIRION
TECHNOLOGIES (Canberra) SAS may cause, harmful interference and void the FCC
authorization to operate this equipment.
: To avoid portal tip over we recommend fixing the feet on the ground.
: The MiniSentry-2 can be used only according to the characteristics and technical
specifications in § 19, defined by MIRION TECHNOLOGIES (Canberra) SAS.
If the device is used of a way which is not specified by MIRION TECHNOLOGIES (Canberra)
SAS, the protection provided by the device may be compromised.

USE MANUAL
MINISENTRY-2
12 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
4 DISPOSAL OF THIS EQUIMPENT
This equipment may contain substances that could have an effect on the environment and human
health.
Users / owners of this equipment are responsible for ensuring that the equipment is not a risk to the
environment or health when it is no longer used and must be disposed of.
The following symbol, which you will also find on MIRION TECHNOLOGIES (Canberra) SAS products,
indicates that these products should not be disposed in unsorted municipal waste. It must be sorted.
This equipment is subject to the Decree 2005-829 of 20/07/05 on the disposal of Waste Electrical and
Electronic Equipment (WEEE), please contact your nearest MIRION TECHNOLOGIES (Canberra)
SAS office for advice on the proper disposal of this equipment.

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
13 / 170
5 PACKING LISTS FOR MINISENTRY-2
Qty Description Order No.
1
MiniSentry-2
108082
1
- MiniSentry-2 monitor
108098
1
- Detector assembly
108097
1 - Power cable
EU: 79025
US: 68025
UK: 88559
1
- User manual
107911
1
- Assembly guide
107912
1
- USB stick
102800
1
- USB cable (PC connection)
105166
6 OPTION LIST
Supplementary options
Description
Qty Description Order No. Description
1
Remote light tower
108126 External result (Green and red) tower light with magnet foot
1 Vehicle kit (2.7m width) 108127 Additional base plate for each detector side, cable 2.7 m
(8.86 ft.) cables and protections
1
Kit for Extended passage
width (91.5 cm)
108184 Wider top part to increase portal width to 91.5 cm (36 in)
1 Battery extension 108181 External 12V battery and portal support to extend battery
autonomy
1 Frisker probe holder 108124 Allows to hold CSP probes on monitor
1 Frisker probe See CSP probe references
1 Flight case 108183 Hard transport case
1 Nylon carry bag 108182 Flexible nylon protection with foam pad
1 Monitor upgrade kit 108125 To connect a new monitor to an old detector assembly

USE MANUAL
MINISENTRY-2
14 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
7 PRESENTATION
The MiniSentry-2 Computer Based Portable Portal Monitor is a portable emergency gamma portal
monitor. It was designed as a monitoring solution for emergency response to allow the screening of
people exiting a contaminated area, as well as monitoring the entrances to large public gatherings to
detect people who are carrying dangerous radioactive materials. It can also be configured to function as
a vehicle monitor if this option is purchased.
Erection or disassembly can be carried out by one person in less than 10 minutes with no tools
required. The MiniSentry-2 is designed for outdoor as well as indoor use.
The software is adapted to reflect the actual configuration of each model, such as the type, number and
location of detectors and the applicable options. As a result, the screens displayed on different models
may differ slightly from those in this manual; however, the procedures described apply to all units,
except where noted.

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
15 / 170
8 DESCRIPTION
8.1 PEDESTRIAN CONFIGURATION
The base configuration of MiniSentry pedestrian (Figure 1) is equipped with:
•Footplate for each post with mounting hardware (x2),
•Primary detector post with MiniSentry Control unit,
•Top cross piece with attached elbows for pedestrian configuration,
•Secondary detector post,
•Power cable.
Options are:
•91.5 cm (36 in) top cross piece kit for extended pedestrian configuration,
•Red / green light tower,
•Nylon case and foam pieces needed for future shipping,
•Flight transport case,
•Frisker probe and holder,
•Battery extension.
Figure 1 Pedestrian Configuration
MiniSentry
Control unit
Top cross piece
Footplates
Primary detector
post
Presence sensors
Secondary
detector post
Red / green light tower
(Optional)

USE MANUAL
MINISENTRY-2
16 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
8.2 VEHICLE OR EXTENDED PASSAGE CONFIGURATION (OPTIONAL)
The MiniSentry vehicle or extended passage configuration (Figure 2) is equipped with:
•Primary detector post with MiniSentry Control unit
•Secondary detector post
•End caps (x2) for vehicle configuration needs, extended passage and shipping
•Red / green light tower (Optional)
•Power cable
•Nylon case and foam pieces needed for future shipping
•Footplate for each post with mounting hardware (x2)
•Vehicle baseplates and bolts for each post
•2.5 m (8.20 ft) rubber spacers
•2.7 m (8.86 ft) cable set between the base of each detector post
Figure 2 Vehicle configuration
MiniSentry
Control unit
End caps
Footplates
Primary
detector post
2.5m (8.20 ft) Rubber spacers
Presence sensors
Vehicle baseplates
Secondary
detector post
Red / green light
tower (Optional)

USER MANUAL
MINISENTRY-2
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S.,BP249, ZI de Vauzelles, 37602
Loches Cedex
17 / 170
8.3 MINISENTRY CONTROL UNIT
Figure 3 Controller module electronics
8.3.1 Front panel
Figure 4 MiniSentry-2 - Front panel
LCD display
Loud speaker
Keyboard
Portal detector LED status
FRISKER CSP
probe LED
status
Charging LED
Bottom panel
Front panel
Clamps
Red / green light tower
(Optional)

USE MANUAL
MINISENTRY-2
18 / 170
107911_D User manual MINISENTRY-2_En.docx
MIRION TECHNOLOGIES (Canberra) S.A.S,BP249, ZI de Vauzelles, 3760
2
Loches Cedex
8.3.2 Keyboard and menu bar functions
The keyboard, equipped with five keys, allows:
Main menu entry / exit
Validation key (See table below)
Back left arrow in the menus
Right arrow of selection in the menus
On / Off of the Frisker probe screen
Down navigation arrow in the menus
On / Off of simulated sound of the Frisker probe
Arrow up menu navigation
On / Off of the backlight
Corresponding keyboard keys with screen information
Keys Bottom screen Function
Selection key
Edit key
Return key to previous menu
Close a folder
Validate a setting
Save a data
Back left arrow or cancel
Move the selection to the left
Decrease a level
