MITREX M A1F Series User manual

1
INSTALLATION MANUAL
FRAME SOLAR MODULES
Mxxx-A1F - Mxxx-B1F - Mxxx-yyyy1F

2
TABLE OF CONTENT
1. SAFETY PRECAUTIONS & HANDLING OF MODULES .............................. 03
1.1 Manual Disclaimer
1.2 Limitation Of Liability
1.3 General Information
1.4 General Warning
2. PRODUCT INFORMATION .................................................................................. 04
2.1 Product Certifications
2.2 Limited Warranty
2.3 Technical Specifications
3. ELECTRICAL INSTALLATION .............................................................................. 04
3.1 General Information
3.2 Wiring Requirements
3.3 Series Connection
3.4 Parallel Connection
3.5 Electrical Grounding
4. MECHANICAL INSTALLATION .......................................................................... 06
4.1 General Information
4.2 Site Considerations
4.3 Module Mounting
4.4 Mounting Via Clamps
5. APPENDIX ................................................................................................................. 08
5.1 Electrical Specifications
5.2 Mechanical Specifications
5.3 Temperature Specifications
5.4 Clamping Position

3
1. SAFETY PRECAUTIONS & HANDLING
OF MODULES
1.1 MANUAL DISCLAIMER
The information presented in this manual
is subject to change by Mitrex without prior
notice. Mitrex gives no warranty of any kind
whatsoever, either explicitly or implicitly, with
respect to the information herein. In the case of
any inconsistency between different language
versions, the English version shall overcome and
take control in all respects.
1.2 LIMITATION OF LIABILITY
Mitrex shall not be held responsible for damages
of any kind, including – without limitation – bodily
harm, injury or damage to property, in connection
with handling PV modules, system installation,
or compliance or non-compliance with the
instructions set forth in this manual.
1.3 GENERAL INFORMATION
The following instructions relate to the
safety and intended use of PV modules.
Failure to comply with any instructions
below may result in product damage,
physical injury and/or death.
This installation manual contains essential
information for the electrical and mechanical
installation that you must know before installing
modules. All information described in this
manual are intellectual property and based on
technologies and experiences that have been
acquired and accumulated throughout years.
The installation of PV modules requires a great
degree of skill and should only be performed by a
qualified licensed professional, including licensed
contractors and licensed electrifications. Please
be aware that there is a serious risk of various
types of injury occurring during the installation
including the risk of electric shock. All modules
are equipped with a permanently attached
junction box that will accept variety of wiring
applications or with a special cable assembly
for ease of installation, and they do not require
special assembly.
1.4 GENERAL WARNING
 All modules must be installed by licensed
electricians in accordance with the applicable
geographic electrical codes and standards.
 Do not connect or disconnect modules when
current from the modules or an external source is
present.
 Always use appropriate Personal Protective
Equipment when installing PV modules.
 Modules should be stored in a dry and
ventilated environment to avoid direct sunlight
and moisture.
 Always use electrically insulated tools to
reduce the risk of electric shock.
 The PV module does not contain any
serviceable parts. Do not attempt to modify or
repair any part of the module.
If modules are stored in an uncontrolled
environment, the storage time should be
less than 3 months and extra precautions
should be taken to prevent connectors
from being exposed to moisture or
sunlight, like using connector endcaps.
 Perform all work in safe and dry conditions.
 External or artificially concentrated sunlight
shall not be directed onto the PV module.
 Do not use or install damaged modules.
 Modules must always be handled and installed
by two people.
 Do not carry the module by its cables.
 Do not stand, step, walk and / or jump on
modules under any circumstances.
 Handle the module in a way that avoids
breakage, scratching, bending of the glass and
backsheet.
 Do not drop or place objects (such as tools) on
the modules.
 Always handle the modules by the frame.
 Do not use sharp instruments on the modules.
 Do not lift modules by their wires or junction
box, lift them by the frame.
 Keep all connectors clean and dry at all times.
 Do not place excessive loads on the module or
twist the module frame.

4
 Do not expose the modules and its connectors
to any unauthorized chemical substance (e.g. oil,
lubricant, pesticide, etc.).
 Do not leave modules unsupported or
unsecured.
 Particular care should be taken to avoid
module backsheets being damaged by sharp
objects, as scratches may directly affect product
safety.
2. PRODUCT INFORMATION
2.1 PRODUCT CERTIFICATIONS
Mitrex products meet and/or exceed the
requirements set forth by UL 61730, UL 61215,
CSA C22.2 NO. 61730, CSA C22.2 NO. 61215, IEC
61730 and IEC 61215 for PV modules. These UL,
CSA and IEC are freestanding. To satisfy the
listing for this product the modules must be
mounted with a rack or standoff structure. The
module is considered to be in compliance with UL
61215/61730, CSA 61215/61730 and/or IEC 61215/61730
only when the module is mounted in the manner
specified by the mounting instructions contained
in this document.
2.2 LIMITED WARRANTY
Mitrex provides a 25-year hardware warranty, and
we guarantee that after 25 years, the efficiency of
the panel will be no less than 80% of the original
energy generation. For more information on the
details covered within the warranty and the claim
process, scan the QR code below.
2.3 TECHNICAL SPECIFICATIONS
A full list of mechanical and electrical technical
specifications for the PV modules can be
found in the Appendix section. Electrical test
data is according to standard test conditions
(IEC 60904-3).
Under normal conditions, a photovoltaic module
is likely to experience conditions that produce
higher current and/or voltage than reported at
standard test conditions. Accordingly, the values
of Isc and Voc marked on the PV module should
be multiplied by a factor of 1.25 when determining
component voltage ratings, conductor current
ratings, and size of controls (e.g. inverter)
connected to the PV output.
3. ELECTRICAL INSTALLATION
3.1 GENERAL INFORMATION
Ensure correct polarity when connecting
PV modules.
 Connectors are not waterproof when unmated.
When installing modules, connector should be
connected to each other as soon as possible or
appropriate measures should be taken to avoid
moisture and dust penetrating into the connector.
 Make sure that all connections are safe and
properly mated. An audible click should be heard
when mating connectors. The PV connector
should not be subjected to stress from the
exterior. Connectors should only be used to

5
produce the desired voltage output.
 The current of each module connected in
series should be the same.
 The maximum PV system voltage for that
circuit shall be calculated as the sum of the rated
open-circuit voltage of the series-connected
PV modules corrected for the lowest expected
ambient temperature.
3.4 PARALLEL CONNECTION
The solar modules may be combined in
parallel to produce the desired current output.
 When modules are combined in parallel, the
total current is equal to the sum of currents from
each module.
 The voltage of each module connected in
parallel should be the same.
 When connecting plural strings of modules in
parallel every series string or solar module must
be fused prior to combining with other strings.
 Abide with all applicable federal, state, and
local codes for additional fusing requirements
and limitations on the maximum number of solar
modules in parallel.
 Depending on national directives, additional
safety factors might be applicable for over current
protection.
A multiplying factor is required for
increased output of the PV modules.
Under normal conditions, a PV module
is likely to experience conditions that
produce more current and/or voltage
than reported at standard test conditions.
The requirements of the National
Electrical Code (NEC) in Article 690 shall
be followed to address these increased
outputs. In installations not under the
requirements of the NEC, the values of
Isc and Voc marked on this PV module
should be multiplied by a factor of 125%
when determining component voltage
ratings, conductor ampacities, fuse sizes,
and size of controls to the PV output.
3.5 ELECTRICAL GROUNDING
 All work must be conducted in conformance
with all Federal, State, and local codes and
connect the circuit. They should never be used to
turn the circuit on and off.
Ensure cabling is adequately protected
from direct sunlight, dirt, debris,
moisture, and mechanical friction.
 Ensure that plug connections are secured
away from any water-accumulating surfaces. Use
UV-resistant cable ties to secure cables to the
mounting system. Cables should avoid exposure
to direct sunlight.
 Only use dedicated solar cable and suitable
connectors (wiring should be sheathed in a
sunlight-resistant conduit or, if exposed, should
be sunlight-resistant itself) that meet local
fire, building and electrical regulations. Please
ensure that all wiring is in perfect electrical and
mechanical condition.
3.2 WIRING REQUIREMENTS
 Mitrex recommends that all wiring be double
insulated with a minimum rating of 90°C (194°F).
 All wiring should use a flexible copper
conductor.
 Minimum size should be determined by
applicable codes.
 Mitrex recommends a minimum size of
10AWG.
 All Mitrex solar modules are connected via
MC4 connectors.
3.3 SERIES CONNECTION
 The solar modules may be wired in series to

6
standards.
 Do not drill any extra ground holes for
convenien¬ce this will void the modules warranty.
 Grounding connections should be performed
by a qualified electrician for the safety and
maintenance of the system in accordance with
all national, state and local electrical codes and
regulations and standards.
 Connect module frames together using
adequate grounding cables: Mitrex recommends
using 4-14 mm² (AWG 12-6) copper wire.
 All bolts, nuts, flat washers, lock washers and
other relevant hardware should be made of
stainless steel, unless otherwise specified.
In most of frames, holes provided for this
purpose are identified with a grounding
symbol (IEC 61730-1). Otherwise the
location is in the middle of long frame on
both side of the module. All conductive
connection junctions must be firmly
fixed.
Where common grounding hardware
(nut, bolts, washers) is used to attach a
listed grounding device, the attachment
must be made in conformance with
the grounding device manufacturer’s
instructions.
 A module with exposed conductive parts is
considered to be in compliance with UL only
when is electrically grounded in accordance
with the instructions presented below and the
requirements of the National Electrical Code.
4. MECHANICAL INSTALLATION
4.1 GENERAL INFORMATION
The module is considered to be in compliance
with applicable standards only when the module
is either mounted in the manner specified by the
mounting instructions, or when the mounting
means has been evaluated with this PV module to
UL 2703. A module with exposed conductive parts
is considered to be in compliance with applicable
standards only when it is either electrically
grounded in accordance with the manufacturer’s
instructions and the requirements of the National
Electrical Code, ANSI/NFPA 70 (2014-2017), or
when the bonding means has been evaluated
with this PV module to UL 2703.
4.2 SITE CONSIDERATIONS
Mitrex Solar Modules should be mounted in a
location that meets the following requirements.
 The module is intended for use in general
open-air climates, as defined in IEC 60721-2-1
Classification of environmental conditions Part-2-1:
Environmental conditions appearing in nature -
Temperature and humidity.
 Note the operating temperature listed in the
Appendix..
 Please consult the Mitrex technical support
department for more information on the use of
modules in special climates, such as an altitude
greater than 2000m.
 Exposing modules to salt (i.e. marine
environments) or sulfur (i.e. sulfur sources,
volcanoes) incurs the risk of module corrosion.
Special considerations should be made for
installations with increased salt content in the air.
 Do not operate solar modules near highly
flammable substances.
 Do not expose modules and their connectors
to any unauthorized chemical substances (e.g. oil,
lubricant, pesticide, etc.), as modules may incur
damages.
 Modules should be installed as to minimize
shading.
 Do not install modules in an enclosed space.
 Failure to comply with these instructions will
void Mitrex limited warranty.
4.3 MODULE MOUNTING
 The mounting design must be certified by a
registered professional engineer. The mounting
design and procedures must comply with all
applicable local codes and requirements from all
relevant authorities.
 PV modules should be oriented to maximize
sunlight exposure.
 A slope less than 5” / ft is required to maintain
a fire class rating.
 The fire rating of this module is valid only
when mounted as specified in the mechanical
mounting instructions.

7
 When installed on a roof, solar modules must
be mounted over a fire-resistant roof covering
rated for the application. The fire resistance of the
solar module is class C after ANSI/UL790 Edition
2004.
 The PV module is considered to be in
compliance with UL61730 only when the module
is mounted in the manner specified by the
mounting instructions below.
4.4 MOUNTING VIA CLAMPS
 Ensure the mounting clamps are compatible
with the racking system (mounting frame) being
used.
 Clamp material should be anodized aluminum
alloy or stainless steel.
 The module may be fastened to a support by
using clamps on a minimum of four points on two
opposites sides.
 Clamps should be positioned according to
the authorized position ranges as defined in the
Appendix.
 Clamps should be positioned symmetrically.
CLAMP SPECS:
 Clamp width: ≥ 43mm (1.69in).
 Clamp height compliant with a 40mm (1.57in)
frame height.
 Clamp depth: 5 – 12mm (0.2in – 0.47in).
 Clamp thickness: ≥ 3mm (0.12in).
 Overlap in length by at least;
- 80 mm (3.15 in) when 2400 Pa < uplift load ≤
54000Pa is required.
- 40 mm (1.57 in) when uplift load ≤ 2400Pa is
required.
 Clamps are not in contact or cast shadows on
the front glass.
 Clamps do not damage, deform, or bend the
module frame.
 Clamps that satisfy the structural
requirements of the installation site.
 Long-term stable clamps that securely affix
the module to the mounting frame.

8
5. APPENDIX
SOLAR PANEL - Mxxx-A1F - Mxxx-B1F
SOLAR ROOF - Mxxx-RF041F
5.2 MECHANICAL SPECIFICATIONS
Electrical characteristics have tolerance of +/- 5% under STC conditions.
5.1 ELECTRICAL SPECIFICATIONS
5.3 TEMPERATURE SPECIFICATIONS
A more accurate correction factor can be
calculated using the equation below:
C = 1 – αx (25 – T)
C: Correction factor
T (°C): Ambient temperature
α(%/°C): Temperature coefficient of the selected
module.
Electrical sizing and design must be performed by
a competent engineer.
5.4 CLAMPING POSITION
A = (250 – 450) mm
Uplift Load ≤ 5400 Pa
Downforce Load ≤ 5400 Pa
Clamp configuration CL1 – 4 point installation, rails
perpendicular to long edge of PV module.

9
A = (250 – 450) mm
Uplift Load ≤ 5400 Pa
Downforce Load ≤ 5400 Pa
Clamp configuration CL2 – 4 point installation,
mounting rails parallel to long edge of PV module.

10
