Mitsubishi Electric 3DA-1 User manual

3D Adapter
MODEL
3DA-1
OWNER’S GUIDE
Features
Converts 3D video originating in several popular formats to checker-•
board format for display on your 3D or 3D-ready Mitsubishi television.
Processes side-by-side, top-and-bottom, and frame-packing 3D•
(e.g., Blu-ray 3D) formats.
Passes 2D images unaltered for normal display.•
Compatible with these Mitsubishi television models:
3D-Ready
Televisions
(2007 through
2010)
833 series (2007) L65-A90 (2008) L75-A91 (2010)
C8 series (2008) 737 series (2009) 638 series (2010)
735 series (2008) 837 series (2009) C10 series (2010)
736 series (2008) C9 series (2009)
835 series (2008) L75-A81 (2010)
3D Televisions
(starting in 2010)
738 series (2010) 838 series (2010)

Please check www.mitsubishi-tv.com for updates on 3D signals and safety.
2
Product: 3D Adapter
Model: 3DA-1
Responsible
Party:
Mitsubishi Digital
Electronics
America, Inc.
9351 Jeronimo Rd.
Irvine, CA
92618-1904
NOTE: This equipment has been
tested and found to comply with
the limits for a Class B digital
device, pursuant to Part 15 of
the FCC Rules. These limits are
designed to provide reasonable
protection against harmful inter-
ference in a residential installation.
This equipment generates, uses
and can radiate radio frequency
energy and, if not installed and
used in accordance with the
instructions, may cause harmful
interference to radio communi-
cations. However, there is no
guarantee that interference will not
occur in a particular installation.
If this equipment does cause
harmful interference to radio or
television reception, which can
be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
Reorient or relocate the•
receiving antenna.
Increase the separation•
between the equipment and
receiver.
Connect the equipment into•
an outlet on a circuit different
from that to which the receiver
is connected.
Consult the dealer or an expe-•
rienced radio/TV technician
for help.
FCC Information
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
8) Only use attachments/accessories specified by the manufacturer.
9)
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
Important Safety Instructions
WARNING. To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.

For assistance call 1(800) 332-2119
3
Battery Installation
Emitter
1
2
Remove the cover.1.
Insert the battery, positive side up. Be sure the retain-2.
ing clip holds the battery securely.
Reinstall the cover.3.
To remove the
battery, press
on the retain-
ing clip.
POWER
POWER 3D MODE
3D STATUS
IR Sensor
POWER Light Lit when power is on.
3D STATUS Light Lit during 3D signal processing.
POWER Button Allows manual override of auto on/off. Press to power
off the Adapter if it powers on when not needed,
3D MODE Button Allows manual selection of 3D format conversion.
Controls and Indicators
POWER
3D MODE
Adapter
Remote Control
Lithium Battery Safety
This product uses a CR2025 Li/MnO2 lithium coin battery.
WARNING: Lithium coin cell batteries pose a serious risk of injury if
ingested. Keep cells out of reach of children. If ingested immediately
contact a physician or the National Poison Center at 202-625-3333.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type (CR2025).
CAUTION: Risk of fire and burns. Do not recharge, disassemble,
heat above 100˚C (212˚F), or incinerate. Keep battery out of reach of
children.
Disposal. Dispose of used batteries promptly according to local
recycling or waste regulations.
The remote control requires one CR2025 lithium battery.

Please check www.mitsubishi-tv.com for updates on 3D signals and safety.
4
3D GLASSES
EMITTER OUT
3D GLASSES
EMITTER IN
HDMI OUT HDMI IN
5V DC 2A
3D GLASSES
EMITTER OUT
3D GLASSES
EMITTER IN
HDMI OUT HDMI IN
5V DC 2A
3D GLASSES
EMITTER OUT
3D GLASSES
EMITTER IN
HDMI OUT HDMI IN
5V DC 2A
3D GLASSES
EMITTER OUT
3D GLASSES
EMITTER IN
HDMI OUT HDMI IN
5V DC 2A
3D GLASSES
EMITTER OUT
3D GLASSES
EMITTER IN
HDMI OUT HDMI IN
5V DC 2A
3D
GLASSES
EMITTER
HDMI OUT
HDMI IN
3D GLASSES
EMITTER IN
5V DC 2A
3D GLASSES
EMITTER OUT
TV
Emitter
AC power adapter
(provided)
HDMI cable
(provided)
Adapter
HDMI
input
Source device
HDMI cable
DIN cable
(provided)
Step 1.
Step 2.
Step 5.
Step 7.
Step 3.
Step 4. Power on the TV.
Step 6. Power on the source device.
If your 3D glasses require an emitter, connect it to the Adapter.
Connecting the Adapter
Connecting a Single 3D Video Source
Power off all devices prior to connecting the Adapter.•
If the device was in use prior to adding the Adapter, use the same•
TV input if possible.
On an 833 series TV, the input must be named• Game.
Connecting Multiple 3D Video Sources
TV
A/V
receiver
HDMI
cables HDMI
cables
Adapter
Source
devices
Connect devices with checkerboard output directly to the TV.•
Enable checkerboard output from the devices if needed.
If using a newer A/V receiver, you may be able to connect devices•
to the A/V receiver as shown below. The A/V receiver must support
HDMI 1.4 and 3D video capabilities.

For assistance call 1(800) 332-2119
5
Using the Adapter
If using an emitter, position it where there 1.
will be a clear path to the 3D glasses.
Note: An emitter is not needed for 3D
glasses using DLP Link.
Power on the TV and the 3D video device.
2.
Note: The 3D video device must be powered on before the 3D Adapter
can power on.
If the 3D Adapter does not power on automatically when you power
3.
on the 3D video device, press the POWER button.
If the 4. New Input Found screen displays, assign a name to the
input. If you have an 833 series TV, name the input Game.
Start video from the 3D video device and wait a few moments for an 5.
image to appear.
Enable the TV’s 3D mode. For an 833 series TV, 3D settings are in 6.
the FX Gaming menu.
Select the Adapter’s 3D mode. Press the 7. 3D MODE button to change.
For ordinary 2D signals, keep the Adapter powered on and use•
3D Mode Normal.
For automatic detection of HDMI 1.4a 3D signals, use 3D Mode•
Normal.
For non-HDMI 1.4a 3D signals, press the•
3D MODE button
repeatedly until the picture appears correct.
Picture Troubleshooting
Blurry double image,
checkerboard format.
Turn on TV’s 3D mode.
Press
3D MODE button to
select 3D Mode
Normal .
Two images, top-and-
bottom format. Press
3D MODE button to select
3D Mode for top/bottom.
Two images, side-by-
side format. Press
3D MODE button to select
3D Mode for side-by-side.
The Mitsubishi 3D Adapter, Model 3DA-1, may be used to display
3D content only when connected to a Mitsubishi 3D Ready TV or a
Mitsubishi 3D TV. A 3D source device coupled with the Mitsubishi 3D
Adapter is required to support display of 3D games, 3D broadcasts
from terrestrial/cable/satellite and 3D Blu-ray disc content.

Please check www.mitsubishi-tv.com for updates on 3D signals and safety.
6
3D Safety Requirements
3D Glasses are NOT designed as sunglasses or safety glasses and do not provide•
protection. 3D glasses should be worn only when viewing 3D material.
Do not wear the wireless glasses in any situations that require unimpaired visual•
perception.
Children under the age of 5 should not view 3D programming.•
Under normal conditions, 3D viewing is safe for your movies or games. Some people
may experience discomfort, however. To minimize the potential for experiencing visual
problems or any adverse symptoms:
Read and follow any and all safety warnings that accompany your 3D glasses or 3D•
source devices.
Maintain a distance of no less than 2 to 2.5 times the screen height measurement•
away from the display. Viewing from too short a distance can strain your eyes.
Take regular breaks, at least 5 minutes after every hour of 3D viewing.•
If you experience any of the following symptoms, discontinue 3D viewing until the symp-
toms go away:
nausea, dizziness, or queasiness,•
headache, or eyestrain,•
blurry vision,•
double• vision that lasts longer than a few seconds,
Do not engage in any potentially hazardous activity (for example, driving a vehicle) until
your symptoms have completely gone away. If symptoms persist, discontinue use and
do not resume 3D viewing without discussing your symptoms with a physician.
Do not use the glasses where loss of balance or limiting your field of vision may be
dangerous to you.
Do not use near staircases, ledges or balconies. You may risk falling during or after
use.
Epilepsy
WARNING! IF YOU OR ANY MEMBER OF YOUR FAMILY HAS A HISTORY OF
EPILEPSY, CONSULT A PHYSICIAN BEFORE USING 3D VIDEO OR GAME PRODUCTS.
A small percentage of the population may experience epileptic seizures when viewing
certain types of TV images or video games that contain flashing patterns of light.
The following people should consult a physician before viewing 3D Games or Video:
Anyone with a history of epilepsy, or who has a family member with a history of•
epilepsy
Anyone who has ever experienced epileptic seizures or sensory disturbances trig-•
gered by flashing light effects.
WARNING! SOME LIGHT PATTERNS MAY INDUCE SEIZURES IN PERSONS WITH
NO PRIOR HISTORY OF EPILEPSY. DISCONTINUE 3D VIEWING IF YOU EXPERI-
ENCE ANY OF THE FOLLOWING SYMPTOMS:
Involuntary movements, eye or muscle twitching•
Muscle cramps•
Nausea, dizziness, or queasiness•
Convulsions•
Disorientation, confusion, or loss of awareness of your surroundings•
Do not engage in any potentially hazardous activity (for example, driving a vehicle) until
your symptoms have completely gone away.
Do not resume 3D viewing without discussing the symptoms with your physician.

For assistance call 1(800) 332-2119
7
Mitsubishi Model 3DA-1
3D Adapter Limited Warranty
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. (“MDEA”) warrants as follows
to the original purchaser of this 3D adapter from an authorized MITSUBISHI Audio/
Video Dealer, should the adapter prove defective by reasons arising from improper
workmanship and/or material:
a. Length of Warranty. The adapter and all included parts, except for “consumable
parts” such as batteries, are warranted for a period of one (1) year from the date of
the original purchase at retail. We will repair or replace, at our option, any defective
adapter or part without charge. Adapters and parts used for replacement may be
replaced with those of like kind and quality and may be new or remanufactured.
Adapter and parts used for replacement are warranted for the remainder of the
original warranty period.
b. Send In Service. MDEA provides send in service only. The owner is responsible
for packaging the adapter or parts for repair safely and the shipping costs to the
MDEA designated service location. MDEA will repair or replace and return the
items without charge for return shipping.
c. Notice. To obtain warranty service, you must notify Mitsubishi Digital Electronics
America, Inc. of any defect within the applicable warranty time period.
BEFORE REQUESTING SERVICE, please review the instruction booklet to insure
proper installation and correct customer control adjustment. If the problem persists
please arrange for warranty service.
1. TO OBTAIN WARRANTY SERVICE:
a. Contact Mitsubishi Digital Electronics America, Inc. (MDEA) by calling 800-332-
2119. The Consumer Relations Representative at this phone number will provide
you with the details AND, when necessary, authorizations for the return of the
adapter for repair. DO NOT send the adapter for repair without the proper authori-
zations.
b. Proof of purchase date from an authorized MITSUBISHI dealer is required when
requesting warranty service. Present your sales receipt or other document which
establishes proof and date of purchase upon request by MDEA. THE RETURN OF
THE OWNER REGISTRATION CARD IS NOT A CONDITION OF COVERAGE UNDER
THIS LIMITED WARRANTY. However, please return the Owner Registration Card so
that we can contact you should a question of safety arise which could affect you.
2. THIS LIMITED WARRANTY DOES NOT COVER:
a. Consumable parts such as batteries, 3D Glasses and IR Emitters sold sepa-
rately (refer to the instructions for the glasses and IR Emitter for warranty details),
cosmetic damage or any other damage where such damage is caused by unau-
thorized modification, alteration, repairs to or service of the product by anyone
other than an authorized MITSUBISHI service center; physical abuse to or misuse
of the product (including any failure to carry out any maintenance as described
in the Owner’s Guide or any product damaged by excessive physical or electri-
cal stress); any products that have had a serial number or any part thereof altered,
defaced or removed; product use in any manner contrary to the Owner’s Guide;
freight damage; or any damage caused by acts of God or other factors beyond the
reasonable control of MDEA, such as power surge damage caused by electrical
system or lightning. This limited warranty also excludes service where no defect in

3DA-1
© 2010 Mitsubishi Digital Electronics America, Inc. 853B710A40
the product covered under this warranty is found, service related to unsatisfactory
audio or visual reception or signal unless caused by a defect in the product that
is covered under this limited warranty, all costs, expenses or any other damages
arising from product installation, or set-ups, any adjustments of user controls
(including contrast, brightness, color, tint, fine tuning, sharpness to the connected
TV), other adjustment necessary to prepare the unit for display or use, connection
with any external audio receiver, antenna, cable or satellite systems, or service of
products purchased or serviced outside the U.S.A. Please consult the operating
instructions contained in the Owner’s Guide furnished with the product for informa-
tion regarding user controls.
3. ANY EXPRESS WARRANTY NOT PROVIDED HEREIN, AND ANY REMEDY
WHICH, BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION OR OPERA-
TION OF LAW, IS HEREBY EXCLUDED AND DISCLAIMED. THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND OF FITNESS FOR ANY PARTICULAR
PURPOSE ARE EXPRESSLY LIMITED TO A TERM OF ONE YEAR.
4. UNDER NO CIRCUMSTANCES SHALL MDEA BE LIABLE TO PURCHASER OR
ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, WHETHER ARISING OUT OF BREACH OF WARRANTY, BREACH OF
CONTRACT, OR OTHERWISE.
5. Some states do not allow limitations on how long an implied warranty lasts, or
the exclusion or limitation of incidental, special, or consequential damages, so the
above limitations or exclusions may not apply to you.
6. This limited warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
9351 Jeronimo Road
Irvine, CA 92618-1904
For questions:
Visit our website at www.mitsubishi-tv.com.-
E-mail us at MDEAser[email protected].-
Call Consumer Relations at- 800-332-2119 for operational or
connection assistance.
To order replacement or additional remote controls or other
accessories, visit our website at www.mitsuparts.com or call
800-553-7278.
