Mitsubishi Electric PAC-USWHS003-TH-1 Service manual

Contents
1. About the Wireless Temperature and Humidity Sensor...........................................1
2. Safety Instructions...................................................................................................2
3. Notes.......................................................................................................................2
4. What’s in the Box....................................................................................................3
5. Installing the Wireless Temperature and Humidity Sensor......................................3
6. About the Battery.....................................................................................................4
7. Specications..........................................................................................................5
Memo..........................................................................................................................6
Back Cover..................................................................................................................8
© 2017 Mitsubishi Electric US, Inc. 1
MANUFACTURED FOR:
MITSUBISHI ELECTRIC US, INC.
PAC-USWHS003-TH-1
INSTALLATION/INSTRUCTION MANUAL
Before using the device, carefully read this installation/instruction manual to ensure
proper operation.
Keep this manual for future reference.
FOR INSTALLER
1. About the Wireless Temperature and Humidity Sensor
The Wireless Temperature and Humidity Sensor senses temperature and humidity
in your living space and communicating with your wireless interface, allows you to
manage the comfort in a particular zone. Installation and conguration of this device
is done through the kumo cloudTM app.
Wireless Temperature And Humidity Sensor

© 2017 Mitsubishi Electric US, Inc. 2
2. Safety Instructions
• This installation manual contains important safety information.
• Read all Safety Instructions before using this wireless sensor.
• Be sure to comply with the instructions.
• Mitsubishi Electric components or other designated components must be used
for installation and proper operation.
• This device is meant for indoor use only.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference
that may cause undesired operation
3. Notes
• Use of the this device implies acceptance of our terms and conditions located at
kumocloud.com/terms.
• Visit kumocloud.com/resources for additional information about setting up and
controlling this device from your web browser or mobile device.
• This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
• This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
• This equipment complies with radio frequency exposure limits set forth by the
FCC for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 cm, 7.8 inches between the device and
the user or bystanders.
• Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

© 2017 Mitsubishi Electric US, Inc. 3
4. What’s in the Box
• Wireless Temperature and Humidity Sensor
• Coin battery CR2477 - installed
• Double-sided adhesive disc
• Installation Manual
5. Installing the Wireless Temperature and Humidity Sensor
We recommend commissioning the Wireless Temperature and Humidity Sensor
to your wireless interface before afxing it to the wall.
Please visit kumocloud.com/resources for the kumo cloudTM installation manual for
details regarding commissioning this wireless sensor and return to this guide for
installing in your desired location.
• Remove the wireless sensor and double-sided adhesive strip from packaging.
• To activate your wireless sensor, pull the insulator tab completely out and it will
power on the sensor.
• Peel away one side of the adhesive strip and apply it to the backside of the wireless
sensor, pressing rmly.
- The backside can be identied by the side with the FCC ID printed on it.
- The small hole on the front, should be facing the room. This hole should
remain unimpeded for sensing purposes.
• Find a location to install your wireless sensor. The device should be placed in an
area allowing it to monitor and sense the room. (Recommended placement is
within
10 ft of wireless interface or indoor unit, unobstructed)
- The wireless sensor will work best when placed in an open area of the room
allowing it to sense the greatest area without obstruction.
- Do not place the wireless sensor in direct sunlight, near vents or window
openings, or in enclosed areas such as drawers, cabinets, behind furniture
or curtains, drafts, radiators, replaces, or on exterior walls.
• Peel away the other side of the adhesive strip and press rmly to the wall or
surface to mount. Allow to remain undisturbed at least 24 hours to ensure it is
bonded securely to surface. Bond should be 100% after 72 hours from application.
Do not move once adhered.
- Ensure surface is clean and dry before adhering. Substrates are best
prepared by cleaning with 50:50 mixture of isopropyl alcohol and water.
- Rigid surfaces may require 2 or 3 times more pressure to ensure adhesion.
- Ideal application temperature range is 70°F to 100°F (21°C to 38°C).

© 2017 Mitsubishi Electric US, Inc. 4
6. About the Battery
• The wireless sensor uses CR2477 coin battery.
• Battery can be replaced by popping off the front cover of the device, removing
the expired battery and replace it with the new. Refer to kumo cloudTM Owner’s
Manual online for specic details.
To replace battery:
- Pop off front cover.
- Gently lift electronic board from case and ip over to reveal battery compartment.
Be careful not to excessively pull the wires attaching the board to the case.
- Nudge expired battery out by pushing through holes until it slides free of the
compartment.
- Replace new battery with positive (+) side facing up and negative side facing the
back of the electronic board. You will hear a faint chime/ringing sound as the
battery is inserted. This will indicate it has been installed correctly.
- Replace the board inside the case with electrical components facing open part of
case.
- Replace cover, being sure to align holes and pressing rmly until it snaps back
into place.
Note: Small hole must be over sensor or device will not correctly sense
temperature and humidity.
For images and more specic details, refer to online kumo cloudTM Installation
manual at kumocloud.com/resources.
Homeowners/Users should refer to the Wireless Sensor section of the kumo cloudTM
Owners manual online at kumocloud.com/resources.

© 2017 Mitsubishi Electric US, Inc. 5
7. Specications
Battery 3V CR2477 coin
Operation Voltage 2.0 – 3.6V DC
Operation Frequency 2400 – 2483.5MHz
Transmission Distance (typical) 33 feet (unobstructed)
Temperature Operating Range 0° – 40°C, ± 3°C
32° - 104°F ± 5.4°F
Humidity Operating Range 0 – 80% RH, ± 5% non-condensing
Size 40 x 40 x 16.5 mm
Weight 40g
FCC ID 2AB4P-IB004N PLUS-SHT
. Memo

© 2017 Mitsubishi Electric US, Inc. 6
Memo

© 2017 Mitsubishi Electric US, Inc. 7
Memo

© 2017 Mitsubishi Electric US, Inc. 8
MEUS DOC# CE-16003-L001, August 2017
Please be sure to put the installer's contact address/telephone number on
this manual before handing it to the customer.
This device is designed and intended for use in the residential,
commercial and light-industrial environment.
www.mitsubishielectric-usa.com
Toll Free: 800-433-4822
Manufactured for MITSUBISHI ELECTRIC US, INC.
kumo cloud is a trademark of Mitsubishi Electric US, Inc.
