QUICK GUIDE

2
Contents
A few tips to get you started!
This quick guide has been prepared
to help you enjoy safe and
comfortable driving.
This quick guide is a short version of
the owner’s manual. For more
details, please refer to the owner’s
manual.
This quick guide covers a range of
specifications and manufacturer’s
options, so some of the descriptions
may not apply to your ASX model.
Congratulations on purchasing your new !
Here are a few important things you need to know:
1. Your vehicle takes 91 unleaded fuel, available at any service station.
2. Your first service is at 1,500km or within one month. But don’t worry if you forget, we’ll be in
contact to remind you!
3. Only have your ASX serviced by a recognised Mitsubishi Motors dealer, for a list of dealers visit
mmnz.co.nz/find-a-dealer/
Wherever your road takes you, we’ll be
right there with you. Its part of our
commitment to ensuring you enjoy
complete driving pleasure. Nothing
demonstrates this commitment better
than our unique Diamond Advantage
package.
Mitsubishi’s Diamond Advantage combines
our 10-year or 160,000km (whichever
occurs first) Powertrain Warranty*, a
5-year or 130,000km (whichever occurs
first) new vehicle warranty* and 5-years
roadside assist, to cover you in the unlikely
event of a breakdown*.
*Please refer to your warranty booklet for
full terms and conditions.
2. A few tips to get you started
3. Starting the Vehicle
4. Around the Centre Console
5. Around the Steering Wheel
6. Around the Steering Wheel
7. Smartphone Link Display (SDA) Screen’s Overview
8. SDA Connections and Quick Tips
9. Advanced Safety Systems

3
Starting the Vehicle
For Push-button start vehicles:
The keyless operation system allows you to lock and unlock the doors
and tailgate, start the engine and change the operation mode simply
by carrying the keyless operation key with you.
Step 1 Make sure the parking brake is applied
Step 2 Press and hold the brake pedal down firmly
Step 3 Make sure the selector lever is in the “P” (PARK) position
Step 4 Press the start/stop engine switch
Step 5 Make certain that all warning lamps are functioning properly
For vehicles with ignition key
Step 1 Make sure the parking brake is applied
Step 2 Press and hold the brake pedal down firmly
Step 3 Make sure the selector lever is in the “P” (PARK) position
Step 4 Rotate the key to the “START” position
Step 5 Make certain that all warning lamps are functioning properly
1. Tachometer
2. Multi-information Display
3. Speedometer
4. Meter illumination control
ACC Mode:
ACC mode allows electrical devices such as the audio and accessory sockets
to operate. The indicator lamp on the engine switch will illuminate orange.
You can put the vehicle in ACC mode from “OFF” by pushing the Start/Stop
engine button once without your foot on the brake pedal.
To put the vehicle in ACC mode from “ON”, press the ignition switch while
the gear shift lever is in Neutral.
Each time the multi-information meter switch (info button)
is operated, a sound is emitted and the multi-information
display changes between information such as warnings,
tripmeter, service reminder, average and momentary fuel
consumption, driving range, and average speed.
It is also possible to change elements such as the language
and units used on the multi-information display by operating
the multi-information meter switch.
Multi-information Meter Switch
INFO
Instrument Cluster

4
Around the Centre Console
2
1
01 Selector Lever - P, R, N, D, Ds, L
P (Park) Locks the transmission to prevent the
vehicle from moving
R (Reverse) : The vehicle moves in reverse.
N (Neutral) : No drive is transmitted to the wheels,
which are not locked either.
D (Drive) : The vehicle moves forward.
Ds (Downshift and
Sporty Driving) :
Use when engine braking is needed,
or for high-powered sport drive. *
L (Low) : This position is for driving up very
steep hills and engine braking at low
speeds when driving down steep hills.
02 Parking Brake
Pull the lever to lock the wheels when you are parking your
vehicle.
Air Conditioning (AC)
A - Temperature control dial
B - Air selection switch (press)
C - Blower speed selection dial
D - Air conditioning switch (press)
E - Mode selection dial
F - Rear window demister switch (press)
* Only available on models without shift paddles
• Select position you chose is illuminated on the
multi-information display.
AB C D E F
Heated Seats*
The front heated seats can be operated when the vehicle is ON.
There are 3 settings for the heated seats (HI, OFF and LOW)
HI Heater high (for quick heating)
OFF Heater off
LOW Heater low (to keep the seat warm)
*if so equipped

5
Around the Steering Wheel
Audio Controls
Handsfree Phone Controls
Cruise Control *
* To activate cruise control press the cruise
control on/off switch (lower left) once.
Adjust the desired speed by pushing
the toggle switch up (increase) or down
(decrease). To deactivate cruise control,
press the cancel switch (top left) or the
on/off switch once again. Using the foot
brake will also stop cruise control.
Quick Tip: You can adjust the sensitivity of the windscreen
wipers when it is in “AUTO” by rotating the “AUTO” ring.
You can use the shift paddles to manually adjust the gear ratio of the vehicle
+ (Shift Up) - The transmission shifts up one gear by each operation
- (Shift Down) - The transmission shifts down one gear by each operation
To return to D (Drive) pull the + (Shift Up) shift paddle for 2 seconds
Shift Paddles*
SHIFT DOWN SHIFT UP
Windscreen Wipers
Rotate the stalk to change the windscreen wiper function
MIST Misting function
The wipers will operate once.
OFF • Off
AUTO
Auto-wiper control
Rain sensor
The wipers will automatically operate
depending on the degree of wetness
on the windscreen.
LO Slow
Hi Fast
*if so equipped *if so equipped

6
Around the Steering Wheel
Parking Sensors Button (SONAR)*
The parking sensors can be turned on or off by
pressing the "SONAR" button (B) once. When the
indicator lamp on the SONAR button is on, the
system is activated. If an obstacle is within the
vicinity of the parking sensors, a warning will be
issued on the multi-information display and a
warning buzzer will sound.
Headlamps
Rotate the stalk to turn on the lamps
OFF All lamps off
AUTO
When the ignition switch or the operating mode is ON,
headlamps, position, tail, licence plate, and instrument
panel lamps turn on and off automatically in accordance
with outside light level. All lamps turn off automatically
when the ignition switch is turned to “LOCK” position or
the operation mode is put in OFF.
Position, tail, licence plate and instrument panel lamps
on
Headlamps and other lamps go on
Auto High Beam (AHB) - The AHB switches between the
headlamp beams (high/low) when the sensor senses
light from a vehicle in front, an oncoming vehicle or
street lamps. For the AHB to operate, the headlamp
position must be switched to the or “AUTO” when
the engine is running. *
The angle of the headlamp beam varies
depending upon the load carried by the
vehicle. You can adjust this angle by using
the headlamp leveling switch.
Other Buttons:
(located to the right hand side of the steering wheel)
A - Blind Spot Warning*
B - SONAR Parking Sensors*
C - Forward Collision Mitigation*
D - Lane Departure Warning * A B
C
D
*if so equipped

7
Smartphone Link Display Audio (SDA) Screen Overview
Multimedia
Phone
Settings
Info
Apps/Android Auto/Apple CarPlay
For further information on the various SDA screens,
refer to your SDA Owners Manual
1.
2.
3.
4.
5.
Changes the settings such as sound control, Bluetooth
connections and volume
Apple CarPlay/Android Auto can be used by connecting a
compatible phone via a USB cable
Connecting your mobile phone with Bluetooth lets you use
the hands-free phone system
Allows playback using radio or various other media Allows you to check version information or the various
“help” screens
Home Screen
5.
1.
2.
3.
4.
*if so equipped

8
SDA Connections and Quick Tips
How to connect a compatible smartphone
via Bluetooth?
1. Display the “settings” menu on the SDA screen
2. Tap “Bluetooth”
3. Tap “Device Management”
4. Select the search icon and follow on screen
instructions
How to select a Bluetooth device once
connected?
1. Display the “settings” menu on the SDA screen
2. Tap “Bluetooth”
3. Tap “Device Management”
4. Tap the name of the device you want to connect
to by either selecting the phone icon
(for hands-free phone access) or the media icon
(for Bluetooth audio access)
Apple CarPlay/Android Auto
Plug in your compatible Apple or Android phone
via USB and follow the on screen instructions
selecting either:
1. Enable this time – this will enable Apple
CarPlay/Android Auto for one time then will
ask again the next time
2. Always enable – this will enable Apple CarPlay/
Android Auto each time your phone is
connected
How to make a call when phone is connected
via Bluetooth
1. Press the “phone” key
2. Select either “call history”, “contacts” or
“telephone keypad”
3. Press on the contact you wish to call or enter a
phone number then select “dial”
Quick Tip: In the “Bluetooth” screen, you can connect one phone to Bluetooth music and one phone to Handsfree
phone by selecting the media/phone icon on the SDA screen for the two different Bluetooth connections.

9
Apple CarPlay/Android Auto
Advanced Safety Systems
Advanced Safety
System
Description How to adjust/ turn
system on/off
Forward Collision
Mitigation (FCM)*
When your vehicle is approaching a vehicle
or a pedestrian straight-ahead in your path
and the FCM judges that there is the risk of
a collision, the system will give audible and
visual warnings, increases the brake fluid,
and also provides braking force assistance
when you depress the brake pedal to avoid
frontal collision.
When the risk of collision increases more, the
system causes the brakes to work moderately
to encourage you to apply brakes. If the
system judges that a potential collision is
imminent, it initiates emergency braking to
mitigate collision-caused damages or to avoid
possible collision.
Press and hold the FCM
button to the right of the
streering wheel to turn
the system ON/OFF.
The FCM system can also
be adjusted by pressing
the FCM button once
to cycle through the
sensitivity of the system.
Lane Departure
Warning (LDW)*
When your vehicle is likely to drift from its
lane, an audible alarm sounds and a visual
alarm is displayed on the information screen
of the multi-information display.
To turn off LDW, press the
LDW button once - The
LDW icon on the multi-
information display will
be removed. To turn the
system back on, press the
button again.
Blind Spot Warning
(with Lane Change
Assist)*
The Blind Spot Warning (BSW) is a driving aid
system that alerts the driver when another
vehicle which may not be visible through the
outside rear-view mirror is travelling in the
next land behind your vehicle.
When a vehicle in the next lane is travelling at
same speed or faster in the detection areas,
the BSW lamp in the corresponding outside
rear-view mirror will illuminate. If the turn
signal lever is operated to the side where the
BSW lamp is illuminated, the BSW lamp will
blink and the system will beep 3 times to alert
the driver.
To turn off BSW, press the
BSW button once - The
BSW icon on the multi-
information display will
be removed. To turn the
system back on, press the
button again.
Rear Cross Traffic
Alert*
The Rear Cross Traffic Alert (RCTA) is an aid
system for backing up. When the RCTA system
detects vehicles approaching from the sides
while your vehicle is reversing, the Blind Spot
Warning lamps in the outside rearview mirrors
on both sides will blink and a buzzer will
sound to alert the driver.
The RCTA system will
be turned on/off when
the Blind Spot Warning
(with Lane Change Assist)
system is turned on/off.
(*if so equipped)

www.mmnz.co.nz
02/2023
