Mitsubishi MOTORS Lancer Evolution 2009 User manual

LANCER
EVOLUTION
OWNER’S MANUAL
LANCER EVOLUTION - ENGLISH - OGEE10E1
LANCER EVOLUTION - ENGLISH - OGEE10E1

Foreword
E09200103196
Thank you for selecting a LANCER Evolution.
This owner’s manual will add to your understanding and full enjoyment of
the many fine features of this vehicle.
It contains information prepared to acquaint you with the proper way to oper-
ate and maintain your vehicle for the utmost in driving pleasure.
MITSUBISHI MOTORS Europe B.V. reserves the right to make changes in
design and specifications and/or to make additions to or improvements in
this product without obligation to install them on products previously manu-
factured.
It is an absolute requirement for the driver to strictly observe all laws and reg-
ulations concerning vehicles.
This owner’s manual has been written in compliance with such laws and reg-
ulations, but some of the contents may become contradictory with later amend-
ment of the laws and regulations.
Please leave this owner’s manual in this vehicle at time of resale. The next
owner will appreciate having access to the information contained in this own-
er’s manual.
Repairs to your vehicle:
Vehicles in the warranty period:
All warranty repairs must be carried out by a MITSUBISHI MOTORS Au-
thorized Service Point.
Vehicles outside the warranty period:
Where the vehicle is repaired is at the discretion of the owner.
Throughout this owner’s manual the words WARNING and CAUTION ap-
pear.
These serve as reminders to be especially careful. Failure to follow instruc-
tions could result in personal injury or damage to your vehicle.
WARNING
indicates a strong possibility of severe personal injury or death if in-
structions are not followed.
CAUTION
means hazards or unsafe practices that could cause minor personal in-
jury or damage to your vehicle.
You will see another important symbol:
NOTE: gives helpful information.
*: indicates optional equipment.
It may differ according to the sales classification; refer to the
sales catalogue.
Abbreviations used in this owner’s manual:
LHD: Left-Hand Drive
RHD: Right-Hand Drive
M/T: Manual Transmission
Information for station service
E09300101630
Fuel
Fuel tank capacity 55 litres
Fuel requirements Unleaded petrol octane number (EN228) 98 RON or higher
Refer to the “General information” section for the fuel selection.
Engine oil Refer to the “Maintenance” section for the selection of engine oil.
Tyre inflation pressure Refer to the “Maintenance” section for the tyre inflation pressure.
© 2009 Mitsubishi Motors Corporation
10
OGEE10E1
09.001476

Table of contents
Overview
General information
Locking and unlocking 1
Seat and seat belts 2
Instruments and controls 3
Starting and driving 4
For pleasant driving 5
For emergencies 6
Vehicle care 7
Maintenance 8
Specifications 9

Instruments and Controls (Driver’s area)
E00100104737
LHD
123
4
5
6
7
8
9
10
11
12
13
14
15
1716
1. Multi-information meter switch p. 3-05
2. Instruments p. 3-02
3. Shift paddles* p. 4-20, 4-21
4. Wiper and washer switch p. 3-46
5. Cruise control switches* p. 4-37
6. Ignition switch p. 1-13, 1-18, 4-09
7. Supplemental restraint system - airbag (for driver’s seat) p. 2-18
Horn switch p. 3-50
8. Steering wheel height adjustment lever p. 4-06
9. Supplemental restraint system - driver’s knee airbag p. 2-22
10. Hands-free Bluetooth® cellular phone interface system with voice
recognition switches* p. 5-47
11. Bonnet release lever p. 8-03
12. Fuses p. 8-17
13. ASC OFF switch p. 4-33
14. Adaptive Front Lighting System (AFS) OFF Switch p. 3-43
15. Combination headlamps and dipper switch p. 3-38
Turn-signal lever p. 3-42
Front fog lamp switch p. 3-45
Rear fog lamp switch p. 3-45
Headlamp washer switch p. 3-49
16. AWC switch* p. 4-28
17. Steering wheel audio remote control switches* p. 5-40
Overview

1
RHD
2
3
4
5
6
7
8
9
10
11
12
1516
13
14
1. Shift paddles* p. 4-20, 4-21
2. Instruments p. 3-02
3. Multi-information meter switch p. 3-05
4. Wiper and washer switch p. 3-46
5. Cruise control switches* p. 4-37
6. ASC OFF switch p. 4-33
7. Trunk lid opener switch p. 1-29
8. Ignition switch p. 1-13, 1-18, 4-09
9. Steering wheel height adjustment lever p. 4-06
10. Bonnet release lever p. 8-03
11. Supplemental restraint system - driver’s knee airbag p. 2-22
12. Hands-free Bluetooth® cellular phone interface system with voice
recognition switches* p. 5-47
13. Supplemental restraint system - airbag (for driver’s seat) p. 2-18
Horn switch p. 3-50
14. Combination headlamps and dipper switch p. 3-38
Turn-signal lever p. 3-42
Front fog lamp switch p. 3-45
Rear fog lamp switch p. 3-45
Headlamp washer switch p. 3-49
15. Steering wheel audio remote control switches* p. 5-40
16. AWC switch* p. 4-28
Overview

Instruments and Controls (Instrument panel)
E00100104740
LHD
1
2
3
4
5
7
6
8
9
10
11
12
13
14
1. Ventilators p. 5-02
2. Gearshift lever p. 4-15, 4-15
3. Supplemental restraint system - airbag (for front passenger’s
seat) p. 2-18
4. Front passenger’s airbag ON-OFF switch p. 2-19, 2-21
5. Glove box p. 5-83
6. Twin Clutch SST control mode switch* p. 4-18
7. AWC switch* p. 4-28
8. Moveable ashtray* p. 5-79
9. Heated seat switch* p. 2-04
10. Floor console box p. 5-84
11. Cup holder p. 5-85
12. Parking brake lever p. 4-04
13. Fuel tank filler door release lever p. 02
14. Trunk lid release lever p. 1-29
Overview

RHD
1 2 3
4
5
6
7
8
9
10
11
12
13
14
15
1. Supplemental restraint system - airbag (for front passenger’s
seat) p. 2-18
2. Gearshift lever p. 4-15, 4-15
3. Ventilators p. 5-02
4. Fuel tank filler door release lever p. 02
5. AWC switch* p. 4-28
6. Cup holder p. 5-85
7. Moveable ashtray* p. 5-79
8. Floor console box p. 5-84
9. Heated seat switch* p. 2-04
10. Twin Clutch SST control mode switch* p. 4-18
11. Adaptive Front lighting System (AFS) OFF switch p. 3-43
12. Parking brake lever p. 4-04
13. Fuses p. 8-17
14. Glove box p. 5-83
15. Front passenger’s airbag ON-OFF switch p. 2-19, 2-21
Overview

Centre panel
E00100600226
1
2
3
4
5
6
7
8
9
10
1. Audio* p. 5-09, 5-24
Digital clock* p. 5-45
Mitsubishi Multi-Communication System*
Refer to the separate “Mitsubishi Multi-Communication System
owner’s manual”
2. Hazard warning flasher switch p. 3-45
3. Front passenger seat belt warning lamp p. 2-08
4. Rear window demister switch (LHD vehicles) p. 3-50
5. Air conditioning p. 5-04
6. Auxiliary Audio connector (RCA)* p. 5-39
Auxiliary Video connector (RCA)* p. 5-39
7. Cigarette lighter* p. 5-80
Accessory socket* p. 5-81
8. Front console box p. 5-84
9. Rear window demister switch (RHD vehicles) p. 3-50
10. Front passenger’s airbag OFF indication lamp p. 2-18, 2-21
Overview

Interior
E00100203441
LHD
12
3
4
5
6
7
8
910
11
12 13
14
1. Adjustable seat belt anchor (for front seats) p. 2-08
Seat belts p. 2-06
2. Inside rear-view mirror p. 4-06
3. Sun visors p. 5-79
Vanity mirror p. 5-79
Card holder p. 5-79
4. Bottle holder (for front seats) p. 5-86
5. Front seats p. 2-03
6. Supplemental restraint system - side airbag (for front
seats) p. 2-25
7. Head restraints p. 2-05
8. Electric window control switches p. 1-36
9. Lock switch p. 1-37
10. Electric remote-controlled outside rear-view mirrors
switch p. 4-07
11. Central door lock switch p. 1-26
12. Front room & map lamp p. 5-81, 8-23, 8-28
13. Sunroof switch* p. 1-38
14. Hands-free Bluetooth® cellular phone interface system with voice
recognition* p. 5-47
Overview

RHD
12
3
4
5
6
7
89
10
11
12
13
1. Inside rear-view mirror p. 4-06
2. Adjustable seat belt anchor (for front seats) p. 2-08
Seat belts p. 2-06
3. Head restraints p. 2-05
4. Supplemental restraint system - side airbag (for front
seats) p. 2-25
5. Front seats p. 2-03
6. Bottle holder (for front seats) p. 5-86
7. Sun visors p. 5-79
Vanity mirror p. 5-79
Card holder p. 5-79
8. Front room & map lamp p. 5-81, 8-23, 8-28
9. Sunroof switch* p. 1-38
10. Hands-free Bluetooth® cellular phone interface system with voice
recognition* p. 5-47
11. Electric remote-controlled outside rear-view mirrors
switch p. 4-07
12. Electric window control switches p. 1-36
13. Lock switch p. 1-37
Overview

Interior
E00100203454
LHD
1
2
3
4
5
6
7
8
9
1. Assist grip p. 5-86
2. Coat hook p. 5-86
3. Supplemental restraint system - curtain airbag p. 2-25
4. Rear room lamp* p. 5-82, 8-23, 8-29
5. Rear seat p. 2-05
6. Cup holder p. 5-85
7. Armrest p. 2-05
8. AWC control fluid tank p. 8-06, 9-11
9. Tether anchorages for child restraint system p. 2-16
Overview

RHD
1
2
3
4
5
6
7
8
9
1. Rear room lamp* p. 5-82, 8-23, 8-29
2. Supplemental restraint system - curtain airbag p. 2-25
3. Coat hook p. 5-86
4. Assist grip p. 5-86
5. AWC control fluid tank p. 8-06, 9-11
6. Tether anchorages for child restraint system p. 2-16
7. Armrest p. 2-05
8. Cup holder p. 5-85
9. Rear seat p. 2-05
Overview

Trunk area (Except for vehicle with spare wheel)
E00100300467
1 2 3
4
5
6
1. Trunk room lamp p. 8-23, 8-29
2. Tyre repair kit p. 6-05
3. Battery p. 6-02, 8-08
4. Tools p. 6-05
5. Jack p. 6-06
6. Front washer fluid reservoir p. 8-07
Overview

Trunk area (Vehicle with full size spare wheel)
E00100300470
1
2
3
4
5
6
1. Trunk room lamp p. 8-23, 8-29
2. Battery p. 6-02, 8-08
3. Tools p. 6-05
4. Jack p. 6-06
5. Spare wheel p. 6-12, 6-13
6. Front washer fluid reservoir p. 8-07
Overview

Trunk area (Vehicle with compact spare wheel)
E00100300483
1
2
3
4
5
6
1. Trunk room lamp p. 8-23, 8-29
2. Battery p. 6-02, 8-08
3. Tools p. 6-05
4. Jack p. 6-06
5. Spare wheel p. 6-12, 6-13
6. Front washer fluid reservoir p. 8-07
Overview

Outside (Front)
E00100504076
1
2
3
4
5
6
7
8
9
1. Bonnet p. 8-03
2. Windscreen wipers and washer p. 3-46, 8-15
3. Sunroof* p. 1-38
4. Keyless entry system* p. 1-04
Keyless operation system* p. 1-08
Locking and unlocking p. 1-21
5. Fuel tank filler p. 02
6. Outside rear-view mirrors p. 4-07
7. Side turn-signal lamps p. 3-42, 8-23
8. Front fog lamps p. 3-45, 8-23, 8-26
9. Headlamps, high/low beam p. 3-38, 8-23, 8-23
Front turn-signal lamps p. 3-34, 8-23, 8-25
Position lamps p. 3-38, 8-23, 8-25
Bending lamps (Adaptive Front lighting System (AFS)) p. 3-38,
8-23, 8-23
Overview

Outside (Rear)
E00100504089
1
23
4
5
6
7
8
9
10
1. Trunk lid p. 1-29
2. High-mounted stop lamp p. 8-23
3. Antenna p. 5-44
4. Tyre inflation pressures p. 8-11
Changing tyres p. 6-12
Tyre rotation p. 8-12
Tyre chains p. 8-13
5. Rear turn-signal lamps p. 3-42, 8-23, 8-27
6. Tail and stop lamps p. 3-38, 8-23, 8-27
7. Tail lamps p. 3-38, 8-23, 8-27
8. Reversing lamps (Passenger’s side only) p. 8-23, 8-27
Rear fog lamp (Driver’s side only) p. 3-34, 8-23, 8-27
9. Licence plate lamps p. 3-38, 8-23, 8-28
10. Trunk lid OPEN switch p. 1-29
Overview

Fuel selection...................................................................................02
Filling the fuel tank..........................................................................02
Installation of accessories................................................................04
Modification/alterations to the electrical or fuel systems................04
Genuine parts...................................................................................05
Used engine oils safety instructions and disposal infor-
mation..........................................................................................05
Disposal information for used batteries...........................................05
General information

Fuel selection
E00200102213
Recommended fuel
Unleaded petrol octane
number (EN228)
98 RON or higher
Your engine is designed to provide satisfactory per-
formance by using unleaded petrol octane number
98 RON or higher. In order to maintain engine per-
formance and exhaust system durability, use unlea-
ded petrol octane number 98 RON or higher.
NOTE
lYour vehicles have the knock control system
so that you can use unleaded petrol 95 RON
as an emergent measure in case unleaded pet-
rol 98 RON or higher is not available on jour-
ney, etc. In such a case, you don’t need to ad-
just the engine specially.
In case of using unleaded petrol 95 RON, the
engine performance level is reduced.
lRepeatedly driving short distance at low
speeds can cause deposits to form in the fuel
system and engine, resulting in poor starting
and poor acceleration. If these problems oc-
cur, you are advised to add a detergent addi-
tive to the gasoline when you refuel the vehi-
cle. The additive will remove the deposits,
thereby returning the engine to a normal con-
dition. Be sure to use a genuine
MITSUBISHI FUEL SYSTEM CLEANER.
Using an unsuitable additive could make the
engine malfunction. For details, please con-
tact your MITSUBISHI MOTORS Author-
ized Service Point.
lPoor quality petrol can cause problems such
as hard starting, stalling, engine noise and hes-
itation. If you experience these problems, try
another brand and/or grade of petrol.
If the check engine warning lamp flashes,
have the system checked as soon as possible
at a MITSUBISHI MOTORS Authorized
Service Point.
Filling the fuel tank
E00200202100
WARNING
lWhen handling fuel, comply with the safe-
ty regulations displayed by garages and
filling stations.
lBefore removing the fuel cap, be sure to
get rid of your body’s static electricity by
touching a metal part of either the car or
the fuel pump. Any static electricity on
your body could create a spark that ig-
nites fuel vapour.
lPerform the whole refueling process
(opening the fuel tank filler door, remov-
ing the fuel cap, etc.) by yourself. Do not
let any other person come near the fuel
tank filler. If you allowed a person to
help you and that person was carrying
static electricity, fuel vapour could be ig-
nited.
lDo not move away from the fuel tank fill-
er until refueling is finished. If you
moved away and did something else (for
example, cleaning your windscreen) part-
way through the refueling process, you
could pick up a fresh charge of static elec-
tricity.
lIf the tank cap must be replaced, use only
a MITSUBISHI MOTORS original part.
Fuel tank capacity
55 litres
Refueling
1. Before filling with fuel, stop the engine.
General information
02
