Air-Conditioners
PKA-RP·HAL
INSTALLATION MANUAL
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing
the air-conditioner unit.
INSTALLATIONSHANDBUCH
Aus Sicherheitsgründen und zur richtigen Anwendung vor Installation der Klimaanlage die vorliegende
Bedienungsanleitung und das Installationshandbuch gründlich durchlesen.
MANUEL D’INSTALLATION
Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil
extérieur pour une utilisation sûre et correct.
INSTALLATIONSMANUAL
Läs bruksanvisningen och utomhusenhetens installationshandbok noga innan luftkonditioneringen installeras så
att den används på ett säkert och korrekt sätt.
INSTALLATIEHANDLEIDING
Lees deze handleiding en de installatiehandleiding van het buitenapparaat zorgvuldig door voordat u met het
installeren van de airconditioner begint.
MANUALE DI INSTALLAZIONE
Per un uso sicuro e corretto, prima di installare il condizionatore d’aria leggere attentamente il presente
manuale ed il manuale d’installazione dell’unità esterna.
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de
aire acondicionado.
MANUAL DE INSTALAÇÃO
Para uma utilização segura e correcta, leia atentamente este manual e o manual de instalação da unidade
exterior antes de instalar o aparelho de ar condicionado.
INSTALLATIONSMANUAL
Læs af sikkerhedshensyn denne manual samt manualen til installation af udendørsenheden grundigt, før du
installerer klimaanlægget.
EΓXEIPIΔIO OΔHΓIΩN EΓKATAΣTAΣHΣ
Για σωστή και ασφαλή χρήση, διαβάστε προσεκτικά αυτό το εγχειρίδιο, καθώς και το εγχειρίδιο εγκατάστασης
της εξωτερικής μονάδας, πριν από την εγκατάσταση της μονάδας κλιματιστικού.
MONTAJ ELKİTABI
Emniyetli ve doğru kullanım için, klima cihazını monte etmeden önce bu kılavuzu ve dış ünite montaj kılavuzunu
tamamıyla okuyun.
РУКОВОДСТВО ПО УСТАНОВКЕ
Для обеспечения безопасной и надлежащей эксплуатации внимательно прочтите данное руководство и
руководство по установке наружного прибора перед установкой кондиционера.
FOR INSTALLER
FÜR INSTALLATEURE
POUR L’INSTALLATEUR
FÖR INSTALLATÖREN
VOOR DE INSTALLATEUR
PER L’INSTALLATORE
PARA EL INSTALADOR
PARA O INSTALADOR
TIL INSTALLATØREN
ΓΙΑ ΑΥΤΟΝ ΠΟΥ ΚΑΝΕΙ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ
MONTÖR İÇİN
ДЛЯ УСТАНОВИТЕЛЯ
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Português
Dansk
Svenska
Türkçe
Русский
RG79D479H02_cover.indd 1 2012/10/09 (火) 午前 11:37:24
2
5. Drainage piping work.........................................................................................7
6. Electrical work...................................................................................................8
7. Test run............................................................................................................13
8. Easy maintenance function (Option)...............................................................15
►Beforeinstallingtheunit,makesureyoureadallthe“Safety
precautions”.
►Pleasereporttoyoursupplyauthorityorobtaintheirconsentbefore
connectingthisequipmenttothepowersupplysystem.
Warning:
Describesprecautionsthatmustbeobservedtopreventdangerofinjuryor
deathtotheuser.
Caution:
Describesprecautionsthatmustbeobservedtopreventdamagetotheunit.
Contents
Warning:
• Askadealeroranauthorizedtechniciantoinstalltheunit.
• Forinstallationwork,followtheinstructionsintheInstallationManualanduse
toolsandpipecomponentsspecificallymadeforusewithrefrigerantspecified
intheoutdoorunitinstallationmanual.
• Theunitmustbeinstalledaccordingtotheinstructionsinordertominimize
the risk of damage from earthquakes, typhoons, or strong winds. An
incorrectlyinstalledunitmayfalldownandcausedamageorinjuries.
• The unit must be securely installed on a structure that can sustain its
weight.
• Iftheairconditionerisinstalledinasmallroom,measuresmustbetakento
preventtherefrigerantconcentrationintheroomfromexceedingthesafety
limitintheeventofrefrigerantleakage.Shouldtherefrigerantleakandcause
theconcentrationlimittobeexceeded,hazardsduetolackofoxygeninthe
roommayresult.
• Ventilatetheroomifrefrigerantleaksduringoperation.Ifrefrigerantcomes
intocontactwithaflame,poisonousgaseswillbereleased.
• Allelectricworkmustbeperformedbyaqualifiedtechnicianaccordingto
localregulationsandtheinstructionsgiveninthismanual.
• Useonlyspecifiedcablesforwiring.Thewiringconnectionsmustbemade
securelywithnotensionappliedontheterminalconnections.Also,never
splicethecablesforwiring(unlessotherwiseindicatedinthisdocument).
Failuretoobservetheseinstructionsmayresultinoverheatingorafire.
• Theterminalblockcoverpaneloftheunitmustbefirmlyattached.
• UseonlyaccessoriesauthorizedbyMitsubishiElectricandaskadealeror
anauthorizedtechniciantoinstallthem.
• Theusershouldneverattempttorepairtheunitortransferittoanother
location.
• Afterinstallationhasbeencompleted,checkforrefrigerantleaks.Ifrefrigerant
leaksintotheroomandcomesintocontactwiththeflameofaheateror
portablecookingrange,poisonousgaseswillbereleased.
• Wheninstallingorrelocating,orservicingtheairconditioner,useonlythe
specifiedrefrigerant(R410A)tochargetherefrigerantlines.Donotmixit
withanyotherrefrigerantanddonotallowairtoremaininthelines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhigh
pressureintherefrigerantline,andmayresultinanexplosionandother
hazards.
Theuseofanyrefrigerantotherthanthatspecifiedforthesystemwillcause
mechanicalfailureorsystemmalfunctionorunitbreakdown.Intheworst
case,thiscouldleadtoaseriousimpedimenttosecuringproductsafety.
1.1. Beforeinstallation(Environment)
Caution:
• Donotusetheunitinanunusualenvironment.Iftheairconditioneris
installedinareasexposedtosteam,volatileoil(includingmachineoil),or
sulfuricgas,areasexposedtohighsaltcontentsuchastheseaside,the
performancecanbesignificantlyreducedandtheinternalpartscanbe
damaged.
• Donotinstalltheunitwherecombustiblegasesmayleak,beproduced,
flow,oraccumulate.Ifcombustiblegasaccumulatesaroundtheunit,fire
orexplosionmayresult.
• Donotkeepfood,plants,cagedpets,artwork,orprecisioninstrumentsin
thedirectairflowoftheindoorunitortooclosetotheunitastheseitems
canbedamagedbytemperaturechangesordrippingwater.
• Whentheroomhumidityexceeds80%orwhenthedrainpipeisclogged,
watermaydripfromtheindoorunit.Donotinstalltheindoorunitwhere
suchdrippingcancausedamage.
• Wheninstallingtheunitinahospitalorcommunicationsoffice,be
preparedfornoiseandelectronicinterference.Inverters,homeappliances,
high-frequencymedicalequipment,andradiocommunicationsequipment
cancausetheairconditionertomalfunctionorbreakdown.Theair
conditionermayalsoaffectmedicalequipment,disturbingmedicalcare,
andcommunicationsequipment,harmingthescreendisplayquality.
1. Safetyprecautions
After installation work has been completed, explain the “Safety precautions,” use,
and maintenance of the unit to the customer according to the information in the
Operation Manual and perform the test run to ensure normal operation. Both the
Installation Manual and Operation Manual must be given to the user for keeping.
These manuals must be passed on to subsequent users.
: Indicates a part which must be grounded.
Warning:
Carefullyreadthelabelsaffixedtothemainunit.
1.4. Beforestartingthetestrun
Caution:
• Turnonthemainpowerswitchmorethan12hoursbeforestartingoperation.
Startingoperationjustafterturningonthepowerswitchcanseverelydamage
theinternalparts.
• Beforestartingoperation,checkthatallpanels,guardsandotherprotective
partsarecorrectlyinstalled.Rotating,hot,orhighvoltagepartscancause
injuries.
• Donotoperatetheairconditionerwithouttheairfiltersetinplace.Iftheair
filterisnotinstalled,dustmayaccumulateandbreakdownmayresult.
• Donottouchanyswitchwithwethands.Electricshockmayresult.
• Donottouchtherefrigerantpipeswithbarehandsduringoperation.
• Afterstoppingoperation,besuretowaitatleastfiveminutesbeforeturning
off the main power switch. Otherwise, water leakage orbreakdown may
result.
1.3. Beforeelectricwork
Caution:
• Besuretoinstallmoldedcasecircuitbrakers.Ifnotinstalled,electricshock
mayresult.
• Forthepowerlines,usestandardcablesofsufficientcapacity.Otherwise,a
shortcircuit,overheating,orfiremayresult.
• Wheninstallingthepowerlines,donotapplytensiontothecables.
• Besuretogroundtheunit.Iftheunitisnotproperlygrounded,electricshock
mayresult.
• Use circuit breakers (ground fault interrupter, isolating switch (+B fuse),
andmoldedcasecircuitbreaker)withthespecifiedcapacity.Ifthecircuit
breakercapacityislargerthanthespecifiedcapacity,breakdownorfiremay
result.
1.2. Beforeinstallationorrelocation
Caution:
• Be extremely careful when transporting the units. Two or more persons
areneededtohandletheunitasitweighs20kgormore.Donotgraspthe
packagingbands.Wearprotectiveglovesasyoucaninjureyourhandson
thefinsorotherparts.
• Besuretosafelydisposeofthepackagingmaterials.Packagingmaterials,
suchasnailsandothermetalorwoodenpartsmaycausestabsorother
injuries.
• Thermalinsulationoftherefrigerantpipeisnecessarytopreventcondensation.
Iftherefrigerantpipeisnotproperlyinsulated,condensationwillbeformed.
• Placethermalinsulationonthepipestopreventcondensation.Ifthe
drainpipeisinstalledincorrectly,waterleakageanddamagetotheceiling,
floor,furniture,orotherpossessionsmayresult.
• Donotcleantheairconditionerunitwithwater.Electricshockmayresult.
• Tightenallflarenutstospecificationusingatorquewrench.Iftightened
toomuch,theflarenutcanbreakafteranextendedperiod.
1. Safety precautions.............................................................................................2
2. Installation location............................................................................................3
3. Installing the indoor unit ....................................................................................3
4. Installing the refrigerant piping..........................................................................6
Note:
Thephrase“Wiredremotecontroller”inthisinstallationmanualreferstothePAR-21MAA.
Ifyouneedanyinformationfortheotherremotecontroller,pleaserefertoeithertheinstallationmanualorinitialsettingmanualwhichare
includedintheseboxes.
RG79D479H02_en.indd 2 2012/10/09 (火) 午前 11:37:48
3
2. Installationlocation
3. Installingtheindoorunit
3.1. Checktheindoorunitaccessories(Fig.3-1)
The indoor unit should be supplied with the following accessories.
PART NUMBER
ACCESSORY QUANTITY LOCATION OF
SETTING
35, 50
1Mount board 1
Fix at the back of the
unit
2Tapping screw 4 ×35 12
3Felt tape 3
4Band 3
5Wireless remote controller 1
6Remocon holder 1
7Alkali batteries (size AAA) 2
8Tapping screw 3.5 ×16 2
9Block of cushion 1
3.2. Installingthewallmountingfixture(Fig.3-2)
3.2.1. Settingthewallmountingfixtureandpipingpositions
►Usingthewallmountingfixture,determinetheunit’sinstallationposition
andthelocationsofthepipingholestobedrilled.
Warning:
Beforedrillingaholeinthewall,youmustconsultthebuildingcontractor.
■PKA-RP·HAL
AMount board 1
BIndoor unit
CBottom left rear pipe hole (ø65)
DBottom right rear pipe hole (ø65)
EKnockout hole for left rear hole (70 × 310)
FBolt hole (4-ø9 hole)
GCenter measurement hole (ø2.5 hole)
HTapping hole (77-ø5.1 hole)
IHole centre
JAlign the scale with the line.
KInsert scale.
3.2.2. Drillingthepipinghole(Fig.3-3)
►Useacoredrilltomakeaholeof75-80mmdiameterinthewallinthe
pipingdirection,atthepositionshowninthediagramtotheleft.
►Theholeshouldinclinesothattheoutsideopeningislowerthanthe
insideopening.
►Insertasleeve(witha75mmdiameterandpurchasedlocally)throughthe
hole.
ASleeve
BHole
C(Indoors)
DWall
E(Outdoors)
Note:
Thepurposeofthehole’sinclinationistopromotedrainflow.
Fig.2-1
2.1. Outlinedimensions(Indoorunit)(Fig.2-1)
Select a proper position allowing the following clearances for installation and
maintenance.
■PKA-RP·HAL (mm)
ABCDE
Min. 100.5 Min. 22.4 Min. 48 Min. 250 Min. 220
F
Air outlet: Do not place an obstacle within 1500 mm of the air outlet.
GFloor surface
HFurnishing
IWhen the projection dimension of a curtain rail or the like from the wall exceeds 60 mm,
extra distance should be taken because the fan air current may create a short cycle.
J1800 mm or greater from the floor surface (for high location mounting)
K108 mm or greater with left or rear left piping and optional drain pump installation
L550 mm or greater with optional drain pump installation
MMinimum 7 mm: 265 mm or greater with optional drain pump installation
Fig.3-1
■PKA-RP·HAL
Fig.3-2
(mm)
■PKA-RP·HAL
Fig.3-3
A
C
DE
B
898
295
*
249
M
F
G
L
BA
K
C
D
H
J
I
E
(mm)
123
456
789
58
2
232.5 231.5
372.3
356.3
327.5
291.5
265
225
200
125
70
15
0
15
70
125
200
225
238
265
291.5
327.5
356.3
372.3
278.3
238
213
174
0
115
140
167
180.3
193.5
20
41
66
91
116
166
0
16
28.5
53.5
78.5
103.5
128.5
153.5
178.5
241
253.5
100 m
RG79D479H02_en.indd 3 2012/10/09 (火) 午前 11:37:50
4
3. Installingtheindoorunit
■PKA-RP·HAL
Fig.3-6
B
A
C
E
D
3.2.3. Installingthewallmountingfixture
►Sincetheindoorunitweighsnear13kg,selectionofthemounting
locationrequiresthoroughconsideration.Ifthewalldoesnotseemtobe
strongenough,reinforceitwithboardsorbeamsbeforeinstallation.
►Themountingfixturemustbesecuredatbothendsandatthecentre,if
possible.Neverfixitatasinglespotorinanynonsymetricalway.
(Ifpossible,securethefixtureatallthepositionsmarkedwithabold
arrow.)
Warning:
Ifpossible,securethefixtureatallpositionsindicatedwithaboldarrow.
Caution:
• Theunitbodymustbemountedhorizontally.
• Fastenattheholesmarkedwith▲asshownbythearrows.
■PKA-RP·HAL(Fig.3-4)
AMin. 90 mm (617.6 mm or greater with optional drain pump installation)
BMin. 200 mm
CMin. 72 mm (142.5 mm or greater with left, rear left, or lower left piping, and optional drain
pump installation)
DFixing screws (4 × 35) 2
ELevel
FFasten a thread to the hole.
G
Place the level against the horizontal reference line of the mount board and mount so that it is
level. Hang a weight from the thread and align with EPK of the mount board to permit leveling.
HWeight
IMount board 1
3.3. Whenembeddingpipesintothewall(Fig.3-5)
• The pipes are on the bottom left.
• When the cooling pipe, drain pipes internal/external connection lines etc are to
be embedded into the wall in advance, the extruding pipes etc, may have to be
bent and have their length modified to suit the unit.
• Use marking on the mount board as a reference when adjusting the length of the
embedded cooling pipe.
• During construction, give the length of the extruding pipes etc some leeway.
AMount board 1
BReference marking for flare connection
CThrough hole
DOn-site piping
3.4. Preparingtheindoorunit
* Check beforehand because the preparatory work will differ depending on the
exiting direction of the piping.
* When bending the piping, bend gradually while maintaining the base of the
piping exiting portion. (Abrupt bending will cause misshaping of the piping.)
Extractionandprocessingofthepipingandwiring(Fig.3-6)
1. Connection of indoor/outdoor wiring ➡See page. 8.
2. Wrap the felt tape 3in the range of the refrigerant piping and drain hose which
will be housed within the piping space of the indoor unit.
• Wrap the felt tape 3securely from the base for each of the refrigerant piping
and the drain hose.
• Overlap the felt tape 3at one-half of the tape width.
• Fasten the end portion of the wrapping with vinyl tape.
ALiquid pipe
BGas pipe
CIndoor/outdoor connection cable
DDrain hose
EFelt tape 3
3. Be careful that the drain hose is not raised, and that contact is not made with the
indoor unit box body.
Do not pull the drain hose forcefully because it might come out.
Rear,rightandlowerpiping(Fig.3-7)
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
Arrange the drain hose at the underside of the piping and wrap it with felt
tape 3.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
ACut off for right piping.
BCut off for lower piping.
Fig.3-4
A
B
C
D
I
G
F
H
E
Fig.3-5
B
A
C
D
Fig.3-7
B
A
1)2)
RG79D479H02_en.indd 4 2012/10/09 (火) 午前 11:37:51
5
3. Installingtheindoorunit
Leftandleftrearpiping(Fig.3-8)
4. Drain hose replacement ➡See 7. Drainage piping work
Be sure to replace the drain hose and the drain cap for the left and rear left
piping. Dripping may occur if you forget to install or fail to replace these parts.
CDrain cap
1) Be careful that the drain hose is not raised, and that contact is not made with
the indoor unit box body.
2) Securely wrap the felt tape 3starting from the base. (Overlap the felt tape at
one-half of the tape width.)
3) Fasten the end portion of the felt tape 3with vinyl tape.
DCut off for left piping.
Fig.3-8
C
D
1)
3)
2)
Fig.3-9
Fig.3-10
Fig.3-11
B
A
C
D
A
C
B
C
A
B
■PKA-RP·HAL
3.5. Mountingtheindoorunit
1. Affix the mount board 1to the wall.
2. Hang the indoor unit on the hook positioned on the upper part of the mount
board.
Rear,rightandlowerpiping(Fig.3-9)
3. While inserting the refrigerant piping and drain hose into the wall penetration
hole (penetration sleeve), hang the top of the indoor unit to the mount board 1.
4. Move the indoor unit to the left and right, and verify that the indoor unit is hung
securely.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
(Fig. 3-10)
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
AMount board 1
BIndoor unit
CHook
Dsquare hole
Leftandleftrearpiping(Fig.3-11)
3. While inserting the drain hose into the wall penetration hole (penetration sleeve),
hang the top of the indoor unit to the mount board 1.
Giving consideration to the piping storage, move the unit all the way to the left
side, then cut part of the packaging carton and wrap into a cylindrical form as
illustrated in the diagram. Hook this to the rear surface rib as a spacer, and raise
the indoor unit.
4. Connect the refrigerant piping with the site-side refrigerant piping.
5. Fasten by pushing the bottom part of the indoor unit onto the mount board 1.
* Check that the knobs on the bottom of the indoor unit are securely hooked into
the mount board 1.
6. After installation, be sure to check that the indoor unit is installed level.
AIndoor unit
BPackaging cushion
CBlock of cushion 9
RG79D479H02_en.indd 5 2012/10/09 (火) 午前 11:37:52
6
4. Installingtherefrigerantpiping
A Flare cutting dimensions
Copper pipe O.D.
(mm) Flare dimensions
øA dimensions (mm)
ø6.35 8.7 - 9.1
ø12.7 16.2 - 16.6
øA
Fig.4-1
Fig.4-2
()
()
4.1. Connectingpipes(Fig.4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or
more, thickness of 12 mm or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam
insulation materials (specific gravity of 0.03, thickness of 9 mm or more).
• Apply thin layer of refrigerant oil to pipe and joint seating surface before
tightening flare nut.
• Use two wrenches to tighten piping connections.
• Use refrigerant piping insulation provided to insulate indoor unit connections.
Insulate carefully.
BFlare nut tightening torque
CDo not apply refrigerating machine oil to the screw portions.
(This will make the flare nuts more apt to loosen.)
DBe certain to use the flare nuts that are attached to the main unit.
(Use of commercially-available products may result in cracking.)
Copper pipe O.D.
(mm) Flare nut O.D.
(mm) Tightening torque
(N·m)
ø6.35 17 14 - 18
ø12.7 28 49 - 61
■PKA-RP·HAL
Fig.4-3
B
A
4.2. Indoorunit
Refrigerant and Drainage Piping Sizes
Item Model PKA-RP35, RP50HAL
Refrigerant piping Liquid ODø6.35 (1/4")
Gas ODø12.7 (1/2")
Drainage piping ODø16
4.3. Positioningrefrigerantanddrainpiping(Fig.4-2)
■PKA-RP·HAL
AGas pipe * Indicates the condition with accessories mounted.
BLiquid pipe
CDrain hose (Effective length: 400)
DLeft-side piping knockout hole
ERight-side piping knockout hole
FLower piping knockout hole
GMount board 1
4.4. Refrigerantpiping(Fig.4-3)
Indoorunit
1. Remove the flare nut and cap of the indoor unit.
2. Make a flare for the liquid pipe and gas pipe and apply refrigerating machine oil
(available from your local supplier) to the flare sheet surface.
3. Quickly connect the on site cooling pipes to the unit.
4. Wrap the pipe cover that is attached to the gas pipe and make sure that the
connection join is not visible.
5. Wrap the pipe cover of the unit’s liquid pipe and make sure that it covers the
insulation material of the on site liquid pipe.
6. The portion where the insulation material is joined is sealed by taping.
ASite-side refrigerant piping
BUnit side refrigerant piping
Fig.4-2
Warning:
Wheninstallingtheunit,securelyconnecttherefrigerantpipesbeforestart-
ingthecompressor.
90°±0.5°
45±2°
R0.4 - R0.8
RG79D479H02_en.indd 6 2012/10/09 (火) 午前 11:37:52
7
Fig.4-4
B
A
D
C
4. Installingtherefrigerantpiping
4.4.1. Storinginthepipingspaceoftheunit(Fig.4-4)
1. Wrap the supplied felt tape in the range of the refrigerant piping which will be
housed within the piping space of the unit to prevent dripping.
2. Overlap the felt tape at one-half of the tape width.
3. Fasten the end portion of the wrapping with vinyl tape, etc.
AGas pipe
BLiquid pipe
CIndoor/outdoor connection cable
DFelt tape 3
5. Drainagepipingwork
5.1. Drainagepipingwork(Fig.5-1)
• Drain pipes should have an inclination of 1/100 or more.
• For extension of the drain pipe, use a soft hose (inner dia. 15 mm) available on
the market or hard vinyl chloride pipe (VP-16/O.D. ø22 PVC TUBE). Make sure
that there is no water leakage from the connections.
• Do not put the drain piping directly in a drainage ditch where sulphuric gas may
be generated.
• When piping has been completed, check that water flows from the end of the
drain pipe.
Caution:
ThedrainpipeshouldbeinstalledaccordingtothisInstallationManualto
ensurecorrectdrainage.Thermalinsulationofthedrainpipesisnecessary
topreventcondensation.Ifthedrainpipesarenotproperlyinstalledand
insulated,condensationmaydripontheceiling,floororotherpossessions.
AInclined downwards
BMust be lower than outlet point
CWater leakage
DTrapped drainage
EAir
FWavy
GThe end of drain pipe is under water.
HDrainage ditch
I5 cm or less between the end of drain pipe and the ground.
JDrain hose
KSoft PVC hose (Inside diameter 15 mm)
or
Hard PVC pipe (VP-16)
* Bond with PVC type adhesive
Preparingleftandleftrearpiping(Fig.5-2)
1Remove the drain cap.
• Remove the drain cap by holding the bit that sticks out at the end of the pipe and
pulling.
ADrain cap
2Remove the drain hose.
• Remove the drain hose by holding on to the base of the hose a(shown by
arrow) and pulling towards yourself b.
3Insert the drain cap.
• Insert a screwdriver etc into the hole at the end of the pipe and be sure to push
to the base of the drain cap.
4Insert the drain hose.
• Push the drain hose until it is at the base of the drain box connection outlet.
• Please make sure the drain hose hook is fastened properly over the extruding
drain box connection outlet.
BHooks
◆Storinginthepipingspaceoftheindoorunit(Fig.5-3)
* When the drain hose will be routed indoors, be sure to wrap it with commercially
available insulation.
* Gather the drain hose and the refrigerant piping together and wrap them with the
supplied felt tape 3.
* Overlap the felt tape 3at one-half of the tape width.
* Fasten the end portion of the wrapping with vinyl tape, etc.
AGas pipe
BLiquid pipe
CDrain hose
DIndoor/outdoor connection wiring
EFelt tape 3
◆Checkofdrainage(Fig.5-4)
1. Open the front grille and remove the filter.
2. Facing the fins of the heat exchanger, slowly fill with water.
3. After the drainage check, attach the filter and close the grille.
Fig.5-4
Fig.5-3
A
B
D
E
C
Fig.5-1
A
B
C
E
D
C
F
C
G
H
I
J
K
Fig.5-2
A
A
1
3
a
b
A
B
2
4
RG79D479H02_en.indd 7 2012/10/09 (火) 午前 11:37:54
8
6. Electricalwork
6.1. Indoorunit
■PKA-RP·HAL(Fig.6-1)
Connection can be made without removing the front panel.
1. Open the front grille, remove the screw (1 piece), and remove the electrical
parts cover.
* Electrical work can be conducted more effectively with the panel removed. When
attaching the panel, check that the hooks Kat five locations on the air outlet side
are connected securely.
2. Securely connect each wire to the terminal board.
* In consideration of servicing, provide extra length for each of the wires.
* Take care when using strand wires, because beards may cause the wiring to
short out.
3. Install the parts that were removed back to their original condition.
4. Fasten each of the wires with the clamp under the electrical parts box.
AElectrical box cover
BFixing screw
CClamp
D Wired remote control terminal board: (option) 1 and 2, do not have polarity
E Indoor/outdoor connection terminal board: S1, S2, and S3, have polarity
FLead
GTerminal screw
H Ground wire: Connect the ground wire in the direction illustrated in the diagram.
IWired remote control cord
JIndoor/outdoor connection cord
KHook
LGround wire connection portion
Warning:
Neversplicethepowercableortheindoor-outdoorconnectioncable,
otherwiseitmayresultinasmoke,afireorcommunicationfailure.
■PKA-RP·HAL
Fig.6-1
6.1.1. Indoorunitpowersuppliedfromoutdoorunit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
S1
S2
L
N
1
2
S1
S2
S3
S3
A B C
D
E
F
G
S1
S2
L
N
1
2
S1
S2
S3
S1
S2
S3
S3
S1
S2
S3
S1
S2
S3
A B C
D
E
FHHH
G G G G
Simultaneous twin/triple/four system
* Affix a labelA that is included with the manuals near each wiring diagram for the indoor and outdoor units.
AOutdoor unit power supply
BEarth leakage breaker
CWiring circuit breaker or isolating switch
DOutdoor unit
EIndoor/outdoor unit connecting cords
FWired remote controller (option)
GIndoor unit
* Affix a labelA that is included with the manuals near each wiring diagram for the indoor and outdoor units.
AOutdoor unit power supply
BEarth leakage breaker
CWiring circuit breaker or isolating switch
DOutdoor unit
EIndoor/outdoor unit connecting cords
FWired remote controller (option)
GIndoor unit
HIndoor unit earth
1:1 System
S1 S2 S3
J
L
H
55 mm
12 mm
55 mm
12 mm
RG79D479H02_en.indd 8 2012/10/09 (火) 午前 11:37:55
9
Indoor unit model PKA-RP·HAL
Indoor unit power supply –
Indoor unit input capacity *1
Main power switch (Breaker) –
Wiring
Wire No. × size
(mm2)
Indoor unit power supply –
Indoor unit earth 1 × Min. 1.5
Indoor unit-Outdoor unit *2 3 × 1.5 (Polar)
Indoor unit-Outdoor unit earth *2 1 × Min. 1.5
Wired remote controller (option) Indoor unit *3 2 × Min. 0.3
Circuit
rating
Indoor unit L-N *4 –
Indoor unit-Outdoor unit S1-S2 *4 AC 230 V
Indoor unit-Outdoor unit S2-S3 *4 DC 24 V
Wired remote controller (option) Indoor unit *4 DC 12 V
*1. A breaker with at least 3 mm contact separation in each pole shall be provided. Use non-fuse breaker (NF) or earth leakage breaker (NV).
*2. <For 25-140 outdoor unit application>
Max. 45 m
If 2.5 mm2used, Max. 50 m
If 2.5 mm2used and S3 separated, Max. 80 m
For PUHZ-RP100/125/140 YHA application, use shield wires. The shield part must be grounded with the indoor unit OR the outdoor unit, NOT with both.
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2used, Max. 30 m
If 4 mm2used and S3 separated, Max. 50 m
If 6 mm2used and S3 separated, Max. 80 m
*3. Max. 500 m
*4. The figures are NOT always against the ground.
S3 terminal has DC 24 V against S2 terminal. However between S3 and S1, these terminals are not electrically insulataed by the transformer or other device.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2. PowersupplycordsandIndoorunit/Outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedflexiblecord.(Design245IEC
57)
3. Installanearthlongerthanothercords.
6. Electricalwork
6.1.2. Separateindoorunit/outdoorunitpowersupplies(ForPUHZapplicationonly)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
* The optional wiring replacement kit is required.
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
ACB
D
J
E
BC
F
G
H
S1
S2
L
N
1
2
L
N
S1
S2
S3
L
N
S1
S2
S3
L
N
S1
S2
S3
L
N
S1
S2
S3
S3
A B C
D
E
J B C
F
H
G G G G
H H H
KKK
* Affix a label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
AOutdoor unit power supply
BEarth leakage breaker
CWiring circuit breaker or isolating switch
DOutdoor unit
EIndoor/outdoor unit connecting cords
FWired remote controller (option)
GIndoor unit
HOption
JIndoor unit power supply
* The optional wiring replacement kits are required.
Simultaneous twin/triple/four system
* Affix a label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
AOutdoor unit power supply
BEarth leakage breaker
CWiring circuit breaker or isolating switch
DOutdoor unit
EIndoor/outdoor unit connecting cords
FWired remote controller (option)
GIndoor unit
HOption
JIndoor unit power supply
KIndoor unit earth
1:1 System
RG79D479H02_en.indd 9 2012/10/09 (火) 午前 11:37:55
10
S1
S2
S3
L
N
BLUE
BLUE
YELLOW
YELLOW
CN01
CN01
BLACK
CN01
BLACK
S1
S2
S3
L
N
YELLOW
BLUE BLUE
YELLOW
CN01
Indoor unit model PKA-RP·HAL
Indoor unit power supply ~/N (single), 50 Hz, 230 V
Indoor unit input capacity *1
Main power switch (Breaker) 16 A
Wiring
Wire No. × size
(mm2)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit earth 1 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Wired remote controller (option) Indoor unit *3 2 × Min. 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 AC 230 V
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 DC 24 V
Wired remote controller (option) Indoor unit *4 DC 12 V
*1. A breaker with at least 3 mm contact separation in each pole shall be provided. Use non-fuse breaker (NF) or earth leakage breaker (NV).
*2. Max. 120 m
For PUHZ-RP100/125/140 YHA application, use shield wires. The shield part must be grounded with the indoor unit OR the outdoor unit, NOT with both.
*3. Max. 500 m
*4. The figures are NOT always against the ground.
Notes: 1. Wiringsizemustcomplywiththeapplicablelocalandnationalcode.
2. Powersupplycordsandindoorunit/outdoorunitconnectingcordsshallnotbelighterthanpolychloroprenesheathedflexiblecord.(Design245IEC
57)
3. Installanearthlongerthanothercables.
If the indoor and outdoor units have separate power supplies, refer to the table
at the below. If the optional wiring replacement kit is used, change the indoor unit
electrical box wiring refering to the figure in the right and the DIP switch settings of
the outdoor unit control board. Indoor unit specifications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector
connection change Required
Label affixed near each wiring diagram for
the indoor and outdoor units Required
Outdoor unit DIP switch settings (when
using separate indoor unit/outdoor unit
power supplies only)
ON
OFF 1 2 (SW8)
3
* There are three types of labels (labels A, B, and C).Affix the appropriate labels to
the units according to the wiring method.
Connectors (connections when shipped
from the factory are for indoor unit power
supplied from outdoor unit)
Indoor unit power supplied from outdoor unit
(when shipped from factory)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
figure.
Connectors
Indoor unit
control board
Separate indoor unit/outdoor unit power
supplies
Indoor unit
control board
6. Electricalwork
6.2. Remotecontroller
6.2.1. Forwiredremotecontroller(option)
1)Installingprocedures
(1) Select an installing position for the remote controller. (Fig. 6-2)
The temperature sensors are located on both remote controller and indoor unit.
►Procurethefollowingpartslocally:
Two piece switch box
Thin copper conduit tube
Lock nuts and bushings
ARemote controller profile
BRequired clearances surrounding the remote controller
CInstallation pitch
(2) Seal the service entrance for the remote controller cord with putty to prevent
possible invasion of dew drops, water, cockroaches or worms. (Fig. 6-3)
AFor installation in the switch box:
BFor direct installation on the wall select one of the following:
• Prepare a hole through the wall to pass the remote controller cord (in order to run
the remote controller cord from the back), then seal the hole with putty.
• Run the remote controller cord through the cut-out upper case, then seal the cut-
out notch with putty similarly as above.
B-1. Toleadtheremotecontrollercordfromthebackofthecontroller:
B-2. Toruntheremotecontrollercordthroughtheupperportion:
(3) For direct installation on the wall
CWall
DConduit
ELock nut
FBushing
GSwitch box
HRemote controller cord
ISeal with putty
JWood screw
B-1. B-2.
Fig.6-3
Fig.6-2
30 46 30
30
120
83.5
RG79D479H02_en.indd 10 2012/10/09 (火) 午前 11:37:55
11
6. Electricalwork
2)Connectingprocedures(Fig.6-4)
1Connect the remote controller cord to the terminal block.
ATo TB5 on the indoor unit
BTB6 (No polarity)
3)Tworemotecontrollerssetting
If two remote controllers are connected, set one to “Main” and the other to “Sub”.
For setting procedures, refer to “Function selection of remote controller” in the
operation manual for the indoor unit.
6.2.2. Forwirelessremotecontroller
1)Installationarea
• Area in which the remote controller is not exposed to direct sunshine.
• Area in which there is no nearby heating source.
• Area in which the remote controller is not exposed to cold (or hot) winds.
• Area in which the remote controller can be operated easily.
• Area in which the remote controller is beyond the reach of children.
2)Installationmethod(Fig.6-5)
1Attach the remote controller holder to the desired location using two tapping
screws.
2Place the lower end of the controller into the holder.
ARemote controller
BWall
CDisplay panel
DReceiver
• The signal can travel up to approximately 7 meters (in a straight line) within 45
degrees to both right and left of the center line of the receiver.
3)Setting(Fig.6-6)
1Insert batteries.
2Press the SET button with something sharp at the end.
MODEL SELECT
blinks and Model No. is lighted.
3Press the temp button to set the Model No.
4Press the SET button with something sharp at the end.
MODEL SELECT
and Model No. are lighted for three seconds, then turned off.
Indoor Outdoor AModel No.
PKA (35, 50) PUH, PUHZ 002
PU 034
4)Assigningaremotecontrollertoeachunit(Fig.6-7)
Each unit can be operated only by the assigned remote controller.
Make sure each pair of an indoor unit PC board and a remote controller is
assigned to the same pair No.
5)Wirelessremotecontrollerpairnumbersettingoperation
1Press the SET button with something sharp at the end.
Start this operation from the status of remote controller display turned off.
MODEL SELECT
blinks and Model No. is lighted.
2Press the
min
button twice continuously.
Pair No. “0” blinks.
3Press the temp button to set the pair number you want to set.
4Press the SET button with something sharp at the end.
Set pair number is lighted for three seconds then turned off.
APair No. of wireless remote controller Indoor PC board
0 Factory setting
1 Cut J41
2 Cut J42
3–9 Cut J41, J42
6.3. Functionsettings
6.3.1 Functionsettingontheunit(Selectingtheunitfunctions)
1)Forwiredremotecontroller(Fig.6-8)
Changing the power voltage setting
• Be sure to change the power voltage setting depending on the voltage used.
1Go to the function setting mode.
Switch OFF the remote controller.
Press the Aand Bbuttons simultaneously and hold them for at least 2
seconds. FUNCTION will start to flash.
2Use the Cbutton to set the refrigerant address (III) to 00.
3Press Dand [--] will start to flash in the unit number (IV) display.
4Use the Cbutton to set the unit number (IV) to 00.
5Press the EMODE button to designate the refrigerant address/unit number. [--]
will flash in the mode number (I) display momentarily.
6Press the Fbuttons to set the mode number (I) to 04.
7Press the Gbutton and the current set setting number (II) will flash.
Use the Fbutton to switch the setting number in response to the power supply
voltage to be used.
Power supply voltage
240 V : setting number = 1
220 V, 230 V : setting number = 2
8Press the MODE button Eand mode and the setting number (I) and (II) will
change to being on constantly and the contents of the setting can be confirmed.
9Press the FILTER Aand TEST RUN Bbuttons simultaneously for at least two
seconds. The function selection screen will disappear momentarily and the air
conditioner OFF display will appear.
A
AB TB6
B
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
2,4
3
A
Fig.6-5
Fig.6-6
Fig.6-4
B
1
C
A
2
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
A
B
DC
G
E
F
II
III IV
I
IV
I
II
I
Fig.6-7
Fig.6-8
Mode number
Setting number
Refrigerant address
Unit number
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
1,4
3
A
2
RG79D479H02_en.indd 11 2012/10/09 (火) 午前 11:37:57
12
6. Electricalwork
2)Forwirelessremotecontroller(Fig.6-9)
Changing the power voltage setting
• Be sure to change the power voltage setting depending on the voltage used.
1Go to the function select mode
Press the
CHECK
button Ftwice continuously.
(Start this operation from the status of remote controller display turned off.)
CHECK
is lighted and “00” blinks.
Press the temp button Conce to set “50”. Direct the wireless remote controller
toward the receiver of the indoor unit and press the
h
button A.
2Setting the unit number
Press the temp button Cand Dto set the unit number “00”. Direct the
wireless remote controller toward the receiver of the indoor unit and press the
min
button B.
3Selecting a mode
Enter 04 to change the power voltage setting using the Cand Dbuttons.
Direct the wireless remote controller toward the receiver of the indoor unit and
press the
h
button A.
Current setting number: 1 = 1 beep (one second)
2 = 2 beeps (one second each)
3 = 3 beeps (one second each)
4Selecting the setting number
Use the Cand Dbuttons to change the power voltage setting to 01 (240 V).
Direct the wireless remote controller toward the sensor of the indoor unit and press
the
h
button A.
5To select multiple functions continuously
Repeat steps 3and 4to change multiple function settings continuously.
6Complete function selection
Direct the wireless remote controller toward the sensor of the indoor unit and press
the button E.
Note:
Wheneverchangesaremadetothefunctionsettingsafterinstallationor
maintenance,besuretorecordthechangeswithamarkinthe“Setting”
columnoftheFunctiontable.
3
CHECK
4
CHECK
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK
E
C,D
FA
B
Fig.6-9
2
CHECK
CHECK
1
6.3.2 Functionsettingontheremotecontroller
Refer to the indoor unit operation manual.
Functiontable
Select unit number 00
Mode Settings Mode no. Setting no. Initial setting setting
Power failure automatic recovery Not available 01 1 *2
Available *1 2 *2
Indoor temperature detecting Indoor unit operating average 02 1
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported 03 1
Supported (indoor unit is not equipped with outdoor-air inlet) 2
Supported (indoor unit is equipped with outdoor-air inlet) 3
Power voltage 240 V 04 1
220 V, 230 V 2
Select unit numbers 01 to 03 or all units (AL [wired remote controller]/07 [wireless remote controller])
Mode Settings Mode no. Setting no. Initial setting setting
Filter sign 100Hr 07 1
2500Hr 2
No filter sign indicator 3
Fan speed Silent 08 1–
Standard 2
High ceiling 3 –
*1 When the power supply returns, the air conditioner will start 3 minutes later.
*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.
RG79D479H02_en.indd 12 2012/10/09 (火) 午前 11:37:58
13
7. Testrun
7.1. Beforetestrun
►Aftercompletinginstallationandthewiringandpipingoftheindoorand
outdoorunits,checkforrefrigerantleakage,loosenessinthepower
supplyorcontrolwiring,wrongpolarity,andnodisconnectionofone
phaseinthesupply.
►Usea500-voltmegohmmetertocheckthattheresistancebetweenthe
powersupplyterminalsandgroundisatleast1.0MΩ.
►Donotcarryoutthistestonthecontrolwiring(lowvoltagecircuit)
terminals.
Warning:
Donotusetheairconditioneriftheinsulationresistanceislessthan1.0MΩ.
Insulationresistance
7.2. Testrun
The following 3 methods are available.
7.2.1. Usingwiredremotecontroller(Fig.7-1)
1Turn on the power at least 12 hours before the test run.
2Press the [TEST] button twice. ➡“TEST RUN” liquid crystal display
3Press the [Mode selection] button. ➡Make sure that wind is blown out.
4Press the [Mode selection] button and switch to the cooling (or heating) mode.
➡Make sure that cold (or warm) wind is blown out.
5Press the [Fan speed] button. ➡Make sure that the wind speed is switched.
6Check operation of the outdoor unit fan.
7Release test run by pressing the [ON/OFF] button. ➡Stop
8Register a telephone number.
The telephone number of the repair shop, sales office, etc., to contact if an
error occurs can be registered in the remote controller. The telephone number
will be displayed when an error occurs. For registration procedures, refer to the
operation manual for the indoor unit.
7.2.2. Usingwirelessremotecontroller(Fig.7-2)
1Turn on the power to the unit at least 12 hours before the test run.
2Press the
TEST RUN
button twice continuously.
(Start this operation from the status of remote controller display turned off.)
A
TEST RUN
and current operation mode are displayed.
3Press the
MODE
button to activate
COOL
mode, then check whether
cool air is blown out from the unit.
4Press the
MODE
button to activate
HEAT
mode, then check whether
warm air is blown out from the unit.
5Press the
FAN
button and check whether fan speed changes.
6Press the
VANE
button and check whether the auto vane operates properly.
7Press the ON/OFF button to stop the test run.
Note:
•Pointtheremotecontrollertowardstheindoorunitreceiverwhile
followingsteps2to7.
• ItisnotpossibletoruntheinFAN,DRYorAUTOmode.
7.2.3. UsingSW4inoutdoorunit
Refer to the outdoor unit installation manual.
7.3. Self-check
7.3.1. Wiredremotecontroller(Fig.7-3)
1Turn on the power.
2Press the [CHECK] button twice.
3Set refrigerant address with [TEMP] button if system control is used.
4Press the [ON/OFF] button to stop the self-check.
ACHECK button
BRefrigerant address
CTEMP. button
DIC: Indoor unit
OC: Outdoor unit
ECheck code
FUnit address
7.3.2. Wirelessremotecontroller(Fig.7-4)
1Turn on the power.
2Press the
CHECK
button twice.
(Start this operation from the status of remote controller display turned off.)
A
CHECK
begins to light.
B“00” begins to blink.
3
While pointing the remote controller toward the unit’s receiver, press the
h
button. The check code will be indicated by the number of times that the buzzer
sounds from the receiver section and the number of blinks of the operation lamp.
4Press the ON/OFF button to stop the self-check.
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
TEST RUN
5
7
A
3,4
2
6
Fig.7-2
Fig.7-1
°C
°C SIMPLE
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
TEST RUN
COOL, HEAT
AON/OFF button
BTest run display
CIndoor temperature liquid
line temperature display
DON/OFF lamp
EPower display
FError code display
Test run remaining time
display
GSet temperature button
HMode selection button
IFan speed button
MTEST button
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
CHECK
2
4
A
3
B
Fig.7-4
Fig.7-3
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
ERROR CODE
ERROR CODE
ERROR CODE
C
B
A
B
F
E
E D
RG79D479H02_en.indd 13 2012/10/09 (火) 午前 11:38:00
14
7. Testrun
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp flashes
(Number of times) Check code
1 P1 Inlet sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3 E6, E7 Indoor/outdoor unit communication error
4 P4 Drain sensor error/Float switch connector open
5P5 Drain pump error
PA Forced compressor
6 P6 Freezing/Overheating safeguard operation
7 EE Communication error between indoor and outdoor units
8 P8 Pipe temperature error
9 E4 Remote controller signal receiving error
10 – –
11 – –
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Wired remote controller transmission error
No sound E1, E2 Wired remote controller control board error
No sound – – – – No corresponding
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp flashes
(Number of times) Check code
1 E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2 UP Compressor overcurrent interruption
3 U3, U4 Open/short of outdoor unit thermistors
4 UF Compressor overcurrent interruption (When compressor locked)
5 U2 Abnormal high discharging temperature/49C worked/insufficient refrigerant
6 U1, Ud Abnormal high pressure (63H worked)/Overheating safeguard operation
7 U5 Abnormal temperature of heat sink
8 U8 Outdoor unit fan safeguard stop
9 U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal
synchronous signal to main circuit/Current sensor error
12 – –
13 – –
14 Others Other errors (Refer to the technical manual for the outdoor unit.)
*1 If the beeper does not sound again after the initial two beeps to confirm the self-check start signal was received and the OPERATION INDICATOR lamp does not come
on, there are no error records.
*2 If the beeper sounds three times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial two beeps to confirm the self-check start signal was received, the
specified refrigerant address is incorrect.
OPERATION
INDICATOR
lamp flash
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec. On
Approx. 3 sec. On
0.5 sec. On
0.5 sec. On
0.5 sec. On
0.5 sec. Off
Approx. 2.5 sec. On
Approx. 3 sec. On
0.5 sec. On
0.5 sec.
· · · Repeated
Number of flashes/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”) Number of flashes/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp flash
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec. On
0.5 sec. On
0.5 sec. On
0.5 sec. On
0.5 sec. Off
Approx. 2.5 sec. On
0.5 sec. On
0.5 sec.
· · · Repeated
Number of flashes/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”) Number of flashes/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
• Refer to the following tables for details on the check codes. (Wireless remote controller)
[Output pattern A]
RG79D479H02_en.indd 14 2012/10/09 (火) 午前 11:38:00
15
7. Testrun
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• If the unit cannot be operated properly after the above test run has been performed, refer to the following table to remove the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit)
PLEASE WAIT For about 2
minutes following
power-on
After LED 1, 2 are lighted, LED 2 is turned off,
then only LED 1 is lighted. (Correct operation)
• For about 2 minutes following power-on, operation of
the remote controller is not possible due to system
start-up. (Correct operation)
PLEASE WAIT → Error code After about 2
minutes has
expired following
power-on
Only LED 1 is lighted. → LED 1, 2 blink.
• Connector for the outdoor unit’s protection device is
not connected.
• Reverse or open phase wiring for the outdoor unit’s
power terminal block (L1, L2, L3)
Display messages do not appear even
when operation switch is turned ON
(operation lamp does not light up).
Only LED 1 is lighted. → LED 1 blinks twice,
LED 2 blinks once.
• Incorrect wiring between indoor and outdoor units
(incorrect polarity of S1, S2, S3)
• Remote controller wire short
On the wireless remote controller with condition above, following phenomena takes place.
• No signals from the remote controller are accepted.
• OPE lamp is blinking.
• The buzzer makes a short pipng sound.
Note:
Operationisnotpossibleforabout30secondsaftercancellationoffunctionselection.(Correctoperation)
For description of each LED (LED 1, 2, 3) provided on the indoor controller, refer to the following table.
LED 1 (power for microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (power for remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of the
indoor unit which is connected to the outdoor unit refrigerant address “0”.
LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED
is always blinking.
8. Easymaintenancefunction(Option)
By using the maintenance mode, you can display many types of maintenance data
on the remote controller such as the heat exchanger temperature and compressor
current consumption for the indoor and outdoor units.
This function can be used whether the air conditioner is operating or not.
During air conditioner operation, data can be checked during either normal
operation or maintenance mode stable operation.
* This function cannot be used during the test run.
* The availability of this function depends on the connecting outdoor unit. Refer to
the brochures.
Displayexample(Compdischargetemperature64°C)
RG79D479H02_en.indd 15 2012/10/09 (火) 午前 11:38:00
16
8. Easymaintenancefunction(Option)
Maintenance mode operation procedures
(1) Press the
TEST
button for three seconds to
activate the maintenance mode.
(2) Press the TEMP. buttons to set the refrigerant address.
MAINTENANCE
(3) Select the data you want to display.
MENU
ON/OFF
Compressor
information
COMP ON
x10 HOURS
COMP ON
x100 TIMES
COMP ON
CURRENT (A)
Cumulative
operation time ON/OFF
number Operation
current
Display
Display
Display
OUTDOOR UNIT
H·EXC.TEMP
OUTDOOR UNIT
OUTLET TEMP
OUTDOOR UNIT
OUTDOOR TEMP
Heat exchanger
temperature Comp discharge
temperature Outdoor ambient
temperature
Display
Outdoor unit
information
INDOOR UNIT
INLET TEMP
INDOOR UNIT
H·EXC.TEMP
INDOOR UNIT
FILTER USE H
Indoor room
temperature Heat exchanger
temperature Filter operation
time
Display
Indoor unit
information
* The filter operation time displayed is the number of hours the filter has been
used since the filter reset was performed.
(4) Press the
FILTER
button.
(5) The data is displayed in C.(Airflow temperature display example)
Flashing
Waiting for
response
Approx.
10 sec. 64°C
* Repeat steps (2) to (5) to check another date.
(6) Press the
TEST
button for three seconds or press the
ON/OFF
button
to deactivate the maintenance mode.
Stableoperation
Using the maintenance mode, the operation frequency can be fixed and the
operation can be stabilized. If the air conditioner is stopped, use the following
procedure to start this operation.
COOL
STABLE MODE
HEAT
STABLE MODE
STABLE MODE
CANCEL
Stable cooling
operation Stable heating
operation Stable operation
cancellation
Display
Press the
MODE
button to select the operation mode.
Press the
FILTER
button.
Waiting for stable
operation
Display
Stable
operation
10-20 min.
* You can check the data using steps (3) to (5) of the maintenance mode
operation procedures while waiting for the stable operation.
Display C
B
A
A
D
A
A
A
RG79D479H02_en.indd 16 2012/10/09 (火) 午前 11:38:03
Please be sure to put the contact address/telephone number on
this manual before handing it to the customer.
•Low Voltage Directive 2006/95 EEC
•Electromagnetic Compatibility Directive
2004/108 EEC
•Energy-related Products Directive
2009/125/EC
This product is designed and intended for use in the residential,
commercial and light-industrial environment.
The product at hand is
based on the following
EU regulations:
RG79D479H02 Printed in Japan
HEAD OFFICE: TOKYO BLDG. 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
Authorized representative in EU: MITSUBISHI EUROPE.B.V HARMAN HOUSE, 1 GEORGE STREET,
UXBRIDE, MIDDLESEX UB8 1QQ.U.K.
RG79D479H02_cover.indd 2 2012/10/09 (火) 午前 11:37:24
Other manuals for PKA-RP-HAL
1
This manual suits for next models
2
Table of contents
Other Mitsubishi Air Conditioner manuals
Mitsubishi
Mitsubishi MSH-07NV 2 User manual
Mitsubishi
Mitsubishi PFD-P250500VM-A User manual
Mitsubishi
Mitsubishi MUZ-D30NA User manual
Mitsubishi
Mitsubishi PKA-RP-HAL User manual
Mitsubishi
Mitsubishi Fresh Master GUF-50RD4 User manual
Mitsubishi
Mitsubishi Mr.Slim PKA-A.HA4 User manual
Mitsubishi
Mitsubishi PEFY-P06NMAU-E2 User manual
Mitsubishi
Mitsubishi MSH-CB50VB User manual
Mitsubishi
Mitsubishi SRK20ZJ-S User manual
Mitsubishi
Mitsubishi Mr.Slim SEZ-KD25 User manual
Mitsubishi
Mitsubishi SRK Series User manual
Mitsubishi
Mitsubishi Mr.Slim MFZ-KA12NA User manual
Mitsubishi
Mitsubishi SRK13YJV-S User manual
Mitsubishi
Mitsubishi PLH-P1.6KAH Operating manual
Mitsubishi
Mitsubishi PEFY-P-VMHS-E User manual
Mitsubishi
Mitsubishi MSZ-FA-VA Quick start guide
Mitsubishi
Mitsubishi MSZ-GE25VA User manual
Mitsubishi
Mitsubishi PCA-RP35KAQ User manual
Mitsubishi
Mitsubishi SRK20ZSX-S User manual
Mitsubishi
Mitsubishi MSZ-GE22VA User manual
