Mitsubishi Outlander PHEV 2019 User manual

OUTLANDER PHEV
OWNER’S MANUAL
OUTLANDER PHEV - ENGLISH - OGGE19E1
OUTLANDER PHEV - ENGLISH - OGGE19E1

Table of contents
Overview 1
General information 2
Charging 3
Locking and unlocking 4
Seats and seat belts 5
Instruments and controls 6
Starting and driving 7
For pleasant driving 8
For emergencies 9
Vehicle care 10
Maintenance 11
Specifications 12
Alphabetical index 13
Declaration of Conformity 14
OGGE19E1

Instruments and controls
E08500102485
LHD
1. Combination headlamps and dipper switch p. 6-59
Automatic High-Beam (AHB) switch* p. 6-62
Turn-signal lever p. 6-67
Front fog lamp switch p. 6-68
Rear fog lamp switch p. 6-69
2. Instruments p. 6-02
3. Steering wheel audio remote control switches p. 8-28
[For DISPLAY AUDIO, Smartphone Link Display Audio and
MITSUBISHI Multi-Communication System (MMCS), refer to
the separate owner’s manual.]
4. Power switch p. 7-11
5. Regenerative braking level selector (paddle type)* p. 7-19
6. Windscreen wiper and washer switch p. 6-69
Rear window wiper and washer switch p. 6-72
Headlamp washer switch p. 6-73
7. Cruise control switches* p. 7-45, 7-55
8. Supplemental restraint system (SRS) - airbag (for driver’s seat)
p. 5-25, 5-29
Horn switch p. 6-77
9. Bluetooth® 2.0 interface* p. 8-51
10. Camera switch* p. 7-112
11. Supplemental restraint system (SRS) - front knee airbag (for driv-
er’s seat) p. 5-25, 5-29
12. Fuses p. 11-16
13. Steering wheel height and reach adjustment lever p. 7-07
14. Driver’s side electric tailgate switch* p. 4-20
15. Lane Depature Warning (LDW) switch* p. 7-88
16. Forward Collision Mitigation System (FCM) and Ultrasonic mis-
acceleration Mitigation System (UMS) ON/OFF switch* p. 7-72
17. Sonar switch* p. 7-99, 7-103
18. Acoustic Vehicle Alerting System (AVAS) OFF switch p. 7-32
19. Headlamp levelling switch* p. 6-66
20. Active stability control (ASC) OFF switch p. 7-44
21. Multi information display switch p. 6-06
Instruments and controls
1-02 OGGE19E1 Overview
1

RHD
1. Combination headlamps and dipper switch p. 6-59
Automatic High-Beam (AHB) switch* p. 6-62
Turn-signal lever p. 6-67
Front fog lamp switch p. 6-68
Rear fog lamp switch p. 6-69
2. Regenerative braking level selector (paddle type)* p. 7-19
3. Power switch p. 7-11
4. Instruments p. 6-02
5. Multi information display switch p. 6-06
6. Active stability control (ASC) OFF switch p. 7-44
7. Headlamp levelling switch* p. 6-66
8. Sonar switch* p. 7-99, 7-103
9. Forward Collision Mitigation System (FCM) and Ultrasonic mis-
acceleration Mitigation System (UMS) ON/OFF switch* p. 7-72
10. Lane Depature Warning (LDW) switch* p. 7-88
11. Acoustic Vehicle Alerting System (AVAS) OFF switch p. 7-32
12. Driver’s side electric tailgate switch* p. 4-20
13. Windscreen wiper and washer switch p. 6-69
Rear window wiper and washer switch p. 6-72
Headlamp washer switch p. 6-73
14. Supplemental restraint system (SRS) - front knee airbag (for driv-
er’s seat) p. 5-25, 5-29
15. Cruise control switches* p. 7-45, 7-55
16. Supplemental restraint system (SRS) - airbag (for driver’s seat)
p. 5-25, 5-29
Horn switch p. 6-77
17. Steering wheel height and reach adjustment lever p. 7-07
18. Bluetooth® 2.0 interface* p. 8-51
19. Steering wheel audio remote control switches p. 8-28
[For DISPLAY AUDIO, Smartphone Link Display Audio and
MITSUBISHI Multi-Communication System (MMCS), refer to
the separate owner’s manual.]
20. Camera switch* p. 7-112
Instruments and controls
1-03
OGGE19E1 Overview
1

1. Multi Around Monitor* p. 7-109
Audio* p. 8-15
[For DISPLAY AUDIO, Smartphone Link Display Audio and
MITSUBISHI Multi-Communication System (MMCS), refer to
the separate owner’s manual.]
2. Hazard warning flasher switch p. 6-67
3. ECO mode switch p. 6-68
4. Front passenger’s airbag indicator p. 5-28
5. Passenger’s ventilators p. 8-02
6. USB input terminal* p. 8-71
7. Accessory socket* p. 8-75
Cigarette lighter* p. 8-75
8. Electric tailgate power switch* p. 4-20
9. Key slot p. 7-15
10. 220-240 V AC power supply switch* p. 8-76
11. Blind Spot Warning (BSW) switch* p. 7-82
12. Heated steering wheel switch* p. 6-76
13. Heated windscreen switch* p. 6-75
14. Cup holder p. 8-84
15. Selector lever (Joystick type) p. 7-15
16. 220-240 V AC power supply* p. 8-76
17. USB input terminal* p. 8-71
18. Rear ventilators p. 8-02
19. Fuel tank filler door release lever p. 2-15
20. Floor console box p. 8-82
Arm rest
21. Bonnet release lever p. 11-04
22. Rear window demister switch p. 6-74
Wiper de-icer switch* p. 6-74
23. Automatic climate control air conditioner p. 8-06
24. Seat belt reminder p. 5-11
Instruments and controls
1-04 OGGE19E1 Overview
1

1. USB input terminal* p. 8-71
2. Accessory socket* p. 8-75
3. Electric tailgate power switch* p. 4-20
4. Key slot p. 7-15
5. 220-240 V AC power supply switch* p. 8-76
6. Blind Spot Warning (BSW) switch* p. 7-82
7. Heated steering wheel switch* p. 6-76
8. Heated windscreen switch* p. 6-75
9. Bonnet release lever p. 11-04
10. Fuel tank filler door release lever p. 2-15
11. Rear ventilators p. 8-02
12. USB input terminal* p. 8-71
13. 220-240 V AC power supply* p. 8-76
14. Floor console box p. 8-82
Arm rest
15. Selector lever (Joystick type) p. 7-15
16. Cup holder p. 8-84
17. Rear window demister switch p. 6-74
Wiper de-icer switch* p. 6-74
18. Automatic climate control air conditioner p. 8-06
19. Seat belt reminder p. 5-11
20. Fuses p. 11-16
21. Passenger’s ventilators p. 8-02
22. Hazard warning flasher switch p. 6-67
23. ECO mode switch p. 6-68
24. Front passenger’s airbag indicator p. 5-28
25. Multi Around Monitor* p. 7-109
Audio* p. 8-15
[For DISPLAY AUDIO, Smartphone Link Display Audio and
MITSUBISHI Multi Communication System (MMCS), refer to
the separate owner’s manual.]
Instruments and controls
1-05
OGGE19E1 Overview
1

1. Supplemental restraint system (SRS) - airbag (for front passeng-
er’s seat) p. 5-25, 5-29
2. Glove box p. 8-82
Card holder p. 8-82
3. Electrical parking switch p. 7-18
4. EV switch p. 7-25
5. Electric parking brake switch p. 7-03
6. Brake auto hold switch p. 7-35
7. Heated seat switch* p. 5-04
8. SPORT mode switch p. 7-31
9. Drive mode switch p. 7-21
10. SAVE/CHARGE mode switch p. 7-28
Instruments and controls
1-06 OGGE19E1 Overview
1

1. Supplemental restraint system (SRS) - airbag (for front passeng-
er’s seat) p. 5-25, 5-29
2. Glove box p. 8-82
Card holder p. 8-82
3. Brake auto hold switch p. 7-35
4. Electric parking brake switch p. 7-03
5. EV switch p. 7-25
6. Electrical Parking switch p. 7-18
7. SAVE/CHARGE mode switch p. 7-28
8. Drive mode switch p. 7-21
9. SPORT mode switch p. 7-31
10. Heated seat switch* p. 5-04
Instruments and controls
1-07
OGGE19E1 Overview
1

Interior
E08500202112
LHD
1. Electric window control switch p. 4-34
2. Lock switch p. 4-35
3. Electric remote-controlled outside rear-view mirrors switch
p. 7-09
4. Central door lock switch p. 4-16
5. Inside rear-view mirror p. 7-07
6. Front seats p. 5-03
7. Supplemental restraint system (SRS) -side airbag (for front seat)
p. 5-25, 5-32
8. Tether anchorages for child restraint system (for front passenger’s
seat) p. 5-22
9. Rear seats p. 5-05
10. Armrest p. 5-05
Cup holder p. 8-84
11. Room lamp (rear) p. 8-80, 11-26
12. Head restraints p. 5-05
13. Supplemental restraint system (SRS) - curtain airbag p. 5-25,
5-32
Interior
1-08 OGGE19E1 Overview
1

RHD
1. Lock switch p. 4-35
2. Electric remote-controlled outside rear-view mirrors switch
p. 7-09
3. Central door lock switch p. 4-16
4. Electric window control switch p. 4-34
5. Head restraints p. 5-05
6. Supplemental restraint system (SRS) - curtain airbag p. 5-25,
5-32
7. Room lamp (rear) p. 8-80, 11-26
8. Armrest p. 5-05
Cup holder p. 8-84
9. Rear seats p. 5-05
10. Tether anchorages for child restraint system (for front passenger’s
seat) p. 5-22
11. Supplemental restraint system (SRS) - side airbag (for front seat)*
p. 5-25, 5-32
12. Front seats p. 5-03
13. Inside rear-view mirror p. 7-07
Interior
1-09
OGGE19E1 Overview
1

LHD
1. Bottle holder p. 8-84
2. Map & room lamps (front) p. 8-80, 8-80, 11-26
3. Downlight p. 8-81
4. Sunroof switch* p. 4-36
5. Hands-free microphone* p. 8-52
6. Sun visors p. 8-73
Vanity mirror p. 8-73
Card holder p. 8-73
7. Sunglasses holder* p. 8-83
8. Cargo area cover p. 8-85
9. Luggage room lamp p. 8-81, 11-26
10. Assist grips p. 8-86
Coat hook p. 8-86
11. Adjustable seat belt anchor p. 5-12
Seat belts p. 5-09
Interior
1-10 OGGE19E1 Overview
1

RHD
1. Bottle holder p. 8-84
2. Adjustable seat belt anchor p. 5-12
Seat belts p. 5-09
3. Assist grips p. 8-86
Coat hook p. 8-86
4. Luggage room lamp p. 8-81, 11-26
5. Cargo area cover p. 8-85
6. Sunglasses holder* p. 8-83
7. Sun visors p. 8-73
Vanity mirror p. 8-73
Card holder p. 8-73
8. Hands-free microphone* p. 8-52
9. Map & room lamps (front) p. 8-80, 8-80, 11-26
10. Downlight p. 8-81
11. Sunroof switch* p. 4-36
Interior
1-11
OGGE19E1 Overview
1

Luggage area
E08500301523
1. Tether anchorages for child restraint system p. 5-22
2. Tools p. 9-06
3. Accessory socket* p. 8-75
220-240 V AC power supply* p. 8-76
4. Luggage hooks p. 8-87
5. Jack p. 9-06
6. Luggage floor box p. 8-83
7. EV charging cable* p. 3-07
8. Auxiliary battery p. 11-09
9. Tyre repair kit p. 9-07
Luggage area
1-12 OGGE19E1 Overview
1

Outside (Front)
E08500402909
Halogen headlamps type LED headlamps type
1. Front-view camera* p. 7-109
2. Bonnet p. 11-04
3. Windscreen wipers p. 6-69
4. Sensor* [for Automatic High-Beam (AHB)*, Forward Collision
Mitigation System (FCM)* and Lane Departure Warning (LDW)*]
p. 6-62, 7-67, 7-88
Rain sensor p. 6-69
5. Sunroof* p. 4-36
6. Electric window control p. 4-34
7. Fuel tank filler p. 2-15
8. Side turn-signal lamps p. 6-67, 11-25
Side-view camera* p. 7-109
9. Ultrasonic misacceleration Mitigation System (UMS)* p. 7-77
Parking sensors* p. 7-101
10. Front fog lamps p. 6-68, 11-25, 11-28
11. Headlamps, high-beam p. 6-61, 11-25, 11-27
12. Headlamps, low beam p. 6-61, 11-25
13. Position lamps p. 6-61, 11-25
Daytime running lamps* p. 11-28, 11-25
14. Front turn-signal lamps p. 6-67, 11-25, 11-28
15. Position lamps p. 6-59, 11-25
Daytime running lamps p. 6-61, 11-25
16. Front turn-signal lamps p. 6-67, 11-25, 11-28
17. Headlamps, high-beam p. 6-61, 11-25, 11-27
18. Headlamps, low beam p. 6-61, 11-25, 11-26
Outside (Front)
1-13
OGGE19E1 Overview
1

Outside (Rear)
E08500402912
1. Antenna
2. Tail lamps p. 11-25, 11-30
3. Keyless entry system p. 4-03
Keyless operation system p. 4-06
Locking and unlocking the doors p. 4-14
4. Changing tyres p. 9-13
Tyre pressure monitoring system (TPMS) p. 7-92
Tyre inflation pressures p. 11-10
Tyre rotation p. 11-12
Snow traction device (tyre chains) p. 11-13
Size of tyres and wheels p. 12-09
5. Charging lid p. 3-12
Charging port courtesy lamp p. 3-06
6. Stop lamps p. 11-25, 11-30
7. Rear turn-signal lamps p. 6-67, 11-25, 11-30
8. Reversing lamp (LHD vehicles) p. 11-25, 11-30
Rear fog lamp (RHD vehicles) p. 6-69, 11-25, 11-30
9. Ultrasonic misacceleration Mitigation System (UMS)* p. 7-77
Reversing sensor system* p. 7-97
Parking sensors* p. 7-101
10. Rear fog lamp (LHD vehicles) p. 6-69, 11-25, 11-30
Reversing lamp (RHD vehicles) p. 11-25, 11-30
11. Licence plate lamps p. 11-25, 11-31
12. Rear-view camera* p. 7-105, 7-109
13. Rear window wiper p. 6-72
14. Tailgate* p. 4-19
Electric tailgate* p. 4-20
15. High-mounted stop lamp p. 11-25
16. Roof spoiler
Outside (Rear)
1-14 OGGE19E1 Overview
1

Quick guide
E08500500010
Locking and unlocking the
doors and tailgate
E08500601832
Keyless entry system
Press the remote control switch, and all doors
and the tailgate will be locked or unlocked as
desired.
The remote control switch will operate within
approximately 4 m from the vehicle.
Vehicles without MITSUBISHI Remote
Control
Vehicles with MITSUBISHI Remote Con-
trol
1- LOCK switch
2- UNLOCK switch
3- Electric tailgate switch
4- Indication lamp
5- Charging timer cancel switch*
Refer to “Keyless entry system” on page
4-03.
On vehicles with the electric tailgate, the tail-
gate can be opened automatically if you press
the electric tailgate switch (3) after unlocking
the tailgate.
Refer to “Electric tailgate” on page 4-20.
On vehicles with the MITSUBISHI Remote
Control, the charging timer can be cancelled
if you press the charging timer cancel switch
(5) twice within 2 seconds.
Refer to “MITSUBISHI Remote Control”
on page 3-20
Keyless operation system
When you are carrying the keyless operation
key and within the operating range, if you
press the driver’s or front passenger’s door
lock/unlock switch (A), or the tailgate lock
switch (B) (when locking) and the tailgate
open switch (C) (when unlocking), the doors
and the tailgate are locked/unlocked.
The operating range is approximately 70 cm
from the driver’s door switch, front passeng-
er’s door switch and the tailgate switches.
Refer to “Keyless operation system” on
page 4-06.
Quick guide
1-15
OGGE19E1 Overview
1

Around the driver’s seat
E08500801687
1-Combination headlamps
Rotate the switch to turn on the lamps.
OFF All lamps off {except for day-
time running lamps}
AUTO
With the operation mode of the
power switch in the “ON” posi-
tion, head-lamps, position, tail,
licence plate, instrument panel
lamps and downlight turn on
and off automatically in accord-
ance with outside light level.
{Daytime running lamps will go
on while the tail lamps are off.}
All lamps turn off automatically
when the operation mode is put
in OFF.
Position, tail, licence plate, in-
strument panel lamps and down-
light on
Headlamps and other lamps go
on
Refer to “Combination headlamps and
dipper switch” on page 6-59.
1-Turn-signal lever
The turn-signal lamps flash when the lever is
operated
1- Turn-signals
2- Lane-change signals
Refer to “Turn-signal lever” on page
6-67.
2-Steering wheel height and
reach adjustment
1. Release the lever while holding the
steering wheel up.
2. Adjust the steering wheel to the desired
position.
Quick guide
1-16 OGGE19E1 Overview
1

3. Securely lock the steering wheel by pull-
ing the lever fully upward.
A- Locked
B- Release
Refer to “Steering wheel height and reach
adjustment” on page 7-07.
3-Power switch
If you are carrying the keyless operation key,
you can start the Plug-in Hybrid EV System.
If you press the power switch without de-
pressing the brake pedal, you can change the
operation mode in the order of OFF, ACC,
ON, OFF.
OFF- The indication lamp (A) on the
power switch turns off.
ACC- The indication lamp on the en-
gine switch illuminates orange.
ON- The indication lamp on the pow-
er switch illuminates blue.
Refer to “Power switch” on page 7-11.
4-Wiper and washer switch
MIST- Misting function
The wipers will operate
once.
OFF- Off
AUTO- Auto-wiper control
The wipers will automati-
cally operate depending on
the degree of wetness on
the windscreen.
LO- Slow
HI- Fast
The washer fluid will be sprayed onto the
windscreen by pulling the lever towards you.
Refer to “Wiper and washer switch” on
page 6-69.
Quick guide
1-17
OGGE19E1 Overview
1

5-Electric remote-controlled
outside rear-view mirrors
To adjust the mirror position
L- Left outside mirror adjustment
R- Right outside mirror adjustment
1- Up
2- Down
3- Right
4- Left
5- Mirror retractor switch
Refer to “Outside rear-view mirrors” on
page 7-09.
6-Electric window control
Press the switch down for opening the win-
dow, and pull the switch for closing.
1- Driver’s door window
2- Front passenger’s door window
3- Rear left door window
4- Rear right door window
5- Lock switch
Lock switch
If you press the switch (5), the passenger’s
switches cannot be operated. To cancel, press
it once again.
Refer to “Electric window control” on
page 4-34.
7-Fuel tank filler door release
lever
Open the fuel tank filler door.
The fuel tank filler is located on the rear left
side of your vehicle.
Refer to “Filling the fuel tank” on page
2-15.
Charging lid
E08502100023
Firmly apply the parking brake, press the
electrical parking switch to shift into the “P”
(PARK) position and put the operation mode
of the power switch in the “OFF” position.
Quick guide
1-18 OGGE19E1 Overview
1

After unlocking the driver’s door, push the
rear portion of the charging lid (A) until it
clicks, and open the charging lid.
Release the tab (B) to open the inner lid.
C- Normal charging lid
D- Quick charging lid
Refer to “Normal charging (charging
method with rated AC 220-240V outlet)”
on page 3-10 and “Quick charging
(charging method with quick charger)” on
page 3-17.
Electrical parking switch
E08502200037
Press the switch to lock the wheels when you
are parking your vehicle. The indication lamp
on the switch illuminates green.
Refer to “Electrical parking switch” on
page 7-18.
Selector lever (Joystick type)
E08502300025
Selector lever operation
The selector lever always returns to its home
(•) position when it is released.
Home
position
Move the selector lever slowly and securely
in the following method.
lTo select “D” (DRIVE) or “R” (RE-
VERSE):
Move the selector lever in the direction
of the arrow.
lTo select “N” (NEUTRAL):
Move the selector lever in the direction
of the arrow and hold it for a while.
lTo select “B” (REGENERATIVE
BRAKE):
Move the selector lever in the direction
of the arrow.
Quick guide
1-19
OGGE19E1 Overview
1
