PURPOSE
This bulletin is issued to supplement and correct the wiring diagrams in the 1985 and 1986
Mirage Service Manuals. As reference to this bulletin, please write the STB number in the
revision boxes on the following pages:
•1985 Mirage Service Manual, Wiring Diagram and Components Wiring Diagram at the end
of the Manual.
•1986 Mirage Service Manual, Wiring Diagram and Components Wiring Diagram at the end
of the Manual.
•Mirage Electrical Wiring Manual, 1986, Page 3-21.
REVISION
The wiring harness connector that plugs into the back of the Mirage radio is different from
that shown in the diagrams.
The actual connector is shown schematically below in Figure 1; functions and wire colors
are identified.
Figure 1
MITSUBISHI
MOTOR SALES OF AMERICA, Inc.
TECHNICAL SERVICE
BULLETIN
SUBJECT :
MIRAGE AUDIO SYSTEM WIRING DIAGRAMS
No: STB-86-08-002
DATE: June, 1986
MODEL: 1985-86 Mirage
CIRCULATE TO: [ ] GENERAL MANAGER [ ] PARTS MANAGER [X] TECHNICIAN
[ ] SERVICE ADVISOR [X] SERVICE MANAGER [ ] WARRANTY PROCESSOR [ ] SALES MANAGER

Specific corrections to the wiring diagrams are shown on Pages 2, 3, and 4.
1985 MIRAGE SERVICE MANUAL, WIRING DIAGRAM
Change the wire color callouts as shown in the illustration below.
1985 MIRAGE SERVICE MANUAL, STEREO CIRCUIT DIAGRAM
Change the wire callouts as illustrated below.
1986 MIRAGE SERVICE MANUAL WIRING DIAGRAM
Change the wire callouts as illustrated below.

1986 MIRAGE SERVICE MANUAL, STEREO CIRCUIT DIAGRAM
Change the wire callouts as illustrated below.
1986 MIRAGE ELECTRICAL WIRING MANUAL, PAGE 3-21 ACCESSORY CIRCUIT
A
dd wire callouts for two terminal cavities as illustrated below.
