MIXVIBES U-MIX 44 Instruction manual

Quick Start Manual

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
Welcome
Thank you for choosing U-MIX44. U-MIX44 is a high quality 4-in / 4-
out USB audio interface providing a number of powerful and amazing
features optimized for DJ applications and home recording. U-MIX44
provides 2 stereo analog line inputs, 2 stereo line outputs, a microphone
input and a headphone output, perfect for monitoring.
We invite you to be a part of the MixVibes community to share your
experiences with other DJs, find help and advice. See you online on the
forum1or on the website2!
Minimum System Requirements for PC
•Windows 98SE, ME, 2000, XP SP2, Vista SP1, Seven
•Intel Pentium III / 600MHz or equivalent
•At least 128 MB RAM
•1 available USB port
Minimum System Requirements for MAC
•Mac OS X 10.3 or higher
•Power Macintosh G3 or higher
•At least 256 MB RAM
•1 available USB port
Content of the box
•U-MIX44 audio interface
• MixVibes DVS LE (PC only), EasyRec (Mac/PC), CROSS demo
(Mac/PC) and ASIO driver installation disc
•This quick start manual
1http://forum.mixvibes.com
2http://www.mixvibes.com
2 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
U-MIX44 Description &
System Diagram
C
M
J
CM
MJ
CJ
CMJ
N
panel.pdf 15/07/2009 14:39:07panel.pdf 15/07/2009 14:39:07
Front panel
1USB cable: Connect the USB cable to the computer.
2 4 RCA output channels: You can use these outputs to connect
an external mixer or your sound system (amplifier, powered
speakers, or home stereo).
3 Headphone output connector: Monitor the outputs 3/4 through
the headphone output.
4 Control of the headphone output: The headphone ouptut level
can be adjusted with the control knob.
3 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
5 Gain control for the microphone input: Control the input level of
the microphone.
6 Microphone input connector: Connect your microphone to this
balanced 1/4” connector.
7 4 RCA input channels: You can use these inputs to connect your
turntables, CD/MP3 players, mixer unit, effect player, cassette
deck play and radio player etc.
8 Grounding screw: When you use a turntable, connect the ground
lead from your turntable to the grounding screw to help prevent
hum.
C
M
J
CM
MJ
CJ
CMJ
N
system_diagram.pdf 15/07/2009 14:35:01system_diagram.pdf 15/07/2009 14:35:01
System Diagram
4 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
Connections
Follow the instructions below to use the U-MIX44 and a DJ software (like
MixVibes CROSS or DVS 7) with a pair of decks and an external mixer.
1 If you are using vinyl, plug the ground of your turntable to the
grounding screw on the U-MIX44 or on your DJ mixer.
2 Connect the outputs of your decks (vinyl or CD) to the RCA
inputs of your U-MIX44 plugging the left deck into the inputs
1/2 and right deck into the inputs 3/4. Match the left channel
(usually white) with the white RCA sockets on the U-MIX44, and
right (usually red) with the red sockets.
3 Connect the outputs of your U-MIX44 to the line inputs of your
mixer. Using the included RCA cables, connect the outputs 1/2
into a line input of your mixer, then repeat for the outputs 3/4,
into another available line input of your mixer.
4Connect the U-MIX44 to a free USB slot of your computer.
line line
Mixer
(optional)
Classic turntable
or CD player
Classic turntable
or CD player
U-MIX44
Classic turntable
C
M
J
CM
MJ
CJ
CMJ
N
connections_pack.pdf 15/07/2009 15:04:22connections_pack.pdf 15/07/2009 15:04:22
Connections
5 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
Audio settings
• After the system has recognized and installed your U-MIX44
you should adjust the volume in the Windows audio settings.
Example Windows XP: [Start > Control panel > Sounds and
audio devices > rider ’Audio’]. Click on ’Volume’ under the item
’Sound Playback’ and adjust all faders to set the output levels.
Click on ’Volume’ under the item ’Sound Recording’ and adjust
all faders to set the input levels.
C
M
J
CM
MJ
CJ
CMJ
N
audio.pdf 15/07/2009 16:02:22audio.pdf 15/07/2009 16:02:22
• If you want to use ASIO drivers to have low latencies with your DJ
or sequencer applications, choose MixVibes ASIO UMIX44 device
in the audio settings of the application and enable the U-MIX44
inputs and outputs.
Find more documentations on our website3.
3http://www.mixvibes.com/support/
6 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
Specifications
LINE Playback
Signal to noise ratio: ≥85dB
Distortion ratio: ≤0.05 %
Channel separation: ≥85dB
Frequency response: 20Hz-20kHz -1±2.5dB
HEADPHONE Playback
Signal to noise ratio: ≥80dB
Distortion ratio: ≤0.07 %
Frequency response: 30Hz-18kHz -1±2.0dB
LINE Record
Signal to noise ratio: ≥80dB
Distortion ratio: ≤0.05 %
Channel separation: ≥70dB
Frequency response: 20Hz-20kHz -1±2.5dB
MIC Record
Signal to noise ratio: ≥60dB
Distortion ratio: ≤0.1 %
Frequency response: 30Hz-18kHz -1±2.0dB
Dimensions (WxDxH): 125x115x40mm
Weight: 250g
7 / 8

C
M
J
CM
MJ
CJ
CMJ
N
vibe-watermark-bright.pdf 03/04/2009 16:07:52vibe-watermark-bright.pdf 03/04/2009 16:07:52
Contact
• For all technical or sales information, please contact your local
reseller or MixVibes directly:
MixVibes
4, rue de la Sablière
92230 Gennevilliers
FRANCE
www.mixvibes.com
•Technical support:
•online on our forum4
•Sales Information:
•by email to [email protected]
Copyright 2009 MixVibes. All rights reserved.
The contents of this manual may change without prior notice. Best
efforts have been put forth to insure the accuracy of the contents of
this manual. MixVibes is not liable for any errors, typographical or other,
contained herein. Except as specifically permitted herein, no portion of
the information on this manual may be reproduced in any form or by
any means without the prior written permission of MixVibes. Trademarks
and trade names displayed on this manual are the property of their
respective owners.
This manual may be updated from time to time. Please check for updates
on our website5.
4http://forum.mixvibes.com
5http://www.mixvibes.com
8 / 8
