Mo-vis P015-61 User manual

moving forward together
Scoot Control
P015-61 Scoot Control R-net
User manual
Edition 4, July 2021

Contents
Contents Other languages ................................................................................. 7
User Manual (english) ......................................................................... 8
Warning labels .......................................................................... 8
Support, scrapping & recycling ................................................. 9
Limited liability ........................................................................ 10
Intended use ........................................................................... 10
Features .................................................................................. 11
Operation ................................................................................ 12
Parts and accessories .............................................................. 18
Qualifications .......................................................................... 22
First time use ........................................................................... 23
Cleaning .................................................................................. 23
Warnings and limitations ........................................................ 24
Dimensions ............................................................................. 24
Uživatelská příručka (česky) .............................................................. 27
Výstražné štítky ....................................................................... 27
Podpora, likvidace a recyklace ................................................ 28
Omezení odpovědnosti ........................................................... 29
Zamýšlené použití ................................................................... 29
Vlastnosti ................................................................................ 30
Obsluha ................................................................................... 31
1

Součásti a příslušenství ........................................................... 39
Kvalifikace ............................................................................... 42
První použití ............................................................................ 42
Čištění ..................................................................................... 43
Výstrahy a omezení ................................................................. 43
Rozměry .................................................................................. 44
Brugermanual (Dansk) ...................................................................... 47
Advarselsmærkater ................................................................. 47
Support, bortskaffelse og genbrug .......................................... 48
Ansvarsbegrænsning ............................................................... 49
Tilsigtet brug ........................................................................... 49
Funktioner ............................................................................... 50
Betjening ................................................................................. 51
Dele og tilbehør ...................................................................... 57
Kvalifikationer ......................................................................... 60
Brug første gang ...................................................................... 61
Rengøring ................................................................................ 61
Advarsler og begrænsninger ................................................... 62
Mål .......................................................................................... 62
Benutzerhandbuch (Deutsch) ............................................................ 65
Warnhinweise ......................................................................... 65
Support, Entsorgung und Recycling ........................................ 66
Haftungsbeschränkung ........................................................... 67
Vorgesehene Verwendung ...................................................... 67
Merkmale ................................................................................ 69
Bedienung ............................................................................... 69
2

Teile und Zubehör ................................................................... 78
Qualifizierungen ...................................................................... 83
Erstmalige Verwendung .......................................................... 83
Reinigung ................................................................................ 83
Warnungen und Beschränkungen ........................................... 84
Abmessungen .......................................................................... 85
Manual del usuario (Español) ............................................................ 87
Etiquetas de advertencia ........................................................ 87
Asistencia, eliminación y reciclaje ........................................... 88
Limitación de responsabilidad ................................................ 89
Uso previsto ............................................................................ 89
Características ......................................................................... 90
Funcionamiento ...................................................................... 91
Componentes y accesorios ..................................................... 99
Personal cualificado .............................................................. 104
Primera utilización ................................................................ 104
Limpieza ................................................................................ 104
Advertencias y limitaciones .................................................. 105
Dimensiones ......................................................................... 106
Manuel de l’utilisateur (Français) .................................................... 108
Étiquettes d’avertissement ................................................... 108
Assistance, mise au rebut et recyclage ................................. 109
Responsabilité limitée ........................................................... 110
Utilisation prévue .................................................................. 110
Fonctionnalités ...................................................................... 111
Fonctionnement .................................................................... 112
3

Pièces et accessoires ............................................................. 121
Qualifications ........................................................................ 125
Première utilisation ............................................................... 126
Nettoyage .............................................................................. 126
Avertissements et limitations ............................................... 127
Dimensions ........................................................................... 127
Manuale utente (Italiano) ............................................................... 129
Segnaletica di avvertenza ...................................................... 129
Assistenza, smaltimento & riciclaggio ................................... 130
Responsabilità limitata .......................................................... 131
Destinazione d’uso ................................................................ 131
Funzioni ................................................................................. 132
Funzionamento ..................................................................... 133
Parti e accessori .................................................................... 141
Qualifiche .............................................................................. 146
Primo utilizzo ........................................................................ 146
Pulizia .................................................................................... 146
Avvertenze e limiti ................................................................ 147
Dimensioni ............................................................................ 148
Brukerhåndbok (Norsk) ................................................................... 150
Advarselsetiketter ................................................................. 150
Brukerstøtte, kassering og gjenvinning ................................. 151
Begrenset ansvar ................................................................... 152
Bruksområde ......................................................................... 152
Funksjoner ............................................................................ 153
Betjening ............................................................................... 154
4

Deler og tilbehør ................................................................... 159
Kvalifikasjoner ....................................................................... 162
Første gangs bruk .................................................................. 163
Rengjøring ............................................................................. 163
Advarsler og begrensninger .................................................. 164
Mål ........................................................................................ 164
Gebruikershandleiding (Nederlands) ............................................... 167
Waarschuwingslabels ............................................................ 167
Ondersteuning, afdanken en recycling .................................. 168
Beperkte aansprakelijkheid ................................................... 169
Beoogd gebruik ..................................................................... 169
Eigenschappen ...................................................................... 170
Bediening .............................................................................. 171
Onderdelen en accessoires ................................................... 179
Bevoegdheden ...................................................................... 184
Eerste gebruik ....................................................................... 184
Reinigen ................................................................................ 184
Waarschuwingen en beperkingen ......................................... 185
Afmetingen ........................................................................... 186
Manual do utilizador (Português) .................................................... 188
Rótulos com advertências ..................................................... 188
Suporte, eliminação e reciclagem ......................................... 189
Responsabilidade limitada .................................................... 190
Utilização prevista ................................................................. 190
Funcionalidades .................................................................... 191
Funcionamento ..................................................................... 192
5

Peças e acessórios ................................................................. 200
Qualificações ......................................................................... 205
Primeira utilização ................................................................. 205
Limpeza ................................................................................. 205
Avisos e limitações ................................................................ 206
Dimensões ............................................................................ 207
Användarhandbok (Svenska) ........................................................... 209
Varningsetiketter ................................................................... 209
Support, kassering och återvinning ....................................... 210
Begränsat ansvar ................................................................... 211
Avsedd användning ............................................................... 211
Funktioner ............................................................................. 212
Användning ........................................................................... 213
Delar och tillbehör ................................................................ 221
Behörighet ............................................................................ 224
Första användningen ............................................................. 225
Rengöring .............................................................................. 225
Varningar och begränsningar ................................................ 226
Mått ...................................................................................... 226
6

Other languages
CS: Tuto příručku naleznete v češtině na našich webových stránkách.
DA: Du kan finde denne manual på dansk på vores websted.
DE: Auf unserer Website finden Sie diese Anleitung in Deutsch.
EN: You can find this manual in English on our website.
ES: Este manual está disponible en español en nuestro sitio web.
FR: Vous pouvez trouver ce manuel en français sur notre site Web.
IT: Nel nostro sito web è disponibile il presente manuale in italiano.
NO: Du finner denne håndboken på norsk på nettstedet vårt.
NL: De Nederlandse handleiding kunt u op onze website vinden.
PT: Pode encontrar este manual em português na nossa página web.
SV: Du hittar den här handboken på svenska på vår webbplats.
7
Scoot Control User manual 7

User Manual (english)
Warning labels
Please read this manual, the safety instructions and warning texts carefully,
in order to reduce the risks associated to the device. Our products are safe
under normal and reasonably foreseeable operating conditions.
NOTE: This symbol indicates general notes and information.
CAUTION: This symbol indicates caution for a hazardous situation that,
if not avoided, could result in minor or moderate injury.
WARNING: This symbol indicates a warning for a hazardous situation
that, if not avoided, could result in death or serious injury.
8
8 Scoot Control User manual

Support, scrapping & recycling
Technical support
TROUBLE: In case of technical problems:
• Contact your dealer
• If your dealer is not available or unknown, please contact mo-vis:
cont[email protected] or [phone].
Always state the product code and device serial number when
contacting us. This ensures you are provided with the correct
information.
Spare parts and accessories
Contact mo-vis or your dealer for more information about spare parts and
accessories.
Scrapping & recycling
CAUTION: For scrapping, adhere to your local waste legislation.
Dispose of obsolete electronic parts responsibly in accordance with
local recycling regulations.
9
Scoot Control User manual 9

Limited liability
mo-vis accepts no liability for personal injury or damage to property
that may arise from the failure of the user or other persons to follow the
recommendation, warnings and instructions in this manual.
CAUTION: This product should only be installed by a qualified service
engineer.
NOTE: All mo-vis manuals can be found at http://www.mo-vis.com
where they can be consulted in PDF format.
NOTE: In case any serious incident occurs in relation to this device,
this should be reported immediately to mo-vis and the competent
authority of the Member State in which the user is established.
Intended use
The Scoot Control is a steering device which can be connected directly to the
wheelchair electronics (R-net), to control the power chair and its functions.
It is intended to support an attendant in controlling or maneuvering a power
chair, both inside and outside.
10
10 Scoot Control User manual

Safe driving
WARNING: The on/off switch must be available to the user at all times.
This allows to instantly stop the wheelchair in case of problems or an
emergency.
WARNING: In case the wheelchair responds in an unexpected way, the
user must immediately release the Scoot Control or use the power on/
off switch.
WARNING: Only adult attendant should operate the Scoot Control.
WARNING: When the wheelchair is in tilt/recline, please be aware that
the Scoot Control could collide with objects or people (especially if the
Scoot Control is not folded in).
Features
The Scoot Control is part of our range of input devices. It is to be mounted on
the back of the power chair and is a steering device with 2 handles (similar to
11
Scoot Control User manual 11

a compact bicycle steer). The Scoot Control R-net is only compatible with the
R-net electronics of Curtiss-Wright.
• Fully proportional handlebar with 2 rubber handles and 2 configurable
thumb throttles at either side
• Built in a compact housing, with a 3.5 mm stereo jack to connect an
external actuator keypad (Curtiss-Wright CJSM2 compatible)
• Full access to wheelchair functions such as Lights, Horn and Speed
settings
• Battery and speed display via LEDs
• On-board configuration possible
• Compatible with multiple types of power chairs equipped with R-net
electronics
Operation
The Scoot Control consists of the following parts:
12
12 Scoot Control User manual

1 Control panel: control the Scoot Control
2 Handlebar: rubber handle at either side to steer the wheelchair
3 Left and right throttle: to move the power chair forward and/or
backward
13
Scoot Control User manual 13

1 3.5 mm jack to connect a Curtiss-Wright CJSM2 compatible Actuator
Keypad
2 Built-in sounder: to be used as horn
3 R-net bus cable
Horizontal movements of the handle bar will result in a steering action of the
wheelchair (turning).
14
14 Scoot Control User manual

In combination with the thumb throttle it is possible to move the wheelchair
in any direction.
• Standard configuration: right throttle = forward, left throttle = backward
• If both throttles are operated simultaneously and that would result in
conflicting direction, the chair will stop driving
WARNING: Do not hang things (e.g. backpacks) on the Scoot Control
or the throttle. This might damage the throttle and the device.
Furthermore, removing items suddenly from the throttle might lead to
unintended movement of the power chair if it is not in stand-by mode.
Control Panel
15
Scoot Control User manual 15

The buttons have the following functions:
BUTTON FUNCTION ACTION
S1 On / Off Switch the power chair on/off
S2 Left indicator Switch the left indicator on/off
S3 Right indicator Switch right indicator on/off
Hold S2 for > 2
seconds
Hazard lights Switch hazard lights on/off
Hold S3 for > 2
seconds
Lights Switch lights on/off
S4 Horn Horn sounds as long as pressed
S5 Direction Switch direction of the throttles
S6 Speed setting Change the speed. The first click on
S6 will show you the current speed
setting. The next clicks will change
the speed.
Hold S6 for > 2
seconds
Grab focus Press long to grab control of the
power chair. See Scoot Control
Installation Manual for more infor-
mation.
16
16 Scoot Control User manual

LED indications on the control panel provide you with the following
information:
LED FUNCTION INFORMATION
Battery gauge Battery indicator: is default on when
Scoot Control is in focus
Speed setting Speed indicator when setting the speed.
5 speeds = 5 green LED in a row (e.g.
speed level 3 = 3 LEDs on)
Becomes active when pressing S6 and
remains active for 5 seconds after last
speed change.
Error D11 and D15 red, D13 flashes red, other
LEDs are off: number of flashes indicates
the fault (see Scoot Control Installation
manual)
D11-D15
Status • In focus: battery indicator
• Not in focus: D13 green heartbeat flash
• Configuration: D13 green fast flash
D16 Left indicator Green flash when left indicator is on
D17 Right indicator Green flash when right indicator is on
17
Scoot Control User manual 17

LED FUNCTION INFORMATION
D16 +
D17
Hazard lights /
lights indicator
Both flash red when hazard lights are on.
Both are orange when the lights are on
and the direction indicator is off.
Forward / reverse In standard configuration:
Forward = green
Backward = orange
No focus Off
D18
Stand-by Flash green / orange (depending on direc-
tion of throttle)
CAUTION: Pushing harder on the throttle will not increase the speed of
the power chair. To increase the speed, press S6 or change the settings
of the power chair.
Parts and accessories
The P015-61 Scoot Control R-net is always accompanied by the D-
P015-61-70-vv Scoot Control User manual and the D-P015-61-71-vv Scoot
Control Installation manual.
The following parts and accessories are optionally available:
18
18 Scoot Control User manual

PART NUMBER FUNCTION INFORMATION
P016-98 Actuator
Keypad Button R-net
CJSM2
P016-99 Actuator
Keypad Paddle R-net
CJSM2
P016-88 Actuator
Keypad PRO Button
R-net CJSM2
P016-89 Actuator
Keypad PRO Paddle
R-net CJSM2
You can connect an
external Curtiss-
Wright CJSM2 com-
patible Actuator Key-
pad to the Scoot
Control to control
the actuators of the
power chair.
See Scoot Control Installa-
tion Manual
19
Scoot Control User manual 19
