Mobia MB?T1 User manual

1


MB‐T1
UserManual
www.mobia.co.th


2

3
Declaration
Turn to a fascinating world of beauty and style with
the mobile phone. With its ornament integrated scroll
audio LED with coloured key, it will impress you with
its dynamic、flashy、dazzling and unique character.
Please read the user’s manual so as to keep your
mobile phone in the best condition.
The manual has been verified and reviewed to
guarantee the accuracy. Instructions and descriptions
contained herein are accurate at the time of
publication. However, mobile phones developed
afterwards and the contents of their manual are
subject to modification without further notification. Our
company reserves the rights in relation to the manual.

4
Content
1 BASIC KNOWLEDGE. ..............................................9
1.1 BRIEF INTRODUCTION..............................................9
1.2 Security preliminary instruction. ...................10
1.3 SAFETY WARNING AND ATTENTION........................10
1.3.1 Points for attention in general.......................10
1.3.2 The attention of cellular phone.....................12
1.3.3 The attention of battery: ................................13
1.3.4 The attention of charger ................................15
1.3.5 Clean with maintenance ................................16
1.3.6 General regulation..........................................16
2 BEFORE USING .......................................................18
2.1 THE NAME AND INTRODUCTION OF EACH PART .......18
2.1.1 Technique parameter.........................................18
2.1.2 Icon ...................................................................18
2.2 MOBILEPHONE SKETCH MAP &KEYS INTRODUCTION
.......................................................................................19
2.2.1 MOBILEPHONE SKETCH MAP：(ELLIPSIS).........19
2.2.2 KEYS INTRODUCTION:...........................................19
2.3 BATTERY...................................................................22
2.4 THE BATTERY REFRESHES.......................................23
2.5 LINK TO THE NETWORK ............................................24

5
2.5.1 SIM card...........................................................25
2.5.2 insert and take out the SIM card ..................25
2.5.3 Open and lock the phone..............................26
2.5.4 SIM card of lock..............................................26
2.5.5 Solve the lock of the phone ..........................27
2.5.6 Link a network.................................................28
2.5.7 Make a phone call ..........................................28
2.5.8 Stir to make local telephone call...................29
2.5.9 Dial the fix telephone extension ...................29
2.5.10 Stir to make international call......................30
2.5.11 Stir to make the telephone ..........................31
2.5.12 Urgency call...................................................31
2.5.13 Receive the telephone.................................32
2.5.14 Call history.....................................................32
2.5.15 Call menu.......................................................32
3 MENU OF FUNCTION.............................................34
3.1 THE USING OF THE MENU OF FUNCTION..................34
3.2 MENU STRUCTURE...................................................34
3.3 PHONEBOOK .............................................................37
3.4 INFORMATION ...........................................................38
3.4.1 Message ..........................................................39
3.4.2 Multimedia Message.........................................44
3.5 CALL HISTORY ..........................................................50

6
3.5.1 Call Log .........................................................50
3.5.2 Common Call Setting.....................................52
3.6 SETTINGS...............................................................54
3.6.1 Mode setting.................................................54
3.6.2 G-sensor settings ......................................54
3.6.3 Cell phone settings....................................54
3.6.4 Network settings ........................................55
3.6.5 The safety settings ....................................55
3.6.6 Factory setting ...........................................57
3.7 FILE MANAGER.....................................................58
3.8 FUN &GAMES ......................................................58
3.9 Camera ..........................................................58
3.10 Image viewer...............................................59
3.11 Video recorder...............................................60
3.12 Video player ................................................61
3.13 Audio player ................................................61
3.14 FM Radio ......................................................63
This cellular phone provides the function of the
radio, if you want to open it you should first input
an earphones. In the interface of the radio, press
the top main key can open or close the function of
searching automatically, after opening this
function, press the left and right main key can
carry on the forward searching or the backward

7
searching automatically, until search a channel.
When you close the function of searching
automatically, you can carry on searching by
yourself. Press the left and right main key will
increase/reduce 0.1 HZ..........................................63
3.15 Sound-recording .........................................64
3.16 SCENE MODE.......................................................65
3.17 Calendar ......................................................66
3.18 Memo ...........................................................67
3.19 Alarm clock..................................................67
3.20 Service .........................................................67
3.20.1 WAP...........................................................67
3.20.2 Account data ............................................68
3.21 Calculator.....................................................69
3.22 Electronic book .............................................70
3.23 Bluetooth.......................................................71
3.24 STOPWATCH..........................................................72
3.25 WORLD TIME......................................................73
4 INPUT METHOD SPECIFICATION....................74
4.1 KEYBOARD DEFINITION ........................................74
4.2 INPUT METHOD SPECIFICATION............................75
4.2.1 The intelligent Pinyin input method..............75
4.2.2 Stroke input method .......................................76

8
4.2.3 The English and numerical input method: ..78
5. THE T-FLASH CARD INTRODUCTION.............80
5.1 THE DISMANTLING AND ASSEMBLING...................80
5.2 THE USAGE OF T-FLASH CARD ............................80
6 COMMON PROBLEMS AND SOLUTION..............82

9
1 Basic knowledge.
1.1 Brief introduction.
Thank you for choosing this whole Chinese colored Mobile Phone. You
can read this manual to understand the usage of this cellular phone
completely, enjoying its’ perfect function and simple operation.
This color-screen cell phone aims at the network environment of the GSM/
GPRS. Besides basic call function, it provide for you intellect
Chinese/English，contacts, 64 polyphonic tones, message and multimedia
message, camera and video, MP3 and movie player, sound clips, the clock,
alarm clock, calculator, automatic start and power off, calendar, T-Flash,
GPRS, keypad lock etc, which will be Convenient for your work and leisure.
The cellular phone adopts characteristic software. Its’ perfect function can
satisfy your different needs.
The color-screen cellular phone accord with the technical specification of
the GSM/GPRS, and gained the attestation form international organization.
Our company reserves rights of revising the manual Before we could give
an advanced notice.

10
1.2 Security preliminary instruction.
Please notify telecommunications office or commission agent immediately
to forbid your cell phone and SIM card if Your cellular phone was lost or
stolen, which will avoid the economic lost when others call the phone
number.
When you contact with telecommunications office or commission agent,
they need to know the IMEI number of your cellular phone. (Printed at the
back of the cell phone, you can discover after took the battery). Please copy
that number to stay and take care of carefully for using in future.
In order to make your cellular phone avoid being used in the wrong way,
please adopt to guard against measure, such as:
- Establish the PIN number of the good hand machine SIM card, and modify
in time before others knowing it.
- When you leave your car please don't put the handle knob machine where
could be found easily. You had better take it on or lock it in your luggage box.
- Establish to call restriction.
1.3 Safety warning and attention.
Before using a cellular phone please read these regulations carefully
when using it in the safe and right way.
1.3.1 Points for attention in general.
You should use the battery and the charger which our company occupied
N

11
for your cellular phone. If you usage other products it may lead to the battery
leak a liquid, lead heat and burst and light a fire.
Please do not bump shot, vibrate or toss a cellular phone, in case it may
break down and light a fire.
Please don't put battery, cellular phone, charger in the microwave oven or
the high pressure equipments, otherwise it may cause the electric circuit
damage and light a fire.
Please do not use a cellular phone in the gaseous place. otherwise it may
cause the cellular phone break down and cause a fire.
Please don't put the cellular phone in the place where there is the heat
degree, high degree of humidity or have a great deal of dust, otherwise it
may cause breakdown.
Please put the cellular phone where the child could not touch it, in order to
prevent child from taking it as a toy, resulting in the Human body hurt.
Please don't put cellular phone on the rough or the unsteady pedestal
table, in case it may drop and cause break down or damage.
At places, such as close storage fuel, chemistry product and explosion
product...etc., please allow to the designation of the marking which says
"close double to wireless telephone".
Please obey the using a cellular phone of laws strictly where you are
driving. If you use a cellular phone while driving , please obey the following
rules: driving carefully, notice the road circumstance; If the cellular phone
has the function of need not to be lifted, please use it to answer the call ; If
N

12
the driver's condition isn't good, please answer the call or call or dial the
number after parking your car.
1.3.2 The attention of cellular phone.
Please close a cellular phone in a plane and a hospital etc. where it forbid
using the cellular phone. The cellular phone has effected the normal working
of electronic equipments and medical treatment instrument, If you use a
cellular phone in these places, please obey their provision. The cellular
phone has the function of opening on in fixed time and automatically, please
look into your alarm clock constitution, and make sure that your phone will
not switch on automatically through flying.
Please do not use your phone in the weak signal or the side of the
equipments of the accuracy electronic. The wireless electric wave
interference may cause the mistaken operation and other problems of
electronic equipments. Especially in the following equipments
neighbourhood: Hearing aid, rise to fight machine and other medical
treatment electronic equipments, a fire locater, automatic doors and other
equipments which can control by themselves. If you want to know the
cellular phones influence on rise to fight machine and other medical
treatment electronic equipments. Please consult with the manufacture or the
business man.
Please don't knock other things with the LCD, otherwise it may cause the
LCD break down and LCD liquid of the LCD out. If the LCD liquid inpour to
your eyes, it may become blind. At this time please to rinse eyes (never rub

13
eyes) with the clear water immediately and go to hospital.
Don't unload or refit a cellular phone, otherwise it may cause damage,
electric leakage and the electric circuit trouble of cellular phone.
In the very few circumstances, the cellular phone may has bad influence
on the electronic equipments that inside the car while using some model
numbers. Please don't use cellular phone in order to prevent from losing the
safe assurance at this time.
Please don't use the sharp thing: key, needle, nip...etc. Otherwise it may
damage cellular phone or lead to mistake operation.
If the antenna is damaged, please don't use a cellular phone, otherwise it
may bring injury to Human body.
To avoid the cell phone closing to magcard or magnetic things. The
radiation wave of the cellular phone may possible clean the information of
the soft dish, savings card, and credit card.
Please put the small metal such as the thumb tack away from the cellular
phone headphone. The loudspeaker has magnetism when the loudspeaker
works, it will draw on these small metals, as a result that it may lead to hurt
or damage a cellular phone to the Human body.
Avoiding the cellular phone affects by damp and cold, while water or other
liquids' getting into a cellular phone it will result in the cellular phone lead
heat, electric leakage and breakdown.
1.3.3 The attention of battery:
please don't throw the battery into the fire, otherwise in will cause the
battery light a fire and burst.
N

14
While installing battery, don't press it heavily, otherwise it will cause
battery leak a liquid, leading heat and bursting and lighting a fire.
Please don't use metals, such as electric wire and needle...etc. they will
short-circuit the battery, also don't put battery with necklace, the metal
together, otherwise it will cause the battery leak a liquid, lead heat and burst
and lighting a fire.
Please don't weld the head of the battery, otherwise it will cause to leak a
liquid, lead heat and burst and light a fire.
If the liquid of battery gets into the danger that eyes will become blind, at this
time please don't rub eyes by hand, use the clear water flush, then go to a
hospital to seek medical advice immediately.
Please don't dismantle to unload or refit battery, otherwise it will cause the
battery leak a liquid, lead heat and burst and light a fire.
Please do not use and put the battery on the side of the fire or the heating
place, otherwise it will cause the battery leak a liquid, leading heat and
bursting and lighting a fire.
If the battery refresh or the conservancy the process heat, changes
countenance, transforms etc. abnormality phenomenon while using,
pleasing stop usage and replace new battery.
If the battery liquid ran into a skin, clothes up, this may cause a skin burn,
flush with the clear water immediately, please cure right away when it's
necessary.
If the battery seeps into liquid or sends out strange smell, please take it
away from the clear fire immediately, avoiding hair light the fire and bursting.

15
Please don't make the battery affect by damp and cold, otherwise it will
lead to the battery lead heat and emit smoke and decay.
Please do not use or place it in the sunlight shooting or the heat place of
the car, otherwise it will cause liquid leak with lead heat, lower function,
shorten service life.
Please don't refresh in a row over 24 hours.
1.3.4 The attention of charger
Please use 220 V alternate current. Using other electric voltages will
cause electric leakage and light a fire with the damage of the opponent
machine and the charger.
Forbid short-circuit charger, otherwise it will lead to get an electric shock,
emit smoke with the damage of charger.
Please don't use it under the situation that the power cable damage,
otherwise it will lead to light a fire and get an electric shock.
Please sweep the dust on the AC outlet in time.
Please don't put container etc. of prosperous water on the side of the
charger, in order to prevent water splashes to result in the charger lead hot,
electric leakage and breakdown.
If the charger comes in contact with water or other liquids, pulling the
power supply out down from the electric outlet immediately in order to
prevent lead heat and light a fire, get an electric shock with the charger
break down.
Please don't dismantle to unload or refit charger, otherwise it will cause
the Human body hurt, get an electric shock, light a fire to damage with
N

16
charger.
Please don't used it in the high degree of humidity charger in the
bathroom, otherwise it will cause and get an electric shock, light a fire with
the charger damage.
Please don't touch contact charger, electric wire and AC outlet with your
wet hand, otherwise it will cause to get an electric shock.
Don't put heavy thing on the power supply on-line or refit electric wire,
otherwise it may lead to get an electric shock and light a fire.
Before clean you should pull the power supply plug from the electric outlet
out first.
To hold tight charger while pulling out plug, pulling the power cable will
damage electric wire, causing to get an electric shock and lighting a fire.
1.3.5 Clean with maintenance
Cellular phone, battery and charger have no waterproof function, please
do not use it in the bathroom and the high degree of humidity, you should
also avoid it being poured by rain
Please clean cellular phone, battery and charger use the dry and soft cloth.
Please don't wipe a cellular phone with the liquor, such as alcohol, dilution
and benzene...etc.
The electric outlet which has dirty mark will cause contact bad, drop an
electricity, with the result that can't refresh again, please sweep periodically.
1.3.6 General regulation
Cellular phone:

17
Please use a cellular phone between 5  temperatures to 40 ～s
and between 35% degree of humidity environments to 85% ～s.
When using the cellular please keep away from a common
telephone, television, radio and a place usage of the automatic
equipments, in case there may be an influence on the equipments and
the cellular phone.
Battery:
Please keep the battery away from the shooting of the sunlight, and
put it in the cool and ventilated place.
The service life of the battery is all limited. Usage time of the battery
shortens gradually in multifariously refresh. Refresh for many times
invalid, it means its life has been already exerted, and you should
replace the new battery of appointed model number.
Don't throw old battery into the generally living garbage. Please
treat the old battery allow to the designation of provision where it can
treat the old battery.
Charger:
Please don't refresh in the following place: The place where the
sunlight keeps shooting; The outside temperature is low in 5  or high
in 40  places; Damp, ashen place or vibrate place; (will cause
breakdown). Television radio etc. electric appliances
neighbourhood.(will influence a picture, orotund result)

18
2 Before using
2.1 The name and introduction of each part
2.1.1 Technique parameter
LI-ION Battery
Rechargeable Battery: 3.7V
Limit Voltage 4.2V
Travelling Charger
Input 100~240V 50/60Hz 200mA
2.1.2 Icon
While need the machine interface, there might appear marks, the
follows are the concrete elucidation:
Icon Explain
Mean the strength of network signal.
You can use a GPRS service.
Receive new information.
Receive a new colorful message.

19
The alarm clock has been already set and started.
Appear while inserting headphones.
Starting the call sign transfers function.
Locking the keyboard didn't open.
Show a battery electricity quantity.
Activate a blue tooth
The manifestation didn't answer the phone.
2.2 MobilePhone Sketch map & Keys introduction
2.2.1 MobilePhone Sketch map：(Ellipsis)
2.2.2 Keys introduction:
KeyBoard ICON Name Function
Left Software
OK & Option Key
Right Software
Goto of PhoneBook
Menu－－Back Key
Direction Key UP、Down、Left、Right、
OK Funtion.

20
Call Call & Receive ；Trasfer
Call’s log under IDLE.
PowerOff End Call or Reject Call。
1_Key
2_Key
3_Key
4_Key
5_Key
6_Key
7_Key
8_Key
9_Key
*_Key
0_Key
#_Key
Enter Dial interface,input
digit, character
Press # Key of a longer
time transfer silence model
1. Numerical key:
Importation numeral and character list; 2-9 numerals can establish for stir
the number fast key quickly.
2. Right and soft key:
Carry out the Cape leading function of the sign that in the right of the screen.
3. Left and soft key:
