Mobile Power 4039 User manual
Model No. 4039
Power Beam
20MCP Searchlight with 12 LED Area Light
and Vehicle Jump Starter
Instruction Manual
Sheet 1 of 8
MobilePower, LLC. Bluffton, SC 29910
www.mobilepower-us.com
Customer Support: (800) 708-8550
Model No. 4039
Sheet 2 of 8
Model No. 4039
IMPORTANT ADVISORY NOTES
• Thespotlightbecomesveryhotduringuse.DONOTtouchlensorblocklensareaduringoperation.
• Lightbeamisextremelypowerful.DONOTshinedirectlyintoeyes.
• Unitisnotwaterproof.DONOTuseSpotlightunderwaterorimmerseinwater.
• Donotusewithdrycellbatteries.Thesebatteriesmayburstandcauseinjurytopersonordamage
personalproperty.
• Donotattempttofacethebatterybeingjumped.Stayawayasfar
aspossiblefromthebatterywhenmakingthenalconnection.
• DONOTCONNECTTOorjumpstarta6or24Voltbattery.
Ifbatteryacidcomesincontactwithskinoreyes,rinseimmediatelywithwaterfor20minutes.Seek
medicalattentionifredness,irritationorpainispresent.
• DONOTsmoke,usematches,lightersoranopenamenearbatteries.
• Thisproductcontainschemicalsubstancesincludinglead.Washhandsthoroughlyafterhandling
LeadAcidBatteries.
• Never allow red (Positive) and black (Negative) clamps to come in contact with each other or
contactwithmetalobjectatthesametime.
• Toprotectagainstelectricalhazards,donotimmersecharger,adaptersorunitinwaterorother
liquid.
• Closesupervisionisnecessarywhenworkingnearchildren.
• Donotuseunitforapplicationsotherthanitsintendeduses.
• Alwaysconnectthered(+)clamptothepositivebatteryterminalrst.Connectblack(-)clamptothe
vehicleengineblock,orametalpartofthevehiclewhichisconnectedtothevehiclemainground
systemasnalconnection.
• Jumpstartvehiclesinawell-ventilatedareaonly.
• Donotexposetheunittomoistureoruseitinexceptionallyhotonditions.
• Wearcompleteeyeandclothingprotection.Donottoucheyeswhileworkingnearbattery
• Donotattempttoremoveorreplacethebatteryusedinthisdevice.Whenthebatteryhasreached
theendofitsusefullifetime,taketheentireunittoabatteryrecyclingfacility.
• Remove metal and personal jewelry such as:rings, bracelets, necklaces and watches, while
workingwith a lead acid battery.Thiscanproduceashort-circuitthatmaycausesevereburns.
Neverchargeorjump-startafrozenbattery.
• Donotoperatethisdevicewhilewearingvinylclothing.
Staticelectricitymaybegeneratedwhenvinylclothingisrubbed.
• Thisproductisnotintendedforuseintherainortemperaturesabove150ºF.
• Useonlytheprovidedchargers,cablesandclamps.Unauthorizedpartsmaydamagetheunit.
Thisproducthasnoconsumerserviceablepartsexceptthereplaceablefuses.
• Keepoutofthereachofchildren.
• Keepbatteryterminalsclean.Becarefultokeepcorrosionfromcomingincontactwitheyes.
• Donotletthecordsoftheunitorjumperclampsgetwet.
Sheet 3 of 8
Model No. 4039
• UseofDAMAGEDorIMPROPERextensioncordstochargethisunitcouldresultinriskofreand/
orelectricshock.Makecertainthattheextensioncordisinsafeandingoodelectricalcondition.
• Preventwaterfromenteringintotheunithousing.Waterwilldamagetheinternalelectronicsboard.
• Thisunithasabuilt-inleadacidbattery.Althoughthisunitarrivespartiallychargedfromthefactory,
itMUSTbefullychargedbeforetherstuse.
• Rechargetheunitaftereachuseorevery3monthstopreventthebatteryvoltagefromdepleting.
ADJUSTABLE HEAD
To adjust headangle, gently pullup on rimat bottom. Angle can beadjusted to 4differentpositions
indicatedbya “click” sound. Donotforcehead beyond nalpoint.Returnhead to closedpositionfor
storagetopreventdamagetomechanism.
SPOTLIGHT
To operatethe spotlight pressthe switchon handle ofyour PowerBeamto either the“High” or“Low”
position.
Theoperationtimeisuptoapproximately35minutes.
Presstheswitchto“O”toturnoffthespotlight.
LED AREA LIGHT
YourPowerBeamisequippedwithbrightLEDlightslocatedin
therim.Theseprovideanarealightforworkingandgeneralillumination.Tooperate,presstheswitch
locatedonthebackoftheunittothe“LEDAreaLight”position.
Thearealightwilloperatecontinuouslyformanyhoursonafullcharge.Presstheswitchtothemiddle
positiontoturnofftheLEDlights.
RED LED EMERGENCY FLASHER
Your Power Beam is also equipped with RED LED emergency ashers. To operate, press the switch
locatedonthebackoftheunittothe“REDLEDEMERGENCYFLASHER”position.
USB POWER PORTS:
Your Power Beam is equipped with THREE 5 volt 2100mAh USB ports for powering or charging
variousdevicesincludingmobilephones,MP3players,tablets,e-Readers,notebookcomputersandother
equipmentwithUSBcapability.Tooperate,connecttheUSBcablethatwassuppliedwiththedeviceyou
wanttochargetooneoftheUSBports.Pressthebuttonlabeled“USB”oncetoturnon,pressagainto
turnoffwhennished.
Sheet4of8
Model No. 4039
VEHICLE JUMP START INSTRUCTIONS:
WARNINGS:
Reviewyourvehicleowner’smanualinstructionsbeforeattemptingtojumpstartyourvehicle.Failureto
followtheseadvisoryinstructionsmayresultinpersonalinjuryandpropertydamage.Usesafetyglasses
toprotectyoureyeswhileworkingnearabatteryduringvehiclejump-starting.Jumpstartavehicle
inanopenareawithoutanytypeofobstructions.
1. Turnoffthevehicleignitionandallaccessories(Suchasradios,lights,andairconditioners,etc).
2. Applytheemergencybrakeandputthosevehicleswithautomatictransmissioninparkposition.
3. Determinethepolarityofthevehiclebatteryterminals.Thepositive(+)batteryterminalnormallyis
largerindiameterthanthenegative(-)terminal.Ifyouareunsure,youmustrefertothevehicle
owner’smanual.
1. Determine whether your vehicle is equipped with a negative or positive grounded system: Most
vehiclesusethistypeofsystem.PositiveGroundedbatteryterminalisgroundedtochassisoranyother
partofthevehicle.Ifyouarenotcertainofthisimportantinformation,YOU SHOULD REFER TOYOUR
VEHICLE OWNER’S MANUAL.
2. Remove clamps from the holders. Never allow clamps (positive & negative terminals) to touch
togetherorcontactthesamepieceofmetaltopreventshort-circuits.
3. Followtheinstructionsforanegativegroundedsystemorpositivegroundedsystemasindicated
below:
Negative Grounded System
Connect the RED CLAMP (positive +) to the positive terminal of the vehicle battery or the remote
positiveterminalifavailable.
ConnecttheBLACKCLAMP(negative-)tothevehicleengineblock,orametalpartofthevehiclewhich
isconnectedtothevehiclemaingroundsystem.Donotclampdirectlytonegativebatteryterminal,main
fueldistributionmoduleorsheetmetalparts.
ThePolarityProtectionSystemGREENLEDisilluminatediftheproperconnectionshavebeenmade.
WARNING: If RED LED is illuminated, DISCONNECT the booster clamps from battery terminals.
Reconnecttheboosterclampsbyreversingtheconnectionstotheproperbatterypolarity.
Sheet5of8
Model No. 4039
Positive Grounded System:
ConnecttheBLACKCLAMP(negative-)tothenegativeterminalofthevehiclebattery.
ConnecttheREDCLAMP(positive+)tothevehicleengineblock,orametalpartofthevehiclewhich
isconnectedtothevehiclegroundsystem.Donotclampdirectlytopositivebatteryterminal,mainfuel
distributionmoduleorsheetmetalparts.
ThePolarityProtectionSystemGREENLEDisilluminatediftheproperconnectionshavebeenmade.
WARNING: If RED LED is illuminated, STOP and disconnect the booster clamps from battery
terminals. Reconnect the booster clamps by reversing the connections to the proper battery
polarity.
1. TurnontheMainPowerBoosterClampsSwitchbyrotatingtheswitchtotheONposition.
2. Allow3to5minutesofchargetime.Itishighlyrecommendedhavingasecondpersontoassist
holdingtheunitsecurelyinplaceduringthenextsteps.
3. StarttheengineandStopifthevehicledoesnotstartafter2to3secondsofenginecranking.Wait
2to3minutesthentryagain.Repeattheabovestepsseveraltimesuntilthevehiclestarts.
4. Ifthevehiclestarts,turnofftheMainPowerSwitchbyturningtheswitchtotheOFFposition.
5. Disconnecttheclampsasfarawayfromthevehiclebatteryaspossible.
6. ForNegativeGroundedSystem,disconnecttheBLACKCLAMPNegativerstandthentheRED
CLAMPPositive.ForPositiveGroundedSystem,disconnecttheREDCLAMPPositiverst,and
thentheBLACKCLAMPNegative.
7. Stowtheboosterclampsintotheirstoragecompartment.
CHARGING INSTRUCTIONS:
USE CAUTION:
Priortochargingthisdevicereadalltherelatedinstructionsindicatedbelow.Thisproductmayarrive
partiallychargedfromthefactory.Itishighlyrecommendedtofullychargetheunitafterpurchaseand
beforeinitialuse:
• MakecertainthatthePowerSwitchissettotheoffposition.
• Do not charge near ammable material, open ames or any location which may accumulate
ammablefumes.
• Makecertainthatanyelectricaloutletusedtochargethisdevicethatislocatedinapotentiallywet
ormoistareaisprotectedbyaGroundFaultCircuitInterrupter(GFCI).
• Makesurethatbothboosterclampsaresecurelyplacedintheirdesignatedstoragecompartments
whennotinuseandduringthechargingperiod.
Sheet6of8
Model No. 4039
A. AC Charging At Home with 110 Volt Charger
1. KeepthePowerSwitchinmiddle“O”offpositionwhilecharging.
2. Insert the AC charger round plug into the Spotlight Charging Port located at the back of the
spotlight.
3. Connectthe110VoltACChargerintothe110VoltAChomereceptacle.
4. Fullychargethespotlightaccordingtothefollowingchargingschedule:
Firsttimecharge:.....................................................24hours
Rechargeandsubsequentcharge:.......................18hours
5. Unplug the AC charger from the 110 Volt receptacle rst and then remove theround plug
fromtheSpotlightChargingPort.
B. DC Charging In Your Vehicle with 12 Volt Charger
1. KeepthePowerSwitchinmiddle“O”offpositionwhilecharging.
2. Insertthe12VoltDCChargerroundPlugintotheSpotlight
3. ChargingPortlocatedatthebackofthespotlight.
4. Connectthe12VoltDCChargerPlugintothevehiclecigarettelighteror12Voltaccessoryport.
5. FullychargetheSpotlightinternalbatteryfor8hourswhilethevehicleengineisrunning.
6. UnplugtheDCchargerfromthevehiclecigarettelighteror12Voltaccessoryportrstandthenremovethe
roundplugfromtheSpotlightChargingPort.
12 VOLT DC CHARGER ADAPTOR FUSE REPLACEMENT:
1. Unscrewtheretainerringatthetipofthe12VoltDCchargerplug.
2. Replacetheinternalglassfusewiththesamegradefuseratedat2-AMP.
SPECIFICATIONS:
Batteryratedcapacity 12Volt-8Ah
Bulb H4-120WattQuartzHalogenBulb
LEDarealight 360mA
NOTE: Specications are subject to change without notice
Sheet 7 of 8
Model No. 4039
MobilePower, LLC. Warrants to the original purchaser that the Vehicle Boosting System shall be free from materials defects
inconstructingmaterialandworkmanshipforaperiodofoneyearfromtheoriginaldateofpurchaseexcepttheinternalLead
Acid rechargeable battery pack warrantied for a period of one year. If the product is determined by MobilePower, LLC. to be
defectiveinmaterialandworkmanshipduringthewarrantyperiodMobilePower,LLC.willrepairorreplacethedefectiveproductor
defective accessories/components with the factory original specication product at MobilePower, LLC. option. The original
purchaser is certied to obtain this warranty with the proof of purchase within the warranty period. To obtain a return
authorizationandshippinginstructionsrelatedtothewarrantyservicesinNorthAmericavisitusatwww.mobilepower-us.comor
call800-708-8550CustomerSupportorcontactusat[email protected].Youmayshipthedefectiveproduct
withfreightprepaidtoMobilePower,LLC.Yourreplacementwillbemailedbacktoyouatnoadditionalcharge.
Greatcaremustbetakenwhenpackingtheproductandallassociatedaccessoriesintoasuitablepackingboxalongwithoriginal
datedpurchasingreceiptorinvoice.Thepackagemustincludealetterstatingthedefectdetails,contactinformationincluding
physicaladdress.AnyaddresswithaPOBoxwillnotbeprocessedandwillbehelduntilfurthernoticationfromtheconsumer.
Makecertainthatyourpackagecanbetrackedwhenyouareshippingthedefectiveproductstous.MobilePower,LLCwillnot
beresponsible for lostpackages sentbyconsumers. MobilePower, LLC.Will notberesponsible fordamages incurred during
shipmenttoourfacilities.Failuretoprovidetheoriginalpurchasereceiptorproofofpurchasewillrenderthiswarrantyinvalid.
THIS WARRANTY SHALL NOT APPLY IF THIS PRODUCT (A) IS DAMAGED RESULTING FROM ABUSE, MISUSE,
NEGLIGENCE, ACCIDENT, LACK OF MAINTENANCE, WEAR AND TEAR, UNREASONABLE USE OR BY OTHER
CAUSESUNRELATEDTOTHEDEFECTIVEMATERIALORWORKMANSHIP;(B)ISUSEDWITHPRODUCTSTHATARENOT
COMPATIBLEWITHVEHICLEBOOSTINGSYSTEM;(C)ISUSEDFORCOMMERCIALPURPOSES;(D)IFTHEPRODUCT
HASBEENSUBJECTEDTOWATERANDFIRE.
This warranty provides you with specic legal rights, and you may also have other rights which vary from state to state.
ThiswarrantyisvalidonlyinNorthAmerica.
MobilePower, LLC. Bluffton, SC 29910
www.mobilepower-us.com
Customer Support: (800) 708-8550
MadeinChina
Sheet 8 of 8
